Multi-information display

5. Press and hold the multi-information dis-

2. Lightly press the multi-information dis-

NOTE

play switch (for approximately 2 seconds

play switch to select

“

”

(language

• When “A or 1”

(language cooperation:

or more) to change the setting to the

cooperative control).

enabled) has been selected, the language for

selected language.

Multi Around Monitor (if so equipped) is

automatically changed to the language

NOTE

selected for the multi-information display.

z If the 12 V starter battery is disconnected,

However, this changing function may not

the memory of the language setting is erased

work depending on the language selected

5

and is automatically set to ENGLISH.

for the multi-information display.

z If “---” is selected in the language setting, a

• When “M, 2 or P” (language cooperation:

warning message is not displayed when there

disabled) has been selected, the language

is a warning display or interrupt display.

for Multi Around Monitor (if so equipped)

is not automatically changed to match the

language selected for the multi-informa-

tion display.

&KDQJLQJ WKH ODQJXDJH RQ RWKHU

3. Press and hold the multi-information dis-

z

The language on the audio system’s display

V\VWHP WR PDWFK WKH PXOWL LQIRU

play switch to switch from A/1 (language

does not automatically change when you

PDWLRQ GLVSOD\

cooperation: enabled) to M/2/P (language

select A or

1

(language cooperation:

N00529801357

cooperation: disabled), or from M/2/P to

enabled) in the language cooperation control.

A/1. The setting is changed to the selected

The language used in Multi Around Monitor

condition.

(if so equipped) can be changed automatically

2SHUDWLRQ VRXQG VHWWLQJ

to the same language as that shown in the

N00557401185

multi-information display.

NOTE

You can turn off the operation sounds of the

z If the 12 V starter battery is disconnected,

multi-information display switch and rheostat

1. Press and hold the multi-information dis-

the language cooperative control is automati-

illumination button.

play switch (for approximately 2 seconds

cally set to “A or 1” (language cooperation:

or more) to switch from the setting mode

enabled).

1. Press and hold the multi-information dis-

screen to the menu screen. Refer to

z The language cooperation setting can be

play switch (for approximately 2 seconds

“Changing the function settings” on page

switched in the following manner.

or more) to switch from the setting mode

5-153.

screen to the menu screen.

Refer to “Changing the function settings”

on page 5-153.

Features and controls

5-157

Multi-information display

2. Lightly press the multi-information dis-

1. Press and hold the multi-information dis-

1. Press and hold the multi-information dis-

play switch (for approximately 2 seconds

play switch (for approximately 2 seconds

play switch to select

“

”

(operation

or more) to switch from the setting mode

or more) to switch from the setting mode

sound setting).

screen to the menu screen.

screen to the menu screen.

3. Press and hold the multi-information dis-

Refer to “Changing the function settings”

Refer to “Changing the function settings”

play switch (for approximately 2 seconds

on page 5-153.

on page 5-153.

or more) to switch from ON (operation

2. Lightly press the multi-information dis-

2. Lightly press the multi-information dis-

sound on) to OFF (operation sound off),

play switch to select “ALARM” (rest time

or from OFF to ON.

play switch to select

(changing the

5

setting).

The setting is changed to the selected con-

turn signal sound)

3. Press and hold the multi-information dis-

dition.

3. Press and hold the multi-information dis-

play switch (for approximately 2 seconds

play switch (for approximately 2 seconds

or more) to display “ALARM” (rest time

NOTE

or more) to switch from 1 (turn-signal

setting).

z If the 12 V starter battery is disconnected,

sound 1) to 2 (turn-signal sound 2), or

4. Lightly press the multi-information dis-

the memory of the operation sound setting is

from 2 to 1.

play switch to select the time until the dis-

erased and is automatically set to

“ON”

The setting changes to the selected turn

(operation sound on).

play appears.

signal sound.

z The operation sound setting only deactivates

5. Press and hold the multi-information dis-

the operation sound of the multi-information

play switch (for approximately 2 seconds

5HVHW RI (9 7RWDO FUXLVLQJ UDQJH

display switch and rheostat illumination but-

or more) to change the setting to the

ton. The warning display and other sounds

selected time.

N00597800038

cannot be deactivated.

The learned value for EV cruising range reset

NOTE

to the initialized value.

z If the 12 V starter battery is disconnected,

&KDQJLQJ WKH WLPH XQWLO ³5(67

the memory of the unit setting is erased and

1. Press and hold the multi-information dis-

5(0,1'(5´ LV GLVSOD\HG

is automatically set to the “OFF”.

play switch for approximately 2 seconds

z The drive time is reset when the operation

or more to switch from the setting mode

N00557501199

mode is in OFF.

screen to the menu screen.

The time until the display appears can be

Refer to “Changing the function settings”

changed.

on page 5-153.

&KDQJLQJ WKH WXUQ VLJQDO VRXQG

N00563501110

It is possible to change the turn signal sound.

5-158

Features and controls

Indicator light, warning light, and information screen display list

,QGLFDWRU OLJKW ZDUQLQJ OLJKW DQG LQIRUPDWLRQ VFUHHQ GLVSOD\ OLVW

N00557701061

,QGLFDWRU DQG ZDUQLQJ OLJKW OLVW

N00557801437

5

1- Position indicator  P.5-186

9- Charging indicator  P.5-187

14- Forward Collision Mitigation System

2- Front fog light indicator  P.5-186

10- Regenerative brake warning light

(FCM) OFF indicator (if so equipped)

3- Turn signal indicators/Hazard warning

 P.5-189

 P.5-104

lights  P.5-186

11- Blind Spot Warning (BSW) indicator

15- LED headlight warning light

(if so

4- High beam indicator  P.5-186

light (if so equipped)  P.5-110

equipped)  P.5-192

5- Ready indicator P.5-187

12- Automatic High Beam (AHB) indicator

16- Information screen display list

6- Theft-alarm indicator  P.5-37

(if so equipped)  P.5-193

 P.5-161

7- 12 V starter battery charging system

13- Acoustic Vehicle Alerting System

17- Active stability control (ASC) indicator

warning light  P.5-188

(AVAS) indicator  P.5-72

 P.5-83

8- Plug-in Hybrid EV System warning

18- Active stability control

(ASC) OFF

light  P.5-189

indicator  P.5-83

5-160

Features and controls

Indicator light, warning light, and information screen display list

:DUQLQJ GLVSOD\ OLVW

N00558001436

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z One or more failure is occurring in the Plug-in

z Have your vehicle inspected by a certified

Hybrid EV System.

Mitsubishi EV dealer.

5

z One or more failure is occurring in the Plug-in

z Park your vehicle in a safe place as soon as possible

Hybrid EV System.

and contact a certified Mitsubishi EV dealer to have

the system checked.

z The parking lock unit is in failure. The Plug-in

z Park the vehicle at a safe, flat place and apply the

Hybrid EV System cannot be kept in standstill con-

parking brake. Contact a certified Mitsubishi EV

dition without applying the parking brake.

dealer to have the system checked.

Refer to “Electrical parking switch” on page 5-55.

z You are attempting to start the Plug-in Hybrid EV

z Disconnect the charge connector from the charge

System when the charge connector is connected to

port before operating the power switch.

the charge port.

z Charging was interrupted due to system failure or

z There is the system failure or the EV charging cable

EV charging cable failure.

is faulty. Immediately stop using the cable and con-

tact a certified Mitsubishi EV dealer to have the sys-

tem checked.

5-162

Features and controls

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z

Normal charging

z

Normal charging

• Charging was interrupted due to poor connection of

• Connect the EV charging cable correctly.

the EV charging cable or power failure.

Refer to “Normal charging” on page 3-20.

z

Quick charging

• If charging is interrupted due to a power failure,

• Charging was stopped by your operation.

charging will resume automatically when the power

• Charging was interrupted after the predetermined

source is reset.

set time.

z

Quick charging

5

• Charging was interrupted due to a poor connection

• Connect the EV charging cable correctly.

of the EV charging cable or a electrical power fail-

Refer to “Quick charging” on page 3-32.

ure.

• If charging is interrupted due to a power failure,

• Charging was interrupted because there is a prob-

start charging procedure again from the beginning

lem in the vehicle or the quick charger.

after the power source is reset.

• If the warning display appear in the meter of the

vehicle or on the quick charger display, follow the

instructions and take the necessary measures.

z

The main drive lithium-ion battery temperature is

z

In the daytime, wait for the temperature to rise.

too cold.

When the temperature in the vicinity of the main

drive lithium-ion battery has risen, start up.

(Except for vehicles equipped with main drive lith-

ium-ion battery warming system)

z

Keep driving if you can drive at the same speed as

surrounding vehicles.

If you cannot drive the same speed as surrounding

vehicles, stop the vehicle in a safe place.

(Vehicles equipped with main drive lithium-ion bat-

tery warming system)

z

The battery charge mode switch is pressed when the

z

You do not have to take any actions, but the time

main drive lithium-ion battery temperature is cold.

needed to charge the main drive lithium-ion battery

will become longer.

Features and controls

5-163

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z

The main drive lithium-ion battery is extremely cold

z

Even if the main drive lithium-ion battery is full

temperature. The Plug-in Hybrid EV System will not

charge, connect EV charging cable (normal charger).

start until the main drive lithium-ion battery is warm

Then, the main drive lithium-ion battery warming

enough.

system is operated, the main drive lithium-ion bat-

tery is automatically warmed up. While the main

drive lithium-ion battery warning system is operat-

5

ing, “BATTERY TOO COLD” will be displayed.

(Vehicles equipped with main drive lithium-ion bat-

tery warming system)

Refer to “Charging from rated AC 120 V outlet” on

page 3-22.

Refer to “Cautions and actions to deal with intense

cold” on page 3-13.

z

The main drive lithium-ion battery is extremely cold

z

Stop the vehicle at a safe place if the vehicle is under

temperature.

running.

After the vehicle is in parking, in the daytime, wait

for the outside temperature to rise and re-start the

Plug-in Hybrid EV System if the outside temperature

has been risen.

Refer to “Cautions and actions to deal with intense

cold” on page 3-13.

z

Charging lid is open.

z

Close the charge lid.

Refer to “Charging from rated AC 120 V outlet” on

page 3-22.

5-164

Features and controls

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z When the air conditioner stops because the main

z Turn the power switch to OFF once after charging

drive lithium-ion battery level becomes low by using

the main drive lithium-ion battery sufficiently, and

the air conditioner during charging.

then turn the power switch to ON. The air condi-

tioner can be used again.

z When the air conditioner can be used again in the

z Turn the power switch to OFF once, and then turn

following conditions.

the power switch to ON. The air conditioner can be

5

The main drive lithium-ion battery is enough

used again.

charged while the “A/C AND HEAT ARE NOT

AVAILABLE BATTERY CHARGE LOW” indica-

tion is displayed or the main drive lithium-ion bat-

tery is enough heated while the “BATTERY TOO

COLD” indication is displayed, etc.

z When the operation mode of the power switch is put

z The electric devices can be used during charging.

in ON during charging.

Refer to “How to use electric device during charg-

ing” on page 3-42.

Features and controls

5-165

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z EV priority mode is not available because the main

Refer to “EV switch” on page 5-66.

drive lithium-ion battery level is low.

z EV priority mode is not available because the cruise

5

control or the Adaptive Cruise Control System

(ACC) is operating.

z EV priority mode is not available because the main

drive lithium-ion battery is too cold.

z EV priority mode is not available because the EV

priority mode is limited to protect the Plug-in Hybrid

EV System or outside temperature is too cold.

z EV priority mode is canceled because the main drive

lithium-ion battery level is low.

5-166

Features and controls

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z EV priority mode is canceled because the vehicle

Refer to “EV switch” on page 5-66.

speed of the cruise control or the Adaptive Cruise

Control System (ACC) is set.

z EV priority mode is canceled because the main drive

lithium-ion battery temperature has become too cold.

5

z EV priority mode is canceled because the protecting

device of the Plug-in Hybrid EV System is operated.

z There is preparing to open the fuel tank filler door.

z Wait until the preparation is complete.

Refer to “Filling the fuel tank” on page 3-51.

z Preparation to refuel has been completed and the fuel

z Please begin refueling.

tank filler door opened.

For information on how to refuel, refer to “Filling

the fuel tank” on page 3-51.

z There is a fault in the refueling system.

z Contact a certified Mitsubishi EV dealer to have the

system checked.

Refer to “Filling the fuel tank” on page 3-51.

Features and controls

5-167

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z The fuel tank filler door is open.

z Check the fuel tank filler cap is closed and then close

the fuel tank filler door.

Refer to “Filling the fuel tank” on page 3-51.

z SPORT mode is not available because the remaining

Refer to “SPORT mode switch” on page 5-71.

5

fuel quantity is low.

z SPORT mode is canceled because the remaining fuel

quantity has become low.

z Battery save mode or battery charge mode is not

Refer to “SAVE/CHARGE mode switch” on page 5-68.

available because the engine coolant temperature is

high or the remaining fuel quantity is low.

z Battery save mode or battery charge mode is can-

celed because the engine coolant temperature has

become high or the remaining fuel quantity has

become low.

z You have forgotten to turn off the lights.

Refer to “Light auto-cutout function (headlights and

other lights)” on page 5-192.

5-168

Features and controls

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z The washer fluid is running low.

z Replenish the container with washer fluid.

Refer to “Washer fluid” on page 9-10.

Refer to “Capacity” on page 11-9.

z There is a malfunction in the LED headlights.

z Contact a certified Mitsubishi EV dealer to have the

system checked.

5

Refer to “LED headlight warning light” on page

5-192.

z The system has received the customer key program-

Refer to “Customer F.A.S.T.-key programming (Except

ming request correctly and is currently processing

for vehicles sold in Canada)” on page 5-17.

the registration request.

Features and controls

5-169

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z There is a fault in the F. A. S. T. -key.

Refer to “Free-hand Advanced Security Transmitter

(F.A.S.T.-key)” on page 5-4.

5

z The F. A. S. T. -key is not detected.

z Insert the F. A. S. T. -key into the key slot. Refer to

“If the F. A. S. T. -key is not operating properly” on

page 5-15.

5-170

Features and controls

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z You have forgotten to remove the F. A. S. T. -key

z Remove the F. A. S. T. -key from the key slot.

from the key slot.

z There is a fault in the EPS.

z Have the vehicle inspected by a certified Mitsubishi

EV dealer as soon as possible.

5

Refer to “Electric power steering system (EPS)” on

page 5-80.

z The RBS (regenerative brake system) cannot be

z Contact a certified Mitsubishi EV dealer to have the

used.

system checked.

z There is a fault in the Anti-lock braking system.

z Avoid sudden braking and high-speed driving, park

the vehicle in a safe place, and take corrective mea-

sures. Refer to “ABS warning light/display” on page

5-79.

z The tire pressure in one of the tires is low.

Refer to “TPMS warning light/display” on page 5-122.

z There is a fault in the Tire Pressure Monitoring Sys-

tem.

Features and controls

5-171

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z One of the doors or the liftgate is not completely

z Close the door or liftgate.

closed.

Refer to “Door ajar warning display screen” on page

The open door is displayed.

5-147.

z The engine hood is open.

z Close the engine hood.

5

Refer to “Engine hood” on page 9-4.

z There is a fault in the electronic immobilizer (Anti-

z Put the operation mode in OFF, and then start the

theft starting system).

Plug-in Hybrid EV System again.

If the warning is not canceled, please contact a certi-

fied Mitsubishi EV dealer.

z The driver's door is open when the operation mode is

z Put the operation mode in OFF.

in any mode other than OFF.

Refer to “Operation mode ON reminder system” on

page 5-26.

z An attempt was made to lock all the doors and the

z Put the operation mode in OFF.

liftgate when the operation mode is in any mode

Refer to “Operation mode OFF reminder system” on

other than OFF.

page 5-12.

z There is a fault in the electrical system.

z Park your vehicle in a safe place as soon as possible

and contact a certified Mitsubishi EV dealer to have

the system checked.

5-172

Features and controls

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z The engine is overheated.

z Park the vehicle in a safe place and take corrective

measures.

Refer to “Engine overheating” on page 8-4.

z The seat belt is not fastened when the operation

z Wear your seat belt properly.

mode is in ON.

Refer to “Driver’s seat belt reminder/warning light

5

and display” on page 4-20.

z There is a fault in the fuel system.

z Contact a certified Mitsubishi EV dealer to have the

system checked.

z The vehicle is being driven with the parking brake

z Release the parking brake. Refer to “Brake warning

still applied.

display” on page 5-189.

z The brake fluid level is low.

z Park the vehicle in a safe place and inspect it.

z There is a fault in the brake system.

z If the light still illuminates after the inspection, con-

tact a certified Mitsubishi EV dealer for assistance.

Refer to “Brake warning display” on page 5-189.

z When the brake pedal has been repeatedly depressed

z If the this warning display is disappeared and brake

over a short period of time, the brake warning light

warning light goes out and the buzzer stops a few

may come on and the brake warning buzzer may

seconds after stopping brake operation, there is no

sound, and this warning may be displayed.

abnormality.

Features and controls

5-173

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z There is a fault in the Electric parking brake.

z Immediately have your vehicle inspected at a certi-

fied Mitsubishi EV dealer.

Refer to “Electric parking brake” on page 5-45.

z The parking brake cannot be applied temporarily due

Refer to “Electric parking brake” on page 5-45.

5

to repeated operation of the Electric parking brake

switch within a short time.

z You try to release the Electric parking brake switch

Refer to “Electric parking brake” on page 5-45.

without depressing the brake pedal.

z The Electric parking brake has been automatically

Refer to “Brake auto hold” on page 5-74.

applied.

z The brake auto hold is automatically canceled.

Refer to “Brake auto hold” on page 5-74.

z The brake auto hold is not available.

Refer to “Brake auto hold” on page 5-74.

5-174

Features and controls

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z The brake auto hold system does not turn on because

z Press the brake auto hold switch after fastening the

the driver’s seat belt is not fastened.

driver’s seat belt.

Refer to “Brake auto hold” on page 5-74.

z The brake auto hold system does not turn off because

z Depress the brake pedal more firmly than usual with

the brake pedal is not pressed.

the right foot. Then, press the brake auto hold switch.

5

Refer to “Brake auto hold” on page 5-74.

z There is a fault in the engine oil circulation system.

z Park your vehicle in a safe place as soon as possible

and contact a certified Mitsubishi EV dealer to have

the system checked.

Refer to “Oil pressure warning display” on page

5-190.

z There is a fault in the SRS airbag or the pre-tensioner

z Contact a certified Mitsubishi EV dealer to have the

system.

system checked, immediately.

Refer to “SRS warning light/display” on page 4-42.

z There is a fault in the Active stability control (ASC).

z Contact a certified Mitsubishi EV dealer to have the

system checked.

Refer to “Active stability control (ASC)” on page

5-81.

z There is a fault in the Hill start assist.

z Have the vehicle checked at a certified Mitsubishi

EV dealer.

Refer to “Hill start assist” on page 5-77.

Features and controls

5-175

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z The fuel is running low.

z Refuel as soon as possible.

Refer to “Fuel remaining display screen” on page

5-147.

z The outside temperature is 37 °F (3 °C) or less.

z Be careful driving on frozen ground.

5

z The ground may be frozen even when this warning is

not displayed, so drive carefully.

z The Adaptive Cruise Control System (ACC) has

z Increase the following distance by depressing the

detected the approach of the vehicles in front.

brake pedal or making other decelerating control.

Refer to “Adaptive Cruise Control System (ACC):

Approach alarm” on page 5-93.

z The Forward Collision Mitigation System (FCM)

z Take appropriate action such as depressing the brake

has detected the danger of collision.

to avoid collision.

Refer to “Forward collision warning function” on

page 5-101.

z The Adaptive Cruise Control System (ACC)

z Depress the brake pedal as soon as your vehicle

detected a stop of the vehicle in front and stopped

comes to a stop.

your vehicle, but the brake will be released soon.

Refer to “When ACC detects a vehicle in front

within the set distance” on page 5-92.

z The Electric parking brake cannot be applied auto-

z Depress the brake pedal as soon as possible.

matically.

Refer to “Brake auto hold” on page 5-74.

5-176

Features and controls

Indicator light, warning light, and information screen display list

6FUHHQ

&DXVH

'R WKLV 5HIHUHQFH

z Conditions for the start of control are not met, the

Refer to “How to use ACC” on page 5-90.

Adaptive Cruise Control System (ACC) cannot start

the control.

z The Adaptive Cruise Control System (ACC) cannot

start the control because the speed is out of speed

5

range.

z The Adaptive Cruise Control System (ACC) cannot

start the control because not detected the approach of

the vehicles in front.

z The Adaptive Cruise Control System (ACC) control

is automatically canceled and the system is placed in

the ‘standby’ state.

z The Adaptive Cruise Control System (ACC) is tem-

Refer to “To cancel ACC control” on page 5-97.

porarily unavailable due to conditions such as the

adhesion of contaminants to the sensor.

This is not a malfunction.

z There is a fault in the Adaptive Cruise Control Sys-

z Contact a certified Mitsubishi EV dealer to have the

tem (ACC).

system checked.

Refer to “Warning display” on page 5-99.

Features and controls

5-177

Content      ..     12      13      14      15     ..
