Removal steps

18. Center lower panel
19

A/C control panel

20. Side cover
21. Glove box side panel
22. Center upper box assembly

Removal steps

23. Upper glove box assembly
·

Steering wheel (Refer to GROUP 37 -
Steering Wheel P.37-20).

24. Solar sensor
25. Instrument panel assembly

INTERIOR

52A-5

INSTRUMENT PANEL ASSEMBLY

CLIP AND CLAW POSITIONS

ZC6004780000

 Section A – A

Section B – B

25

15

 Section E – E

25

21

 Section I – I

7

25

Section J – J

18

25

Section K – K

2

1

Section F – F

20

25

25

6

Section C – C

25

22

Section D – D

25

14

Section G – G

Section H – H

20

25

Section L – L

25

17

A

A

B

B

C

C

D

D

E

E

G
G

I

I

J

J

K

K

L

L

Clip

Clip

Clip

Clip

Clip

Clip

Clip

Clip

Clip

Claw

Claw

F

F

H

H

NOTE
(1)       :Clip positions
(2)       :Claw positions

52A-6

INTERIOR

INSTRUMENT PANEL ASSEMBLY

NOTE:

Each number in the illustration indicates a

part number.

DISASSEMBLY AND ASSEMBLY

M15201000019USA0000010000

ZC600541

2

2

3

4

8

6

8

0000

7

5

1

11

a

h

a

a

a

a

a

a

a

a

a

a

a

a

9

a

10

a

Disassembly steps

1.

Front passenger's seat air bag module
(Refer to GROUP 52B, - Driver's and
Front  Passenger's  Air  Bag  Modules
and Clock Spring P.52B-329).

2.

Side defroster nozzle

3.

Center defroster nozzle

4.

Ventilation air distribution

5.

Front passenger's air bag lid assembly

Disassembly steps

6.

Instrument holder

7.

Glove box light bracket

8.

Wiring harness bracket

9.

Interior temperature sensor

10. Aspirator hose
11. Instrument panel

INTERIOR

52A-7

INSTRUMENT PANEL ASSEMBLY

FLOOR CONSOLE ASSEMBLY

FRONT FLOOR CONSOLE ASSEMBLY

REMOVAL AND INSTALLATION

M15201000052USA0000010000

ZC600575

1

1

2

3

4

5

6

7

0000

A

A

B

B

 Section A – A

 Section B – B

1

4

Clip

Clip

Removal steps

1.

Lower side cover

2.

Front floor console bracket

·

Cigarette Lighter connector

3.

Front floor console panel

·

Rear  floor  console  assembly  (Refer
to P.52A-9).

4.

Front floor console assembly

Removal steps

·

Interior  transmission  antenna  (front)
(Refer  to  GROUP  42B,  Exterior
Transmission

 Antenna,

 Interior

Transmission  Antenna  Assembly,
Receiver Antenna Module P.42B-176).

5.

Front floor console base

6.

Front floor console base bracket

7.

Front floor console mid bracket

52A-8
