DTC SET CONDITIONS

Logic Flow Chart

Start

End

No

No

Yes

Yes

Yes

No

Malfunction

Continuous Failure

for specified time

Monitoring
Conditions

ZK604051AA00

Communication status

Fails

Good

Check Conditions

｠

After  4  seconds  have  passed  since  the  ignition
switch was turned to "ON" position.

｠

Battery  positive  voltage  is  between  10  and  16.5
volts.

Judgement Criterion

｠

The  communication  between  the  Meter-ECU
andthe  ETACS-ECU  has  been  down  through  the
CAN bus line for 4 seconds.

OBD-II DRIVE CYCLE PATTERN
None.

TROUBLESHOOTING HINTS (The most likely
causes for this code to be set are:)

｠

CAN line harness damage or connector damage.



DIAGNOSIS

Required Special Tools:

｠

MB991958: Scan tool (M.U.T.-III Sub Assembly)

｠

MB991824: V.C.I.

｠

MB991827: USB Cable

｠

MB991910: Main Harness A

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

13Ab-751

DIAGNOSTIC TROUBLE CODE PROCEDURES

STEP 1. Using scan tool MB991958, diagnose CAN bus line.

ZC501967

AC404789

ZC5019680000

MB991824

MB991827

MB991910

Data link

connector

To prevent damage to scan tool MB991958, always turn the
ignition  switch  to  the  "LOCK"  (OFF)  position  before
connecting or disconnecting san tool MB991958.

(1)

Connect scan tool MB991958 to the data link connector.

(2)

Turn the ignition switch to the "ON" position.

(3)

Diagnose CAN bus line.

(4)

Turn the ignition switch the "LOCK" (OFF) position.

Q:Is the CAN bus line normal?

YES:

 It can be assumed that this malfunction is

intermittent. Refer to GROUP 00, How to Use
Troubleshooting/Inspection Service Points - How to Cope
with Intermittent Malfunctions P.00-15.

NO:

 Repair the CAN bus line. Refer to GROUP 54D, Can bus

Diagnostics Table P.54D-10. Then go to Step 2.

STEP 2. Recheck for diagnostic trouble code.
Check again if the DTC is set.

(1)

Erase the DTC.

(2)

Turn the ignition switch to the "ON" position.

(3)

Check if DTC is set.

(4)

Turn the ignition switch to the "LOCK" (OFF) position.

Q:Is DTC U1180 set?

YES:

 Retry the troubleshooting.

NO:

 The inspection is complete.

13Ab-752

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

DIAGNOSTIC TROUBLE CODE PROCEDURES

SYMPTOM PROCEDURES

INSPECTION PROCEDURE 1: Scan Tool Communication with ECM Is Not Possible.

M11310100081USA0000010001

71 72 73 74 75 76 77 78 79 80 81 82

83 84 85 86 87 88 89 90 91 92 93 94

95 96 97 98 99

100 101 102 103 104

112 113 114

109

108

107

110 111

115 116

106

105

118

117

1 2 3 4 5 6

12

11

10

1516

14

13

9

7 8

ZK602868

1

12 13 14 15 16 1718 19 20 2122 2324

2 3 4 5

6 7 8 9 10 11

1

12 13 14 15 16 1718 19 20 2122 2324

2 3 4 5

6 7 8 9 10 11

1

12 13 14 15 16 1718 19 20 2122 2324

2 3 4 5

6 7 8 9 10 11

2

8

7

6

5

4

3

11

21

20

19

18

17

16

15

14

13

12

9

22

1

10

1 2 3 4

5 6 7

15

14

13

12

11

10

9

8

1 2

FUSIBLE LINK

1

C-309

8

C-317

5

4

16

4

5

7

8

10

8

80

B-11

C-317

C-301

C-309

C-01

C-04

C-33

103

90

91

4

15

5

16

J/C (CAN3)
C-01

J/C (CAN2)
C-04

7

20

6

19

9

C-301

8

21

C-33

20

C-33

ENGINE
CONTROL
MODULE

DATA LINK
CONNECTOR

C-125

ETACS-ECU

6

14

10A

RED

BLA

CK

WHITE

BLA

CK

BLA

CK

BLA

CK

ORANGE

YELLO

W

PINK

YELLO

W

BLACK

YELLO

W

-GREEN

YELLO

W

-BLUE

YELLO

W

-BLUE

VIOLET

GREEN

GREEN-

WHITE

GREEN-

WHITE

GREEN-

RED

GREEN

34

5

ANALOG
INTERFACE

ANALOG
INTERFACE

INTERFACE

CAN DRIVER

INTERFACE

CAN DRIVER

AA00

CAN COMMUNICATION CIRCUIT

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

13Ab-753

SYMPTOM PROCEDURES

ZK603637

Data link connector

Brakepedal

AA00

C-125 (B)

Connector: C-125

ZK603655

C-01

Connector: C-01

AA00

ZK603592

ECM

B-11 (GR)

Connector: B-11

AA00

ZK603654AA00

C-33

Connector: C-33

ZK603645 AA00

ETACS-ECU

C-317

Connectors: C-301, C-309 and C-317

C-301

C-309 (B)

ZK603656

C-04

Connector: C-04

AA00



CIRCUIT OPERATION

｠

Battery  voltage  is  applied  to  the  diagnosis
connector (terminal No. 16).

｠

The diagnosis connector (terminal No. 4 and No. 5)
is grounded to the vehicle body.

COMMENT

｠

When  the  communication  between  M.U.T.-III  and
ECM  is  impossible,  it  can  be  suspected  that  the
CAN bus line, power supply circuit of the diagnosis
connector, and/or grounding circuit are defective.

｠

Communication  can  not  be  achieved  either,  if  a
wrong vehicle type is selected on M.U.T.-III.

13Ab-754

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

SYMPTOM PROCEDURES
