Mitsubishi Outlander XL. Manual - part 356

YES:

 Replace the ECM. When the ECM is replaced, register

the ID code. Refer to GROUP 42B, ID Code Registration
Judgment Table <Vehicles with KOS> P.42B-12or GROUP
42C, ID Code Registration Judgment Table <Vehicles with
WCM> P.42C-8. Then go to Step 8.

NO:

 The Inspection is complete.

STEP 8. Test the OBD-II Drive Cycle.

(1)

Carry  out  test  drive  with  the  drive  cycle  pattern.  Refer  to
Diagnostic  Function  -  OBD-II  Drive  Cycle  -  Pattern  21  P.
13Ab-8.

(2)

Check the diagnostic trouble code (DTC).

Q:Is DTC P1020 set?

YES:

 Retry the trouble shooting.

NO:

 The Inspection is complete.

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

13Ab-619

DIAGNOSTIC TROUBLE CODE PROCEDURES

DTC P1021: Engine Oil Control Valve Circuit

M11310100252USA0000010000

2

1

ZK602859

1

2

3 4 5 6 7 8 9 10 11 12 13 14 15 16

17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32

33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48

49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64

1

3

2

4

1

10 111213 14 1516 17 1819 20

2 3 4

5 6 7 8 9

1

2

1

B-106

MU802779

ENGINE
CONTROL
MODULE

B-10

20A

WHITE

WHITE

WHITE

VIOLET

WHITE

A-33X

MFI
RELAY

RELAY BOX
(ENGINE COMPARTMENT)

4

3

1

2

22

TO ECM

OFF

ON

AA00

ENGINE OIL CONTROL VALVE CIRCUIT

ENGINE OIL
CONTROL VALVE

36

FUSIBLE LINK

4

A-13

13Ab-620

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

DIAGNOSTIC TROUBLE CODE PROCEDURES

ZK603631

Engine oil
control valve

AA00

B-106 (B)

Connector: B-106

ZK603589

MFI relay

A-33X

Connector: A-33X

AA00

ZK603591

ECM

B-10 (GR)

Connector: B-10

AA00

ZK603650AA00

A-13

Connector: A-13



CIRCUIT OPERATION

｠

The engine oil control valve power is supplied from
the MFI relay (terminal No. 2).

｠

The ECM controls ground engine oil control valve
by turning the power transistor in the ECM "ON" and
"OFF".

TECHNICAL DESCRIPTION

｠

The  engine  oil  pressure  switches  the  cams  to
operate  the  MIVEC  system  in  the  low-speed  or
high-speed  mode  in  accordance  with  the  signals
from the ECM.

DESCRIPTIONS OF MONITOR METHODS

Circuit voltage stays low when solenoid status is off.

MONITOR EXECUTION

Continuous

MONITOR EXECUTION CONDITIONS (Other
monitor and Sensor)

Other Monitor (There is no temporary DTC stored in
memory for the item monitored below)

｠

Not applicable

Sensor (The sensor below is determined to be
normal)

｠

Not applicable

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

13Ab-621

DIAGNOSTIC TROUBLE CODE PROCEDURES

DTC SET CONDITIONS

Logic Flow Chart

ZK603802AA00

Good

Malfunction

Start

End

No

No

Yes

Yes

Yes

No

Monitoring

conditions

Continuous

failure for 2secs

Circuit voltage

< 1.5V

Check Conditions

｠

Ignition switch: "ON"

｠

Right bank engine oil control valve is OFF.

｠

Battery  positive  voltage  is  between10  and  16.5
volts.

｠

0.1 seconds has elapsed after the above mentioned
conditions have been met.

Judgment Criterion

｠

The ECM terminal voltage of right bank engine oil
control  valve  circuit  is  less  than  1.5  volts  for  2
seconds.

OBD-II DRIVE CYCLE PATTERN
Refer to Diagnostic Function - OBD-II Drive Cycle -
Pattern 24 P.13Ab-8.

TROUBLESHOOTING HINTS (The most likely
causes for this code to be set are:)

｠

Connector damage.

｠

Harness damage.

｠

Engine oil control valve failed.

｠

ECM failed.



DIAGNOSIS

Required Special Tools:

｠

MB991958: Scan Tool (M.U.T.-III Sub Assembly)

｠

MB991824: V.C.I.

｠

MB991827: USB Cable

13Ab-622

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

DIAGNOSTIC TROUBLE CODE PROCEDURES
