NOTE:
For the vacuum routing, refer to GROUP 17,
Emission Control - Vacuum Hoses - Vacuum Hose
Routing P.17c-5
SPECIFICATION(S)
GENERAL SPECIFICATION(S)
M11301000002USA0000010000
ITEMS
SPECIFICATIONS
Throttle body
Throttle bore mm (in.)
65 (2.56)
Throttle position sensor
Hall element type
Throttle actuator control motor
DC motor type, having brushes
Engine control
module (ECM)
Identification model No.
E6T70475 <Federal-FWD>
E6T70476 <Federal-AWD>
E6T70477 <California-FWD>
E6T70478 <California-AWD>
Sensors
Mass airflow sensor
Heat sensitizing type
Barometric pressure sensor
Semiconductor type
Intake air temperature sensor
Thermistor type
Engine coolant temperature sensor
Thermistor type
Heated oxygen sensor
Zirconia type
Accelerator pedal position sensor
Hall element type
Camshaft position sensor
Magneto resistance element type
Crankshaft position sensor
Magneto resistance element type
Knock sensor
Piezoelectric type
Power steering pressure sensor
Semiconductor type
Manifold absolute pressure sensor
Semiconductor type
Actuators
Multiport fuel injection (MFI) relay
Contact switch type
Fuel pump relay
Contact switch type
Throttle actuator control motor relay
Contact switch type
Injector type and number
Electromagnetic type, 6
Injector identification mark
JLN240B
Engine oil control valve
Duty cycle type solenoid valve
Exhaust gas recirculation (EGR) valve
Stepper motor type
Evaporative emission purge solenoid
Duty cycle type solenoid valve
Intake manifold tuning solenoid
ON/OFF control type solenoid valve
SERVICE SPECIFICATION(S)
M11301000003USA0000010000
ITEMS
STANDARD VALUE
Fuel pressure kPa (psi)
Approximately 324 (47) at curb
idle
MULTIPORT FUEL INJECTION (MFI)
13Aa-7
SPECIFICATION(S)
