MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS)

CIRCUIT DIAGRAMS

90-189

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

DATA LINK
CONNECTOR

ETACS-
ECU

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

ETACS-ECU

(FUSE    )

5

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS)

CIRCUIT DIAGRAMS

90-190

MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS) (CONTINUED)

AUDIO AMPLIFIER

AUDIO VISUAL NAVIGATION UNIT

<VEHICLES WITH AUDIO AMPLIFIER>

MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS)

CIRCUIT DIAGRAMS

90-191

SATELLITE
RADIO
TUNER

(FUSE     )

7

ETACS-ECU

POWER
SUPPLY

DIN CABLE

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

<VEHICLES WITH SATELLITE RADIO TUNER>

MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS)

CIRCUIT DIAGRAMS

90-192

MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS) (CONTINUED)

AUDIO VISUAL NAVIGATION UNIT

TWEETER

FRONT DOOR SPEAKER

(LH)

(RH)

(LH)

(RH)

<VEHICLES WITHOUT AUDIO AMPLIFIER>
