Mitsubishi Outlander XL. Manual - part 101

STOPLIGHT

CIRCUIT DIAGRAMS

90-101

NOTES

BACKUP LIGHT

CIRCUIT DIAGRAMS

90-102

BACKUP LIGHT

IGNITION
SWITCH (IG1)

IG1
RELAY

TRANSMISSION
RANGE SWITCH

FRONT SIDE

ETACS-ECU

·SPARE CONNECTOR
 (FOR TRAILER LIGHT)
·SUPPLEMENTAL
 RESTRAINT
 SYSTEM (SRS)

INVECS-II 6A/T

BACKUP LIGHT

CIRCUIT DIAGRAMS

90-103

FUSIBLE
LINK

34

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

DATA LINK
CONNECTOR

BACKUP
LIGHT (LH)

BACKUP
LIGHT (RH)

POWER
DISTRIBUTION
SYSTEM

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

MITSUBISHI
MULTI-COMMUNICATION
SYSTEM (MMCS)

HORN

CIRCUIT DIAGRAMS

90-104

HORN

FUSIBLE
LINK

36

HORN
RELAY

HORN
(LOW)

HORN
(HIGH)

HORN
SWITCH

CLOCK
SPRING

ETACS-
ECU

RELAY BOX

ENGINE
COMPARTMENT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE
