Mitsubishi Outlander XL. Manual - part 102

HORN

CIRCUIT DIAGRAMS

90-105

NOTES

METER AND GAUGE

CIRCUIT DIAGRAMS

90-106

METER AND GAUGE

:

DATA LINK
CONNECTOR

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ETACS-
ECU

IG1
RELAY

FUSIBLE
LINK

36

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

34

POWER
DISTRIBUTION
SYSTEM

RELAY BOX

ENGINE
COMPARTMENT

NOTE

·AIR CONDITIONING
 SYSTEM
·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DAYTIME RUNNING LIGHT
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
 SYSTEM (KOS)
·POWER WINDOWS
·REAR WIPER AND WASHER
·SUNROOF
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
 WASHER

THEFT-ALARM
SYSTEM

METER AND GAUGE

CIRCUIT DIAGRAMS

90-107

:

INPUT SIGNAL

ANALOG
INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE CIRCUIT

ANALOG
INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

INPUT SIGNAL

COMBINATION
METER

ENGINE
CONTROL
MODULE

FRONT SIDE

TRANSMISSION
CONTROL
MODULE

OUTPUT SHAFT
SPEED SENSOR

·CRANKSHAFT POSITION
 SENSOR
·ENGINE COOLANT
 TEMPERATURE SENSOR

NOTE

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS)
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE SKID CONTROL
 SYSTEM (ASC)
·BRAKE WARNING LIGHT
·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DAYTIME RUNNING LIGHT
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT

·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEADLIGHT AUTOMATIC
 LEVELING SYSTEM
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·KEYLESS OPERATING
 SYSTEM (KOS)
·POWER WINDOWS
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER

·SEAT BELT WARNING
 TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL
 RESTRAIN SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
 SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
 WASHER

METER AND GAUGE

CIRCUIT DIAGRAMS

90-108

METER AND GAUGE (CONTINUED)

INTERFACE CIRCUIT

LED DRIVE
CIRCUIT

COMBINATION
METER

CAN TRANSCEIVER
CIRCUIT

ETACS-ECU

(FUSE     )

8

ETACS-ECU

(FUSE     )

9

METER
INFORMATION
SWITCH

(FUSE     )

12

ETACS-ECU
