Mitsubishi Outlander XL. Manual - part 4

ZB5004010000

4

17

A

15

ZB5004020000

4

15

B

13

14



FRONT DECK

The impact absorbing opening on the cowl top outer
panel  has  been  added  to  efficiently  absorb  energy
upon  impact  and  improve  the  pedestrian  protection
capability.

ZB500403

4

5

6

10

12

0000

11

9

7

3

8

1

2

1.

Cowl top lower panel

2.

Brake pedal reinforcement upper

3.

Cowl top inner panel

4.

Wiper bracket

5.

Cowl top outer panel

6.

Fender bracket

7.

Cowl top bulkhead side

8.

Upper frame extension inner

9.

Upper frame outer

10. Upper frame to front pillar brace
11. Deck crossmember stay bracket
12. Brake pedal support bracket

BODY CONSTRUCTION

1-13

BODY CONSTRUCTION CHARACTERISTICS

DASH PANEL

ZB500404 0000

2

14

3

12

8

13

5

10

1

6

4

11

7

9

1.

Brake tube bracket

2.

Dash panel crossmember center

3.

Dash crossmember extension

4.

Dash heat protector bracket

5.

Backbone reinforcement front

6.

Accelerator pedal bracket

7.

Dash panel lower

8.

Dash crossmember lower

9.

Dash crossmember lower bulkhead

10. Steering shaft bracket
11. Dash crossmember side
12. Dash panel
13. Dash panel reinforcement
14. Canister bracket

1-14

BODY CONSTRUCTION

BODY CONSTRUCTION CHARACTERISTICS

SIDE BODY

M40100000110USA0000010000

SIDE STRUCTURE

ZB6010280000

1

2

3

5

6

7

8

9

10

11

54

17

18

20

56

22

23

58

21

24

25

26

27

28

29

30

34

35

36

38

65

39

40

41

45

37

42

43

44

31

48

47

46

49

53

52

50

14

13

15

16

19

57

55

33

32

61

51

60

59

62

64

63

4

12

1.

Front door hinge reinforcement lower

2.

Front pillar reinforcement bulkhead center

3.

Front door check reinforcement

4.

Front door hinge reinforcement upper

5.

Front pillar reinforcement lower support

6.

Front pillar inner lower

7.

Harness bracket

8.

Front pillar inner upper

9.

Roof side rail inner

10. Assist grip bracket front
11. Quarter inner panel
12. Side outer reinforcement rear (Right side)
13. Gate inner pillar upper
14. Gate pillar inner reinforcement upper <7 person>
15. Gate pillar inner reinforcement <7 person>

16. Gate inner pillar lower
17. Third seat belt reinforcement lower (Left side) <7 person>
18. Quarter inner lower extension
19. Third  seat  belt  reinforcement  lower  (Right  side)  <7

person>

20. Roof side rail reinforcement
21. Third seat belt reinforcement upper <7 person>
22. Gate pillar reinforcement
23. Second seat belt reinforcement upper
24

Liftgate lower cable reinforcement

25. Quarter outer extension upper
26. Quarter outer extension rear
27. Rear bumper bracket side
28. Quarter outer extension lower
29. Filler neck bracket (Left side)

BODY CONSTRUCTION

1-15

BODY CONSTRUCTION CHARACTERISTICS

30. Side sill outer reinforcement rear
31. Side sill outer reinforcement front
32. Side sill bulkhead C
33. Side sill reinforcement support center
34. Side sill bulkhead A
35. Side sill reinforcement support front
36. Side sill bulkhead front
37. Side sill inner support front
38. Fender bracket
39. Front pillar reinforcement lower
40. Deck support pipe (Left side)
41. Rear door hinge reinforcement
42. Center pillar seat belt reinforcement lower
43. Center pillar seat belt reinforcement upper
44. Front pillar upper reinforcement
45. Side sill end plate
46. Hood opener bracket (Left side)
47. Cowl side trim bracket

48. Deck crossmember bracket (Right side)
49

Center inner pillar lower

50. Center inner pillar upper
51. Center pillar inner reinforcement lower
52

Quarter inner plate front

53. Quarter inner front extension
54. Jack bracket (Right side)
55. Splash shield bracket
56. Roof side reinforcement support
57. Front pillar reinforcement plate
58. Rear door catch reinforcement
59. Rear pillar reinforcement lower
60. Second seat belt reinforcement lower (Right side)
61. Second seat belt reinforcement lower (Left side)
62. Rear pillar reinforcement upper
63. Liftgate lower striker reinforcement
64. Center pillar reinforcement
65. Side outer panel



1-16

BODY CONSTRUCTION

BODY CONSTRUCTION CHARACTERISTICS
