Mitsubishi Outlander GS45X. Manual - part 305

SPARE CONNECTOR (FOR SATELLITE RADIO)

TSB Revision

CIRCUIT DIAGRAMS

90-301

RADIO AND CD PLAYER

MULTIVISION DISPLAY

<VEHICLES WITH MMCS>

<VEHICLES WITHOUT MMCS>

·AUDIO SYSTEM
 <VEHICLES WITHOUT
 AUDIO AMPLIFIER>
·HANDS-FREE
 INTERFACE SYSTEM
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
 <VEHICLES WITHOUT
 AUDIO AMPLIFIER>
·SPARE CONNECTOR
 (FOR NAVIGATION SYSTEM)
·UNIVERSAL SERIAL BUS (USB) BOX

NOTE

: :

·HANDS-FREE
 INTERFACE SYSTEM
·REAR SEAT
 ENTERTAINMENT SYSTEM
·SPARE CONNECTOR
 (FOR HANDS-FREE
 INTERFACE SYSTEM)
·SPARE CONNECTOR
 (FOR REAR DISPLAY)
·UNIVERSAL SERIAL BUS (USB) BOX

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

SPARE CONNECTOR (FOR NAVIGATION SYSTEM)

TSB Revision

CIRCUIT DIAGRAMS

90-302

SPARE CONNECTOR (FOR NAVIGATION SYSTEM)

M1901025001268

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

IG1
RELAY

ETACS-
ECU

REFER TO
POWER
DISTRIBUTION
SYSTEM

·SPARE CONNECTOR
 (FOR TRAILER LIGHTS)
·SUPPLEMENTAL
 RESTRAINT SYSTEM
 (SRS)

SPARE CONNECTOR
(FOR NAVIGATION UNIT)

RELAY BOX

ENGINE
COMPARTMENT

FUSIBLE
LINK

36

·INVECS-II 6A/T
·INVECS-III CVT

BACKUP
LIGHT

TRANSMISSION
RANGE SWITCH

CENTER
PANEL UNIT

SPARE CONNECTOR
(FOR SATELLITE RADIO)

·AUDIO SYSTEM
·HANDS-FREE
 INTERFACE SYSTEM
·UNIVERSAL SERIAL
 BUS (USB) BOX

SPARE CONNECTOR (FOR NAVIGATION SYSTEM)

TSB Revision

CIRCUIT DIAGRAMS

90-303

NOTE

:
:
: ·HANDS-FREE INTERFACE SYSTEM

·REAR SEAT ENTERTAINMENT SYSTEM
·SPARE CONNECTOR
 (FOR HANDS-FREE INTERFACE SYSTEM)
·SPARE CONNECTOR
 (FOR REAR DISPLAY)
·UNIVERSAL SERIAL BUS (USB) BOX

AUDIO
ADAPTER

<VEHICLES WITHOUT REAR DISPLAY UNIT (WITH AUDIO ADAPTER)>

2.4L ENGINE
3.0L ENGINE

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

SPARE CONNECTOR (FOR NAVIGATION SYSTEM)

TSB Revision

CIRCUIT DIAGRAMS

90-304

SPARE CONNECTOR (FOR NAVIGATION SYSTEM) (CONTINUED)

SPARE CONNECTOR
(FOR NAVIGATION UNIT)

REAR DISPLAY UNIT

<VEHICLES WITH REAR DISPLAY UNIT>

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER
