SPARE CONNECTOR (FOR NAVIGATION SYSTEM)

TSB Revision

CIRCUIT DIAGRAMS

90-305

NOTES

SPARE CONNECTOR (FOR REAR DISPLAY)

TSB Revision

CIRCUIT DIAGRAMS

90-306

SPARE CONNECTOR (FOR REAR DISPLAY)

M1901023700406

ETACS-
ECU

RELAY BOX

ENGINE
COMPARTMENT

·AUDIO SYSTEM
·HANDS-FREE
 INTERFACE SYSTEM
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·SPARE CONNECTOR
 (FOR HANDS-FREE
 INTERFACE SYSTEM)
·SPARE CONNECTOR
 (FOR NAVIGATION SYSTEM)
·SPARE CONNECTOR
 (FOR SATELLITE RADIO)
·UNIVERSAL SERIAL
 BUS (USB) BOX

FUSIBLE
LINK

36

COMBINATION
METER

CPU

INTERFACE
CIRCUIT

·AIR CONDITIONING
 SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE STABILITY
 CONTROL SYSTEM (ASC)
·AUDIO SYSTEM
·CRUISE
 CONTROL SYSTEM
·ELECTRONIC
 CONTROLLED AWD
·HANDS-FREE
 INTERFACE SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·S-AWC
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·UNIVERSAL SERIAL
 BUS (USB) BOX

THEFT-ALARM
SYSTEM

SPARE CONNECTOR
(FOR REAR DISPLAY)

·AIR CONDITIONING
 SYSTEM
·CENTRAL DOOR
 LOCKING SYSTEM
·DAYTIME RUNNING
 LIGHT (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER
 TONE ALARM
 <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
 SYSTEM (KOS)
·REAR WIPER AND WASHER
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR TONE
 ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
 WASHER

SPARE CONNECTOR (FOR REAR DISPLAY)

TSB Revision

CIRCUIT DIAGRAMS

90-307

ACC
RELAY 2

ETACS-
ECU

IGNITION
SWITCH (ACC)

·AUDIO SYSTEM
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·REMOTE CONTROLLED
 MIRROR

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

37

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

SPARE CONNECTOR (FOR REAR DISPLAY)

TSB Revision

CIRCUIT DIAGRAMS

90-308

SPARE CONNECTOR (FOR REAR DISPLAY) (CONTINUED)

AUDIO AND VIDEO ADAPTER

VIDEO IN

AUDIO
R

AUDIO
L (MONO)

MULTIVISION DISPLAY

<VEHICLES WITH MMCS>

SPARE
CONNECTOR

FOR REAR
DISPLAY
