Mitsubishi Outlander GS45X. Manual - part 253
INVECS-II 6A/T
TSB Revision
CIRCUIT DIAGRAMS
90-93
A/T
CONTROL
RELAY
POWER SUPPLY
BATTERY
BACKUP
ENGINE
COMPARTMENT
RELAY BOX
FUSIBLE
LINK
36
·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
AND ACTIVE STABILITY CONTROL
SYSTEM (ASC)
·CENTRAL DOOR LOCKING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
COMPARTMENT LIGHT AND
IGNITION KEY HOLE ILLUMINATION
LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER
TONE ALARM <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
SYSTEM (KOS)
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING
TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
REAR SIDE MARKER LIGHT,
LICENSE PLATE LIGHT AND
LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER
NOTE
·SPARE CONNECTOR
(FOR TRAILER LIGHTS)
·SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)
:
:
·ANTI-LOCK BRAKING
SYSTEM (ABS)
·ANTI-LOCK BRAKING
SYSTEM (ABS) AND
ACTIVE STABILITY
CONTROL SYSTEM (ASC)
TRANSAXLE
CONTROL
MODULE
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER
