INVECS-II 6A/T

TSB Revision

CIRCUIT DIAGRAMS

90-97

LINE
PRESSURE
LINEAR
SOLENOID
VALVE

LOW-
REVERSE
BRAKE SHIFT
SOLENOID
VALVE

2-6 BRAKE
LINEAR
SOLENOID
VALVE

3-5 REVERSE
CLUTCH
LINEAR
SOLENOID
VALVE

HIGH CLUTCH
LINEAR
SOLENOID
VALVE

LOW CLUTCH
SHIFT
SOLENOID
VALVE

A/T
CONTROL
SOLENOID
VALVE
ASSEMBLY

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

INVECS-II 6A/T

TSB Revision

CIRCUIT DIAGRAMS

90-98

INVECS-II 6A/T (CONTINUED)

PADDLE
SHIFT
SWITCH

SHIFT
SWITCH

SPORT
MODE

AUTO
MODE

SELECT
SWITCH

SELECTOR
LEVER
ASSEMBLY

<VEHICLES WITH
PADDLE SHIFT>

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM
 (ABS) AND ACTIVE STABILITY
 CONTROL SYSTEM (ASC)
·AUDIO SYSTEM
·ELECTRONIC CONTROLLED AWD
·HANDS-FREE INTERFACE SYSTEM
·HEADLIGHT MANUAL
 LEVELING SYSTEM
·S-AWC
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·UNIVERSAL SERIAL
 BUS (USB) BOX

TRANSAXLE
CONTROL
MODULE

INVECS-II 6A/T

TSB Revision

CIRCUIT DIAGRAMS

90-99

ETACS-ECU

(CAN DRIVE CIRCUIT)

ETACS-ECU

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

CAN TRANSCEIVER
CIRCUIT

LCD

A/T POSITION
A/T TEMPERATURE
A/T FAILURE

COMBINATION METER

RHEOSTAT

RELAY BOX

(FUSE     )

30

ETACS-ECU

12

(FUSE     )

CPU

TONE
ALARM

·AIR CONDITIONING
 SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE STABILITY
 CONTROL SYSTEM (ASC)
·AUDIO SYSTEM
·CRUISE CONTROL
 SYSTEM
·ELECTRONIC
 CONTROLLED AWD
·HANDS-FREE INTERFACE
 SYSTEM
·HEADLIGHT MANUAL
 LEVELING SYSTEM
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·REAR SEAT
 ENTERTAINMENT SYSTEM
·S-AWC
·SPARE CONNECTOR
 (FOR REAR DISPLAY)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·UNIVERSAL SERIAL
 BUS (USB) BOX

THEFT-ALARM
SYSTEM

JOINT
CONNECTOR
(CAN1)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

INVECS-II 6A/T

TSB Revision

CIRCUIT DIAGRAMS

90-100

INVECS-II 6A/T (CONTINUED)

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

ENGINE
CONTROL
MODULE

INPUT SIGNAL

·ACCELERATOR PEDAL
 POSITION SENSOR
·CRANKSHAFT POSITION
 SENSOR

ETACS-ECU

(FUSE     )

5

ETACS-ECU

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)
