ETACS-ECU

TSB Revision

CIRCUIT DIAGRAMS

90-13

AC904474AU

1

7

8

9 10

20

4

2

3

5

6

11 12

13

14 15

16

17 18

19

C-301

C-312

C-313

C-314

C-310

C-311

C-315

C-307

C-309

C-316

C-317

C-304

C-302

C-303

To front wiring
harness

Blower relay

Fusible link

No connection

Fuse

No connection

Fusible link

To instrument
panel wiring
harness

To roof wiring
harness

To instrument
panel wiring
harness

To instrument
panel wiring
harness

To floor wiring
harness

To front wiring
harness

To front wiring
harness

CENTRALIZED JUNCTION

TSB Revision

CIRCUIT DIAGRAMS

90-14

CENTRALIZED JUNCTION

M1901000303848

FUSIBLE LINK AND FUSE

ENGINE COMPARTMENT

No. Power supply circuit Name

Rated
capacity (A)

Housing
color

Load circuit

1

Fusible link (engine
compartment) No.36

Fuse

15

Blue

Fog light and fog light relay

2

7.5

Brown

Engine control module

3

20

Yellow

Input shaft speed sensor <3.0L
Engine>, output shaft speed sensor
<3.0L Engine>, primary pulley speed
sensor <2.4L Engine>, secondary
pulley speed sensor <2.4L Engine>
and transaxle control module

4

10

Red

Horn and horn relay

5

7.5

Brown

Generator

6

7

10

Red

A/C compressor assembly and A/C
compressor relay

8

15

Blue

Engine control module

9

20

Yellow

Theft-alarm horn <Vehicles without
theft-alarm sensor> and theft-alarm
horn relay <Vehicles without
theft-alarm sensor>

10

11

12

13

10

Red

Daytime running light relay <Vehicles
with discharge headlight> and
headlight assembly

14

Fusible link (engine
compartment) No.36
(Headlight relay:
High)

10

Red

Headlight assembly (LH)

15

10

Red

Headlight assembly (RH)

16

Fusible link (engine
compartment) No.36
(Headlight relay: Low)

20

Yellow

Headlight assembly (LH)

17

20

Yellow

Headlight assembly (RH)

18

10

Red

Headlight assembly and headlight
leveling switch

19

10

Red

Headlight assembly (RH)

20

Fusible link (engine
compartment) No.36
(MFI relay)

10

Red

Evaporative emission ventilation
solenoid <3.0L Engine>

21

10

Red

Ignition coil

CENTRALIZED JUNCTION

TSB Revision

CIRCUIT DIAGRAMS

90-15

22

Fusible link (engine
compartment) No.36
(MFI relay)

Fuse

20

Yellow

Engine control module, engine oil
control valve <3.0L Engine>,
evaporative emission purge solenoid,
evaporative emission ventilation
solenoid <2.4L Engine>, exhaust
engine oil control valve <2.4L
Engine>, exhaust gas recirculation
valve, heated oxygen sensor <2.4L
Engine>, injector, intake engine oil
control valve <2.4L Engine>, left bank
heated oxygen sensor <3.0L
Engine>, linear air-fuel ratio sensor
<2.4L Engine>, mass airflow sensor,
right bank heated oxygen sensor
<3.0L Engine> and throttle actuator
control motor relay

23

15

Blue

Fuel pump module

24

Fusible link (engine
compartment) No.36

Fusible
link

30

Pink

Starter

25

26

40

Green

ABS-ECU and ASC-ECU

27

30

Pink

ABS-ECU and ASC-ECU

28

30

Pink

Condenser fan motor, condenser fan
relay and fan control relay

29

40

Green

Radiator fan motor and radiator fan
relay

30

Fuse

30

Green

Fuse (passenger compartment) No.7
to 9

31

30

Green

Audio amplifier

32

Fusible link (engine
compartment) No.36
(MFI relay)

No. Power supply circuit Name

Rated
capacity (A)

Housing
color

Load circuit

CENTRALIZED JUNCTION

TSB Revision

CIRCUIT DIAGRAMS

90-16

NOTE:

.

1. *

1

: 2.4L Engine

2. *

2

: 3.0L Engine

33

Battery/Generator

Fusible
link

120*

140*

Fusible link (engine compartment)
No.37/Fusible link (engine
compartment) No.34 to 36

34

Battery/Fusible link
(engine compartment)
No.33

80

Fuse (passenger compartment) No.2,
4, 5, 10 to 12, 14, 15, 17, 18, 24, 25,
fusible link (passenger compartment)
No.20, ETACS-ECU and
ETACS-ECU (ACC relay 3)

35

80

36

120

Fuse (engine compartment) No.1 to
5, 7 to 9, 13 to 18, 20 to 23, 30, 31,
fusible link (engine compartment)
No.24, 26 to 29, headlight relay and
MFI relay

37

Fusible link (engine
compartment) No.33/
Generator

80

Fuse (passenger compartment) No.3,
6, 13, 16, 19, fusible link (passenger
compartment) No.1, 21 and
ETACS-ECU (ACC relay 2)

No. Power supply circuit Name

Rated
capacity (A)

Housing
color

Load circuit
