HOW TO READ CIRCUIT DIAGRAMS
TSB Revision
CIRCUIT DIAGRAMS
90-9
SYMBOLS (EXCEPT CONNECTOR AND GROUNDING)
Devices appearing in circuit diagrams are indicated by the following symbols.
WIRE COLOR CODES
Wire colors are identified by the following color codes.
If a cable has two colors, the first of the two color code charac-
ters indicates the basic color (color of the cable coating) and
the second indicates the marking (tracer) color.
NOTE:
*: No code indicates 0.5 mm
2
(0.0008 in
2
). Cable color code in
parentheses indicates 0.3 mm
2
(0.0005 in
2
).
ACX02377AB
Battery
ACX02378 AB
Buzzer
ACX02379AB
Capacitor
ACX02380 AB
Electrolytic
capacitor
ACX02381 AB
Variable
capacitor
ACX02382 AB
Coil
ACX02383 AB
Diode
ACX02384
Light emitting
diode
AB
ACX02385
Photo diode
AB
ACX02386 AB
Zener diode
ACX02387AC
Dual filament bulb
ACX02388AC
Single filament
bulb
ACX02389AB
Fuse
ACX02390AB
Fusible link
ACX02391AB
Horn
ACX02392 AB
Motor
ACX02393 AB
Pulse generator
ACX02394 AB
Piezoelectric
device
ACX02395AB
Resistor
ACX02396AB
Variable resistor
ACX02397AB
Speaker
ACX02398 AB
Thermistor
ACX02399AB
Transistor
ACX02400AB
Photo transistor
Code
Wire color
Code
Wire color
Code
Wire color
Code
Wire color
B
Black
L
Blue
PU
Purple
V
Violet
BR
Brown
LG
Light green
R
Red
W
White
G
Green
O
Orange
SB
Sky blue
Y
Yellow
GR
Gray
P
Pink
SI
Silver
−
−
No.
Meaning
1
<F>: Flexible wire
<T>: Twisted wire
2
Wire size (mm
2
)*
3
Basic color (color of the cable coating)
4
Marking color
ACX01279 AB
<F>
1.25
G
B
1
2
3
4
Example:
