TRAILING ARM ASSEMBLY

TSB Revision

REAR SUSPENSION

34-17

Removal steps

1.

Rear wheel speed sensor (Refer to
GROUP 35B

− Wheel speed

sensor

P.35B-189

)

2.

O ring

3.

Clamp

4.

Brake hose connection

5.

Brake hose bracket

<<

B

>>

6.

Caliper assembly

7.

Brake disk

8.

Shoe and lining assembly (Refer to
GROUP 36, Parking Brake and
Drum

P.36-15

.)

9.

Rear wheel hub assembly
mounting bolt

10. Rear wheel hub assembly
11. Parking brake cable connection
12. Rear brake backing plate
13. Control link connection
14. Upper arm connection
15. Lower arm connection
16. Trailing arm assembly

Removal steps (Continued)

AC709421AB

N

16 ± 3 N·m
12 ± 2 ft-lb

*3

*2

*1

*1

*2

*2

*2

*2

*1

*1

*1

*1

110 ± 11 N·m
81 ± 8 ft-lb

95 ± 14 N·m
70 ± 10 ft-lb

8.5 ± 1.5 N·m
76 ± 13 in-lb

11 ± 2 N·m
98 ± 17 in-lb

55 ± 5 N·m
41 ± 3 ft-lb

71 ± 10 N·m
52 ± 7 ft-lb

90 ± 9 N·m
67 ± 6 ft-lb

*1

*1

71 ± 10 N·m
52 ± 7 ft-lb

13 ± 2 N·m
115 ± 17 in-lb

<AWD>

144   176 N·m

107   129 ft-lb

2

3

1

N

7

9

5

4

6

8

10

11

12

13

14

15

16

17

18

*3

N

Removal steps

1.

Cotter pin

<<A>> >>A<<

2.

Driveshaft nut

>>A<<

3.

Washer

4.

Rear wheel speed sensor

5.

Clamp

6.

Brake hose connection

7.

Brake hose bracket

<<

B

>>

8.

Caliper assembly

9.

Brake disk

10. Shoe and lining assembly (Refer to

GROUP 36, Parking Brake and
Drum

P.36-18

.)

11. Rear wheel hub assembly mounting

bolt

<<C>>

12. Rear wheel hub assembly
13. Parking brake cable connection
14. Rear brake backing plate
15. Control link connection
16. Upper arm connection
17. Lower arm connection
18. Trailing arm assembly

Removal steps (Continued)

TRAILING ARM ASSEMBLY

TSB Revision

REAR SUSPENSION

34-18

Required Special Tools:

• MB990211: Slide Hammer

• MB990241: Rear Axle Shaft Puller

• MB990242: Puller Shaft

• MB990244: Puller Bar

• MB990767: Front Hub and Flange Yoke Holder

• MB991354: Puller Body

REMOVAL SERVICE POINTS

.

<<A>> DRIVESHAFT NUT REMOVAL

CAUTION

Do not apply the vehicle weight on the rear wheel hub
assembly with the driveshaft nut loosened. Otherwise, the
wheel bearing will be broken.
Use special tool MB990767 to fix the hub and remove the
driveshaft nut.

.

<<B>> CALIPER ASSEMBLY REMOVAL

1. Remove the caliper assembly with brake hose.
2. Secure the removed caliper assembly with a wire or other

similar material at a position where it will not interfere with
the removal and installation of the rear wheel hub assembly.

.

<<C>> REAR WHEEL HUB ASSEMBLY REMOVAL

1. If the rear wheel hub assembly is seized with the rear

driveshaft assembly, use special tools MB990242 and
MB990244, MB991354 and MB990767 to push the rear
driveshaft assembly out from the hub and then remove the
rear wheel hub assembly.

AC703485 AB

MB990767

AC708477

MB991354

MB990244
(MB990241)

MB990242
(MB990241)

AC

MB990767

(Three)

TRAILING ARM ASSEMBLY

TSB Revision

REAR SUSPENSION

34-19

2. If the rear wheel hub assembly is seized with the knuckle,

use special tools MB990211 and MB990241 {combination
(A)}, or MB990211 and MB991354 {combination (B)} to
remove the rear wheel hub assembly.

INSTALLATION SERVICE POINTS

.

>>A<< WASHER/DRIVESHAFT NUT INSTALLA-
TION

CAUTION

• The magnetic encoder collects metallic particles easily,

because it is magnetized. Make sure that the magnetic
encoder does not collect metallic particles. Check that
there is not any trouble prior to reassembling it.

• When installing the drive shaft, make sure that it does

not contact with the magnetic encoder (integrated with
the inner oil seal) to avoid damage.

• Do not apply the vehicle weight on the rear wheel hub

assembly before fully tightening the driveshaft nuts.
Otherwise, the wheel bearing will be broken.

1. Incorporate the driveshaft washer as shown in the figure.
2. Use special tool MB990767 to tighten the driveshaft nuts. At

this time, tighten the nuts within the specified torque range
considering the final tightening.

Tightening torque: 144

− 176 N⋅m (107 − 129 ft-lb)

3. If the pin holes do not align with the pins, tighten the

driveshaft nut [less than 200 N

⋅m (147 ft-lb)] and find the

nearest hole then bend the split ping to fit it.

AC701415 AC

MB990241

MB990211

Combination (A)

AC706385 AB

MB991354

MB990211

Combination (B)

AC703486 AB

Magnetic
encoder

Wheel
bearing

Rear wheel
hub assembly

AC703487AB

MB990767

Washer

TRAILING ARM ASSEMBLY

TSB Revision

REAR SUSPENSION

34-20

REMOVAL AND INSTALLATION <2.4L ENGINE: 7 PERSONS SEAT, 3.0L ENGINE>

M1341004200181

CAUTION

• The parts indicated by

*1

 should be temporarily tightened, and then fully tightened with the vehicle

standing on the ground and the curb weight condition.

• The parts indicated by

*2

 are the bolts/nuts with friction coefficient stabilizer. In removal, ensure

there is no damage, clean dust and soiling from the bearing and thread surfaces, and tighten them
to the specified torque.

• The part indicated by

*3

is the bolt/nut with friction coefficient stabilizer. In removal, replace it with

new one.

Pre-removal operation
• Brake Fluid Draining (Refer to GROUP 35A, On-vehicle

Service

− Brake Fluid Level Inspection and Bleeding

P.35A-20

.)

Post-installation operation
• Brake Fluid Refilling and Bleeding (Refer to GROUP 35A,

On-vehicle Service

− Brake Fluid Level Inspection and

Bleeding

P.35A-20

.)

• Wheel Alignment Check and Adjustment (Refer to

P.34-10

.)

• Parking Brake Lever Stroke Check and Adjustment (Refer to

GROUP 36, On-vehicle Service

− Parking Brake Lever

Stroke Check and Adjustment

P.36-9

.)

AC802598

110 ± 11 N·m
81 ± 8 ft-lb

95 ± 14 N·m
70 ± 10 ft-lb

N

8.5 ± 1.5 N·m
76 ± 13 in-lb

11 ± 2 N·m
98 ± 17 in-lb

58 ± 7 N·m
43 ± 5 ft-lb

11 ± 2 N·m
98 ± 17 in-lb

71 ± 10 N·m
52 ± 7 ft-lb

39 ± 6 N·m
29 ± 4 ft-lb

90 ± 9 N·m
67 ± 6 ft-lb

11 ± 2 N·m
98 ± 17 in-lb

<FWD>

AC

*3

*2

*2

*2

*1

*2

*2

*2

*1

*1

*1

*1

*1

71 ± 10 N·m
52 ± 7 ft-lb

*1

*1

7

9

6

8

10

11

12

13

14

145 ± 15 N·m
107 ± 11 ft-lb

1

2

3

4

5

*3

Removal steps

1.

Rear wheel speed sensor

2.

Brake hose bracket

<<

B

>>

3.

Caliper assembly

4.

Brake disk

5.

Rear wheel hub assembly
mounting bolt

6.

Rear wheel hub assembly

7.

Parking brake cable connecting bolt

<<

D

>>

8.

Rear brake assembly

9.

Control link connection

10. Stabilizer link connection

<<

E

>>

11. Lower arm assembly connection
12. Upper arm connection
13. Trailing arm assembly

>>

A

<< 14. Rear sensor cover

Removal steps (Continued)
