DOOR

TSB Revision

BODY

42A-155

INSTALLATION SERVICE POINTS

.

>>A<< DOOR CHECK INSTALLATION

Install the door check with the following identification marks fac-
ing upward.

.

Door lock key cylinder and door
outside handle removal steps

•

Rear lower sash (Refer to

P.42A-159

.)

2.

Plug

3.

Door outside handle cover

4.

Door outside handle

5.

Door outside handle gasket

6.

Door outside handle base
Door handle and door latch
removal steps

•

Rear lower sash (Refer to

P.42A-159

.)

7.

Screw

8.

Door latch assembly

9.

Inside lock cable

10. Inside handle cable
11. Outside handle rod

Door check removal steps

•

Rear door speaker (Refer to
GROUP 54A, Speaker

P.54A-692

.)

>>A<<

12. Door check

Applicable location

Identification
mark

Front door

Left door

55L

Right door 55R

Rear door

Left door

58L

Right door 58R

AC703291AB

Identification mark

DOOR

TSB Revision

BODY

42A-156

>>B<< DOOR INSIDE HANDLE INSTALLATION

When connecting the inside cable to the door inside handle,
ensure that the door latch and the inside handle are unlocked.

INSPECTION

M1423004701630

FRONT DOOR LOCK ACTUATOR CHECK

ACTUATOR OPERATION CHECK

ACTUATOR SWITCH CHECK <DRIVER'S SIDE>

ACTUATOR SWITCH CHECK <PASSENGER'S SIDE [Vehi-
cles with keyless operation system (KOS)]>

Lever
position

Battery
connection

Lever
operation

At the
"LOCK"
position

• Connect

terminal No.4 to
the negative
battery terminal.

• Connect

terminal No.6 to
the positive
battery terminal.

The lever moves
from the "LOCK"
position to the
"UNLOCK"
position.

At the
"UNLOCK"
position

• Connect

terminal No.6 to
the negative
battery terminal.

• Connect

terminal No.4 to
the positive
battery terminal.

The lever moves
from the
"UNLOCK"
position to the
"LOCK"
position.

Lever position Terminal

number

Normal value

UNLOCK

1

− 3

Continuity exists
(2

Ω or less)

Lever position Terminal

number

Normal value

UNLOCK

1

− 3

Continuity exists
(2

Ω or less)

4

2
5

3
6

1

4

2
5

3
6

1

AC703351

B

A

AB

Lever

UNLOCK

<Front left side>

<Front right side>

LOCK

View A

UNLOCK

LOCK

View B

Lever

DOOR

TSB Revision

BODY

42A-157

REAR DOOR LOCK ACTUATOR CHECK

ACTUATOR OPERATION CHECK

CENTRAL DOOR LOCK SWITCH CONTINUITY
CHECK

Remove the power window switch (Refer to

P.42A-148

).

<DRIVER'S SIDE>

<PASSENGER'S SIDE>

Lever
position

Battery
connection

Lever
operation

At the
"LOCK"
position

• Connect

terminal No.4 to
the negative
battery terminal.

• Connect

terminal No.6 to
the positive
battery terminal.

The lever moves
from the "LOCK"
position to the
"UNLOCK"
position.

At the
"UNLOCK"
position

• Connect

terminal No.6 to
the negative
battery terminal.

• Connect

terminal No.4 to
the positive
battery terminal.

The lever moves
from the
"UNLOCK"
position to the
"LOCK"
position.

4

2
5

3
6

1

AC703352

4

2
5

3
6

1

B

A

AB

Lever

UNLOCK

LOCK

UNLOCK

LOCK

<Rear left side>

<Rear right side>

View A

View B

Lever

Switch
position

Tester
connection

Specified
condition

LOCK

10

− 14

Continuity exists
(2

Ω or less)

OFF

10

− 14, 10 − 13 Open circuit

UNLOCK

10

− 13

Continuity exists
(2

Ω or less)

Switch
position

Tester
connection

Specified
condition

LOCK

13

− 14

Continuity exists
(2

Ω or less)

OFF

13

− 14, 12 −14 Open circuit

UNLOCK

12

− 14

Continuity exists
(2

Ω or less)

AC703355

Door lock switch

AB

AC703356

Door lock switch

AC

DOOR

TSB Revision

BODY

42A-158

LOCK/UNLOCK SWITCH CHECK



<VEHICLE WITH KOS>

Switch
position

Tester
connection

Specified
condition

ON

1

− 2

Continuity exists
(2

Ω or less)

OFF

1

− 2

Open circuit

AC609545

ZC600097

AC

Lock/unlock
switch

Door outside

handle base
