DOOR

TSB Revision

BODY

42A-147

INSPECTION

M1423006000753

DOOR SWITCH CHECK

Switch position Terminal

number

Normal
value

Release (ON)

1

− Ground, 2 −

Ground, 3

−

Ground

Continuity
exists (2

Ω or

less)

Depressed
(OFF)

1

− Ground, 2 −

Ground, 3

−

Ground

Open circuit

AC211414AB

1

2

3

DOOR

TSB Revision

BODY

42A-148

DOOR GLASS AND REGULATOR

REMOVAL AND INSTALLATION

M1429001301299

Required Special Tool:

• MB990480: Window Glass Holder

Post-installation operation
• Door window glass adjustment (Refer to

P.42A-138

.)

AC703242

1

2

3

AC

2

<Front door>

4.0 ± 2.0 N·m
35 ± 17 in-lb

4.0 ± 2.0 N·m
35 ± 17 in-lb

7.5 ± 1.5 N·m
66 ± 13 in-lb

7.5 ± 1.5 N·m
66 ± 13 in-lb

Door window glass assembly
removal steps

•

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-11

.)

•

Waterproof film, belt line molding,
belt line weatherstrip inner, and
speaker bracket (Refer to

P.42A-159

.)

1.

Door window glass assembly

Power window regulator
assembly removal steps

>>A<<

•

Post-installation operation check
<Driver’s side only>

•

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-11

.)

•

Waterproof film and speaker
bracket (Refer to

P.42A-159

.)

<<A>>

2.

Power window regulator assembly

3.

Power window motor

DOOR

TSB Revision

BODY

42A-149

Required Special Tool:

• MB990480: Window Glass Holder

AC703241

2

1

3

AC

2

<Rear door>

4.0 ± 2.0 N·m
35 ± 17 in-lb

7.5 ± 1.5 N·m
66 ± 13 in-lb

Door window glass assembly
removal steps

•

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-11

.)

•

Waterproof film, belt line molding,
belt line weatherstrip inner, door
window glass channel, and speaker
bracket (Refer to

P.42A-159

.)

•

Door latch assembly (Refer to

P.42A-153

.)

1.

Door window glass assembly

Power window regulator
assembly removal steps

•

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-11

.)

•

Waterproof film and speaker
bracket (Refer to

P.42A-159

.)

<<A>>

2.

Power window regulator assembly

3.

Power window motor

AC703245

1

2

3

4

5

6

AC

<Front door>

<Rear door>

DOOR

TSB Revision

BODY

42A-150

REMOVAL SERVICE POINT

.

<<A>> POWER WINDOW REGULATOR REMOVAL

1. Remove the door window glass installation bolts.

CAUTION

If tinting film is adhered to the door window glass, attach
special tool MB990480 to the outside of the glass to pre-
vent the film from peeling off.
2. Lift the door window glass, and attach special tool

MB990480 to the glass as shown to prevent the glass from
falling.

3. Remove the power window regulator.

INSTALLATION SERVICE POINT

.

>>A<< POST-INSTALLATION OPERATION CHECK
<DRIVER'S SIDE ONLY>

When the following procedures are carried out, carry out the
learning procedures of the power window fully closed position
(Refer to

P.42A-140

).

• Power window regulator removal or replacement

• Power window switch removal or replacement

INSPECTION

M1429001400884

POWER WINDOW SWITCH CONTINUITY CHECK

.

Power window switch <Front
door> removal step

>>A<<

•

Post-installation operation check
<Driver’s side only>

•

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-11

.)

1.

Power window switch panel
assembly

2.

Power window switch panel

3.

Power window main switch
<Driver's side>, power window sub
switch <Front passenger's side>

Power window sub switch <Rear
door> removal step

•

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-11

.)

4.

Power window switch panel
assembly

5.

Power window switch panel

6.

Power window sub switch

AC703243AB

MB990480
