SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-73

Step 21. Check the wiring harness from C-217
ETACS-ECU connector terminal Nos. 12 and 13 to
F-06 tailgate lock actuator connector terminal
Nos. 2 and 3.

NOTE:

Prior to the wiring harness inspection, check
intermediate connector F-05 and junction block
connector C-209, and repair if necessary.

•

Check the input and output lines for open circuit.

Q: Is the check result normal?

YES :

The trouble can be an intermittent

malfunction (Refer to GROUP 00

−

 How to

Cope with Intermittent Malfunction

P.00-6

).

NO :

Repair the wiring harness.

AC308722

Connector: C-217

Junction block (Rear view)

Junction block side

AD

3

1

2

14

4

5

7 6

8

1110 9

1312

17

15

16

18

19

20

<LHD>

AC308809

Connectors: F-05, F-06

F-05

AB

F-05

F-06(B)

5

1

8

7

6

2

9 10

3 4

5

6

4

2

3

1

F-06

Harness side

AC308720

Connector: C-209
<LHD>

Harness side

AH

7

15

5

6

1413

2

9

12

4 3

10

11

1

8

Junction block (Front view)

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-74

INSPECTION PROCEDURE C-2: A Door or a Tailgate can not be Locked or Unlocked by the Central
Door Locking System. <R.H. drive vehicles>

ETACS-ECU

DOOR LOCK
ACTUATOR
(FRONT: RH)

DOOR LOCK
ACTUATOR
(FRONT: LH)

DOOR LOCK
ACTUATOR
(REAR: LH)

DOOR LOCK
ACTUATOR
(REAR: RH)

TAILGATE
LOCK
ACTUATOR

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Gray     R : Red     P : Pink     V : Violet

DOOR
UNLOCK
RELAY

DOOR
LOCK
RELAY

Central Door Lock Circuit <RHD>

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-75

COMMENT ON TROUBLE SYMPTOM
If a door or the tailgate can not be locked or unlocked
by the central door locking system, the door lock
actuator or the tailgate lock actuator may be
defective.

POSSIBLE CAUSES

•

Malfunction of the door lock actuator

•

Malfunction of the tailgate lock actuator

•

Damaged harness wires and connectors

DIAGNOSIS PROCEDURE

Step 1. Confirm which door lock actuator is
defective.

Q: Which door fails to lock correctly?

Driver's door :

Go to Step 2.

Front passenger's door :

Go to Step 6.

Rear right door :

Go to Step 10.

Rear left door :

Go to Step 14.

Tailgate :

Go to Step 18.

Step 2. Connector check: E-25 door lock actuator
(front: RH) connector

Q: Is the check result normal?

YES :

Go to Step 3.

NO :

Repair the defective connector.

Step 3. Check the door lock actuator (front: RH)

Check that the door lock actuator (front: RH) works
normally. Refer to GROUP 42

−

 Door

P.42-35

.

Q: Is the check result normal?

YES :

Go to Step 4.

NO :

Replace the door lock actuator (front: RH).

Step 4. Connector check: C-217, C-220
ETACS-ECU connector

Q: Is the check result normal?

YES :

Go to Step 5.

NO :

Repair the defective connector.

AC308805AD

Connector: E-11

Harness side

E-11(B)

5

6

4

2

3

1

<RHD>

AC308777

Connectors: C-217, C-220
<RHD>

C-220

AB

C-220

28

37

43

29

44

38

23

32

41

24

25

26

27

34

42

3635

33

21

22

30

39

40

31

C-217

C-217

Junction block side

3

1

2

14

4

5

7 6

8

1110 9

1312

17

15

16

18

19

20

Harness side

Junction block (Rear view)

SYMPTOM PROCEDURES

SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR

54B-76

Step 5. Check the wiring harness from C-217
ETACS-ECU connector terminal No. 12 and C-220
ETACS-ECU connector No. 22 to E-25 door lock
actuator (front: RH) connector terminal Nos. 4
and 6.

NOTE:

Prior to the wiring harness inspection, check
intermediate connector C-15 and junction block
connector C-205, and repair if necessary.

•

Check the input and output lines for open circuit.

Q: Is the check result normal?

YES :

The trouble can be an intermittent

malfunction (Refer to GROUP 00

−

 How to

Cope with Intermittent Malfunction

P.00-6

).

NO :

Repair the wiring harness.

Step 6. Connector check: E-11 door lock actuator
(front: LH) connector

Q: Is the check result normal?

YES :

Go to Step 7.

NO :

Repair the defective connector.

AC308777

Connectors: C-217, C-220
<RHD>

C-220

AB

C-220

28

37

43

29

44

38

23

32

41

24

25

26

27

34

42

3635

33

21

22

30

39

40

31

C-217

C-217

Junction block side

3

1

2

14

4

5

7 6

8

1110 9

1312

17

15

16

18

19

20

Harness side

Junction block (Rear view)

AC308797AB

Connector: E-25

Harness side

E-25(B)

5

6

4

2

3

1

<RHD>

AC308769

AI

Connector: C-15 <RHD>

AC308772

Connector: C-205

Harness side

AC

Junction block (Front view)

<RHD>

AC308805AD

Connector: E-11

Harness side

E-11(B)

5

6

4

2

3

1

<RHD>
