Mitsubishi Outlander (2003+). Manual - part 329

MOULDINGS

EXTERIOR

51-15

MOULDINGS

SPECIAL TOOL

M1511000601006

MOULDINGS

REMOVAL AND INSTALLATION

M1511004700132

Tool

Number

Name

Application

MB990449

Window moulding remover Removal of drip moulding

MB990449

AC301945

AB

1, 2

Clip

1, 2

Clip

Clip

1, 3

Section A – A

Section B – B

Section C – C

A

A

B

B

C

C

1

<Vehicle with roof rail>

<Vehicle without roof rail>

2

3

A

A

B

B

C

C

Roof drip moulding removal steps
<Vehicles without roof rail>

<<A>> >>A<<

1. Roof drip moulding

Roof drip moulding removal steps
<Vehicles with roof rail>

•

Roof rail (Refer to

P.51-18

).

<<A>> >>A<<

2. Front roof drip moulding

<<A>> >>A<<

3. Centre roof drip moulding

MOULDINGS

EXTERIOR

51-16

REMOVAL SERVICE POINT

<<A>> ROOF DRIP MOULDING REMOVAL

CAUTION

If the moulding has become warped, it should not
be reused.

Use special tool MB990449 to pry out the moulding.

INSTALLATION SERVICE POINT

>>A<< ROOF DRIP MOULDING INSTALLATION
Install the clips to the roof drip moulding before
installing the moulding to the vehicle body.

AC003626AB

MB990449

TAILGATE SPOILER

EXTERIOR

51-17

TAILGATE SPOILER

SPECIAL TOOL

M1511000601017

TAILGATE SPOILER

REMOVAL AND INSTALLATION

M1511020800043

Tool

Number

Name

Application

MB990784

Ornament remover

Removal of tailgate spoiler

MB990784

AC103231

Section A – A

Clip

3

2

1

3

A

A

AC

5.1 ± 0.2 N·m

5.1 ± 0.2 N·m

Removal steps

•

Tailgate upper trim (Refer to GROUP
52A, Tailgate trim

P.52A-25

).

•

High-mounted stop lamp connector
connection

•

Rear washer hose connection

1. Tailgate spoiler assembly
2. High-mounted stop lamp assembly
3. Tailgate spoiler

Removal steps (Continued)

ROOF RAIL

EXTERIOR

51-18

ROOF RAIL

REMOVAL AND INSTALLATION

M1511016600165

AC300386

1

4

2

3

AB

3

B

B

C

C

F

F

F

F

E

E

D

D

2

C

C

B

B

A

A

NOTE
          : Claw positions

Section C – C

Section A – A

Section B – B

Section F – F

Section D – D

Section E – E

Claw

1

4

2

1

1

4

4

4

2

4

4

2

Claw

Claw

Claw

Claw

Claw

Claw

Claw

Claw

5

6

8.5 ± 1.5 N·m

5.0 ± 1.0 N·m

5.0 ± 1.0 N·m

8.5 ± 1.5 N·m

Removal steps
1. Front roof rail cover
2. Centre roof rail cover
3. Rear roof rail cover

4. Roof rail
5. Front roof rail bracket
6. Centre roof rail bracket

Removal steps (Continued)
