SUNROOF ASSEMBLY
BODY
42-75
DISASSEMBLY AND ASSEMBLY
M1426001400250
AC102840
N
N
2
3
4
5
6
1
7
8
9
10
11
12
13
12
13
10
AD
Disassembly steps
1. Deflector assembly
•
Decoration cover (Refer to
).
2. Adjusting plate
3. Roof lid glass assembly
4. Weatherstrip
>>A<<
5. Weatherstrip inner
6. Sunroof motor assembly
7. Operating unit
8. Sun shade assembly
9. Lifter link
10. Guide assembly
11. Drip plate
12. Seal tape
13. Frame assembly
Disassembly steps (Continued)
