REAR SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-49

REAR SEAT ASSEMBLY

REMOVAL AND INSTALLATION

M1522001800178

AC003270 AB

: RESIN CLIP POSITION
  <VEHICLES WITH SPLIT SEAT>

44 N·m

33 ft-lb

44 N·m

33 ft-lb

1

8

22 N·m

16 ft-lb

22 N·m

16 ft-lb

2

<BENCH SEAT>

<SPLIT SEAT>

DETACHABLE TYPE

NON-DETACHABLE TYPE

44 N·m

33 ft-lb

8

1

44 N·m

33 ft-lb

8

44 N·m

33 ft-lb

22 N·m
16ft-lb

5

2

5

22 N·m
16ft-lb

22 N·m
16ft-lb

2

2

4

3

6

6

7

5

1. HEAD RESTRAINT

REAR SEAT REMOVAL STEPS

2. REAR SEAT CUSHION ASSEMBLY
3. STRIKER COVER
4. STRIKER ASSEMBLY
5. CATCH

6. PARCEL HOOK
7. CARGO FLOOR BOX, FRONT

<VEHICLES WITH SPLIT SEAT>

8. REAR SEATBACK ASSEMBLY

REAR SEAT REMOVAL STEPS

REAR SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-50

DISASSEMBLY AND ASSEMBLY

M1522002000205

AC003271

<BENCH SEAT>

12

13

9

11

10

9

8

7

13

12

44 N·m

33 ft-lb

14

18

17

16

44 N·m

33 ft-lb

15

4

5

1

22 N·m

16 ft-lb

2

6

12 N·m

104 in-lb

3

AB

REAR SEAT CUSHION
DISASSEMBLY STEPS

1.

HINGE

2.

BAND

3.

LOCK COVER

4.

REAR SEAT CUSHION COVER

5.

REAR SEAT CUSHION PAD

6.

LOCK BRACKET
REAR SEAT BACK
DISASSEMBLY STEPS

7.

PANEL

8.

SHELF CLIP

9.

HEAD RESTRAINT GUIDE

10. KNOB
11. GARNISH
12. RECLINING COVER
13. CONTROL CABLE
14. RECLINING ADJUSTER <LH>
15. RECLINING ADJUSTER, OUTER

<RH>

16. REAR SEATBACK COVER
17. REAR SEATBACK PAD
18. REAR SEATBACK FRAME

REAR SEAT BACK
DISASSEMBLY STEPS

REAR SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-51

AC003272

<SPLIT SEAT>

17

18

14

13

44 N·m

33 ft-lb

21

12

22

13 N·m

115 in-lb

15 16

11

23

24

10 20

44 N·m

32 ft-lb

17

23

18

24

19

44 N·m

33 ft-lb

17

18

14

13

11

25

12

7

8

9

6

12 N·m

106 in-lb

22 N·m

16 ft-lb

4

<NON-DETACHABLE TYPE>

7

8

9

6

12 N·m

106 in-lb

5

22 N·m

16 ft-lb

4

9

6

5

3

22 N·m

16 ft-lb

<DETACHABLE TYPE>

7

8

3

2

22 N·m

16 ft-lb

1

AB

5

25

10

REAR SEAT CUSHION
DISASSEMBLY STEPS

1.

BOTTOM COVER

2.

LEVER ASSEMBLY

3

BRACKET COVER

4.

HINGE

5.

BAND

6.

LOCK COVER

7.

REAR SEAT CUSHION COVER

8.

REAR SEAT CUSHION PAD

9.

LOCK BRACKET
REAR SEATBACK
DISASSEMBLY STEPS

10. PANEL
11. SHELF CLIP
12. HEAD RESTRAINT GUIDE
13. KNOB

14 GARNISH
15. HINGE BRACKET
16. BUSH
17. RECLINING COVER
18. CONTROL CABLE
19. RECLINING ADJUSTER <LH>
20. RECLINING ADJUSTER, INNER

<LH>

21. RECLINING ADJUSTER, OUTER

<RH>

22. ARMREST
23. REAR SEATBACK COVER
24. REAR SEATBACK PAD
25. REAR SEATBACK FRAME

REAR SEATBACK
DISASSEMBLY STEPS

FRONT SEAT BELT

TSB Revision

INTERIOR

52A-52

FRONT SEAT BELT

REMOVAL AND INSTALLATION

M1523001300198

AC103792

5

4

2

1

44 N·m

33 ft-lb

44 N·m

33 ft-lb

44 N·m

33 ft-lb

44 N·m

33 ft-lb

6

3

AB

7

1.

ETACS-ECU
OUTER SEAT BELT REMOVAL
STEPS

•

CENTER PILLAR TRIM, LOWER
(REFER TO

P.52A-41

.)

2.

SASH GUIDE COVER

3.

OUTER SEAT BELT

4.

CENTER PILLAR TRIM, UPPER
(REFER TO

P.52A-41

.)

5.

ADJUSTABLE SEAT BELT
ANCHOR

INNER SEAT BELT REMOVAL
STEPS

•

FRONT SEAT (REFER TO

P.52A-44

.)

6.

INNER SEAT BELT

7.

FRONT SEAT BELT EXTENSION
