SPECIFICATIONS
TSB Revision
CHASSIS ELECTRICAL
54A-239
<HEADLIGHT>
<FOG LIGHT>
SEALANT
M1543000500191
<COMBINATION METER>
Combination mete resistance
(terminal number)
Power supply and ground (67-25)
Approximately 1 M or more
Power supply and ground (67-11)
Approximately 1 M or more
IG power supply and ground (62-
25)
Approximately 1 M or more
IG power supply and ground (62-11) Approximately 1 M or more
Battery power supply and fuel gage
(67-63)
Approximately 1 M or more
IG power supply and fuel gage (62-
63)
Approximately 1 M or more
Fuel gauge and ground (63-25)
Approximately 180
Fuel gauge and ground (63-11)
Approximately 180
Battery power supply and engine
coolant temperature (67-64)
Approximately 1 M or more
IG power supply and engine coolant
temperature (62-64)
Approximately 1 M or more
Engine coolant temperature and
ground (64-25)
Approximately 210
Engine coolant temperature and
ground (64-11)
Approximately 210
ITEM
STANDARD VALUE
ITEM
STANDARD VALUE
LIMIT
Headlight aiming
(Vertical direction)
53 mm (2.1 inches) (0.4
°)
below horizontal (H)
Standard value
± 50 mm (2.0
inches) (
± 0.38°)
Headlight intensity cd (at high-beam)
-
40,000 or more {when a screen
is set 18.3 m (60 feet) ahead of
the vehicles}
ITEM
STANDARD VALUE
LIMIT
Fog light aiming
(Vertical direction)
Top of the hot zone should be
101 mm (4.0 inches) below
the fog light center (equivalent
to the fog light beam angle of
0.76
°).
Top of the hot zone should be at
most 152 mm (6.0 inches)
below the fog light center
(equivalent to the fog light beam
angle of 1.14
°).
ITEM
SPECIFIED SEALANT
REMARK
Engine coolant temperature gauge
unit threaded portion
3M
ä AAD part No. 8731, Loctite â242
or equivalent
Drying sealant
