Mitsubishi Montero (2002-2004). Manual - part 405

REAR SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-21

<RH SIDE>

AC006067

9

17

22

16

11

10

26

27

13

12

21 20

19

15

14

7

24

25

28

7

3

1

34

8

30

6

36

35

23

6

31

32

33

31

32

33

29

4

2

40

39

38

5

41

42

41

43

42

N

N

52 ± 7 N·m
39 ± 5 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

22  ± 4 N·m
16 ± 3 ft-lb

AC

18

37

REAR SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-22

DISASSEMBLY STEPS

1.

LOWER RECLINING ADJUSTER
COVER

2.

INNER SEAT BELT

3.

CENTER RECLINING ADJUSTER
COVER

4.

GAS SPRING CONNECTION

5.

SECOND SEAT CUSHION UNDER
COVER

6.

CATCH CABLE A CONNECTION

7.

CATCH CABLE A

8.

RECLINING CABLE
CONNECTION

9.

SECOND SEAT BACK ASSEMBLY

10. FOLDING LEVER KNOB
11. FOLDING KNOB GARNISH
12. SECOND SEAT SIDE BACK

ASSEMBLY

13. SECOND SEAT BACK BOARD
14. ARMREST
15. CUP HOLDER

<<A>>

16. HEAD RESTRAINT GUIDE
17. SASH ANCHOR GARNISH
18. HOG RING
19. SECOND SEATBACK FRAME
20. SECOND SEATBACK PAD
21. SECOND SEATBACK COVER

22. SEAT BELT PROTECTOR
23. CENTER SEAT BELT

CONNECTION

24. SHAFT
25. RECLINING ADJUSTER BACK

COVER

26. ROD
27. SPRING
28. RECLINING ADJUSTER
29. GAS SPRING
30. RECLINING CABLE
31. SECOND SEAT CATCH

ASSEMBLY

32. UPPER FOOT COVER
33. LOWER FOOT COVER
34. RECLINING KNOB
35. INNER SEAT BELT
36. CENTER SEAT BELT
37. HOG RING
38. SECOND SEAT CUSHION FRAME
39. SECOND SEAT CUSHION PAD
40. SECOND SEAT CUSHION COVER
41. STRIKER COVER
42. STRIKER
43. PLUG

DISASSEMBLY STEPS

REAR SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-23

CLAW POSITIONS

REMOVAL SERVICE POINTS

.

<<A>>HEAD RESTRAINT GUIDE REMOVAL

ACX00631

A

A

<LOWER RECLINING
ADJUSTER COVER>

<FOLDING KNOB GARNISH>

SECTION A -



A

SECTION B -



B

LOWER RECLINING
ADJUSTER COVER

CLAW

CLAW

CLAW

RECLINING
ADJUSTER

B

B

FOLDING KNOB
GARNISH

SECOND SEAT
BACK ASSEMBLY

AB

NOTE

: Claw position

ACX01300AB

THIRD SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-24

THIRD SEAT ASSEMBLY

DISASSEMBLY AND ASSEMBLY

M1522003000048

ACX00632

2

3

28

27

26

24

29

4

5

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

33

30

4

35

36

44 ±10 N·m
33 ± 7 ft-lb

31

31

32

34

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

52 ± 7 N·m
38 ± 5 ft-lb

7

18 17

16

14

13

12

11

20

19

22

8

9

10

23

44 ± 10 N·m
33 ± 7 ft-lb

21

6

1

AD

15

N

25

N
