INPUT SIGNAL PROCEDURES

TSB Revision

SWS INPUT SIGNAL PROCEDURES

54Bc-135

STEP 5. Check the wiring harness between rear wiper
motor connector I-07 (terminal 4) and the ignition switch
(ACC).

AC204182

CONNECTOR : I-07

AE

HARNESS SIDE

I-07(B)

I-07(B)

1

2

4 3

INPUT SIGNAL PROCEDURES

TSB Revision

SWS INPUT SIGNAL PROCEDURES

54Bc-136

NOTE: Also check intermediate connectors D-111, G-10, junc-
tion block connectors D-208 and D-217 for loose, corroded, or
damaged terminals, or terminals pushed back in the connector.
If intermediate connector D-111, G-10, junction block connector
D-208 or D-217 is damaged, Repair or replace the damaged
component(s) as described in GROUP 00E, Harness Connec-
tor Inspection

P.00E-2

.

Q: Is the wiring harness between rear wiper motor

connector I-07 (terminal 4) and the ignition switch (ACC)
in good condition?
YES : No action is necessary and testing is complete.
NO :  The wiring harness may be damaged or the

connector(s) may have loose, corroded or damaged
terminals, or terminals pushed back in the connector.
Repair the wiring harness as necessary. If the rear
wiper operates normally, it indicates that a correct
auto-stop signal is sent from the rear wiper motor.

AC204171

CONNECTOR : D-111

AC

9

8

6 7

5

3 4

20

32

21

33

43

17 18

30

41

16

29

28

39 40

13

25

12

24

35 36

14

26

37

15

27

38

19

31

42

1

10

22

2

11

23

34

AC204191

CONNECTORS : D-208, D-217

D-208

AE

HARNESS SIDE

HARNESS SIDE

D-217

D-208

D-217

1

2

3

5

6

4

8

1

11 10

3

4

12

9

2

13

14

6 5

15

7

AC204179

CONNECTOR : G-10

AD

4

10

8

7

3

9

5

1

6

2

INPUT SIGNAL PROCEDURES

TSB Revision

SWS INPUT SIGNAL PROCEDURES

54Bc-137

STEP 6. Check rear wiper motor connector I-07 and
ETACS-ECU connector D-222 for loose, corroded or
damaged terminals, or terminals pushed back in the
connector.
Q: Are rear wiper motor connector I-07 and ETACS-ECU

connector D-222 in good condition?
YES : Go to Step 7.
NO :  Repair or replace the damaged component(s). Refer

to GROUP 00E, Harness Connector Inspection

P.00E-2

. If the rear wiper operates normally, it

indicates that a correct auto-stop signal is sent from
the rear wiper motor.

AC204174

CONNECTOR : D-222

AB

1

2

3

5

6

4

9 8

121110

13

15 14

16

17

7

19

20

18

JUNCTION BLOCK SIDE

D-222

AC204182

CONNECTOR : I-07

AE

HARNESS SIDE

I-07(B)

I-07(B)

1

2

4 3

INPUT SIGNAL PROCEDURES

TSB Revision

SWS INPUT SIGNAL PROCEDURES

54Bc-138

STEP 7. Check the wiring harness between rear wiper
motor connector I-07 (terminal 3) and ETACS-ECU
connector D-222 (terminal 5).

AC204174

CONNECTOR : D-222

AB

1

2

3

5

6

4

9 8

121110

13

15 14

16

17

7

19

20

18

JUNCTION BLOCK SIDE

D-222

AC204182

CONNECTOR : I-07

AE

HARNESS SIDE

I-07(B)

I-07(B)

1

2

4 3
