VEHICLE IDENTIFICATION

TSB Revision

GENERAL <BODY AND CHASSIS>

00-17

VEHICLE INFORMATION CODE PLATE

M1001005400280

The vehicle information code plate is riveted onto the cowl top
outer panel in the engine compartment.
The plate shows model code, engine model, transmission
model and body color code.

For monotone color vehicles, the body color code shall be indi-
cated. For two-tone vehicles, each color code only shall be indi-
cated in series.

CHASSIS NUMBER

STAMPING LOCATION
The chassis number is stamped on the center of the dash
panel.

CHASSIS NUMBER CODE CHART

VEHICLE SAFETY CERTIFICATION LABEL

The vehicle safety certification label is attached to the face of
the left door sill.
This label indicates the month and year of manufacture, Gross
Vehicle Weight Rating (GVWR), front and rear Gross Axle
Weight Rating (GAWR), and Vehicle Identification Number
(VIN).

NO. ITEMS

CONTENTS

MODEL

V77WLYXV
L2M

V77W; Vehicle model

LYXVL2M; Model series

ENGINE

6G75

Engine model

EXT

A69D

Exterior code

TRANSAXL
E

V5A51
4300

V5A51; Transmission model

4300; Rear differential
reduction

COLOR,
INT OPT

A69 21T
Z08

A69; Body color code

21T; Interior code

Z08; Equipment code

ACX01697

CHASSIS
NUMBER
CODE

CONTENTS

V77W3J000001 V77W;

Vehicle line

V77W; MONTERO

3J000001; Refer to 10th thru 17th digits of
VIN plate

AC203793

AC203794

VEHICLE IDENTIFICATION

TSB Revision

GENERAL <BODY AND CHASSIS>

00-18

ENGINE MODEL STAMPING

The engine model is stamped on the cylinder block.
These engine model numbers are as shown as follows.

The engine serial number is stamped near the engine model
number.

THEFT PROTECTION

In order to protect against theft, a Vehicle Identification Number
(VIN) is attached as a plate or label to the following major parts
of the engine and transmission, as well as main outer panels:
Engine cylinder block, Transmission housing. Fender, Doors,
Liftgate, Quarter panel, Hood, Bumpers
In addition, a theft-protection label is attached to replacement
parts for the body outer panel main components, and the same
data are stamped into replacement parts for the engine and the
transmission.

CAUTION

Cautions regarding panel repairs:

1. When repainting original parts, do so after first masking

the theft-protection label. After painting, be sure to peel
off the masking tape.

2. The theft-protection label for replacement parts is cov-

ered by masking tape, so such parts can be painted as
is. The masking tape should be removed after painting
is finished.

3. The theft-protection label should not be removed from

original parts or replacement parts.

ENGINE MODEL

ENGINE DISPLACEMENT

6G75

3.8L

AC203954 AB

ACX00878 AB

THEFT PROTECTION PLATE (VIN PLATE)

FOR ENGINE

FOR TRANSMISSION

THEFT PROTECTION LABEL

FOR MAIN OUTER PANELS

[FOR ORIGINAL PARTS]

[FOR REPLACEMENT PARTS]

VEHICLE IDENTIFICATION

TSB Revision

GENERAL <BODY AND CHASSIS>

00-19

LOCATIONS

TARGET AREA (A: FOR ORIGINAL EQUIPMENT PARTS, B: FOR REPLACEMENT PARTS)

ACX01547

ENGINE

ENGINE UNDERSIDE

ACX01191

AUTOMATIC TRANSMISSION
<V4A51, V5A51>

ACX01192

FENDER

The illustration indicates left outer side.
Right side is symmetrically opposite.

ACX01193

QUARTER PANEL

The illustration indicates left outer side.
Right side is symmetrically opposite.

VEHICLE IDENTIFICATION

TSB Revision

GENERAL <BODY AND CHASSIS>

00-20

TARGET AREA (A: FOR ORIGINAL EQUIPMENT PARTS, B: FOR REPLACEMENT PARTS)

ACX01194

FRONT DOOR

The illustration indicates right outer side.
Left side is symmetrically opposite.

ACX01195

REAR DOOR

The illustration indicates right outer side.
Left side is symmetrically opposite.

ACX01196

HOOD

ACX01197 AB

BACK DOOR

AC203795

FRONT BUMPER

AC203796

REAR BUMPER
