MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE> 13A-301 STEP 2. Measure the sensor output voltage at cylinder 2, 3 (1) Do not disconnect the connector B-36. (3) Measure the voltage between terminal No. 4 and ground by backprobing. • Warming up the engine. When the engine is 2,500 r/min, the output voltage should repeat 0 to 0.8 volt alternately. (4) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 3. AK303830 1 2 3 4 AB CONNECTOR: B-36 B-36 (GR) CYLINDER 2, 3 HARNESS 1 2 4 3 AK201407AF B-36 HARNESS |
