HOW TO DIAGNOSE
TSB Revision
GENERAL <ELECTRICAL>
00E-15
3. CONTINUITY CHECK
(1) When the switch is in the "OFF" position, the self-
powered test light should illuminate or the ohmmeter
should read 0 ohm, only when the contact points of
terminals 1 and 2 are connected.
(2) When the switch is the "ON" position, the self-powered
test light should come on or the ohmmeter should read 0
ohm, only when the contact points of terminals 3 and 4
are connected.
ACX00960 AB
SELF POWER TEST
LIGHT (OR OHMMETER)
1 4
2 3
ON
OFF
ON
OFF
