TRANSAXLE ASSEMBLY TSB Revision AUTOMATIC TRANSAXLE 23A-390 REMOVAL SERVICE POINTS . <<A>> DRIVE SHAFT NUT REMOVAL CAUTION Do not apply pressure to the wheel bearing by the vehicle . <<B>> TIE ROD END CONNECTION/LOWER ARM CAUTION • Do not remove the nut from ball joint. Loosen it and use the special tool to avoid possible damage to ball joint • Hang the special tool with cord to prevent it from fall- ing. 1. Replace the self locking nut with a regular nut, because the original one is a little bit large to install the special tool. 2. Turn the bolt and knob as necessary to make the jaws of special tool MB991897 parallel, tighten the bolt by hand and 3. Tighten the bolt with a wrench to disconnect the tie rod end and remove the self locking nut. . AC102462 AC MB990767 AC208247AC CORD BOLT MB991897 NUT BALL JOINT AC106821 KNOB PARALLEL BOLT CORRECT WRONG AC |
