CHASSIS ELECTRICAL –

Rear Combination Lamp, Rear Fog Lamp

54A-40

REMOVAL AND INSTALLATION <R.H. drive vehicles>

6

8

7

3

5

4

Section B – B

Body
panel

Gronmet

3

9

9

7

7

9

B

B

6

Section A – A

Claw

Instrument
panel

1

1

2

A

A

A

A

9

2.5

±

 0.2 Nm

BX0283AL

Fog lamp switch removal steps

1. Switch panel
2. Fog lamp switch

Rear combination lamp removal
steps

D

Quarter trim removal and installation
(Refer to GROUP 52A)

3. Rear combination lamp (Stop and

back up lamp)

4. Rear combination lamp (Turn-signal

and tail lamp)

5. Rear combination lamp (Rear fog

lamp, turn-signal lamp and tail
lamp)

6. Bracket
7. Socket assembly
8. Socket
9. Bulb

CHASSIS ELECTRICAL –

Rear Combination Lamp, Rear Fog Lamp

54A-41

INSPECTION

FOG LAMP SWITCH CONTINUITY CHECK

Terminal No.

3

ILL

4

5

6

Relased

Pressed

INSPECTION

REAR FOG LAMP RELAY CONTINUITY CHECK

Battery voltage

Terminal No.

y

g

1

3

4

5

Not supplied

Supplied

Rear fog
lamp relay

CHASSIS ELECTRICAL –

High-mounted Stop Lamp and Licence Plate Lamp

54A-42

HIGH-MOUNTED STOP LAMP AND LICENCE
PLATE LAMP

REMOVAL AND INSTALLATION

1

2

3

Section A – A

Tab

A

A

4

1

4

5

6

7

8

9

10

A

A

High-mounted stop lamp removal
steps

1. High-mounted stop lamp cover
2. Socket assembly
3. Bulb
4. High-mounted stop lamp

Licence plate lamp removal steps

D

Back door trim and waterproof film
(Refer to GROUP 42.)

D

Licence plate lamp garnish (Refer to
GROUP 42 – Back Door.)

5. Licence plate lamp assembly
6. Lens
7. Packing
8. Licence plate lamp
9. Bulb

10. Socket assembly

CHASSIS ELECTRICAL –

Column Switch

54A-43

COLUMN SWITCH

REMOVAL AND INSTALLATION

Section A – A

Tab

A

4

2

A

A

A

3

B

B

B

B

1

Section B – B

Tab

1

2

1

2

Removal steps

1. Column cover, lower
2. Column cover, upper

3. Wiper and washer switch
4. Lighting switch
