TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-36

INTERIOR <WAGON>

M4020009000163

AB300630

AB

37

32

34

31

35

38

33

40

39

36

mm

1,395

1,145

1,388

1,368

1,289

1,121

1,297

1,407

1,379

1,281

AB300631

AB

31

33

35

37

39

40

38

36

52

51

34

32

Body centre point

1,041

1,136

1,100

1,016

1,108

1,064

809

683

706

856

AB300609AB

53

54

760

930

1,110

1,269

No. Standard measurement point

Hole shape Size mm

31

Front pillar positioning notch (upper)

−

−

32

Front pillar positioning notch (lower)

−

−

33

Side roof rail positioning notch (front)

−

−

34

Side sill positioning notch (front)

−

−

35

Centre pillar positioning notch (upper)

−

−

36

Centre pillar positioning notch (lower)

−

−

37

Side roof rail positioning notch (rear)

−

−

38

Side sill positioning notch (rear)

−

−

39

Quarter panel positioning notch (upper)

−

−

40

Quarter panel positioning notch (lower)

−

−

51

Centre of front seat rail mounting hole

Round

14

52

Centre of floor carpet mounting hole (Body centre point)

Round

6

53

Centre of rear shock absorber mounting hole

Round

12

54

Centre of rear end trim mounting hole

Round

8.5

AB201845

51

AE

AB200385AD

52

AB300889 AB

53

AB300890AB

54

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-37

AB301011

AC

56

55

Body centre point

57

58

59

1,283

1,283

1,279

1,290

664

678

662

660

mm

<L.H. drive
vehicles>

AB301010

AC

56

55

Body centre point

57

58

59

1,283

1,283

1,279

1,290

664

678

662

660

<R.H. drive
vehicles>

No. Standard measurement point

Hole shape Size mm

55

Instrument panel bracket centre tip (Body centre point)

−

−

56

Centre of deck crossmember mounting hole (upper)

Round

11

57

Centre of deck crossmember  mounting hole (lower)

Round

11

58

Centre of deck crossmember mounting hole (upper)

Round

11

59

Centre of deck crossmember  mounting hole (lower)

Round

11

AB200388AD

55

AB200389

56,57

AD

56

57

AB301012

58,59

AC

58

59

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-38

3-1

GROUP 3

WELDED PANEL



REPLACEMENT

CONTENTS

HEADLAMP SUPPORT . . . . . . . . . . .

3-2

FENDER SHIELD. . . . . . . . . . . . . . . .

3-4

FRONT SIDEMEMBER (PARTIAL
REPLACEMENT) . . . . . . . . . . . . . . . .

3-8

FRONT PILLAR . . . . . . . . . . . . . . . . .

3-10

CENTRE PILLAR . . . . . . . . . . . . . . . .

3-16

SIDE SILL. . . . . . . . . . . . . . . . . . . . . .

3-20

QUARTER, OUTER <SEDAN> . . . . .

3-24

QUARTER, OUTER <WAGON>  . . . .

3-28

ROOF <SEDAN> . . . . . . . . . . . . . . . .

3-31

ROOF <WAGON>  . . . . . . . . . . . . . . .

3-32

REAR FLOOR <SEDAN>  . . . . . . . . .

3-34

REAR FLOOR <WAGON> . . . . . . . . .

3-36

REAR END PANEL <SEDAN>. . . . . .

3-38

REAR END CROSSMEMBER



WAGON>  . . . . . . . . . . . . . . . . . . . . . .

3-39

QUARTER, INNER <SEDAN> . . . . . .

3-40

QUARTER, INNER <WAGON>  . . . . .

3-42

FRONT DOOR OUTER PANEL



(ADHESION TYPE). . . . . . . . . . . . . . .

3-44

FRONT DOOR OUTER PANEL



(WELDED TYPE)  . . . . . . . . . . . . . . . .

3-45

REAR DOOR OUTER PANEL



(ADHESION TYPE). . . . . . . . . . . . . . .

3-46

REAR DOOR OUTER PANEL



(WELDED TYPE)  . . . . . . . . . . . . . . . .

3-47
