TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-28

SUSPENSION INSTALLATION
DIMENSIONS <WAGON>

M4020013000315

AB300580

AB

mm

3

10

11

12

13

14

15

16

389

295

713

713

906

387

293

1,201

104

534

386

289

178

372

880

350

650

AB300581

AB

3

10

11

12

676

978

558

777

1,093

1,033

859

890

895

853

13

14

15

16

No. Standard measurement point

Hole shape Size mm

3

Centre of front  crossmember mounting hole

Round

18

10

Tip of front  crossmember mounting bolt (left)

−

−

11

Tip of front  crossmember mounting bolt (right)

−

−

12

Centre of front crossmember mounting hole

Round

11

13

Centre of trailing arm mounting position

Round

11

14

Centre of control link mounting position

−

−

15

Centre of upper arm mounting position

−

−

16

Centre of lower arm  mounting position

−

−

AB201819

3,12

AE

3

12

AB200334AC

10

AB201822AD

11

AB200336AC

13

AB300842AB

14

AB300843AB

15

AB300844AB

16

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-29

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-30

FRONT BODY <WAGON>

M4020006000153

AB300750AB

mm

18

24

25

26

17

23

19

20

21

22

Body centre point

Body centre point

1,502

576

813

951

734

540

730

318

870

873

758

872

600

894

1,091

1,390

1,340

1,437

1,040

1,508

AB300751AB

30

29

28

27

Body centre point

704

700

894

775

889

542

328

1,050

No. Standard measurement point

Hole shape Size mm

17

Centre of front bumper  mounting hole

Round

6.6

18

Centre of front end upper bar  water draining hole (Body centre point)

Round

8

19

Centre of harness mounting hole

Oblong

7

× 12

20

Centre of intercooler pipe mounting hole

Round

9

21

Centre of front fender mounting hole

Round

6.6

22

Centre of front strut mounting hole

Round

11.5

23

Front deck notch (Body centre point)

−

−

24

Centre of front fender mounting hole

Round

6.6

25

Centre of hood hinge mounting hole

Round

9

26

Corner of roof panel

−

−

27

Centre of front end cross-member outer positioning hole

Round

20

28

Centre of front bumper beam mounting hole

Round

10

29

Centre of headlamp mounting hole

Round

6.6

30

Centre of front end upper bar positioning hole (Body centre point)

Round

8

AB300752 AB

17

29

17,29

AB300753 AB

30

18

18,30

AB200346 AC

19

AB200347AC

20

AB200348AC

21

AB201830 AD

22

AB200350AC

23

AB200351AC

24,25

24

25

AB201833AD

26
