TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-32

SIDE BODY <WAGON>

M4020007000156

AB300625AB

31

32

33

34

35

36

37

38

39

40

mm

688

808

716

863

581

897

875

969

902

445

1,084

1,174

1,170

AB300624

AB

42

41

33

37

45

43

44

709

1,124

1,041

1,067

1,094

1,100

355

338

837

901

No. Standard measurement point

Hole shape Size mm

31

Front pillar positioning notch (upper)

−

−

32

Front pillar positioning notch (lower)

−

−

33

Side roof rail positioning notch (front)

−

−

34

Side sill positioning notch (front)

−

−

35

Centre pillar positioning notch (upper)

−

−

36

Centre pillar positioning notch (lower)

−

−

37

Side roof rail positioning notch (rear)

−

−

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-33

38

Side sill positioning notch (rear)

−

−

39

Quarter panel positioning notch (upper)

−

−

40

Quarter panel positioning notch (lower)

−

−

41

Centre of front door hinge mounting hole (upper)

Round

11

42

Centre of front door hinge mounting hole (lower)

Round

11

43

Centre of rear door hinge mounting hole (upper)

Round

11

44

Centre of rear door hinge mounting hole (lower)

Round

11

45

Centre of rear door switch mounting hole

Round

5

AB201836AD

32

42

32,42

AB202191AD

36

44

36,44

AB201838

AD

40

45

40,45

No. Standard measurement point

Hole shape Size mm

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-34

REAR BODY <WAGON>

M4020008000160

AB300589AB

47

48

46

49

50

mm

361

562

700

668

750

880

703

896

1,020

1,079

1,213

1,169

1,205

No. Standard measurement point

Hole shape Size mm

46

Centre of tailgate hinge mounting hole

Round

12

47

Centre of tailgate gas spring mounting hole

Round

11

48

Centre of tailgate striker mounting hole

Round

13

49

Centre of rear bumper mounting hole

Oblong

11

× 12

50

Centre of rear end crossmember positioning hole

Round

16

AB200377AC

46

AB300888AB

47

AB300590AB

48

AB300608AB

49,50

49

50

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-35
