Mitsubishi Evolution X. Manual - part 507





DOOR

TSB Revision

BODY

42A-131

Required Special Tool:

• T-type Long Torx Wrench (T30)

AC711190

AC607394

1

4

5

6

7

8

10

11

12

13

14

16

N

AB

<Rear door>

25 ± 4 N·m
19 ± 3 ft-lb

7.0 ± 2.0 N·m
43 ± 17 in-lb

4.0 ± 2.0 N·m
35 ± 17 in-lb

4.0 ± 2.0 N·m
35 ± 17 in-lb

5.0 ± 1.0 N·m
44 ± 9 in-lb

5.0 ± 1.0 N·m
44 ± 9 in-lb

3

9

15

2

15

AC605594

1

8

AF

Door inside handle removal
steps

>>B<<

1.

Door inside handle

2.

Clip

3.

Grommet
Door outside handle removal
steps

4.

Plug

<<A>>

>>C<<

5.

Door outside handle cover

6.

Door outside handle

7.

Door outside handle gasket

8.

Door outside handle base

9.

Clip

Door latch assembly removal
steps

>>B<<

1.

Door inside handle

10. Screw
11. Door latch assembly
12. Door inside lock cable
13. Door inside handle cable
14. Door outside handle rod
15. Clip

Door check removal steps

Rear door speaker (Refer to
GROUP 54A, Speaker

P.54A-575

.)

>>A<<

16. Door check

DOOR

TSB Revision

BODY

42A-132

REMOVAL SERVICE POINT

.

<<A>> DOOR OUTSIDE HANDLE COVER
REMOVAL

Prepare a tool as shown to remove the door outside handle
cover.

INSTALLATION SERVICE POINTS

.

>>A<< DOOR CHECK INSTALLATION

Install the door check with the following identification marks fac-
ing upward.

.

>>B<< DOOR INSIDE HANDLE INSTALLATION

When connecting the inside cable to the door inside handle,
ensure that the door latch and the inside handle are locked.

.

>>C<< DOOR OUTSIDE HANDLE BASE
INSTALLATION

Prepare a tool as shown, and tighten it to the specified torque.

Tightening torque: 4.0

± 2.0 N⋅ m (35 ± 17 in-lb)

AC608854

AC609541AB

Equal to or more than

40mm (1.6 inch).

Applicable location

Identification
mark

Front door

Left door

55L

Right door 55R

Rear door

Left door

64L

Right door 64R

AC605596AC

Identification mark

AC608854

AC609541AB

Equal to or more than

40mm (1.6 inch).

DOOR

TSB Revision

BODY

42A-133

INSPECTION

M1423004701265

FRONT DOOR LOCK ACTUATOR CHECK

ACTUATOR OPERATION CHECK

ACTUATOR SWITCH CHECK <DRIVER'S SIDE>

ACTUATOR SWITCH CHECK <PASSENGER'S SIDE (VEHI-
CLES WITH KOS)>

Lever
position

Battery
connection

Lever
operation

At the
"LOCK"
position

• Connect

terminal No.4 to
the negative
battery terminal.

• Connect

terminal No.6 to
the positive
battery terminal.

The lever moves
from the "LOCK"
position to the
"UNLOCK"
position.

At the
"UNLOCK"
position

• Connect

terminal No.6 to
the negative
battery terminal.

• Connect

terminal No.4 to
the positive
battery terminal.

The lever moves
from the
"UNLOCK"
position to the
"LOCK"
position.

Lever position Terminal

number

Normal value

UNLOCK

− 3

Continuity exists
(2

Ω or less)

Lever position Terminal

number

Normal value

UNLOCK

− 3

Continuity exists
(2

Ω or less)

4

2
5

3
6

1

4

2
5

3
6

1

AC208145

B

A

AC

Lever

UNLOCK

<Front left side>

<Front right side>

LOCK

View A

Lever

UNLOCK

LOCK

View B

DOOR

TSB Revision

BODY

42A-134

REAR DOOR LOCK ACTUATOR CHECK

ACTUATOR OPERATION CHECK

CENTRAL DOOR LOCK SWITCH CONTINUITY
CHECK

Remove the power window switch (Refer to

P.42A-124

).

<DRIVER'S SIDE>

<PASSENGER'S SIDE>

Lever
position

Battery
connection

Lever
operation

At the
"LOCK"
position

• Connect

terminal No.4 to
the negative
battery terminal.

• Connect

terminal No.6 to
the positive
battery terminal.

The lever moves
from the "LOCK"
position to the
"UNLOCK"
position.

At the
"UNLOCK"
position

• Connect

terminal No.6 to
the negative
battery terminal.

• Connect

terminal No.4 to
the positive
battery terminal.

The lever moves
from the
"UNLOCK"
position to the
"LOCK"
position.

4

2
5

3
6

1

AC208587

4

2
5

3
6

1

B

A

AC

Lever

UNLOCK

LOCK

Lever

UNLOCK

LOCK

<Rear left side>

<Rear right side>

View A

View B

Switch
position

Tester
connection

Specified
condition

LOCK

14

− Ground

Continuity exists
(2

Ω or less)

UNLOCK

13

− Ground

Continuity exists
(2

Ω or less)

Switch
position

Tester
connection

Specified
condition

LOCK

− 4

Continuity exists
(2

Ω or less)

UNLOCK

− 4

Continuity exists
(2

Ω or less)

AC609544

ZC600611

Door lock switch

AB

AC609543

ZC600610

Door lock switch

AB
