TYPE A (PROJECTED DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-7

NOTES

TYPE A (PROJECTED DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-8

SUSPENSION INSTALLATION DIMENSIONS

M4020013001783

AB700578

AB

4

5

9

15

16

17

14

18

20

19

Center line of the vehicle

  903

(35.6)

  894

(35.2)

  886

(34.9)

mm (in)

1,138

(44.8)

  510

(20.1)

  787

(31.0)

  875

(34.4)

  910

(35.8)

1,132

(44.6)

1,298

(51.1)

1,000

(39.4)

1,004

(39.5)

  328

(12.9)

  441

(17.4)

  84

(3.3)

  331

(13.0)

  293

(11.5)

 217

(8.5)

  760

(29.9)

  480

(18.9)

  768

(30.2)

  529

(20.8)

AB700579

AB

4

5

9

15

16

17

14

18

20

19

Center line of the vehicle

1,187

(46.7)

1,048

(41.3)

  945

(37.2)

  907

(35.7)

1,028

(40.5)

1,230

(48.4)

1,272

(50.1)

1,200

(47.2)

1,117

(44.0)

1,116

(43.9)

1,323

(52.1)

No. Standard measurement point

Hole shape

Size mm (in)

4

Center of front axle crossmember mounting hole (front)

Round

15.5 (0.61)

5

Center of front sidemember rear water draining hole

Round

16 (0.63)

9

Center of front floor sidemember positioning hole (rear)

Round

16 (0.63)

14

Center of front shock absorber mounting hole

Round

80 (3.15)

15

Center of front axle crossmember mounting hole (rear)

Round

15.5 (0.61)

16

Center of trailing arm mounting hole (outer side)

Round

15.5 (0.61)

17

Center of trailing arm mounting hole (inner side)

Round

15.5 (0.61)

18

Center of rear suspension crossmember mounting hole (front)

Round

15 (0.59)

19

Center of rear shock absorber mounting hole

Round

70.8 (2.79)

20

Center of rear suspension crossmember mounting hole (rear)

Round

15 (0.59)

TYPE A (PROJECTED DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-9

NOTE: The assumed standard line is established 100 mm (3.9in) below the measurement point No.5.

AB700848

A

6˚54´

B

15˚34´

3˚06´

0˚

AB

A

B

4

5

9

15

16

17

14

18

20

19

1,087

(42.8)

  540

(21.3)

 100

(3.9)

mm (in)

Vehicle center

Vehicle center

  767

(30.2)

  294

(11.6)

  510

(20.1)

  284

(11.2)

  354

(13.9)

 162

(6.4)

 217

(8.5)

 105

(4.1)

1,223

(48.1)

1,066

(42.0)

  464

(18.3)

  489

(19.3)

  785

(30.9)

 187

(7.4)

 187

(7.4)

  683

(26.9)

Standard line

AB700472

4

AB

AB700479

5, 15

AB

15

5

AB601180

9

AB

AB700478AB

14

AB700480

16, 17

16

17

AB

AB700481

18, 20

20

18

AB

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-10

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

UNDER BODY

M4020005002167

AB700482AB

19

AB700576

1

2

3

4

6

5

7

9

10

11

12

13

8

AB

  967

(38.1)

  960

(37.8)

  542

(21.3)

  546

(21.5)

1,079

(42.5)

  910

(35.8)

  875

(34.4)

  894

(35.2)

  877

(34.5)

  990

(39.0)

  487

(19.2)

1,262

(49.7)

  567

(22.3)

  378

(14.9)

  350

(13.8)

  644

(25.4)

mm (in)

1,022

(40.2)

  545

(21.5)

  399

(15.7)

  460

(18.1)

  894

(35.2)

 101

(4.0)

 102

(4.0)

  616

(24.3)

  616

(24.3)

 222

(8.7)

  348

(13.7)

  669

(26.3)

  740

(29.1)

  856

(33.7)

  932

(36.7)

AB700577

1

2

3

4

6

5

7

9

10

11

12

13

8

AB

  566

(22.3)

  960

(37.8)

  971

(38.2)

  966

(38.0)

1,415

(55.7)

1,118

(44.0)

1,046

(41.2)

1,124

(44.3)

1,225

(48.2)

1,027

(40.4)

1,080

(42.5)

1,371

(54.0)

1,255

(49.4)

1,209

(47.6)

1,357

(53.4)

1,120

(44.1)

1,081

(42.6)

  765

(30.1)

  643

(25.3)

1,138

(44.8)

  704

(27.7)
