BODY DIMENSIONS AND MEASUREMENT METHODS

TSB Revision

BODY DIMENSIONS

2-3

NOTES

TYPE A (PROJECTED DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-4

TYPE A (PROJECTED DIMENSIONS)

 UNDER BODY

M4020005002156

AB700574

1

2

3

4

6

5

7

9

10

11

12

13

8

AB

  967

(38.1)

  960

(37.8)

mm (in)

  616

(24.3)

  616

(24.3)

  910

(35.8)

  510

(20.1)

  540

(21.3)

1,050

(41.3)

  875

(34.4)   564

(22.2)

  624

(24.6)

  462

(18.2)

  375

(14.8)

 197

(7.8)

  894

(35.2)

  894

(35.2)

  350

(13.8)

  667

(26.3)

1,262

(49.7)

  877

(34.5)

  990

(39.0)

1,022

(40.2)

  718

(28.3)

  833

(32.8)

  929

(36.6)

  545

(21.5)

  393

(15.5)

  440

(17.3)

  344

(13.5)

Center line of the vehicle

 76

(3.0)

 76

(3.0)

AB700575

1

2

3

4

6

5

7

9

10

11

12

13

8

AB

Center line of the vehicle

  544

(21.4)

  960

(37.8)

  969

(38.1)

  964

(38.0)

1,394

(54.9)

1,117

(44.0)

1,028

(40.5)

1,124

(44.3)

1,138

(44.8)

1,218

(48.0)

1,025

(40.4)

1,080

(42.5)

1,369

(53.9)

1,254

(49.4)

1,195

(47.0)

1,342

(52.8)

1,120

(44.1)

1,079

(42.5)

  763

(30.0)

  641

(25.2)

  686

(27.0)

No. Standard measurement point

Hole shape

Size mm (in)

1

Center of front end crossmember lower water draining hole (left side)

Round

8 (0.31)

2

Center of front end crossmember lower water draining hole (right side) Round

8 (0.31)

3*

Center of front sidemember inner positioning hole

Round

25 (0.98)

4*

Center of front axle crossmember mounting hole (front)

Round

15.5 (0.61)

5*

Center of front sidemember rear water draining hole

Round

16 (0.63)

6

Center of propeller shaft mounting hole (left side)

Round

11 (0.43)

7

Center of propeller shaft mounting hole (right side)

Round

11 (0.43)

8*

Center of front floor sidemember positioning hole (front)

Round

16 (0.63)

TYPE A (PROJECTED DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-5

NOTE: The * mark indicates the mounting position for the frame centering gauge.

NOTE: The assumed standard line is established 100 mm (3.9in) below the measurement point No.5.

9*

Center of front floor sidemember positioning hole (rear)

Round

16 (0.63)

10* Center of rear floor sidemember lower positioning hole (front)

Oblong

33.9

×18

(1.335

×0.71)

11*

Center of rear suspension bracket front water draining hole

Round

16 (0.63)

12* Center of rear floor sidemember lower positioning hole (rear)

Round

25 (0.98)

13* Center of rear floor sidemember extension water draining hole (left

side), Center of rear shipping bracket mounting hole (right side)

Round

14 (0.55)

No. Standard measurement point

Hole shape

Size mm (in)

AB700418

AB

5

3

4

6

7

8

9

10

12

11

13

1

2

mm (in)

 105

(4.1)

 100

(3.9)

 157

(6.2)  105

(4.1)

 230

(9.1)

 154

(6.1)

  347

(13.7)

  354

(13.9)

  357

(14.1)

1,125

(44.3)

1,049

(41.3)

  286

(11.3)

  259

(10.2)

  510

(20.1)

  716

(28.2)

  486

(19.1)

Standard line

  280

(11.0)

  294

(11.6)

  350

(13.8)

1,644

(64.7)

1,101

(43.3)

  715

(28.1)

  291

(11.5)

AB700470

1, 3

1

3

AB

AB700471

2

AB

AB700472

4

AB

AB700473

5

AB

AB600999

6, 7

AB

6

7

AB601000

8, 9

AB

8

9

TYPE A (PROJECTED DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-6

AB700474AB

10

AB700475AB

11, 12

12

11

AB700973AB

13
