REAR SUSPENSION -
Stabilizer Bar
34-21
2. Apply multipurpose grease to the inside of the dust cover.
3. Wrap plastic tape around the stabilizer link stud, and
then install the dust cover to the stabilizer link.
4. Secure the dust cover by the clip ring. Then install the
clip ring end in order to position on 90 degrees toward
the axis of the link.
5. Check the dust cover for cracks or damage by pushing
it with finger.
90_
Clip ring end
(possible on opposite direction)
