REAR SUSPENSION - Stabilizer Bar 34-21 2. Apply multipurpose grease to the inside of the dust cover. 3. Wrap plastic tape around the stabilizer link stud, and then install the dust cover to the stabilizer link. 4. Secure the dust cover by the clip ring. Then install the clip ring end in order to position on 90 degrees toward the axis of the link. 5. Check the dust cover for cracks or damage by pushing it with finger. 90_ Clip ring end (possible on opposite direction) |
