HOW TO READ WIRING DIAGRAMS GENERAL <ELECTRICAL> 00E-3 HOW TO READ CONFIGURATION M1001006400090 The wiring harness diagrams clearly show the connector locations and harness routings at each site on AC208446 Denotes connector No. Example: A-19 Number specific to connector (serial number) Connector location site symbol D: Door E: Tailgate Denotes earth point. Denotes the colour of the corrugated The number of connector pins and the connector colour Example: (2-B) Connector colour Number of connector pins *: Typical connector colours BR: Brown Y: Yellow V: Violet L: Blue O: Orange G: Green GR: Grey R: Red None: Milk white A-15 (2) Fog lamp (RH) Indicates the device to which the The mark shows the AH A-17 A-16 A-15 A-18 A-19 Y Denotes a section covered by a Front Denotes harness name. 1 Main Index Group TOC |
