Mitsubishi 380. Manual - part 278





DOOR

BODY

42-44

NOTE: *: Set the window lock switch to UNLOCK position.

.

Sub switch <Front>

Sub switch <Rear>

REAR (RH)

UP

− 10, 6 − 2*

Less than 2 ohms

OFF

− 6, 4 − 2*, 6 − 2* Less than 2 ohms

DOWN 6

− 10, 4 − 2*

Less than 2 ohms

REAR (RH)

UP

− 10, 3 − 2*

Less than 2 ohms

OFF

− 1, 3 − 2*, 2* − 1 Less than 2 ohms

DOWN 3

− 10, 2* − 1

Less than 2 ohms

SWITCH POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

UP

− 5, 6 − 7

Less than 2 ohms

OFF

− 5, 7 − 8

Less than 2 ohms

DOWN

− 6, 7 − 8

Less than 2 ohms

SWITCH POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

UP

− 5, 6 − 7

Less than 2 ohms

OFF

− 5, 7 − 8

Less than 2 ohms

DOWN

− 6, 7 − 8

Less than 2 ohms

SWITCH POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

AC210746

8

3

4 5

1

2

6 7

AD

<FRONT>

AC210747

8

3

1
4 5 6

2
7

AB

<REAR>

DOOR

BODY

42-45

DOOR WINDOW REGULATOR CHECK

.

1. Connect a battery directly to the motor terminals and check

that the motor runs smoothly.

2. Check that the motor runs in the opposite direction when the

battery is connected with the polarity reversed.

3. If a defect is found, replace the window regulator as an

assembly.

.

<Front door>

.

<Rear door>

BATTERY CONNECTION

SLIDER POSITION

• Connect terminal No. 1

and the negative battery
terminal.

• Connect terminal No. 2

and the positive battery
terminal.

UP

• Connect terminal No. 2

and the negative battery
terminal.

• Connect terminal No. 1

and the positive battery
terminal.

DOWN

BATTERY CONNECTION

SLIDER POSITION

• Connect terminal No. 1

and the negative battery
terminal.

• Connect terminal No. 2

and the positive battery
terminal.

UP

• Connect terminal No. 2

and the negative battery
terminal.

• Connect terminal No. 1

and the positive battery
terminal.

DOWN

1 2

AC204901AB

1 2

AC206013AB

DOOR

BODY

42-46

DOOR HANDLE AND LATCH

REMOVAL AND INSTALLATION

M1423004600340

Pre-removal Operation
• Door Trim Assembly Removal (Refer to GROUP 52A

Door Trim

P.52A-14

).

Post-installation Operation
• Door Inside Handle Play Check (Refer to

P.42-35

).

• Door Outside Handle Play Check (Refer to

P.42-35

).

• Door Trim Assembly Installation (Refer to GROUP 52A,

Door Trim

P.52A-14

).

18DB161A

1

2

3

4

5

8

6

7

9

5.0 ± 1.0 N·m

44 ± 9 in-lb

5.9 ± 1.0 N·m

52 ± 9 in-lb

5.0 ± 1.0 N·m

44 ± 9 in-lb

<FRONT DOOR>

N

AC306499

AC306729

AC209702

AB

1

7

DOOR HANDLE AND DOOR LATCH
ASSEMBLY REMOVAL STEPS

1. DOOR INSIDE HANDLE

WATERPROOF FILM (REFER TO

P.42-52

).

>>B<<

2. LOWER SASH
3. DOOR LATCH ASSEMBLY

4. INSIDE LOCK CABLE
5. INSIDE HANDLE CABLE
6. DOOR OUTSIDE HANDLE

MOUNTING BOLT

DOOR HANDLE AND DOOR LATCH
ASSEMBLY REMOVAL STEPS

DOOR

BODY

42-47

Required Special Tool:

• MB991223: Harness Set

Required Special Tool:

• MB991223: Harness Set

<<A>>

7. DOOR LOCK KEY CYLINDER

ASSEMBLY (LH)

8. DOOR OUTSIDE HANDLE

DOOR HANDLE AND DOOR LATCH
ASSEMBLY REMOVAL STEPS

DOOR CHECK REMOVAL

>>A<<

9. DOOR CHECK

AC306166

1

2

3

4

5

6

7

5.0 ± 1.0 N·m
44 ± 9 in-lb

5.9 ± 1.0 N·m
52 ± 9 in-lb

5.0 ± 1.0 N·m
44 ± 9 in-lb

AB

N

<REAR DOOR>

AC306499

AC306729

AC209702

AB

1

7

DOOR HANDLE AND DOOR LATCH
ASSEMBLY REMOVAL STEPS

1. DOOR INSIDE HANDLE

WATERPROOF FILM (REFER TO

P.42-52

).

>>B<<

2. LOWER SASH
3. DOOR LATCH ASSEMBLY
4. INSIDE LOCK CABLE

5. INSIDE HANDLE CABLE
6. DOOR OUTSIDE HANDLE

DOOR CHECK REMOVAL

>>A<<

7. DOOR CHECK

DOOR HANDLE AND DOOR LATCH
ASSEMBLY REMOVAL STEPS
