Mitsubishi Grandis. Manual - part 678





DOOR

BODY

42-40

<RH DRIVER VEHICLES>

WINDOW GLASS RUNCHANNEL AND
DOOR OPENING WEATHERSTRIP

REMOVAL AND INSTALLATION

M1423003100438

Switch
position

Tester
connection

Specified
condition

LOCK

− 3

Less than 2
ohms

UNLOCK

− 3

Less than 2
ohms

AC302823

AC310969

AC302817

AC303077

AB

1

2

3

4

5

6

8

7

7

A

A

Note
        : The convex position of the door

3

Section A – A

Door

<Front door>

Sealant: 3M ATD Part No. 8633
or equivalent

AC302864

AC302865

AC302866

AC303042 AB

:Sectional view of clip position

:Sectional view of clip position

:Sectional view of clip position

DOOR

BODY

42-41

DOUBLE-SIDED TAPE POSITION

Waterproof film removal steps

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-12

).

1.

Pull handle bracket

2.

Armrest bracket (Passenger’s side)

Speaker (Refer to GROUP 54A,
Speaker

P.54A-139

).

>>A<<

3.

Waterproof film
Door opening weatherstrip inner
removal steps

Cowl side trim and scuff plate
(Refer to GROUP 52A, Interior Trim

P.52A-10

).

4.

Door opening weatherstrip inner
Door opening weatherstrip outer
removal steps

Door check mounting bolt (Body
side) (Refer to

P.42-36

).

<<A>>

>>B<<

5.

Door opening weatherstrip outer

Door beltline weatherstrip inner
removal steps

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-12

).

6.

Door beltline weatherstrip inner
Door beltline moulding removal
steps

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-12

).

Door mirror assembly (Refer to
GROUP 51, Door Mirror

P.51-46

).

7.

Door beltline moulding
Door window glass runchannel
removal steps

>>A<<

2.

Waterproof film

Door window glass (Refer to

P.42-33

).

8.

Door window glass runchannel

AC311386

AC311024

AC311025

AC311026

AC311027

25 mm

Section A – A

Section B – B

Door opening weatherstrip outer

Door opening
weatherstrip outer

Door opening
weatherstrip outer

A

A

AB

B

B

Adhesive tape: Double-sided tape  5 mm width, 45 mm length and 0.5 mm thickness

<Front door>

DOOR

BODY

42-42

AC302824

AC310970

AC303077

AC302818

AB

1

2

2

6

8

3

7

9

8

5

A

A

Section A – A

Door

<Rear door>

4

Note
        : The convex position of the door

Sealant: 3M ATD Part No. 8633
or equivalent

AC302864

AC302865

AC303043

AC302867

AC302868

AB

:Sectional view of clip position

:Sectional view of clip position

:Sectional view of clip position

:Sectional view of clip position

DOOR

BODY

42-43

Waterproof film removal steps

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-12

).

1.

Pull handle bracket

Speaker (Refer to GROUP 54A,
Speaker

P.54A-139

).

>>A<<

2.

Waterproof film
Door opening weatherstrip inner
removal steps

Scuff plate (Refer to GROUP 52A,
Interior Trim

P.52A-10

).

3.

Door opening weatherstrip inner
Door opening weatherstrip outer
removal steps

Door check mounting bolt (Body
side) (Refer to

P.42-36

).

4.

Weatherstrip retainer

<<A>>

>>B<<

5.

Door opening weatherstrip outer
Door opening weatherstrip lower
removal

<<A>>

6.

Door opening weatherstrip lower
Door beltline weatherstrip inner
removal steps

Door trim assembly (Refer to
GROUP 52A, Door Trim

P.52A-12

).

7.

Door beltline weatherstrip inner
Door beltline moulding removal

8.

Door beltline moulding
Door window glass runchannel
removal

9.

Door window glass runchannel

Door opening weatherstrip outer
removal steps (Continued)
