Mitsubishi L200. Manual - part 900





INSTRUMENT PANEL

CONFIGURATION DIAGRAMS

80-10

INSTRUMENT PANEL

INSTRUMENT PANEL <LHD>

M1801000702448

ACB01794

C-22

C-47

C-09

C-51

C-60

C-32

C-54

C-33

C-29

11

C-24

C-07

C-38

Floor
wiring
harness

Frame
wiring
harness

Roof wiring
harness

C-30

C-12

C-20

C-19

C-06
C-44

C-05
C-43

C-21
C-45

C-23
C-46

C-10

Connector
symbol

-01
thru
-60

C

AB

C-52

C-53

C-15

C-16

C-02

C-41

C-01

Instrument panel
wiring harness

Floor
wiring
harness

C-40

C-03

C-28

C-27

C-48

C-25

C-50

10

9

Y

7

C-13

Control wiring
harness

C-39

C-49

8

C-08

C-58

Connector colour
code
B: Black
BR: Brown
G: Green
GR: Grey
L: Blue
None: Milk white
O: Orange
R: Red
V: Violet
Y: Yellow

C-59

C-01

(22-L)

J/C (CAN2)

C-02

(2-R)

Passenger’s (front) air bag module
(squib)

C-03

(2)

Glove box lamp

C-05

(12)

A/C switch module <Heater, manual
A/C>

C-06

(6)

Blower switch <Heater, manual A/
C>

C-07

(4)

Hazard warning switch

C-08

(12-B)

J/C (8)

C-09

(22-GR) J/C (7)

C-10

(12-GR) J/C (9)

C-12

(16)

A/T-ECU

C-13

(18)

Instrument panel wiring harness
and front wiring harness
combination

C-15

(20)

Instrument panel wiring harness
and floor wiring harness
combination

C-16

(20)

Instrument panel wiring harness
and floor wiring harness
combination

C-19

(26)

A/T-ECU

C-20

(22)

A/T-ECU

C-21

(6)

A/C evaporator air outlet thermistor
<Manual A/C>

C-22

(16-B)

Diagnosis connector

C-23

(4)

A/C temperature control resister
<Heater, manual A/C>

C-24

(2)

Down lamp

C-25

(2)

Cigarette lighter

C-27

(10)

4WD indicator-ECU

C-28

(2)

Blower motor

C-29

(20)

Frame wiring harness and front
wiring harness combination

C-30

(16)

Instrument panel wiring harness
and frame wiring harness
combination

C-32

(12-GR) J/C (6)

C-33

(14)

Instrument panel wiring harness
and front wiring harness
combination

C-38

(6-B)

Mode selection damper control
motor and potentiometer
<Automatic A/C>

C-39

(6-Y)

Passenger’s air bag cut off switch

C-40

(4)

Outside/ inside air selection damper
control motor <Automatic A/C>

C-41

(2)

No connection

C-43

(22)

A/C-ECU <Automatic A/C>

C-44

(14)

A/C-ECU <Automatic A/C>

C-45

(2)

Air thermo sensor <Automatic A/C>

C-46

(3)

Power transistor <Automatic A/C>

C-47

(1)

Parking brake switch <Stick type>

C-48

(2)

Interior temperature sensor
<Automatic A/C>

C-49

(6-B)

Air mixing damper control motor
and potentiometer <Automatic A/C>

C-50

(6)

Heated seat switch (RH)

C-51

(6)

Heated seat switch (LH)

C-52

(16)

Instrument panel wiring harness
and control wiring harness
combination

C-53

(24)

Instrument panel wiring harness
and control wiring harness
combination

C-54

(16)

Instrument panel wiring harness
and front wiring harness
combination

C-58

(16)

Instrument panel wiring harness
and floor wiring harness
combination

INSTRUMENT PANEL

CONFIGURATION DIAGRAMS

80-11

INSTRUMENT PANEL <LHD> (CONTINUED)

ACB01364

C-125

C-115

C-130

C-137

C-117

C-120

C-133

11

C-131

C-126

Floor
wiring
harness

Roof wiring
harness

C-134

C-114

C-141

C-147

C-171

C-138

C-113

C-112

Connector
symbol

-103
thru
-174

C

C-111

C-139
C-140

C-118

C-146

C-129
C-172

C-143

Frame
wiring
harness

C-107

AB

C-105

C-119

C-122

C-121

C-135

Instrument panel
wiring harness

Floor
wiring
harness

C-148

C-123

C-145

C-149

C-150

C-127

C-128
C-144

10

9

Y

7

C-103

Control wiring
harness

8

<Vehicles with side-airbag>

Floor wiring
harness

Instrument panel
wiring harness

C-127

C-155

C-154

C-153

C-128
C-144

C-129
C-172

C-132

C-157

Connector colour
code
B: Black
BR: Brown
G: Green
GR: Grey
L: Blue
None: Milk white
O: Orange
R: Red
V: Violet
Y: Yellow

C-156

C-152

C-167 C-168

C-169 C-170

C-166

C-173
C-174

C-59

(20)

Instrument panel wiring harness
and floor wiring harness
combination

C-60

(1)

Roof antenna <Vehicles with
MMCS>

C-103 (58-B)

Engine-ECU

C-105 (96-B)

Engine-ECU

C-107 (1-B)

Radio or spare connector (for audio
system)

C-111 (14)

Combination meter

C-112 (12)

Combination meter

C-113 (24)

Combination meter

C-114 (4)

Stop lamp switch

C-115 (6-B)

Accelerator pedal position sensor

C-117 (10)

Instrument panel wiring harness
and roof wiring harness
combination

C-118 (10)

Remote controlled mirror switch

C-119 (22-GR) J/C (CAN1)
C-120 (12-L)

J/C (1)

C-121 (20)

Instrument panel wiring harness
and front door wiring harness (RH)
combination

C-122 (16)

Instrument panel wiring harness
and front door wiring harness (RH)
combination

C-123 (4-Y)

Instrument panel wiring harness
and floor wiring harness
combination

C-125 (14)

Radio and CD player or spare
connector (for audio system)

C-126 (22)

Radio and CD player or spare
connector (for audio system)

C-127 (22-GR) J/C (2)
C-128 (3-B)

G-sensor <ABS>

C-129 (8)

Overdrive switch <4A/T>

C-130 (22-Y)

SRS-ECU <Vehicles without side-
airbag>

C-131 (20-Y)

SRS-ECU <Vehicles without side-
airbag>

C-132 (22-GR) J/C (5)
C-133 (20)

Instrument panel wiring harness
and front door wiring harness (LH)
combination

C-134 (16)

Instrument panel wiring harness
and front door wiring harness (LH)
combination

C-135 (3)

Passenger’s air bag cut off indicator
lamp

C-137 (22-L)

J/C (3)

C-138 (22-L)

J/C (3)

C-139 (6)

Rear differential lock switch

C-140 (6)

ASC switch

C-141 (6-GR)

Headlamp levelling switch

C-143 (1)

Roof antenna <Vehicles without
MMCS>

C-144 (4-GR)

G and yaw rate sensor <ASTC>

C-145 (10-B)

Rear differential lock-ECU

C-146 (3)

Spare connector (for trailer)

C-147 (4)

Spare connector (for trailer)

C-148 (4)

Control wiring harness and PTC
heater wiring harness combination

C-149 (2-GR)

PTC heater

C-150 (2-GR)

PTC heater

C-152 (2)

Clutch switch <Cruise control
system-M/T>

INSTRUMENT PANEL

CONFIGURATION DIAGRAMS

80-12

C-153 (16-Y)

SRS-ECU <Vehicles with side-
airbag>

C-154 (23-Y)

SRS-ECU <Vehicles with side-
airbag>

C-155 (16-Y)

SRS-ECU <Vehicles with side-
airbag>

C-156 (4-Y)

Instrument panel wiring harness
and floor wiring harness
combination <Vehicles with side-
airbag>

C-157 (4-Y)

Instrument panel wiring harness
and roof wiring harness
combination

C-166 (8)

Rear panel power window switch

C-167 (32-GR) Multivision display <Vehicles with

MMCS>

C-168 (7-G)

Multivision display <Vehicles with
MMCS>

C-169 (5-GR)

Multivision display <Vehicles with
MMCS>

C-170 (17-GR) Multivision display <Vehicles with

MMCS>

C-171 (28-GR) RV meter
C-172 (8)

Shift switch assembly <5A/T>

C-173 (28)

Hands free-ECU

C-174 (28)

USB box

INSTRUMENT PANEL

CONFIGURATION DIAGRAMS

80-13

INSTRUMENT PANEL <LHD> (CONTINUED)

AC508841

Connector
symbol

-201
thru
-221

C

C-207

C-208

C-209

C-210

C-211

C-213

C-215

C-218

C-201

C-219

C-206

<J/B>

C-220

AC

C-205

C-212

C-221

C-203

C-214

C-202

C-216

C-217

C-201 (4)

Blower relay

C-202 (4)

Accessory socket relay

C-203 (4)

Heated seat relay

C-205 (4)

No connection

C-206 (4)

Roof wiring harness and J/B
combination

C-207 (6)

Instrument panel wiring harness and
J/B combination

C-208 (14)

Instrument panel wiring harness and
J/B combination

C-209 (8)

Instrument panel wiring harness and
J/B combination

C-210 (13)

Front wiring harness and J/B
combination

C-211 (10)

Front wiring harness and J/B
combination

C-212 (4)

Floor wiring harness and J/B
combination

C-213 (1)

Front wiring harness and J/B
combination

C-214 (4)

No connection

C-215 (4)

Rear fog lamp relay

C-216 (4)

No connection

C-217 (4)

Rear window defogger relay

C-218 (20)

ETACS-ECU

C-219 (24-GR) ETACS-ECU
C-220 (24)

ETACS-ECU

C-221 (10)

Frame wiring harness and J/B
combination
