BASIC SYSTEM

07–11–1

07–11

07–11

BASIC SYSTEM

BASIC SYSTEM STRUCTURAL

VIEW  . . . . . . . . . . . . . . . . . . . . . . . . . . .  07–11–1

BASIC SYSTEM FLOW DIAGRAM . . . . .  07–11–2
AIR DIST UNIT CONSTRUCTION  . . . . .  07–11–3

Airflow Mode Door Operation. . . . . . . .  07–11–3
Airflow Distribution . . . . . . . . . . . . . . . .  07–11–4

A/C UNIT

CONSTRUCTION/OPERATION  . . . . . .  07–11–4

Construction  . . . . . . . . . . . . . . . . . . . . . 07–11–4
Air Mix Damper Operation. . . . . . . . . . . 07–11–4

A/C COMPRESSOR

CONSTRUCTION . . . . . . . . . . . . . . . . . . 07–11–5

CONDENSER CONSTRUCTION . . . . . . . 07–11–5
REFRIGERANT LINES

CONSTRUCTION . . . . . . . . . . . . . . . . . . 07–11–6

End of Toc

BASIC SYSTEM STRUCTURAL VIEW

E5U071100000N02

End Of Sie

A/C UNIT

AIR DIST UNIT

HEATER HOSE

REFRIGERANT
LINES

CONDENSER

A/C COMPRESSOR

AIRFLOW
MODE MAIN
LINK

E5U711ZS5101

BASIC SYSTEM

07–11–2

BASIC SYSTEM FLOW DIAGRAM

E5U071100000N03

VENTILATION SYSTEM

REFRIGERANT SYSTEM

End Of Sie

RECIRCULATE

FRESH

SIDE

DEMISTER

SIDE

DEMISTER

DEFROSTER DEFROSTER

SIDE VENT

CENTER VENT

WAIST LOUVER

HEAT

HEAT

HEATER

CORE

EVAPORATOR

BLOWER

MOTOR

SIDE VENT

CENTER VENT

WAIST LOUVER

E5U711ZS5002

LOW-PRESSURE CHARGING VALVE

HIGH-PRESSURE CHARGING VALVE

A/C COMPRESSOR

EVAPORATOR

CONDENSER

EXPANSION VALVE

CHU0711S005

BASIC SYSTEM

07–11–3

07–11

AIR DIST UNIT CONSTRUCTION

E5U071161140N01

• Composed of the following parts:

— Airflow mode actuator

— Airflow mode main link

— Airflow mode door

Airflow Mode Door Operation

• The airflow mode doors move to the OPEN-VENT, OPEN-BI-LEVEL, OPEN-HEAT, VENT HEAT, HEAT/DEF or

DEFROSTER position, depending on the position of the airflow mode control dial. As a result, the airflow mode
changes.

AIRFLOW
MODE
ACTUATOR

AIRFLOW
MODE
DOOR

AIRFLOW
MODE MAIN
LINK

E5U711ZS5003

CENTER VENT,
SIDE VENT

CENTER VENT,
SIDE VENT

WAIST
LOUVER

WAIST
LOUVER

WAIST
LOUVER

[OPEN-VENT]

[OPEN-HEAT]

FRONT HEAT

FRONT HEAT

FRONT HEAT

FRONT HEAT

[OPEN-BI-LEVEL]

DEFROSTER, SIDE DEMISTER

DEFROSTER, SIDE DEMISTER

DEFROSTER, SIDE DEMISTER

[HEAT]

[HEAT/DEF]

[VENT]

: AIR FLOW

[DEFROSTER]

E5U711ZS5004

BASIC SYSTEM

07–11–4

Airflow Distribution

End Of Sie

A/C UNIT CONSTRUCTION/OPERATION

E5U071161132N01

Construction

• An A/C unit with integrated cooling and heater units has been adopted.

— Evaporator

— Heater core

— Expansion valve

— Air mix damper

— Air intake door

— Evaporator temperature sensor

— Power MOS FET

— Air mix actuator

— Air intake actuator

— Blower motor

Air Mix Damper Operation

• The air mix damper, installed in the A/C unit, controls HOT or COLD positions, depending on the position of the

temperature control dial. As a result, the airflow temperature is controlled.

End Of Sie

AIRFLOW

MODE

AIRFLOW RATE (%)

VENT

WAIST

HEAT

DEFROSTER

DRIVER-SIDE

PASSENGER-

SIDE

DRIVE

R-SIDE

PASSE

NGER-

SIDE

DRIVE

R-SIDE

PASSE

NGER-

SIDE

DRIVER-SIDE

PASSENGER-

SIDE

SIDE CENTER

CENTER SIDE

SIDE CENTER

CENTER SIDE

OPEN-VENT 21.25

21.25

21.25

21.25

7.5

7.5

–

–

–

–

–

–

OPEN-BI-

LEVEL

12.5

12.5

12.5

12.5

7.5

7.5

17.5

17.5

–

–

–

–

OPEN-HEAT

–

–

–

–

12.5

12.5

25

25

25

VENT

25

25

25

25

–

–

–

–

–

–

–

–

HEAT

–

–

–

–

–

–

35

35

4.5

3

19.5

3

HEAT/DEF

–

–

–

–

–

–

25

25

7.5

7.5

27.5

7.5

DEFROSTER

–

–

–

–

–

–

–

–

15

20

50

15

AIR MIX
ACTUATOR

POWER MOS FET

AIR INTAKE
ACTUATOR

AIR INTAKE
DOOR

BLOWER MOTOR

HEATER CORE

EVAPORATOR
TEMPERATURE
SENSOR

AIR MIX
DAMPER

EVAPORATOR

EXPANSION VALVE

E5U711ZS5005

BLOWER MOTOR

BLOWER MOTOR

[HOT]

[COLD]

AIR MIX DAMPER

EVAPORATOR

EVAPORATOR

AIR MIX DAMPER

HEATER CORE

HEATER CORE

E5U711ZS5006
