Hyundai Tucson (2024 year). Manual in english - page 5





Driver Assistance System
Rear View Monitor Operation
Rear view
Parking/View button
The rear view appears on the screen
when parking.
„ Type A
Turns on if:
ś You shift the gear to R (Reverse).
ś You press the Parking/View button
while the gear is in P (Park).
Turns off if:
ś You press the Parking/View button
again while the gear is in P (Park) with
the rear view on the screen.
ONX4070040
„ Type B
ś You shift the gear from R (Reverse) to
P (Park).
Extended rear view monitor
The rear view maintains on the screen
when parking.
Turns on if:
You shift the gear from R (Reverse) to N
(Neutral) or D (Drive), and your vehicle
speed is below 6 mph (10 km/h).
ONX4E070102
Press the Parking/View button to turn
Turns off if:
on Rear View Monitor.
ś Your vehicle speed is above 6 mph (10
Press the button again to turn off the
km/h).
function.
ś You shift the gear to P (Park).
ś You press the Parking/View button .
7-98
CarManuals2.com
07
Rear top view
Rear View Monitor Malfunction
and Limitations
Rear View Monitor malfunction
When Rear View Monitor is not working
properly, or the screen flickers, or the
camera image does not display normally,
have the vehicle inspected by an
authorized HYUNDAI dealer.
Limitations of Rear View Monitor
When your vehicle is stopped for a long
time in winter or when your vehicle
ONX4OB071109
is parked in an indoor parking lot, the
Press the icon.
exhaust fumes may temporarily blur the
image.
The top view appears on the screen and
the distance from the vehicle appears in
the back of your vehicle.
WARNING
ś Always turn your head to check blind
Information
spots. The wide-rear view camera
does not cover the entire area behind
ś The rear view cannot be turned off
your vehicle.
when the gear is in R (Reverse).
ś The perceived distance on the screen
ś When the Rear View Monitor is turned
may differ from the actual distance.
on, the last displayed view mode
appears on the screen. If the gear is in
ś Always keep the wide-rear view
R (Reverse), the rear view appears on
camera lens clean. If the lens is
the screen.
blocked or covered, the Rear View
Monitor may not operate normally.
Do not clean with strong chemicals
containing high alkaline or volatile
organic solvents (for example,
gasoline, acetone).
7-99
CarManuals2.com
Driver Assistance System
6855281' 9,(: 021,725 ǣ690Ǥ ǣ,) (48,33('Ǥ
Surround View Monitor Settings
Camera settings
ONX4E070129
Surround View Monitor uses the wide
view cameras and displays images
OTM070213L
around your vehicle through the
infotainment system screen to help with
To change the settings of Surround View
safe parking or driving.
Monitor's Display Contents or Display
Settings, press the setup icon (
) on
ś Parking Assist View provides various
the screen while Rear View Monitor is
view modes of your vehicle's
operating, or go to Setup > Vehicle >
surroundings.
Driver Assistance > Parking Safety >
Camera Settings from the Settings menu
in the infotainment system when the
Information
engine is on.
Surround View Monitor function uses the
ś If Display Contents is selected, you
following sensor:
can change settings for Top View
ś Wide-front view camera
Parking Guidance or Rear View
ś Wide-side view cameras
Parking Guidance.
ś Wide-rear view camera
ś If Display Settings is selected, you
can change the screen’s brightness
Refer to the "Driver Assistance System
Sensors" section in this chapter for the
and contrast.
location.
7-100
CarManuals2.com
07
Top View Parking Guidance
Rear View Parking Guidance
„ Front top view
ONX4EPH071002L
OTM070216L
„ Rear top view
If Rear View Parking Guidance is
selected, the parking guideline appears
on the right side of the Surround View
Monitor screen when the rear view is
displayed.
Information
The rear view horizontal guideline shows
the distance of about 1.6 feet (0.5 m), 3.3
feet (1 m) and 7.6 feet (2.3 m) from the
ONX4E070131
vehicle.
If Top View Parking Guidance is
selected, the parking guideline appears
Parking Distance Warning
on the right side of the Surround View
Monitor screen when the front top view
and rear top view is displayed.
Information
The rear top view horizontal guideline
shows the liftgate opening distance and
6.6 feet (2 m) from the vehicle.
ONX4PH072026N
ś With the ignition switch ON, go to
Setup > Vehicle > Driver Assistance
> Parking Safety > Parking Distance
Warning Auto On (for infotainment
system type) from the Settings menu
to use the function.
If Parking Distance Warning Auto
On is selected, the parking distance
warning appears on the right side of
the Surround View Monitor screen.
7-101
CarManuals2.com
Driver Assistance System
ś The warning appears only when
Parking Distance Warning is on.
Surround View Monitor Auto On
With the ignition switch ON, go to Setup
> Vehicle > Driver Assistance > Parking
Safety > Surround View Monitor Auto
On (for infotainment system type) from
the Settings menu to use the function.
If Surround View Monitor Auto On
is selected, the front parking assist
ONX4PH072027N
view screen appears when the Parking
Distance Warning warns you while
Front view
driving in D (Drive).
The front view appears on the screen
when the gear is in N (Neutral) or D
Information
(Drive) to assist parking. The front view
has top view, front view, and side view.
You can set the following Warning
Methods:
View modes can be selected by pressing
the view buttons on the Surround
ś Parking Safety Priority
View Monitor screen.
For more information, refer to the "Driver
Assistance System Settings" section in
Turns on if:
this chapter.
ś You shift the gear from R (Reverse)
to N (Neutral) or D (Drive), and your
Surround View Monitor
vehicle speed is below 6 mph (10
Operation
km/h).
Parking/View button
ś You press the Parking/View button
„ Type A
„ Type B
when the gear is in N (Neutral) or
D (Drive) and your vehicle speed is
below 6 mph (10 km/h).
ś The Parking Distance Warning warns
you while driving in D (Drive).
(Surround View Monitor Auto On
must be selected from the Settings
menu.)
Information
ONX4070040
ONX4E070102
When the front view is turned on, the last
Press the Parking/View button to turn
view mode appears.
on Surround View Monitor.
Press the button again to turn off the
function.
7-102
CarManuals2.com
07
Turns off if:
Surround View Monitor
ś You press the Parking/View button
Malfunction and Limitations
or the infotainment system buttons
Surround View Monitor malfunction
.
When Surround View Monitor is not
ś Your vehicle speed is above 6 mph (10
working properly, or the screen flickers,
km/h).
or the camera image does not display
ś You shift the gear to P (Park).
normally, have the vehicle inspected by
an authorized HYUNDAI dealer.
Information
Limitations of Surround View
Surround View Monitor turns off if your
Monitor
vehicle speed is greater than 6 mph (10
ś
When your vehicle is stopped
km/h). Although you slow down to less
for a long time in winter or when
than 6 mph (10 km/h) again, Surround
your vehicle is parked in an indoor
View Monitor does not turn on again.
parking lot, the exhaust fumes may
temporarily blur the image.
Rear view
ś
The screen may not display the
The rear view appears on the screen
surround view properly and an icon
when the gear is in R (Reverse) or P
may appear at the top left of the
(Park) to assist parking. The rear view has
screen if:
top view, front view, and side view.
- The liftgate is opened.
View modes can be selected by pressing
- The driver or front passenger door
the view buttons on the Surround
is opened.
View Monitor screen.
- The side view mirror is folded.
Turns on if:
ś You shift the gear to R (Reverse).
WARNING
ś You press the Parking/View button
ś
Always look around your vehicle to
while the gear is in P (Park).
make sure there are no objects or
obstacles before driving.
Turns off if:
ś
The perceived distance on the screen
ś You press the Parking/View button
may differ from the actual distance.
again while the gear is in P (Park).
ś
Surround View Monitor is designed to
ś You shift the gear from R (Reverse) to
be used on a flat surface. When your
P (Park).
vehicle is used on roads with different
heights such as curbs and speed
bumps, the image on the screen may
Information
not look correct.
The rear view cannot be turned off
ś
Always keep the camera lens clean.
when the gear is in R (Reverse) even if
If the lens is blocked or covered,
the infotainment system buttons are
the Surround View Monitor may not
pressed.
operate normally. Do not clean with
strong chemicals containing high
alkaline or volatile organic solvents
(gasoline, acetone etc.).
7-103
CarManuals2.com
Driver Assistance System
5($5 &5266ǘ75$)),& &2//,6,21 :$51,1* ǣ5&&:Ǥ
ǣ,) (48,33('Ǥ
Rear Cross-Traffic Collision Warning uses
Rear Cross-Traffic Collision
the rear corner radars to help detect
Warning Settings
vehicles approaching from the left or
Rear Cross-Traffic Safety
right while your vehicle is reversing, and
to warn you that a collision is imminent
with a warning message and an audible
warning.
OTM070194N
With the ignition switch ON, go to User
Settings > Driver Assistance > Parking
OJX1070108L
Safety > Rear Cross-Traffic Safety (for
: Rear Cross-Traffic Collision Warning operating
cluster type) or Setup > Vehicle > Driver
range
Assistance > Parking Safety > Rear
Cross-Traffic Safety (for infotainment
The warning timing may differ depending
system type) from the Settings menu to
on the speed of the detected vehicle.
turn Rear Cross-Traffic Collision Warning
on and off.
Information
Rear Cross-Traffic Collision Warning
WARNING
function uses the following sensor:
When the engine is restarted, the Rear
ś Rear corner radars
Cross-Traffic Collision Warning turns
Refer to the "Driver Assistance System
on. If Off is selected after the engine is
Sensors" section in this chapter for the
restarted, Rear Cross-Traffic Collision
location.
Warning does function until the next
time the vehicle is started.
Information
You can set the Warning Timing and
following Warning Methods:
ś Warning Volume
Even if you change the Warning
Volume to Off or 0, the warning
sounds at the volume to Low or 1.
For more information, refer to the "Driver
Assistance System Settings" section in
this chapter.
7-104
CarManuals2.com
07
Rear Cross-Traffic Collision
Collision warning may operate if:
Warning Operation
ś You shift the gear to R (Reverse) and
your vehicle speed is below 5 mph (8
Rear Cross-Traffic Collision Warning may
km/h).
warn your vehicle depending on the
collision risk level.
ś The approaching vehicle is detected
within about 82 feet (25 m) from the
Collision Warning
left or right of your vehicle.
ś The speed of the vehicle approaching
from the left or right is above 3 mph
(5 km/h).
Information
ś If the operating conditions are met,
a warning is provided whenever your
vehicle approaches from the left or
right even though your vehicle speed
is 0 mph (0 km/h).
OPDEN060039
ONX4070055
ś The images and colors in the
instrument cluster may differ
depending on the cluster type or
theme selected from the settings
menu.
WARNING
Always look over your shoulder for
possible hazards and make sure it is safe
to back up.
ONX4E070133
To warn you of an approaching vehicle
from the rear left or right of your vehicle,
the warning light on the side view mirror
may blink, a warning message may
appear on the instrument cluster, and an
audible warning may sound.
When Rear View Monitor is operating, a
warning may appear on the infotainment
system screen.
7-105
CarManuals2.com
Driver Assistance System
Rear Cross-Traffic Collision
Rear Cross-Traffic Collision Warning
Warning Malfunction and
disabled
Limitations
Rear Cross-Traffic Collision Warning
malfunction
OTM070124N
If the rear corner radar is blocked or
covered, or when the rear bumper
OTM070125N
around the rear corner radar or sensor
is covered by any foreign material, such
When the Rear Cross-Traffic Collision
as snow, rain, or dirt, or when a trailer
Warning is not working properly, the
or hitch mounted carrier is installed, the
"Check Rear Cross-Traffic Safety system"
detecting performance may reduce and
warning message may appear, and the
temporarily limit or disable Rear Cross-
warning light may illuminate on the
Traffic Collision Warning.
instrument cluster. Have the vehicle
inspected by an authorized HYUNDAI
The " Rear Cross-Traffic Safety system
dealer.
disabled. Radar blocked" warning
message may appear on the instrument
cluster.
The function operates normally when
such foreign material, trailer, or carrier is
removed, and the engine is restarted.
If the function does not operate normally
after anything covering or blocking the
sensors is removed, have the vehicle
inspected by an authorized HYUNDAI
dealer.
OTM070100N
When the side view mirror warning
light is not working properly, the
"Check side view mirror warning light"
warning message may appear, and the
warning light may illuminate on the
instrument cluster. Have the vehicle
inspected by an authorized HYUNDAI
dealer.
7-106
CarManuals2.com
07
WARNING
WARNING
ś Rear Cross-Traffic Collision Warning
ś Driving near a vehicle or structure
may not operate properly even if there
is no warning message or warning
light on the instrument cluster.
ś Rear Cross-Traffic Collision Warning
may not operate properly in open
areas where no objects are detected
(for example, empty parking lot)
or when the detecting sensors are
blocked right after turning on the
engine.
ś Always turn off Rear Cross-Traffic
Collision Warning when towing a
OJX1079111
trailer or using a hitch mounted
: Structure
carrier.
Rear Cross-Traffic Collision Warning
may be limited when driving near
Limitations of Rear Cross-Traffic
another vehicle or a structure,
Collision Warning
and it may not detect the vehicle
Rear Cross-Traffic Collision Warning may
approaching from the left or right. The
not operate normally, or may operate
function may not activate a warning.
unexpectedly if:
Always check your surroundings while
ś Departing from where trees or grass
backing up.
are overgrown.
ś Departing from where roads are wet.
ś Speed of the approaching vehicle is
fast or slow.
Information
For more information on the limitations
of the rear corner radar, refer to the
"Blind-Spot Collision Warning" section in
this chapter.
7-107
CarManuals2.com
Driver Assistance System
ś When your vehicle is in a complex
ś When your vehicle is on or near a
parking environment
slope
OJX1079112
ONX4070082
Rear Cross-Traffic Collision Warning
Rear Cross-Traffic Collision Warning
may detect vehicles that are parking
may be limited when your vehicle is
or pulling out near your vehicle (for
on a uphill or downhill slope, and may
example, leaving beside your vehicle,
not detect any vehicle approaching
parking or pulling out behind your
from the left or right. If this occurs,
vehicle, approaching your vehicle
the function may activate a warning
making a turn). If this occurs, the
even when not needed.
function may activate a warning even
Always check your surroundings while
when not needed.
backing up.
Always check your surroundings while
backing up.
ś Pulling into the parking space where
there is a structure
ś When your vehicle is parked
diagonally
OJX1079115
: Structure, : Wall
OJX1079113
Rear Cross-Traffic Collision Warning
: Vehicle
may detect vehicles passing by in
Rear Cross-Traffic Collision Warning
front of you when parking in reverse
may be limited when backing up
into a parking space with a wall or
diagonally, and may not detect any
structure in the rear or side area. If
vehicle approaching from the left or
this occurs, the function may activate
right. If this occurs, the function may
a warning.
not activate a warning.
Always check your surroundings while
Always check your surroundings while
backing up.
backing up.
7-108
CarManuals2.com
07
ś When your vehicle is parked
rearward
OJX1079116
Rear Cross-Traffic Collision Warning
may detect vehicles passing by
behind you when parking in reverse
into a parking space. If this occurs, the
function may activate a warning even
when not needed.
Always check your surroundings while
backing up.
WARNING
ś Rear Cross-Traffic Collision Warning
may not operate normally if
there is interference from strong
electromagnetic waves.
ś Rear Cross-Traffic Collision Warning
may not operate for 3 seconds right
after your vehicle is started or when
the rear corner radars are initialized.
7-109
CarManuals2.com
Driver Assistance System
5($5 &5266ǘ75$)),& &2//,6,21ǘ$92,'$1&( $66,67
ǣ5&&$Ǥ ǣ,) (48,33('Ǥ
Rear Cross-Traffic Collision-Avoidance
Rear Cross-Traffic Collision-
Assist detects vehicles approaching from
Avoidance Assist Settings
the rear left or right while your vehicle
Rear Cross-Traffic Safety
is reversing and warns you of a possible
collision with a warning message and a
warning sound. Also, Rear Cross-Traffic
Collision-Avoidance Assist may assist
with braking your vehicle to help avoid a
collision.
OTM070194N
With the ignition switch ON, go to User
Settings > Driver Assistance > Parking
Safety > Rear Cross-Traffic Safety (for
cluster type) or Setup > Vehicle > Driver
OJX1079108
Assistance > Parking Safety > Rear
: Rear Cross-Traffic Collision Warning operating
Cross-Traffic Safety (for infotainment
range,
system type) from the Settings menu
: Rear Cross-Traffic Collision-Avoidance Assist
to turn Rear Cross-Traffic Collision-
operating range
Avoidance Assist on and off.
The warning timing may differ depending
on the speed of the detected vehicle.
WARNING
When the engine is restarted, the Rear
Information
Cross-Traffic Collision-Avoidance Assist
turns on. If Off is selected after the
Rear Cross-Traffic Collision-Avoidance
engine is restarted, Rear Cross-Traffic
Assist function uses the following sensor:
Collision-Avoidance Assist does not
ś Rear corner radars
function until the next time your vehicle
Refer to the "Driver Assistance System
is started.
Sensors" section in this chapter for the
location.
Information
Settings for Rear Cross-Traffic Safety
include Rear Cross-Traffic Collision
Warning and Rear Cross-Traffic Collision-
Avoidance Assist.
7-110
CarManuals2.com
07
Rear Cross-Traffic Collision-
Information
Avoidance Assist Operation
You can set the Warning Timing and
following Warning Methods:
Rear Cross-Traffic Collision-Avoidance
Assist may warn and control your vehicle
ś Warning Volume
depending on the collision risk level.
Even if you change the Warning
Volume to Off or 0, the warning
Collision Warning
sounds at the volume to Low or 1.
ś Haptic Warning
For more information, refer to the "Driver
Assistance System Settings" section in
this chapter.
OPDEN060039
ONX4070055
ONX4E070133
To warn you of an approaching vehicle
from the rear left or right of your vehicle,
the warning light on the side view mirror
may blink, a warning message may
appear on the instrument cluster, and
an audible warning sound and haptic
feedback of the steering wheel (if
equipped).
When Rear View Monitor is operating, a
warning may appear on the infotainment
system screen.
7-111
CarManuals2.com
Driver Assistance System
Collision warning may operate if:
Emergency Braking
ś
You shift the gear to R (Reverse) and
your vehicle speed is below 5 mph (8
km/h).
ś
The approaching vehicle is detected
within about 82 feet (25 m) from the
left or right of your vehicle.
ś
The speed of the vehicle approaching
from the left or right is above 3 mph
(5 km/h).
Information
OPDEN060039
ONX4E070057
ś
If the operating conditions are met,
a warning is provided whenever your
vehicle approaches from the left or
right even though your vehicle speed
is 0 mph (0 km/h).
ś
The images and colors in the
instrument cluster may differ
depending on the cluster type or
theme selected from the settings
menu.
ONX4E070133
To warn you of an approaching vehicle
from the rear left or right of your vehicle,
the warning light on the side view mirror
may blink, a warning message may
appear on the instrument cluster, and an
audible warning may sound.
When Rear View Monitor is operating, a
warning may appear on the infotainment
system screen.
If a collision is imminent, emergency
braking is assisted to help prevent
collision with approaching vehicles from
the left and right side or your vehicle.
7-112
CarManuals2.com
07
Emergency braking may operate if:
Stopping vehicle and ending brake
ś You shift the gear to R (Reverse) and
control
your vehicle speed is below 5 mph (8
km/h).
ś The approaching vehicle is detected
within about 5 feet (1.5 m) from the
left or right of your vehicle.
ś The speed of the vehicle approaching
from the left or right is above 3 mph
(5 km/h).
WARNING
ONX4E070058
Braking control ends when:
After your vehicle is stopped following
ś The approaching vehicle is out of the
an Emergency Braking event, the "Drive
detection range.
carefully" warning message may appear
ś The approaching vehicle passes
on the instrument cluster.
behind your vehicle.
Depress the brake pedal immediately
ś The approaching vehicle does not
and check the surroundings.
continue to drive toward your vehicle.
ś Braking control ends about 2 seconds
ś The approaching vehicle speed slows
after your vehicle is stopped.
down.
ś During Emergency Braking, braking
ś You depress the brake pedal
control by Rear Cross-Traffic
sufficiently in response to the
Collision-Avoidance Assist may
potential hazard detected by the
be automatically canceled when
function.
you depress the brake pedal with
sufficient force.
WARNING
Rear Cross-Traffic Collision-Avoidance
Assist may not operate in all situations
and cannot avoid all collisions.
To prevent serious injury or death:
ś Only change the settings after parking
the vehicle at a safe location.
ś Always look over your shoulder for
possible hazards and make sure it is
safe to back up.
ś When other system’s warning
message appears or audible warning
is heard, Rear Cross-Traffic Collision-
Avoidance Assist may not warn you.
7-113
CarManuals2.com
Driver Assistance System
ś
You may not hear the audible warning
WARNING
of Rear Cross-Traffic Collision-
Avoidance Assist if the surrounding
Braking is not assisted and only a
environment is too noisy.
warning is provided when:
ś
During Rear Cross-Traffic Collision-
ś The ESC (Electronic Stability Control)
Avoidance Assist operation, your
warning light is on.
vehicle may stop suddenly. Always
ś ESC (Electronic Stability Control) is
wear your seatbelt, check your
controlling the brake force to the
occupants have their seat belts
wheels.
fastened and secure loose objects
that may become projectiles.
Information
ś
Rear Cross-Traffic Collision-Avoidance
Assist may not operate if you apply
After shifting the gear to R (Reverse),
the brake pedal with sufficient force
Rear Cross-Traffic Collision-Avoidance
in response to the potential hazard
Assist operates once for left or right
detected by the system.
vehicle's approach.
ś
Even if there is an issue with Rear
Cross-Traffic Collision-Avoidance
Assist, the vehicle’s braking system
operates normally.
ś
When Rear Cross-Traffic Collision-
Avoidance Assist is operating, braking
assist is automatically canceled when
you depress the accelerator pedal
with sufficient force.
ś
Rear Cross-Traffic Collision-Avoidance
Assist may warn you late or may not
warn you depending on the road and
driving conditions.
ś
Control your vehicle at all times. It is
your responsibility to operate your
vehicle in a safe manner. Do not
solely rely on the Rear Cross-Traffic
Collision-Avoidance Assist to avoid
a collision. Rather, maintain a safe
braking distance, and If needed,
reduce your vehicle speed or depress
the brake pedal to reduce the driving
speed or to stop your vehicle.
ś
Never attempt to activate Rear Cross-
Traffic Collision-Avoidance Assist by
intentionally driving toward people,
animals, objects, or other vehicles.
7-114
CarManuals2.com
07
Rear Cross-Traffic Collision-
Rear Cross-Traffic Collision-
Avoidance Assist Malfunction
Avoidance Assist disabled
and Limitations
Rear Cross-Traffic Collision-
Avoidance Assist malfunction
OTM070124N
If the rear corner radar is blocked or
covered, or when the rear bumper
OTM070125N
around the rear corner radar or sensor
is covered by any foreign material, such
When the Rear Cross-Traffic Collision-
as snow, rain, or dirt, or when a trailer
Avoidance Assist is not working properly,
or hitch mounted carrier is installed, the
the "Check Rear Cross-Traffic Safety
detecting performance may reduce and
system" warning message may appear,
temporarily limit or disable Rear Cross-
and the warning light may illuminate
Traffic Collision-Avoidance Assist.
on the instrument cluster. Have the
vehicle inspected by an authorized
The "Rear Cross-Traffic Safety system
HYUNDAI dealer.
disabled. Radar blocked" warning
message may appear on the instrument
cluster.
The function operates normally when
such foreign material, trailer, or carrier is
removed, and the engine is restarted.
If the function does not operate normally
after anything covering or blocking the
sensors is removed, have the vehicle
inspected by an authorized HYUNDAI
dealer.
OTM070100N
When the side view mirror warning
light is not working properly, the
"Check side view mirror warning light"
warning message may appear, and the
warning light may illuminate on the
instrument cluster. Have the vehicle
inspected by an authorized HYUNDAI
dealer.
7-115
CarManuals2.com
Driver Assistance System
WARNING
Information
ś Rear Cross-Traffic Collision-Avoidance
For more information on the limitations
Assist may not operate properly
of the rear corner radar, refer to the
even if there is no warning message
"Blind-Spot Collision-Avoidance Assist
or warning light on the instrument
(BCA)" section in this chapter.
cluster.
ś Rear Cross-Traffic Collision-Avoidance
WARNING
Assist may not operate properly in
open areas where no objects are
ś Driving near a vehicle or structure
detected (for example, empty parking
lot) or when the detecting sensors
are blocked right after turning on the
engine.
ś Always turn off Rear Cross-Traffic
Collision-Avoidance Assist when
towing a trailer or using a hitch
mounted carrier.
Limitations of Rear Cross-Traffic
Collision-Avoidance Assist
OJX1079111
Rear Cross-Traffic Collision-Avoidance
: Structure
Assist may not operate normally, or may
operate unexpectedly if:
Rear Cross-Traffic Collision-Avoidance
Assist may be limited when driving
ś Departing from where trees or grass
near another vehicle or a structure,
are overgrown.
and it may not detect the vehicle
ś Departing from where roads are wet.
approaching from the left or right. The
ś Speed of the approaching vehicle is
function may not activate a warning or
fast or slow.
brake your vehicle
Always check your surroundings while
Braking may not be assisted if:
backing up.
ś Your vehicle severely vibrates while
driving over a bumpy road, uneven
road, or concrete patch.
ś You are driving on a slippery surface
due to snow, water puddle, ice, etc.
ś The tire pressure is low or any tire is
damaged.
ś The braking system is adjusted
differently from the factory default
settings.
ś Remote Smart Parking Assist is
operating (if equipped).
7-116
CarManuals2.com
07
ś When your vehicle is in a complex
ś When your vehicle is parked
parking environment
diagonally
OJX1079112
OJX1079113
: Vehicle
Rear Cross-Traffic Collision-Avoidance
Assist may detect vehicles that are
Rear Cross-Traffic Collision-Avoidance
parking or pulling out near your
Assist may be limited when backing
vehicle (for example, leaving beside
up diagonally, and may not detect any
your vehicle, parking or pulling out
vehicle approaching from the left or
behind your vehicle, approaching your
right. If this occurs, the function may
vehicle making a turn). If this occurs,
not activate a warning or brake your
the function may activate a warning
vehicle.
and brake your vehicle even when not
Always check your surroundings while
needed.
backing up.
Always check your surroundings while
backing up.
7-117
CarManuals2.com
Driver Assistance System
ś When your vehicle is on or near a
ś When your vehicle is parked
slope
rearward
ONX4070082
OJX1079116
Rear Cross-Traffic Collision-Avoidance
Rear Cross-Traffic Collision-Avoidance
Assist may be limited when your
Assist may detect vehicles passing by
vehicle is on a uphill or downhill
behind you when parking in reverse
slope, and may not detect any vehicle
into a parking space. If this occurs,
approaching from the left or right. If
the function may activate a warning
this occurs, the function may activate
and brake your vehicle even when not
a warning and brake your vehicle even
needed.
when not needed.
Always check your surroundings while
Always check your surroundings while
backing up.
backing up.
WARNING
ś Pulling into the parking space where
there is a structure
ś Rear Cross-Traffic Collision-Avoidance
Assist may not operate normally if
there is interference from strong
electromagnetic waves.
ś Rear Cross-Traffic Collision-Avoidance
Assist may not operate for 3 seconds
right after your vehicle is started
or when the rear corner radars are
initialized.
OJX1079115
: Structure, : Wall
Rear Cross-Traffic Collision-Avoidance
Assist may detect vehicles passing by
in front of you when parking in reverse
into a parking space with a wall or
structure in the rear or side area. If
this occurs, the function may activate
a warning or brake your vehicle.
Always check your surroundings while
backing up.
7-118
CarManuals2.com
07
)25:$5' 5(9(56( 3$5.,1* ',67$1&( :$51,1* ǣ3':Ǥ
ǣ,) (48,33('Ǥ
Forward/Reverse Parking Distance
Parking Distance Warning
Warning uses the front and rear
Operation
ultrasonic sensors to detect and warns
Parking Safety button
you if a person, animal, or object is within
a certain distance when your vehicle is
„ Type A
stopped or driving at low speed.
Information
Forward/Reverse Parking Distance
Warning function uses the following
sensor:
ś Front ultrasonic sensors
ś Rear ultrasonic sensors
Refer to the "Driver Assistance System
ONX4070061
Sensors" section in this chapter for the
„ Type B
location.
Parking Distance Warning
Settings
Parking Distance Warning Auto On
With the ignition switch ON, go to User
Settings > Driver assistance > Parking
Safety > Parking Distance Warning Auto
On (for cluster type) or Setup > Vehicle
> Driver Assistance > Parking Safety
> Parking Distance Warning Auto On
ONX4E070106
(for infotainment system type) from the
Press the Parking Safety (
) button to
Settings menu to use Parking Distance
turn on Parking Distance Warning.
Warning Auto On.
Press the button again to turn off the
function.
Information
ś When Parking Distance Warning is
When Parking Distance Warning Auto
off (button indicator light off), if you
On is selected, the Parking Safety (
)
shift the gear to R (Reverse), Parking
button indicator light stays on.
Distance Warning automatically turns
on.
Information
You can set the following Warning
Methods:
ś Warning Volume
Even if you change the Warning
Volume to Off or 0, the warning
sounds at the volume to Low or 1.
For more information, refer to the "Driver
Assistance System Settings" section in
this chapter.
7-119
CarManuals2.com
Driver Assistance System
Forward Parking Distance Warning
Warning indicator and warning sounds
Forward Parking Distance Warning may
Warning
operate if:
indicator
ś
You shift the gear from R (Reverse) to
Distance
Warning
when
D (Drive).
from object
sound
driving
ś
The gear is in D (Drive) and the
backward
Parking Safety button indicator light
is on.
24~40 in.
Buzzer beeps
(60~100 cm)
intermittently
ś
An obstacle is detected while driving
in D (Drive).
(Parking Distance Warning Auto On
12~24 in.
Beeps more
must be selected from the Settings
(30~60 cm)
frequently
menu.)
ś
Your vehicle’s forward speed is below
within 12 in.
Beeps
6 mph (10 km/h).
(30 cm)
continuously
ś The corresponding indicator
Information
illuminates whenever each ultrasonic
ś
Forward Parking Distance Warning
sensor detects a person, animal, or
does not operate when your vehicle's
object in its sensing range and an
forward speed is greater than 6 mph
audible warning sounds.
(10 km/h) even if the Parking Safety
ś When two or more objects are
button indicator light is on. Forward
detected at the same time, an audible
Parking Distance Warning operates
warning sounds for the object closest
again when your vehicle's forward
to your vehicle.
speed decreases to less than 6 mph
ś The shape of the indicator in the
(10 km/h) while the Parking Safety
illustration above may differ from the
button indicator light is on.
actual object detected.
ś
If your vehicle speed is greater than
18 mph (30 km/h), Forward/Reverse
Parking Distance Warning turns off
(button indicator light off). Although
you slow down to less than 6 mph
(10 km/h) again, Forward Parking
Distance Warning does not turn on
again.
7-120
CarManuals2.com
07
Reverse Parking Distance Warning
Parking Distance Warning
Reverse Parking Distance Warning may
Malfunction and Limitations
operate if:
Parking Distance Warning
ś You shift the gear to R (Reverse).
malfunction
ś Your vehicle’s rearward speed is below
After starting the engine, a beep sounds
6 mph (10 km/h).
when the gear is shifted to R (Reverse)
to indicate Parking Distance Warning is
operating normally.
Information
If one or more of the following occurs,
When your vehicle’s rearward speed
check whether the ultrasonic sensor is
is below 6 mph (10 km/h), both the
damaged or blocked.
front and rear ultrasonic sensors detect
ś The audible warning does not sound.
objects.
ś The buzzer sounds intermittently.
Warning indicator and warning sounds
ś The "Parking sensor error or blockage"
warning message may appear on the
Warning
instrument cluster.
indicator
If it still does not work properly, have
Distance
Warning
when
the vehicle inspected by an authorized
from object
sound
driving
HYUNDAI dealer.
backward
24~48 in.
Buzzer beeps
(60~120 cm)
intermittently
12~24 in.
Beeps more
(30~60 cm)
frequently
within 12 in.
Beeps
(30 cm)
continuously
ONX4E070062
ś The corresponding indicator
illuminates whenever each ultrasonic
sensor detects a person, animal, or
object in its sensing range and an
audible warning sounds.
ś When two or more objects are
detected at the same time, an audible
warning sounds for the object closest
to your vehicle.
ś The shape of the indicator in the
illustration above may differ from the
actual object detected.
7-121
CarManuals2.com
Driver Assistance System
Limitations of Parking Distance
The following objects may not be
Warning
detected:
Parking Distance Warning may not
ś
Narrow or slim objects such as ropes,
operate normally when:
chains, or small poles
ś Any sensor is covered or blocked with
ś
Objects that tend to absorb sensor
snow, water, or dirt. Parking Distance
frequency, such as clothes, spongy
Warning operates normally again
material, or snow.
when unblocked or uncovered.
ś
Objects less than 40 inches (100 cm)
ś The weather is very hot or cold.
high and less than 6 inches (14 cm)
wide
ś The sensor or sensor assembly is
disassembled.
ś
Pedestrians, animals, or objects
that are very close to the ultrasonic
ś The surface of the sensor has been
sensors
damaged or scratched with a sharp
object.
ś The sensors or its surrounding area
WARNING
is directly sprayed with high pressure
ś
The operation of Parking Distance
washer.
Warning can be affected by several
factors (including environmental
Parking Distance Warning may
conditions). Parking Distance Warning
malfunction when:
is a supplemental function only.
ś Heavy rain or water spray is present.
ś
Always turn your head and look for
ś Water flows on the surface of the
potential hazards around your vehicle
sensor.
when parking.
ś The sensor is covered with snow.
ś
To prevent serious injury or death,
pay close attention when driving near
ś An ultrasonic sensor with similar
objects, pedestrians, and especially
frequency is near your vehicle.
children. Some objects may not be
ś Sources that generate ultrasonic
detected by ultrasonic sensors, due to
waves are near your vehicle.
the object's distance, size, or material.
ś Driving on uneven road, gravel roads,
or bushes.
ś Your vehicle's bumper height or
ultrasonic sensor installation has been
modified.
ś Equipment, license plate, or
accessories are attached near the
ultrasonic sensors.
7-122
CarManuals2.com
07
5(9(56( 3$5.,1* &2//,6,21ǘ$92,'$1&( $66,67 ǣ3&$Ǥ ǣ,)
(48,33('Ǥ
Reverse Parking Collision-Avoidance
Reverse Parking Collision-
Assist detects pedestrians or objects
Avoidance Assist Settings
behind the vehicle and may warn you or
assist you with braking to help avoid a
collision while your vehicle is reversing.
Information
Reverse Parking Collision-Avoidance
Assist function uses the following sensor:
ś Wide-rear view camera
ś Rear ultrasonic sensors
Refer to the "Driver Assistance System
OTM070231N
Sensors" section in this chapter for the
location.
With the ignition switch ON, go to User
Settings > Driver Assistance > Parking
Safety (for cluster type) or Setup >
Vehicle > Driver Assistance > Parking
Safety (for infotainment system type)
from the Settings menu to select the
following:
ś If Rear Active Assist is selected,
Reverse Parking Collision-Avoidance
Assist warns you and assists braking
when a collision with a pedestrian or
object is detected.
ś If Rear Warning Only is selected,
Reverse Parking Collision-Avoidance
Assist warns you when a collision with
a pedestrian or object is detected.
Braking is not assisted.
ś If Off is selected, Reverse Parking
Collision-Avoidance Assist turns off.
Information
You can set the following Warning
Methods:
ś Warning Volume
Even if you change the Warning
Volume to Off or 0, the warning
sounds at the volume to Low or 1.
ś Haptic Warning
For more information, refer to the "Driver
Assistance System Settings" section in
this chapter.
7-123
CarManuals2.com
Driver Assistance System
Reverse Parking Collision-
Rear Active Assist
Avoidance Assist Operation
If Reverse Parking Collision-Avoidance
If Rear Active Assist or Rear Warning
Assist detects a risk of collision with a
pedestrian or object, Reverse Parking
Only is selected from the settings menu,
Reverse Parking Collision-Avoidance
Collision-Avoidance Assist warns you
with an audible warning and warning
Assist is in ready status when all of the
following conditions are met:
message on the instrument cluster.
When Rear View Monitor is operating, a
ś The liftgate is closed.
warning may appear on the infotainment
ś The EPB (Electronic Parking Brake) is
system screen.
released.
ś The gear is shifted to R (Reverse).
If Reverse Parking Collision-Avoidance
ś Vehicle speed is less than 6 mph (10
Assist detects an imminent collision
km/h).
with a pedestrian or object behind
your vehicle, Reverse Parking Collision-
ś Reverse Parking Collision-Avoidance
Assist components such as wide-
Avoidance Assist may assist braking.
Immediately depress the brake pedal and
rear view camera and rear ultrasonic
sensors are in normal conditions.
check vehicle surroundings because the
brake assist ends within 2 seconds.
When Reverse Parking Collision-
Braking control ends when:
Avoidance Assist activates, a line
ś You shift the gear to P (Park) or D
appears behind the vehicle image on the
(Drive).
instrument cluster.
ś You depress the brake pedal with
sufficient force.
ś Braking assist has stopped your
vehicle for about 2 seconds.
OTM070174
Information
Reverse Parking Collision-Avoidance
Assist operates only once after the gear
is shifted to R (Reverse). To reactivate
Reverse Parking Collision-Avoidance
Assist, shift the gear from another gear
to R (Reverse).
7-124
CarManuals2.com
07
Rear Warning Only
Reverse Parking Collision-Avoidance
If Reverse Parking Collision-Avoidance
Assist disabled
Assist detects a risk of collision with a
„ Wide-rear view
„ Rear ultrasonic
pedestrian or object, Reverse Parking
camera
sensor
Collision-Avoidance Assist warns you
with an audible warning and warning
message on the instrument cluster.
When Rear View Monitor is operating, a
warning may appear on the infotainment
system screen.
ś If Rear Warning Only is selected,
braking is not assisted.
ś The warning turns off when the gear
OTM070219L
OTM070176L
is shifted to P (Park), N (Neutral), or D
The "Rear camera error or blockage"
(Drive).
or "Parking sensor error or blockage"
warning message may appear on the
Reverse Parking Collision-
instrument cluster if:
Avoidance Assist Malfunction
ś The wide-rear view camera or rear
and Limitations
ultrasonic sensor(s) is covered or
Reverse Parking Collision-
blocked with snow or rain.
Avoidance Assist malfunction
ś There is inclement weather, such as
heavy snow or heavy rain. Reverse
Parking Collision-Avoidance Assist
may turn off or may not operate
properly. Check the wide-rear view
camera and rear ultrasonic sensors
are clean.
Limitations of Reverse Parking
Collision-Avoidance Assist
Reverse Parking Collision-Avoidance
Assist may not assist braking or warn you
OTM070173L
even if there are pedestrians or objects if:
When Reverse Parking Collision-
ś Any non-factory equipment or
Avoidance Assist or other related
accessory is installed on the rear of
functions are not working properly,
your vehicle.
the "Check Parking Safety system"
warning message may appear on the
ś Your vehicle has been damaged due
to an accident or other causes.
instrument cluster, and Reverse Parking
Collision-Avoidance Assist may turn
ś Bumper height or rear ultrasonic
off automatically. Have the vehicle be
sensor installation locations have
inspected by an authorized HYUNDAI
been modified.
dealer.
ś Wide-rear view camera or rear
ultrasonic sensor(s) is damaged.
ś Wide-rear view camera or rear
ultrasonic sensor(s) is covered or
blocked with snow, water, or dirt.
7-125
CarManuals2.com
Driver Assistance System
ś
The surrounding is very bright or dark.
ś You back up the vehicle immediately
after shifting to R (Reverse).
ś
The weather is very hot or cold.
ś You accelerate your vehicle or drive in
ś
The wind speed is either greater
circles.
than 12 mph (20 km/h) or blowing
perpendicular to the rear bumper.
Reverse Parking Collision-Avoidance
ś
Objects generating excessive
Assist may unnecessarily warn you
noise, such as vehicle horns, loud
or assist braking even if there are no
motorcycle engines, or truck air
pedestrians or objects if:
brakes, are near your vehicle.
ś
Any non-factory equipment or
ś
An ultrasonic sensor with similar
accessory is installed on the rear of
frequency is near your vehicle.
your vehicle.
ś
The road is slippery or inclined.
ś
Your vehicle has been damaged due
ś
There is elevation difference between
to an accident or other causes.
your vehicle and the pedestrian.
ś
Bumper height or rear ultrasonic
ś
The pedestrian blends into the
sensor installation locations have
background when seen from the
been modified.
wide-rear view camera.
ś
Your vehicle height is lower or higher
ś
The pedestrian is near the rear edge of
than normal due to heavy loads,
your vehicle.
abnormal tire pressure, etc.
ś
The pedestrian is not standing upright.
ś
Wide-rear view camera or rear
ś
The pedestrian is very short or tall.
ultrasonic sensor(s) is covered or
blocked with snow, water, or dirt.
ś
The pedestrian is wearing clothing
that easily blends into the
ś
The pattern on the road is mistaken
background, making them difficult to
for a pedestrian.
detect.
ś
There are shadows or light reflecting
ś
The pedestrian is wearing clothing
on the ground.
that does not reflect ultrasonic waves
ś
Objects generating excessive
well.
noise, such as vehicle horns, loud
ś
Size, thickness, height, or shape of
motorcycle engines, or truck air
the object does not reflect ultrasonic
brakes, are near your vehicle.
waves well (for example, pole, bush,
ś
Your vehicle is backing toward a
curbs, carts, edge of a wall, etc.).
narrow passage or parking space.
ś
The pedestrian or object is moving
ś
Your vehicle is backing towards an
very quickly.
uneven road surface, such as unpaved
ś
The pedestrian or object is very close
road, gravel, bump, gradient, etc.
to the rear of your vehicle.
ś
A trailer or hitch mounted carrier is
ś
There is a wall is behind the
installed on the rear of your vehicle.
pedestrian or object.
ś
An ultrasonic sensor with similar
ś
The object is not located at the rear
frequency is near your vehicle.
center of your vehicle.
ś
Pedestrians or objects are near the
ś
The object is not parallel to the rear
path of your vehicle.
bumper.
ś
The pedestrian or object is moving
ś
The road is slippery or inclined.
very quickly.
ś
The pedestrian is in a state that is
ś
You accelerate your vehicle or drive in
difficult detect.
circles.
7-126
CarManuals2.com
07
ś Turn off Reverse Parking Collision-
WARNING
Avoidance Assist when towing a
Reverse Parking Collision-Avoidance
trailer. If towing and moving in
Assist may not operate in all situations
reverse, Reverse Parking Collision-
and cannot avoid all collisions.
Avoidance Assist activates when it
To prevent serious injury or death:
detects a trailer.
ś
Always pay attention to road and
ś The brake control may not operate
traffic conditions while driving. Brake
properly depending on the status of
as needed to avoid collisions. Do
ESC (Electronic Stability Control).
not solely rely on Reverse Parking
There is only a warning when:
Collision-Avoidance Assist.
- The ESC (Electronic Stability
ś
Always look around your vehicle to
Control) warning light is on.
make sure there are no pedestrians or
- ESC (Electronic Stability Control) is
objects before parking.
controlling the brake force to the
ś
The performance of Reverse Parking
wheels.
Collision-Avoidance Assist may
ś Check the brake fluid and brake pad
differ under certain conditions. If
condition periodically. Depending
your vehicle speed is greater than
on the condition, brake operation
2 mph (4 km/h), Reverse Parking
performance may reduce.
Collision- Avoidance Assist provides
collision avoidance assist only when
pedestrians are detected.
Information
ś
Some objects may not be detected by
Reverse Parking Collision-Avoidance
the rear ultrasonic sensors due to the
Assist can detect a pedestrian or an
object's distance, size, or material.
object when:
ś A pedestrian is standing behind the
WARNING
vehicle.
ś
Noise may be heard when sudden
ś A large obstacle, such as a vehicle,
is parked in the rear center of your
braking occurs to avoid a collision.
vehicle.
ś
When other system’s warning
message appears or audible warning
is heard, Reverse Parking Collision-
Avoidance Assist may not warn you.
ś
You may not hear the audible
warning of Reverse Parking Collision-
Avoidance Assist if the surrounding
environment is too noisy.
ś
Reverse Parking Collision-Avoidance
Assist may not work properly if the
bumper has been damaged, replaced,
or repaired.
ś
Reverse Parking Collision-Avoidance
Assist may not operate normally if
there is interference from strong
electromagnetic waves.
7-127
CarManuals2.com
Driver Assistance System
5(027( 60$57 3$5.,1* $66,67 ǣ563$Ǥ ǣ,) (48,33('Ǥ
Remote Smart Parking Assist uses the
Information
front, front side, rear side, and rear
ultrasonic sensors to detect parking
Remote Smart Parking Assist function
spaces and control vehicle steeing,
uses the following sensor:
speed, gear shifts, and help enter and
ś Front ultrasonic sensors
exit parking spaces remotely from
ś Front side ultrasonic sensors
outside your vehicle.
ś Rear side ultrasonic sensors
Function
Description
ś Rear ultrasonic sensors
Remotely moving forward
Refer to the "Driver Assistance System
or backward
Sensors" section in this chapter for the
location.
Remote
Information
Operation
You can set the following Warning
Methods:
ś Warning Volume
OJX1079037
Even if you change the Warning
ś The Remote Operation function helps
Volume to Off or 0, the warning
you move the vehicle forward or
sounds at the volume to Low or 1.
backward from outside the vehicle
For more information, refer to the "Driver
using the smart key.
Assistance System Settings" section in
ś When Remote Smart Parking Assist
this chapter.
operates, Surround View Monitor
and Parking Distance Warning also
operates. For more information,
refer to the "Surround View Monitor
(SVM) and "Parking Distance Warning
(PDW)" sections in this chapter.
7-128
CarManuals2.com
07
Remote Smart Parking Assist Operation
Remote Smart Parking Assist button
Parking/View button
Smart key
ONX4070043
OTM070177
Location
Name
Symbol
Description
ś Press and hold the Parking/View button to turn
Parking/View
on Remote Smart Parking Assist. Also, Forward/
button
Reverse Parking Distance warning automatically
Inside
turns on.
vehicle
ś Press the Parking Safety button while Remote
Parking
Smart Parking Assist is operating to end Remote
Safety button
Smart Parking Assist operation.
ś Press the Remote Start button after the door is
locked with the engine off to start the engine
Remote Start
remotely.
button
ś Press the Remote Start button while Remote
Operation function is operating to end function
Smart
operation.
key
Forward
button
ś When using the Remote Operation function, the
vehicle moves in the direction of the button while
Backward
the button is pressed.
button
7-129
CarManuals2.com
Driver Assistance System
Remote Operation
Operating order
1. Getting ready to remotely move forward
and backward
There are two ways to operate the
Remote Operation function.
ONX4070076
OTM070178L
Method 1: Using the function with
engine off.
(1) Within a certain range from your
vehicle press the door lock (
)
OTM070223L
button on the smart key and lock
all doors.
Method 2: Using the function with
engine on
(2) Press and hold the Remote Start
(
) button within 4 seconds until
(1) Park the vehicle in front of the
the engine starts.
space where you want to use
Remote Operation function, and
ś For more details on remotely
then shift the gear to P (Park).
starting the engine, refer to
the "Remote Start" section in
(2) Press and hold the Parking/View
Chapter 6.
(
) button to turn on Smart
Parking Assist. The "Under Remote
Control" message appears on the
infotainment system screen.
(3) Get out of your vehicle with the
smart key and close all doors.
Information
Agree must be selected on the
infotainment system screen and the
infotainment system has to operate
properly to use the Remote Operation
function.
7-130
CarManuals2.com
07
2. Remotely moving forward and
(3) Get in your vehicle with the smart
backward
key or press the Remote Start
(
) button on the smart key from
outside the vehicle.
ś A message appears informing
you that remotely moving your
vehicle forward or backward is
complete on the infotainment
system screen. The gear is
shifted to P (Park) and the EPB
(Electronic Parking Brake) is
applied.
ś The engine remains on if you are
OTM070084L
in the vehicle. The engine turns
(1) Press and hold one of the Forward
off if you press the Remote Start
(
) or Backward (
) button on
(
) button.
the smart key.
ś Remote Smart Parking Assist
automatically controls the
steering wheel, vehicle speed,
and gearshift. Your vehicle moves
in the direction of the button
pressed.
ś If you do not hold down the
Forward (
) or Backward (
)
button, your vehicle stops and
function control pauses. The
function starts operating again
when the button is pressed and
held again.
(2) When your vehicle reaches the
target location, release the smart
key Forward (
) or Backward (
)
button.
7-131
CarManuals2.com
Driver Assistance System
Information
WARNING
ś
Check that all smart keys are outside
ś
When using Remote Operation
your vehicle before using the Remote
function, make sure all passengers
Operation function.
have exited your vehicle and are
standing in a safe location away from
ś
Remote Operation function operates
your vehicle.
only when the smart key is within 13
feet (4 m) from your vehicle. If there
ś
If your vehicle’s battery is discharged
is no vehicle movement even when
or Remote Smart Parking Assist
the Forward or Backward button is
malfunctions when parked in a narrow
pressed on the smart key, check the
parking space, the Remote Operation
distance from the vehicle and press
function does not operate. Always
the button again.
park your vehicle in a space wide
enough for you to get in or out of your
ś
The detection range of the smart key
may differ depending on radio waves
vehicle.
in the area such as transmission
ś
Depending on the parking space or
towers or broadcast stations.
the movement of other vehicle after
you have parked, you may not be
ś
When remotely moving forward
able to exit from the space using the
using Method 1, it is intended to
Remote Operation function.
be a departure scenario, and your
vehicle moves 13 feet (4 m) to check
ś
Before leaving your vehicle, close the
for pedestrians, animals, or objects
windows and sunroof. Make sure the
around your vehicle. Your vehicle
engine is off before locking the doors.
makes small steering changes when
driving forward.
ś
When remotely moving forward
using Method 2, it is recognized as a
parking situation, and immediately
controls the steering wheel depending
on the condition ahead to assist
with entering the parking space and
aligning your vehicle. The function
performance may be reduced
depending on the pedestrians,
animals, and objects near your vehicle
or other factors.
ś
When moving remotely backward,
both Method 1 and 2 align the steering
wheel and then only move your
vehicle in a straight path.
7-132
CarManuals2.com
07
Remote Operation function
How to turn off Remote Forward/
operation status
Backward function while operating
ś Press the Parking/View (
) button
Hazard
Operation
while the infotainment system screen
Smart key LED
warning
guides you using Method 2.
status
light
ś Shift the gear except to P (Park)
Green LED
Under
while the infotainment system screen
continuously
-
control
guides you using Method 2.
blinks
ś Press the Parking Safety (
) button
Red LED
or select Cancel on the infotainment
Pause
continuously
Blinks
system screen.
blinks
ś Press the Remote Start (
) button
Red LED
Blinks 3
on the smart key while the vehicle
illuminates for
Off
times and
is being controlled by the Remote
4 seconds and
turns off
Operation function. Remote Operation
then turns off
function and the engine turn off.
Green LED
Blinks 1
ś Get on your vehicle with the smart
illuminates for
Complete
time and
key. Remote Operation function turns
4 seconds and
turns off
off and the engine remains on.
then turns off
Information
ś Operation status by the hazard
warning light may not be available
based on the regulation of your state.
ś If the smart key is not within the
operating range from the vehicle
(about 13 feet (4 m)), the smart key
LED does not illuminate or blink. Use
the smart key within the operating
range.
7-133
CarManuals2.com
Driver Assistance System
The function pauses in the following
The function cancels in the following
conditions when:
conditions when:
ś There is a pedestrian, animal, or
ś
The steering wheel is turned.
object detected in the direction your
ś
The gear is shifted while your vehicle
vehicle is moving.
is moving.
ś A door or the liftgate is open.
ś
Electronic Parking Brake is operating
ś The Forward (
) or Backward (
)
while your vehicle is moving.
button is not continuously pressed.
ś
The hood is opened.
ś Multiple buttons are pressed
ś
The brake pedal or accelerator pedal
simultaneously on a smart key.
is depressed when all the doors are
ś The smart key is not within 13 feet (4
closed.
m) from your vehicle.
ś
The smart key is outside your vehicle
ś A button on another smart key is
when the brake pedal is depressed
pressed in addition to the operating
while the driver's door is open.
smart key.
ś
Rapid acceleration occurs.
ś Blind-Spot Collision-Avoidance
ś
Vehicle skid occurs.
Assist or Rear Cross-Traffic Collision-
ś
An obstacle prevents the wheel from
Avoidance Assist operates when your
moving.
vehicle is backing while remotely
controlled.
ś
About 3 minutes and 50 seconds
have passed since Remote Operation
ś Your vehicle moves about 22 feet (7
function was initiated.
m) while the smart key is pressed
with the Remote Operation function
ś
The slope of the road exceeds the
(maximum travel distance per button
operational range.
press).
ś
The function is paused for more than
1 minute.
When Remote Operation function
ś
The total travel distance of your
is paused, your vehicle stops. If the
vehicle has exceeded about 45
condition that causes the function
feet (14 m) after Remote Operation
to pause changes, the function may
function is operated.
operate again.
ś
There is a problem with the smart key
or the smart key battery is low.
ś
ABS, TCS, or ESC system operates due
to slippery road conditions.
ś
Theft Alarm System sounds.
When Remote Operation function is
canceled, your vehicle automatically
stops, shifts the gear to P (Park), and
applies EPB (Electronic Parking Brake).
7-134
CarManuals2.com
07
Remote Smart Parking Assist
Malfunction and Limitations
Remote Smart Parking Assist
malfunction
OJX1079200L
Remote Smart Parking Assist canceled
When Remote Parking Assist is
operating, the function can be canceled,
and the "Parking Assist Canceled"
OTM070222L
warning message may appear on the
Remote Smart Parking Assist check
infotainment system screen. Other
When Remote Smart Parking Assist is
messages may appear depending on the
not working properly, the "Check Parking
given situation. Follow the instructions
Assist" warning message may appear
provided while parking your vehicle
on the infotainment system screen.
with Remote Parking Assist. Always look
If the message appears, stop using
around and pay attention when using
Remote Smart Parking Assist, and have
Remote Smart Parking Assist.
the vehicle inspected by an authorized
HYUNDAI dealer.
OTM070221L
Remote Smart Parking Assist standby
The "Parking Assist Conditions Not
Met" message may appear on the
infotainment system screen if:
ś Parking/View (
) button has been
pressed and held. After a while, press
and hold the Parking/View (
)
button again to see if Remote Smart
Parking Assist operates.
ś The smart key's battery is low. Check
the battery and replace it if needed.
7-135
CarManuals2.com
Driver Assistance System
Limitations of Remote Smart Parking
ś
The parking space is near a vehicle
Assist
with higher ground clearance or a
larger vehicle such as truck.
In the following circumstances, the use
of Remote Smart Parking Assist may be
ś
The parking space is inclined.
limited, there may be a risk of collision,
ś
There is a heavy wind.
or Remote Smart Parking Assist may turn
ś
Remote Smart Parking Assist is
off. You may have to park your vehicle
operating on uneven roads, gravel
or drive away from the parked location
roads, bushes, etc.
without using this function.
ś
The weather is very hot or cold.
ś
An object is attached to the steering
wheel.
ś
The ultrasonic sensor is covered or
blocked with snow, water, or dirt.
ś
Your vehicle has snow chains, spare
ś
A wireless transmission device
tire, or different size wheels installed.
operates near the ultrasonic sensors.
ś
Tire pressure is lower or higher than
ś
An ultrasonic sensor with a similar
the standard tire pressure.
frequency is near your vehicle.
ś
Your vehicle is loaded with cargo
ś
A sensor has been damaged or
longer or wider than your vehicle or
a trailer or hitch mounted carrier is
scratched by a sharp object.
connected to your vehicle.
ś
When the ultrasonic sensor cannot
detect the following objects:
ś
There is an issue with the wheel
alignment.
- Narrow or slim objects such as
ropes, chains, or small poles
ś
Your vehicle is leaning severely to one
side.
- Objects less than 40 inches (100
cm) in height and narrower than 6
ś
Your vehicle is equipped with a trailer
hitch.
inches (14 cm) in diameter
ś
The license plate is installed in a
- Objects that tend to absorb sensor
frequency such as clothes, spongy
location different from the intended
location.
material, or snow
- Pedestrians, animals, or objects
ś
There is a person, animal, or object
above or below the ultrasonic sensor
that are very close to the ultrasonic
sensors
when Remote Smart Parking Assist is
activated.
ś
The parking space is narrow, curved
or angled.
ś
There is an obstacle such as person,
animal, or object (trash can, bicycle,
motorcycle, shopping cart, narrow
pillar, etc.) detected near the parking
space.
ś
There is a circular pillar or narrow
pillar, or a pillar surrounded by objects
such as fire extinguisher detected
near the parking space.
ś
The road surface is bumpy (curbstone,
speed bump, etc.) or slippery.
7-136
CarManuals2.com
07
Remote Smart Parking Assist may not
ś Parking behind a truck
operate normally under the following
circumstances:
ś Parking on inclines
ONX4H072008N
Do not use Remote Smart Parking
Assist around vehicles with higher
ONX4A073013
ground clearance such as bus or
truck, etc. The other vehicle may
Operate Remote Smart Parking Assist
not be detected and may cause a
manually on inclines.
collision.
ś Parking on uneven road
ś Parking near a pillar
ONX4H072007N
ONX4A073014
Remote Smart Parking Assist may
Remote Smart Parking Assist
cancel when your vehicle slips or
performance may be reduced when
cannot move due to road conditions
there is a narrow object, pillar (for
such as pebbles or fragmented
example, circular shaped or edge of
stones.
a square shaped pillar, etc.), or pillar
surrounded by objects such as fire
extinguisher near the parking space.
7-137
CarManuals2.com
Driver Assistance System
ś Parking in a parking space with a
ś Parking in snow
vehicle on one side only
ONX4A073015
ONX4H072009N
Snow may interfere with sensor
If Remote Smart Parking Assist is
operation, or Remote Smart Parking
used, when parking in a parking space
Assist may cancel if the road is
with a vehicle only on one side, your
slippery where you are parking.
vehicle may cross the parking marking
on the opposite side of the parked
vehicle.
ś Parking in angled spaces
ONX4H072010N
Remote Smart Parking Assist cannot
park your vehicle in angled or diagonal
spaces. Even if your vehicle can enter
the parking space, do not use Remote
Smart Parking Assist because the
function does not operate normally.
7-138
CarManuals2.com
07
ś
If the 3rd stage warning (continuous
WARNING
beep) of Forward/Backward Parking
You are responsible for parking and
Distance Warning sounds while
exiting safely when using Remote Smart
Remote Smart Parking Assist is
Parking Assist. Make sure there are no
operating, it means the obstacle
pedestrians, animals, or objects around
detected is close to your vehicle
the vehicle when using Remote Smart
and Remote Smart Parking Assist
Parking Assist.
temporarily stops operating.
To prevent serious injury or death:
ś
Do not use Remote Smart Parking
ś
When using Remote Smart Parking
Assist when under the influence of
Assist, stay out of the path of your
alcohol.
vehicle.
ś
Do not let children or other people to
ś
A collision may occur if a pedestrian,
use the smart key.
animal, or object are in the blind spot
ś
If Remote Smart Parking Assist is
area of the sensors or are very close to
used continuously for a long period,
the sensors.
it may adversely affect Remote Smart
ś
A collision may occur if a pedestrian,
Parking Assist performance.
animal, or object suddenly enters the
ś
Remote Smart Parking Assist may
path of your vehicle while Remote
not operate normally if the vehicle
Smart Parking Assist is operating.
needs wheel alignment adjustment
ś
Do not use Remote Smart Parking
such as when the vehicle tilts to one
Assist under the influence of alcohol.
side. Have the vehicle inspected by an
authorized HYUNDAI dealer.
ś
Do not let children or other people use
the smart key.
ś
Remote Smart Parking Assist may
suddenly apply the brake to avoid
ś
Do not use Remote Smart Parking
collision.
Assist continuously for a long time. It
may adversely affect Remote Smart
ś
Use Remote Smart Parking Assist only
Parking Assist performance.
in a parking space that is large enough
for the vehicle to move safely.
ś
Remote Smart Parking Assist may
not operate normally if your vehicle
needs wheel alignment adjustment
Information
such as when your vehicle tilts to one
ś
The vehicle may move with the stop
side. Have the vehicle inspected by an
lights on when the brakes are applied
authorized HYUNDAI dealer.
by Remote Smart Parking Assist.
ś
Noise may be heard when Remote
ś
The Remote Smart Parking Assist's
Smart Parking Assist is braking or
performance may temporarily reduce
when the brake pedal is depressed.
or may turn off when the engine is
ś
Remote Smart Parking Assist may
turned on after being parked in cold
suddenly brake to help avoid a
weather for a long time.
collision.
ś
Noise may be heard when braking
ś
Only use Remote Smart Parking Assist
occurs by Remote Smart Parking
in parking spaces large enough for
Assist or when the brake pedal is
your vehicle.
depressed.
7-139
CarManuals2.com
Driver Assistance System
DRIVER ASSISTANCE SYSTEM SENSORS
The Driver Assistance system on your
Wide-side view camera
vehicle uses cameras and sensors to
detect potential hazards in the vicinity of
your vehicle.
Cameras
Front view camera
ONX4A072004
The wide-side view cameras are
mounted to the bottom of the side view
mirrors outside your vehicle.
Wide-rear view camera
ONX4A072001
The front view camera is mounted near
the top of the windshield inside your
vehicle.
Wide-front view camera
ONX4A072005
The wide-rear view camera is mounted
above the license plate holder outside
your vehicle.
ONX4A072011
The wide-front view camera is mounted
on the front grill outside your vehicle.
7-140
CarManuals2.com
07
WARNING
Radars
Front radar
To prevent serious injury or death:
ś Never disassemble the camera
sensors or camera sensor assemblies.
ś Only have the detecting sensor
replaced or repaired by an authorized
HYUNDAI dealer.
ś Never install any accessories, stickers,
or tint the front windshield.
ś Always keep the camera dry.
ś Never place any reflective objects (for
example, white paper, mirror) on the
ONX4A072002
dashboard.
The front radar is mounted behind the
ś Do not use any cleanser containing
front grill.
acid or alkaline detergents when
cleaning the camera lenses. Use only
Rear corner radar
a mild soap or neutral detergent, and
rinse thoroughly with water.
ONX4A072003
The rear corner radars are mounted near
the rear corners of your vehicle above
the bumper.
7-141
CarManuals2.com
Driver Assistance System
WARNING
Ultrasonic Sensors
Front ultrasonic sensors
To prevent serious injury or death:
ś
Never disassemble the radar or radar
assembly, and never apply any impact
on it.
ś
If there is impact on or near the radar,
the sensors may be damaged or not
be properly aligned near the radar,
even though a warning message does
not appear on the instrument cluster,
Driver Assistance system may not
operate properly. Have the vehicle
inspected by an authorized HYUNDAI
ONX4A072006
dealer.
These ultrasonic sensors are mounted to
ś
If the radars have been replaced or
the bumper outside your vehicle.
repaired, have the vehicle inspected
by an authorized HYUNDAI dealer.
Front side ultrasonic sensors
ś
Use only genuine HYUNDAI parts to
repair the bumper where the radar is
located.
ś
Do not install a license plate frame or
other objects such as bumper sticker,
film, bumper guard, or bumper wrap
near the radar.
ś
Driver Assistance system may not
work properly if the bumper has been
replaced, or the surroundings of the
radar has been damaged or painted.
ONX4A072008
ś
If a trailer or hitch mounted carrier is
attached, it may adversely affect the
These ultrasonic sensors are mounted
performance of the rear corner radar
near the front wheels outside your
or Driver Assistance system may not
vehicle.
operate.
7-142
CarManuals2.com
07
Rear side ultrasonic sensors
WARNING
To prevent serious injury or death:
ś Always keep the ultrasonic sensors
clean.
ś Do not spray the ultrasonic sensors
or the surrounding area directly with
high pressure water.
ś Do not apply objects such as bumper
sticker or bumper guard, near the
ultrasonic sensors or never apply paint
to the bumper or other locations.
ONX4A072009
ś Never disassemble or strike the
These ultrasonic sensors are mounted
ultrasonic sensors components.
near the rear wheels outside your
ś Do not modify the vehicle bumper
vehicle.
height or ultrasonic sensor
installations. Any non-factory installed
Rear ultrasonic sensors
equipment or accessories may also
interfere with the sensor performance.
ś If the ultrasonic sensors have
been forcibly moved out of proper
alignment or are damaged, have the
vehicle inspected by an authorized
HYUNDAI dealer.
ONX4A072007
These ultrasonic sensors are mounted to
the bumper outside your vehicle.
7-143
CarManuals2.com
Driver Assistance System
DECLARATION OF CONFORMITY
Front Radar
Rear Corner Radar
The radio frequency components (Front
The radio frequency components (Rear
Radar) complies :
Corner Radar) complies:
OANATEL124
OANATEL275
7-144
CarManuals2.com
8.Emergency Situations
Hazard Warning Flasher
8-2
In Case of an Emergency While Driving
8-2
If the Engine Stalls While Driving
8-2
If the Engine Stalls at a Crossroad or Crossing
8-2
If You Have a Flat Tire While Driving
8-3
If the Engine Will Not Start
8-3
Jump Starting
8-4
If the Engine Overheats
8-7
Tire Pressure Monitoring System (TPMS)
8-8
Check Tire Pressure
8-8
Tire Pressure Monitoring System
8-9
Low Tire Pressure Warning Light
8-10
Low Tire Pressure Position and Tire Pressure Telltale
8-10
TPMS Malfunction Indicator
8-11
Changing a Tire with TPMS
8-11
If You Have a Flat Tire (with Spare Tire)
8-13
Jack and Tools
8-13
Jack Label
8-14
Changing Tires
8-15
If You Have a Flat Tire (with Tire Mobility Kit)
8-20
Introduction
8-20
Notes on the safe use of the Tire Mobility Kit
8-21
Components of the Tire Mobility Kit
8-22
Using the Tire Mobility Kit
8-23
Checking the Tire Inflation Pressure
8-26
Towing
8-28
Towing Service
8-28
8
Removable Towing Hook
8-29
Emergency Towing
8-30
CarManuals2.com
Emergency Situations
HAZARD WARNING
IN CASE OF AN EMERGENCY
FLASHER
WHILE DRIVING
If the Engine Stalls While Driving
ś Reduce the speed gradually, keeping
a straight line. Move cautiously off the
road to a safe place.
ś Turn on your hazard warning flasher.
ś Try to start the engine again. If your
vehicle does not start, contact an
authorized HYUNDAI dealer or seek
other qualified assistance.
ONX4080001
If the Engine Stalls at a Crossroad
The hazard warning flashers warn other
or Crossing
drivers to exercise extreme caution when
approaching, overtaking, or passing your
If the engine stalls at a crossroad or
vehicle.
intersection, if safe to do so, shift the
gear to N (Neutral) and then push the
It should be used whenever making
vehicle to a safe location.
emergency repairs or when stopped near
the edge of a roadway.
To turn on or off the hazard warning
flasher, press the hazard warning
flasher button with the ignition switch
in any position. The hazard warning
flasher button is located in the center
fascia panel. All turn signal lights flash
simultaneously.
ś The hazard warning flasher operates
whether your vehicle is running or not.
ś The turn signals do not work when the
hazard flasher is on.
8-2
CarManuals2.com
08
IF THE ENGINE WILL NOT
If You Have a Flat Tire While
START
Driving
ś Be sure to shift the gear to N (Neutral)
If a tire goes flat while you are driving:
or P (Park). The engine starts only
when the gear is in N (Neutral) or P
ś Take your foot off the accelerator
(Park).
pedal and let the vehicle slow down
while driving straight ahead. Do not
ś Turn on the interior light. If the light
apply the brakes immediately or
dims or goes out when you operate
attempt to pull off the road because
the starter, the battery is drained.
this may cause loss of vehicle control
Refer to the instructions in “Jump
resulting in a collision. When the
Starting” provided in this chapter.
vehicle has slowed to such a speed
ś Check the fuel level and add fuel if
that it is safe to do so, brake carefully
necessary.
and pull off the road. Drive off the
If the vehicle still does not start, contact
road as far as possible and park on
an authorized HYUNDAI dealer for
a firm, level ground. If you are on a
assistance.
divided highway, do not park in the
median area between the two traffic
lanes.
NOTICE
ś When the vehicle is stopped, press the
Starting the vehicle by pushing or pulling
hazard warning flasher button, shift
may cause the catalytic converter to
the gear to P (Park), apply the parking
overload and damage the emission
brake, and move the ignition switch to
control system.
the LOCK/OFF position.
ś Have all passengers get out of the
vehicle. Make sure they all get out on
the side of the vehicle that is away
from traffic.
ś When replacing a flat tire, follow the
instructions provided later in this
chapter.
8-3
CarManuals2.com
Emergency Situations
JUMP STARTING
Jump starting can be dangerous if done
If acid gets into your eyes, flush your
incorrectly. Follow the jump starting
eyes with clean water for at least 15
procedure in this section to avoid serious
minutes and get immediate medical
injury or damage to your vehicle. If in
attention. If acid gets on your skin,
doubt about how to properly jump start
thoroughly wash the area. If you feel
your vehicle, have a service technician or
pain or a burning sensation, get medical
towing service do it for you.
attention immediately.
ś When lifting a plastic-cased battery,
excessive pressure on the case may
WARNING
cause battery acid to leak. Lift with a
To prevent SERIOUS INJURY or DEATH
battery carrier or with your hands on
to you or bystanders, always follow
opposite corners.
these precautions when working near or
ś Do not attempt to jump start your
handling the battery:
vehicle if your battery is frozen.
Always read and follow
ś NEVER attempt to recharge the
instructions carefully when
battery when the vehicle’s battery
handling a battery.
cables are connected to the battery.
ś The electrical ignition system works
Wear eye protection designed
with high voltage.
to protect the eyes from acid
NEVER touch these components
splashes.
with the engine running or when the
ignition switch is in the ON position.
Keep all flames, sparks, or
smoking materials away from
the battery.
Hydrogen gas is always present
in battery cells. It is highly
combustible, and may explode
if ignited.
Keep batteries out of reach of
children.
Batteries contain sulfuric acid
that is highly corrosive. Do not
allow acid to contact your eyes,
skin, or clothing.
8-4
CarManuals2.com
08
Jump starting procedure
1. Position the vehicles close enough
that the jumper cables can reach. Do
not allow the vehicles to touch.
2. Avoid fans or any moving parts in the
engine compartment at all times, even
when the vehicles are turned off.
3. Turn off all electrical devices such as
radios, lights, air conditioning, etc. Put
the vehicles in P (Park) and apply the
parking brake. Turn both vehicles OFF.
ONX4080003
4. Open the engine hood.
5. Connect the jumper cables in
the exact sequence shown in the
illustration. First connect one jumper
CAUTION
cable to the red, positive (+) battery
Before jump starting, make sure to
terminal of your vehicle M.
correctly identify the positive (+) and
6. Connect the other end of the jumper
negative (-) terminals to avoid reverse
cable to the red, positive (+) battery/
polarity connections.
jumper terminal of the assisting
vehicle N.
7. Connect the second jumper cable to
the black, negative (-) battery/jumper
terminal of the assisting vehicle O.
8. Connect the other end of the second
jumper cable to the chassis ground of
your vehicle P.
Do not allow the jumper cables to
contact anything except the correct
battery or jumper terminals or the
correct ground. Do not lean over the
battery when making connections.
WARNING
Do not connect the jumper cable to
the negative (-) jumper terminal of the
discharged battery. A spark could cause
the battery to explode and lead to a
personal injury or vehicle damage.
8-5
CarManuals2.com
Emergency Situations
9. Start the engine of the assisting
Information
vehicle and let it run at about 2,000
RPM for a few minutes. Then start
Always dispose of a used
your vehicle.
battery according to your local
law(s) or regulations.
10. Keep your vehicle operating for at
least 30 minutes at idle or driving
to make sure your battery receives
enough charge to be able to start on
NOTICE
its own after the vehicle is shut off. A
To prevent damage to your vehicle:
completely discharged battery may
require as long as 60 minutes runtime
ś Only use a 12-volt power supply
to fully recharge. If the vehicle is run
(battery or jumper system) to jump
for less, the vehicle may not restart.
start your vehicle.
If your vehicle does not start after a
ś Do not attempt to jump start your
few attempts, it probably requires
vehicle by push-starting.
service. Have your vehicle inspected
by an authorized HYUNDAI dealer.
WARNING
Disconnect the jumper cables in the
While jump starting your vehicle, avoid
exact reverse order you connected them:
the positive (+) and negative (-) cables
to come in contact. A spark could cause
1. Disconnect the jumper cable from the
personal injury.
chassis ground of your vehicle P.
2. Disconnect the other end of the
jumper cable from the black, negative
(-) battery/jumper terminal of the
assisting vehicle O.
3. Disconnect the second jumper cable
from the red, positive (+) battery/
jumper terminal of the assisting
vehicle N.
4. Disconnect the other end of the
jumper cable from the red, positive (+)
battery terminal of your vehicle M.
8-6
CarManuals2.com
08
IF THE ENGINE OVERHEATS
If your temperature gauge indicates
WARNING
overheating, you experience a loss of
power, hear loud pinging or knocking,
Never remove the engine
or the engine may be overheating. If this
coolant cap or the drain plug
happens, you must:
while the engine and radiator
are hot.
1. Pull off the road and stop as soon as it
is safe to do so.
Hot coolant and steam may blow out
2. Shift the gear to P (Park) and apply the
under pressure, causing serious injury.
parking brake. If the air conditioning is
Turn off the engine and wait until the
ON, turn it OFF.
engine cools down. Use extreme care
3. If engine coolant is running out under
when removing the coolant cap. Wrap
the vehicle or steam is coming out
a thick towel around it, and turn it
from the hood, stop the engine. Do
counterclockwise slowly to the first
not open the hood until the coolant
stop. Step back while the pressure is
has stopped running or the steaming
released from the cooling system. When
has stopped. If there is no visible
you are sure all the pressure has been
loss of engine coolant and no steam,
released, press down on the cap, using
leave the engine running and check
a thick towel, and continue turning
to make sure the engine cooling fan
counterclockwise to remove it.
is operating. If the fan is not running,
turn off the engine.
6. If you cannot find the cause of the
overheating, wait until the engine
WARNING
temperature has returned to normal.
Then, if coolant has been lost,
While the engine is running,
carefully add coolant to the reservoir
keep hands, clothing, and tools
to bring the fluid level in the reservoir
away from the moving parts
up to the halfway mark.
such as cooling fan and drive
7. Proceed with caution, keeping alert
belt to prevent serious injury.
for further signs of overheating. If
overheating happens again, contact
an authorized HYUNDAI dealer for
assistance.
4. Check for coolant leaking from the
radiator, hoses, or under the vehicle.
(If air conditioning has been used, it is
NOTICE
normal for cold water to be draining
ś Serious loss of coolant indicates a
from it when you stop.)
leak in the cooling system. Have the
5. If engine coolant is leaking out, stop
system inspected by an authorized
the engine immediately and call the
HYUNDAI dealer as soon as possible.
nearest authorized HYUNDAI dealer
ś When the engine overheats from
for assistance.
low engine coolant, suddenly adding
engine coolant may cause cracks
in the engine. To prevent damage,
add engine coolant slowly in small
quantities. It may require several
refilling cycles to properly fill the
engine cooling system. If necessary,
contact an authorized HYUNDAI
dealer.
8-7
CarManuals2.com
Emergency Situations
7,5( 35(6685( 021,725,1* 6<67(0 ǣ7306Ǥ
Check Tire Pressure
ONX4080004
ONX4E040019
ś
You can check the tire pressure in the
Driving Assist mode in the instrument
cluster.
Refer to the “View Modes” section in
Chapter 4.
ś
Tire pressure appears after a few
minutes of driving. If the tire pressure
does not appear when the vehicle
is stopped, the message, “Drive to
ONX4E080005
display” appears.
(1) Low Tire Pressure Telltale/TPMS
ś
The displayed tire pressure values may
Malfunction Indicator
differ from those measured with a tire
(2) Low Tire Pressure Position Telltale
pressure gauge.
and Tire Pressure Telltale (Shown on
ś
You can change the tire pressure
the cluster display)
unit from the Settings menu in the
instrument cluster or infotainment
system.
Select:
- User Settings > Units > Tire
Pressure Unit > psi, kpa, bar (for
cluster type)
- Setup > General > Units > Tire
Pressure Unit > psi, kpa, bar (for
infotainment system type)
Information
The infotainment system may change
after software updates. For more
information, refer to the user's manual
provided in the infotainment system and
the quick reference guide.
8-8
CarManuals2.com
08
Tire Pressure Monitoring System
Your vehicle has also been equipped with
a TPMS malfunction indicator to indicate
when the system is not operating
WARNING
properly. The TPMS malfunction
indicator is combined with the low
Over-inflation or under-inflation can
tire pressure telltale. When the system
reduce tire life, adversely affect vehicle
detects a malfunction, the telltale flashes
handling, and lead to sudden tire failure
for about one minute and then remains
that may cause loss of vehicle control
continuously illuminated. This sequence
resulting in an collision.
continues upon subsequent vehicle
start-ups as long as the malfunction
Each tire, including the spare (if
exists.
provided), should be checked monthly
when cold and inflated to the inflation
When the malfunction indicator is
illuminated, the system may not be able
pressure recommended by the vehicle
manufacturer on the vehicle placard
to detect or signal low tire pressure as
intended. TPMS malfunctions may occur
or tire inflation pressure label. (If your
vehicle has tires of a different size than
for a variety of reasons, including the
installation of replacement or alternate
the size indicated on the vehicle placard
or tire inflation pressure label, you should
tires or wheels on the vehicle that
prevent the TPMS from functioning
determine the proper tire inflation
pressure for those tires.)
properly.
Always check the TPMS malfunction
As an added safety feature, your
vehicle has been equipped with a tire
telltale after replacing one or more tires
or wheels on your vehicle to ensure that
pressure monitoring system (TPMS)
that illuminates a low tire pressure
the replacement or alternate tires and
wheels allow the TPMS to continue to
telltale when one or more of your tires is
significantly under-inflated. Accordingly,
function properly.
when the low tire pressure telltale
illuminates, you should stop and check
NOTICE
your tires as soon as possible, and inflate
Have the system inspected by an
them to the proper pressure. Driving on
authorized HYUNDAI dealer if:
a significantly under-inflated tire causes
the tire to overheat and can lead to tire
1. The Low Tire Pressure Telltale/TPMS
failure.
Malfunction Indicator does not
illuminate for 3 seconds when the
Under-inflation also reduces fuel
ignition switch is moved to the ON
efficiency and tire tread life, and may
position or the engine is running.
affect the vehicle’s handling and
stopping ability.
2. The TPMS Malfunction Indicator
remains illuminated after blinking for
Please note that the TPMS is not a
about 1 minute.
substitute for proper tire maintenance,
and it is the driver’s responsibility to
3. The Low Tire Pressure Position Telltale
maintain correct tire pressure, even if
remains illuminated.
under-inflation has not reached the level
to trigger illumination of the TPMS low
tire pressure telltale.
8-9
CarManuals2.com
Emergency Situations
Low Tire Pressure
The Low Tire Pressure Telltale remains on
and the TPMS Malfunction Indicator may
Warning Light
blink for one minute and then remain
illuminated (when the vehicle is driven
Low Tire Pressure Position and
about 10 minutes at the speed above 15.5
Tire Pressure Telltale
mph (25 km/h)) until you have the low
pressure tire repaired and replaced on
the vehicle.
WARNING
In winter or cold weather, the Low Tire
Pressure Telltale may be illuminated if
the tire pressure was adjusted to the
recommended tire inflation pressure
in warm weather. It does not mean
your TPMS is malfunctioning because
the decreased temperature leads to a
ONX4E040019
proportional lowering of tire pressure.
TMPS is not a substitute for manually
When you drive your vehicle from a
checking the tire pressure with a tire
warm area to a cold area or from a cold
gauge. Changes in temperature affect
area to a warm area, or the outside
tire pressure. Refer to "Check tire
temperature is greatly higher or lower,
inflation pressure" in the Maintenance
check the tire inflation pressure and
chapter for proper tire inflation and tire
adjust the tires to the recommended tire
pressure measurement procedure.
inflation pressure.
When the tire pressure monitoring
system warning indicators illuminate
and a warning message appears on the
WARNING
cluster display, one or more of your tires
Low pressure damage
are significantly under-inflated. The Low
Significantly low tire pressure makes
Tire Pressure Position Telltale indicates
the vehicle unstable and may contribute
which tire is significantly underinflated
to loss of vehicle control and increased
by illuminating the corresponding
braking distances.
position light.
Continued driving on low pressure tires
If either telltale illuminates, immediately
may cause the tires to overheat and fail.
reduce the vehicle speed, avoid hard
cornering and anticipate increased
stopping distances. Stop and check
your tires as soon as possible. Inflate the
tires to the proper pressure as indicated
on the vehicle’s placard or tire inflation
pressure label located on the driver’s
side center pillar outer panel.
If you cannot reach a service station or
the tire cannot hold the newly added air,
replace the low pressure tire with the
spare tire.
8-10
CarManuals2.com
08
TPMS Malfunction
Changing a Tire with TPMS
Indicator
If you have a flat tire, the Low Tire
Pressure and Position telltales come
The TPMS Malfunction Indicator
on. Have the flat tire repaired by an
illuminates after it blinks for about one
authorized HYUNDAI dealer as soon as
minute when there is a problem with the
possible or replace the flat tire with the
Tire Pressure Monitoring System.
spare tire.
Have the system inspected by an
authorized HYUNDAI dealer as soon as
NOTICE
possible.
Do not use a puncture-repair kit not
approved by HYUNDAI. Tire sealant not
NOTICE
approved by HYUNDAI or the equivalent
sealant specified for your vehicle may
If there is a malfunction with the TPMS,
damage the tire pressure sensor.
the individual tire pressures on the
cluster display are not be available. Have
the system inspected by an authorized
The spare tire (if equipped) does not
HYUNDAI dealer as soon as possible.
come with a tire pressure monitoring
sensor. When the low pressure tire or the
flat tire is replaced with the spare tire,
NOTICE
the Low Tire Pressure Telltale remains
The TPMS Malfunction Indicator may
on. Also, the TPMS Malfunction Indicator
illuminate after blinking for one minute if
illuminates after blinking for one minute
the vehicle is near electric power supply
if the vehicle is driven at the speed above
cables or radio transmitters such as
15.5 mph (25 km/h) for about 10 minutes.
police stations, government and public
Once the original wheel equipped with
offices, broadcasting stations, military
a tire pressure monitoring sensor is
installations, airports, transmitting
reinflated to the recommended pressure
towers, etc.
and reinstalled on the vehicle, the
Additionally, the TPMS Malfunction
Low Tire Pressure Telltale and TPMS
Indicator may illuminate if snow chains
Malfunction Indicator goes off within a
are used or if electronic devices such as
few minutes of driving.
computers, chargers, remote starters,
navigation, etc. are near the vehicle. This
may interfere with normal operation of
the TPMS.
8-11
CarManuals2.com
Emergency Situations
If the indicators do not turn off after
WARNING
a few minutes, visit an authorized
HYUNDAI dealer.
Tampering with, modifying, or disabling
the Tire Pressure Monitoring System
Each wheel is equipped with a tire
(TPMS) components may interfere with
pressure sensor mounted inside the tire
the system’s ability to warn the driver
behind the valve stem (except for the
of low tire pressure conditions and/or
spare tire). You must use TPMS specific
TPMS malfunctions and may void the
wheels. It is recommended that you
warranty.
always have your tires serviced by an
authorized HYUNDAI dealer.
You may not be able to identify a tire
with low pressure by simply looking at it.
Always use a good quality tire pressure
gauge to measure. Note that a tire that
is hot (from being driven) has a higher
pressure measurement than a tire that is
cold.
A cold tire means the vehicle has been
sitting for 3 hours and driven for less
than 1 mile (1.6 km) in that 3 hour period.
Allow the tire to cool before measuring
the inflation pressure. Always make sure
the tire is cold before inflating to the
recommended pressure.
WARNING
ś The TPMS cannot alert you to severe
and sudden tire damage caused by
external factors such as nails or road
debris.
ś If you feel any vehicle instability,
immediately take your foot off the
accelerator pedal, apply the brakes
gradually with light force, and slowly
move to a safe position off the road.
8-12
CarManuals2.com
08
,) <28 +$9( $ )/$7 7,5( ǣ:,7+ 63$5( 7,5( ,) (48,33('Ǥ
WARNING
Follow the instructions in this section
when replacing a tire to reduce the risk
of serious injury or death. Changing a tire
can be dangerous.
Jack and Tools
OTL065005
Turn the winged hold down bolt
counterclockwise to remove the spare
tire.
Store the spare tire in the same
compartment by turning the winged hold
down bolt clockwise.
ONX4E080033
To prevent the spare tire and tools from
M Jack handle
"rattling", store them in their proper
N Jack
locations.
O Wheel nut wrench
The jack and wheel lug wrench are stored
in the luggage compartment under the
luggage box cover.
The jack is provided for emergency tire
changing only.
OTLE065040
If it is hard to loosen the tire hold down
wing bolt by hand, you can loosen it
easily using the jack handle.
1. Put the jack handle M inside of the tire
hold-down wing bolt.
2. Turn the tire hold-down wing bolt
counterclockwise with the jack
handle.
8-13
CarManuals2.com
Emergency Situations
Jack Label
OOS067043
The actual jack label in the vehicle may differ from the illustration.
For more detailed specifications, refer to the label attached to the jack.
1. Model Name
2. Maximum allowable load
3. Always apply the parking brake before using a jack.
4. Always turn off the engine before using a jack.
5. Never put any portion of your body under the vehicle supported by a jack.
6. Only use the designated jacking locations on the frame.
7. When supporting the vehicle, have the base plate of the jack flat on the ground
under the lifting point.
8. Shift to the P (Park) position with the automatic transmission.
9. Do not jack the vehicle on an incline. Only jack the vehicle on a firm level ground.
10. Jack manufacturer
11. Production date
12. Representative company and address
8-14
CarManuals2.com
08
Changing Tires
Keep the following steps to change your
vehicle’s tire:
1. Park on a level, firm surface.
WARNING
2. Shift the gear to P (Park), apply the
Because the vehicle may slip or roll off
parking brake, and move the ignition
of a jack causing serious injury or death,
switch to the LOCK/OFF position.
take the following safety precautions:
3. Press the hazard warning flasher
ś Never place any portion of your body
button.
under the vehicle that is supported by
4. Remove the wheel lug wrench, jack,
a jack.
jack handle, and spare tire from the
ś Never attempt to change a tire in
vehicle.
the lane of traffic. ALWAYS move
the vehicle completely off the road
on a level, firm ground away from
traffic before trying to change a tire.
If you cannot find a level, firm place
off the road, call a towing service for
assistance.
ś ONLY use the jack provided with the
vehicle.
ś ALWAYS place the jack on the
designated jacking positions on the
vehicle and Never on the bumpers
or any other part of the vehicle for
ONX4080025L
jacking support.
A : Block
ś Do not start or run the engine while
5. Block both the front and rear of the
the vehicle is on the jack.
tire diagonally opposite of the tire you
are changing.
ś Do not allow anyone to remain in the
vehicle while it is on the jack.
ś Keep children away from the road and
the vehicle.
8-15
CarManuals2.com
Emergency Situations
ONX4080024L
ONX4080027L
6. Loosen the wheel nuts
8. Insert the jack handle into the jack
counterclockwise one turn each in
and turn it clockwise, raising the
the order shown above, but do not
vehicle until the tire clears the ground.
remove any wheel nuts until the tire
Make sure the vehicle is stable on the
has been raised off of the ground.
jack.
9. Loosen the lug nuts with the wheel
lug nut wrench and remove them with
your fingers. Remove the wheel from
the studs and lay it flat on the ground
out of the way. Remove any dirt or
debris from the studs, mounting
surfaces, and spare tire.
WARNING
Because the wheels may have sharp
edges, handle them carefully to avoid
ONX4080026L
possible severe injury. Before putting the
7. Place the jack at the designated
wheel into place, make sure that there
jacking position under the frame
is nothing on the hub or wheel (such as
closest to the tire you are changing.
mud, tar, gravel, etc.) that interferes with
The jacking positions are plates
the wheel from fitting solidly against the
welded to the frame with two
hub.
notches. Never jack at any other
If there is, remove it. If there is not
position or part of the vehicle to
good contact on the mounting surface
prevent the vehicle slipping off of the
between the wheel and hub, the wheel
jack or damaging the vehicle.
nuts may come loose and cause the loss
of a wheel. Loss of a wheel may result in
loss of control of the vehicle. This may
cause serious injury or death.
8-16
CarManuals2.com
08
10. Install the spare tire onto the studs of
Check the tire pressure after installing
the hub.
the compact spare tire. The compact
spare tire should be inflated to 420 kPa
11. Tighten the lug nuts with your fingers
(60 psi).
onto the studs with the smaller end of
the lug nuts closest to the wheel.
If you have a tire gauge, check the
12. Lower the vehicle to the ground
spare tire pressure (refer to the “Tires
by turning the jack handle
and Wheels” section in Chapter 10 for
counterclockwise.
tire pressure instructions.). If the spare
tire pressure is lower or higher than
the recommended, drive slowly to the
nearest service station and adjust to the
recommended pressure.
Always reinstall the valve cap after
checking or adjusting the tire pressure.
If the cap is not replaced, air may leak
from the tire. If you lose a valve cap, buy
another and install it as soon as possible.
After changing tires, secure the flat tire
and return the jack and tools to their
OTL065007
proper storage locations.
13. Use the wheel lug wrench to tighten
the wheel nuts in the order shown.
Double-check each wheel nuts until
NOTICE
they are tight. After changing tires,
Check the tire pressure as soon as
have an authorized HYUNDAI dealer
possible after installing a spare tire.
tighten the wheel nuts to their proper
Adjust it to the recommended pressure.
torque as soon as possible. Tighten
the wheel nuts to 79-94 lbf.ft (11-13
kgf.m).
8-17
CarManuals2.com
Emergency Situations
Use of compact spare tires
WARNING
Compact spare tires are designed for
ś Your vehicle has metric threads on
emergency use only. Drive carefully on
the studs and wheel nuts. During tire
the compact spare tire and always follow
changing, make sure that the nuts that
the safety precautions.
were removed are reinstalled. If you
have to replace your wheel and nuts,
make sure they have metric threads to
WARNING
avoid damaging the studs and make
To prevent compact spare tire failure and
sure the wheel is properly secured
loss of control possibly resulting in an
to the hub. Contact an authorized
collision:
HYUNDAI dealer for assistance.
ś Use the compact spare tire only in an
ś If the studs are damaged, they may
emergency.
lose their ability to retain the wheel.
This could lead to the loss of the
ś NEVER operate your vehicle over 50
wheel and a collision resulting in
mph (80 km/h).
serious injuries or death.
ś Do not exceed the vehicle’s maximum
ś If the wheel studs are damaged,
load rating or the load carrying
they may lose their ability to retain
capacity shown on the sidewall of the
the wheel. This may cause loss of
compact spare tire.
the wheel and a collision resulting in
ś Do not use the compact spare tire
serious injuries.
continuously. Repair or replace the
original tire as soon as possible to
If any of the equipment such as jack,
avoid failure of the compact spare tire.
wheel nuts, studs, or other equipment
is damaged or in poor condition, do not
attempt to change the tire and call for
assistance.
8-18
CarManuals2.com
08
When driving on the compact spare tire
NOTICE
mounted to your vehicle:
To prevent damaging the compact spare
ś Do not take this vehicle through an
tire and your vehicle:
automatic car wash after the compact
ś Drive slowly enough for the road
spare tire has been installed.
conditions to avoid all hazards, such
ś Do not use the compact spare tire on
as a potholes or debris.
any other vehicle because this tire
ś Avoid driving over obstacles. The
has been designed especially for your
compact spare tire diameter is smaller
vehicle.
than the diameter of a conventional
ś The compact spare tire’s tread life is
tire and reduces the ground clearance
shorter than a regular tire. Inspect
about 1 inch (25 mm).
your compact spare tire regularly and
ś Do not use tire chains on the compact
replace worn compact spare tires with
spare tire. Because of the smaller size,
the same size and design, mounted on
a tire chain will not fit properly.
the same wheel.
ś Do not use the compact spare tire on
ś Do not use more than one compact
any other wheels, nor should standard
spare tire at a time.
tires, snow tires, wheel covers or trim
ś Do not tow a trailer while the compact
rings be used with the compact spare
spare tire is installed.
wheel.
ś Do not suddenly accelerate or
decelerate (0~25 mph (0~40 km/h))
Information
in any driving mode. It may cause
When the original tire and wheel
leakage of transfer oil.
are repaired and reinstalled on the
vehicle, the wheel nut torque must be
set correctly. The correct wheel nut
tightening torque is 79~94 lbf.ft (11~13
kgf.m).
8-19
CarManuals2.com
Emergency Situations
,) <28 +$9( $ )/$7 7,5( ǣ:,7+ 7,5( 02%,/,7< .,7
,) (48,33('Ǥ
Introduction
With the Tire Mobility Kit you stay mobile
even after experiencing a tire puncture.
The compressor and sealing compound
system effectively and comfortably seals
most punctures in a passenger car tire
caused by nails or similar objects and
reinflates the tire.
After you ensure that the tire is properly
sealed you can drive cautiously on the
ONX4E080039
tire (distance up to 120 miles (200 km))
at a max. speed of 50 mph (80 km/h) in
For safe operation, carefully read and
order to reach a service station or tire
follow the instructions in this manual
dealer for the tire replacement.
before use.
It is possible that some tires, especially
(1) Compressor
with larger punctures or damage to the
(2) Sealant bottle
sidewall, cannot be sealed completely.
The Tire Mobility Kit is a temporary fix to
Air pressure loss in the tire may adversely
the tire and have the tire inspected by an
affect tire performance.
authorized HYUNDAI dealer as soon as
For this reason, you should avoid abrupt
possible.
steering or other driving maneuvers,
especially if the vehicle is heavily loaded
CAUTION
or if a trailer is in use.
When two or more tires are flat, do not
The Tire Mobility Kit is not designed
use the tire mobility kit because the
or intended as a permanent tire repair
sealant provided with the Tire Mobility
method and is to be used for one tire
Kit must be used for only one flat tire.
only.
This instruction shows you step by step
how to temporarily seal the puncture
WARNING
simply and reliably.
Do not use the Tire Mobility Kit to repair
Read the section “Notes on the safe use
punctures in the tire walls. This can
of the Tire Mobility Kit”.
result in an accident due to tire failure.
WARNING
WARNING
Do not use the TMK if a tire is severely
Have your tire repaired as soon as
damaged by driving run flat or with
possible. The tire may lose air pressure
insufficient air pressure.
at any time after inflating with the Tire
Only punctured areas located within the
Mobility Kit.
tread region of the tire can be sealed
using the TMK.
8-20
CarManuals2.com
08
Notes on the safe use of the Tire
ś
Do not use the Tire Mobility Kit if a tire
is severely damaged by driving run flat
Mobility Kit
or with insufficient air pressure.
ś
Park your car at the side of the road
ś
Do not remove any foreign objects
so that you can work with the Tire
such as nails or screws that have
Mobility Kit away from moving traffic.
penetrated the tire.
ś
To be sure your vehicle will not move,
ś
Provided the car is outdoors, leave the
even when you’re on fairly level
engine running. Otherwise operating
ground, always set your parking brake.
the compressor may eventually drain
ś
Only use the Tire Mobility Kit for
the car battery.
sealing/inflation passenger car tires.
ś
Never leave the Tire Mobility Kit
Only punctured areas located within
unattended while it is being used.
the tread region of the tire can be
sealed using the tire mobility kit.
ś
Do not leave the compressor running
for more than 10 minutes at a time or
ś
Do not use on motorcycles, bicycles
it may overheat.
or any other type of tires.
ś
Do not use the Tire Mobility Kit if the
ś
When the tire and wheel are
ambient temperature is below -22°F
damaged, do not use Tire Mobility Kit
(-30°C).
for your safety.
ś
In case of skin contact with the
ś
Use of the Tire Mobility Kit may not be
sealant, wash the area thoroughly
effective for tire damage larger than
with plenty of water. If the irritation
approximately 16 inch (4 mm).
persists, seek medical attention.
Please contact the nearest HYUNDAI
ś
In case of eye contact with the
dealer if the tire cannot be made
sealant, flush your eyes for at least 15
roadworthy with the Tire Mobility Kit.
minutes. If the irritation persists, seek
medical attention.
ś
In case of swallowing the sealant,
rinse the mouth and drink plenty of
water. However, never give anything
to an unconscious person and seek
medical attention immediately.
ś
Long time exposure to the sealant
may cause damage to bodily tissue
such as kidney, etc.
8-21
CarManuals2.com
Emergency Situations
Components of the Tire Mobility Kit
OTM080022
1. Speed restriction label
2. Sealant and sealant bottle
3. Connection hose of compressor and tire
4. Connector and cable for connection of power outlet
5. Holder for the sealant bottle
6. Compressor
7. ON/OFF switch
8. Pressure gauge for displaying the tire inflation pressure
9. Valve for reducing tire inflation pressure
Connectors, cable and connection hose are stored in the compressor housing.
Strictly follow the specified sequence, otherwise the sealant may escape under high
pressure.
8-22
CarManuals2.com
08
WARNING
Using the Tire Mobility Kit
Do not use the tire sealant after the
sealant has expired (for example, past
WARNING
the expiration date on the sealant
container). This can increase the risk of
tire failure.
WARNING
ś Keep out of reach of children.
ś Avoid contact with eyes.
ś Do not swallow.
ONX4080010
Detach the speed restriction label (1)
from the sealant bottle (2), and place
it in a highly visible place inside the
vehicle such as on the steering wheel to
remind the driver not to drive too fast.
OTM080025
1. Shake the sealant bottle (2).
8-23
CarManuals2.com
Emergency Situations
OTM080023
ONX4A083002
2. Remove the cover (A) of the sealant
5. Unscrew the valve cap from the
bottle (2) and compressor (6).
valve of the defective and screw
the connection hose (3) of the
compressor and tire.
NOTICE
Securely install the sealant filling hose
to the valve. If not, sealant may flow
backward, possibly clogging the filling
hose.
6. Make sure the compressor turns off by
pressing [O] of the main switch (7).
OTM080024
3. Connect the sealant bottle (2) and
compressor (6).
4. Make sure that the valve (9) for
reducing tire inflation pressure is
closed.
ONX4080012
7. Connect the cable and connector (4)
to the power outlet in the vehicle.
8. Start the vehicle.
8-24
CarManuals2.com
08
9. With the engine Start/Stop button
Distributing the sealant
position on or ignition switch position
on, switch on the compressor and
let it run for approximately 5~7
minutes to fill the sealant up to proper
pressure. (Refer to “Tire and Wheels”
section in chapter 10). The inflation
pressure of the tire after filling is
unimportant and will be checked/
corrected later.
Be careful not to overinflate the tire
and stay away from the tire when
filling it.
OOSH079022L
12. Immediately drive approximately 4~6
CAUTION
miles (7~10 km or about 10 minutes)
to evenly distribute the sealant in the
Do not attempt to drive your vehicle if
tire.
the tire pressure is below 29 psi (200
kPa). This could result in an accident
Do not exceed a speed of 50 mph (80
due to sudden tire failure.
km/h). If possible, do not fall below a
speed of 12 mph (20 km/h).
While driving, if you experience any
10. Switch off the compressor.
unusual vibration, ride disturbance or
11. Detach the hoses from the sealant
noise, reduce your speed and drive with
bottle connector and from the tire
caution until you can safely pull off of the
valve.
side of the road.
Return the Tire Mobility Kit to its storage
Call for road side service or towing.
location in the vehicle.
WARNING
Do not leave your vehicle running in
a poorly ventilated area for extended
periods of time. Carbon monoxide
poisoning and suffocation can occur.
8-25
CarManuals2.com
Emergency Situations
13. After driving approximately 4~6 miles
Checking the Tire Inflation
(7~10 km or about 10 minutes), stop at
Pressure
a safe location.
1. After driving approximately 4~6 miles
(7~10 km or about 10 minutes), stop at
a safe location.
ONX4A083001
14. Connect the connection hose (3) of
the compressor and tire into the tire
ONX4A083001
valve.
2. Connect the connection hose (3) of
15. Connect cables (4) to the power
the compressor and tire into the tire
outlet.
valve.
16. Adjust the tire inflation pressure to the
3. Connect cables (4) to the power
recommended tire inflation.
outlet.
With the engine Start/Stop button
4. Adjust the tire inflation pressure to the
position on or ignition switch position
recommended tire inflation.
on, proceed as follows.
With the engine Start/Stop button
- To increase the inflation pressure:
position on or ignition switch position
Switch on the compressor.
on, proceed as follows.
To check the current inflation
- To increase the inflation pressure:
pressure setting, briefly switch off
Switch on the compressor.
the compressor.
To check the current inflation
- To reduce the inflation pressure:
pressure setting, briefly switch off
Press the button (9) on the
the compressor.
compressor.
- To reduce the inflation pressure:
Press the button (9) on the
NOTICE
compressor.
Do not let the compressor run for more
than 10 minutes, otherwise the device
NOTICE
will overheat and may be damaged.
Do not let the compressor run for more
than 10 minutes, otherwise the device
will overheat and may be damaged.
8-26
CarManuals2.com
08
Information
WARNING
The pressure gauge may show higher than
The tire inflation pressure must be
actual reading when the compressor is
inflated to the proper pressure (Refer
running. To get an accurate tire pressure,
to “Tire and Wheels” section in chapter
the compressor needs to be turned off.
10). If it is not, do not continue driving.
Call for road side service or towing.
CAUTION
If the inflation pressure is not
CAUTION
maintained, drive the vehicle a second
Tire pressure sensor
time, refer to Distributing the sealant.
The sealant on the tire pressure sensor
Then repeat steps 11 to 14.
and wheel should be removed when
Use of the TMK may be ineffectual for
you replace the tire with a new one and
tire damage larger than approximately
inspect the tire pressure sensors. Get
0.16 in (4 mm).
this done at an authorized dealer.
Contact an authorized HYUNDAI dealer
if the tire cannot be made roadworthy
with the Tire Mobility Kit.
Information
When reinstalling the repaired or replaced
tire and wheel on the vehicle, tighten the
wheel nut to 79~94 lbf·ft (11~13 kgf·m).
8-27
CarManuals2.com
Emergency Situations
TOWING
Towing Service
NOTICE
To prevent damage when towing:
ś Do not lift using the trailer hitch or
body and chassis parts.
ś Do not tow the vehicle with the front
wheels on the ground.
A
ONX4080016
ś Do not tow vehicles with sling-type
equipment. Only use wheel lift or
A
flatbed equipment.
ONX4080013
A : Dollies
If towing is necessary, contact an
authorized HYUNDAI dealer or a
commercial tow-truck service.
AWD vehicles must be towed with a
wheel lift and dollies or flatbed with all
ONX4080015
the wheels off the ground.
2WD vehicles can be towed with the rear
wheels on the ground (without dollies)
and the front wheels off the ground.
The use of wheel dollies or flatbed is
recommended. If any of the loaded
wheels or suspension components are
damaged or the vehicle is towed with the
front wheels on the ground, use a towing
dolly under the front wheels.
8-28
CarManuals2.com
08
When towing your vehicle without wheel
Removable Towing Hook
dollies:
1. Open the liftgate, and remove the
1. Release the EPB before turning off the
towing hook from the tool case.
engine.
„ Front
2. Place the ignition switch to the LOCK/
OFF position.
3. Change the gear to N (Neutral) while
depressing the brake pedal.
4. Place the ignition switch to the ACC
position.
NOTICE
Always shift the gear to N (Neutral) to
prevent damage to the transmission
ONX4080018
before towing.
„ Rear
ONX4E080041
2. Remove the hole cover by pressing
the lower part of the cover on the
bumper.
3. Install the towing hook by turning it
clockwise into the hole until it is fully
secured.
4. Remove the towing hook and install
the cover after use.
8-29
CarManuals2.com
Emergency Situations
Emergency Towing
WARNING
„ Front
Use extreme caution when towing the
vehicle with a cable or chain. A driver
must be in the vehicle to steer it and
operate the brakes. Passengers other
than the driver must not be in the
vehicle.
Always keep the following emergency
towing precautions:
ś
Place the ignition switch in the ACC
position so the steering wheel is not
ONX4080019
locked.
„ Rear
ś
Shift the gear to N (Neutral).
ś
Release the parking brake.
ś
Depress the brake pedal with more
force than normal because you have
reduced braking performance.
ś
More steering effort is required
because the power steering system is
disabled.
ś
Use a vehicle heavier than your own to
ONX4E080042
tow your vehicle.
If emergency towing is necessary,
ś
The drivers of both vehicles must
contact an authorized HYUNDAI dealer
communicate with each other
or a commercial tow-truck service.
frequently.
If a tow-truck service is not available
ś
Before emergency towing, check the
in an emergency, your vehicle can be
removeable hook is not broken or
temporarily towed using a cable or chain
damaged.
secured to the removeable towing hook
ś
Fasten the towing cable or chain
at the front (or rear) of the vehicle.
securely to the hook.
Perform emergency towing using cables
ś
Do not jerk the cables, chains, or
or chains on hard-surfaced roads for a
removeable hook. Apply steady and
short distance and at low speeds. The
even force.
wheels, axles, power train, steering,
and brakes must all be in good working
condition.
8-30
CarManuals2.com
08
NOTICE
Accelerate or decelerate the vehicle
in a slow and gradual manner while
maintaining tension on the tow rope
or chain to start or drive the vehicle.
16 ft.
Otherwise, tow hooks and the vehicle
may be damaged.
NOTICE
To avoid damage to your vehicle and
ONX4080022
vehicle components when towing:
ś Use a towing cable or chain less than
ś Always pull straight ahead when using
16 feet (5 m) long. Attach a white or
the towing hooks. Do not pull from the
red cloth (about 12 inches (30 cm)
side or at a vertical angle.
wide) in the middle of the cable or
ś Do not use the towing hooks to pull
chain for easy visibility.
the vehicle out of mud, sand, or other
ś Drive carefully so the towing cable or
conditions from which the vehicle
chain remains tight during towing.
cannot be driven out under its own
ś Before towing, check the automatic
power.
transmission for fluid leaks under your
ś Limit the vehicle speed to 10 mph (15
vehicle. If the automatic transmission
km/h) and drive less than 1 mile (1.5
fluid is leaking, flatbed equipment or a
km) when towing to avoid serious
towing dolly must be used.
damage to the transmission.
8-31
CarManuals2.com
9.Maintenance
Engine Compartment
9-3
Maintenance Services
9-4
Guide to Hyundai Genuine Parts
9-4
Owner’s Responsibility
9-5
Owner Maintenance Precautions
9-5
Owner Maintenance
9-6
Owner Maintenance Schedule
9-6
Scheduled Maintenance Services
9-8
Normal Maintenance Schedule
9-10
Maintenance Under Severe Usage Conditions
9-14
Explanation of Scheduled Maintenance Items
9-16
Engine Oil
9-18
Checking the Engine Oil Level
9-18
Checking the Engine Oil and Filter
9-19
Engine Coolant
9-20
Checking the Coolant Level
9-20
Changing Coolant
9-22
Brake Fluid
9-23
Checking the Brake Fluid Level
9-23
Washer Fluid
9-24
Checking the Washer Fluid Level
9-24
Air Cleaner
9-25
Filter Replacement
9-25
Cabin Air Filter
9-26
Filter Inspection
9-26
Filter Replacement
9-26
Wiper Blades
9-27
Blade Inspection
9-27
Blade Replacement
9-27
9
Battery
9-30
For Longer Battery Life
9-31
Battery Capacity Label
9-31
Battery Recharging
9-32
Reset Items
9-33
CarManuals2.com
Tires and Wheels
9-34
Tire Care
9-34
Recommended Cold Tire Inflation Pressures
9-34
Check Tire Inflation Pressure
9-35
Tire Rotation
9-36
Wheel Alignment and Tire Balance
9-37
Tire Replacement
9-37
Wheel Replacement
9-38
Tire Traction
9-38
Tire Maintenance
9-38
Tire Sidewall Labeling
9-39
Tire Terminology and Definitions
9-42
All Season Tires
9-45
Summer Tires
9-45
Snow Tires
9-46
Radial-Ply Tires
9-46
Fuses
9-47
Instrument Panel Fuse Replacement
9-48
Engine Compartment Panel Fuse Replacement
9-49
Fuse Panel Description
9-50
Light Bulbs
9-56
Headlight, Parking light, Turn Signal light, Daytime Running Light (DRL)
Replacement
9-57
Side Repeater Light Replacement
9-58
Rear Combination Light Replacement
9-58
High Mounted Stop Light Replacement
9-61
License Plate Light Replacement
9-62
Interior Light Replacement
9-62
Appearance Care
9-64
Exterior Care
9-64
Interior Care
9-69
Emission Control System
9-72
9
Crankcase Emission Control System
9-72
Evaporative Emission Control System Including Onboard Refueling Vapor
Recovery (ORVR)
9-72
Exhaust Emission Control System
9-73
Fuel Requirements
9-74
Gasoline Engine
9-74
California Perchlorate Notice
9-76
CarManuals2.com
09
ENGINE COMPARTMENT
„ Smartstream G2.5 GDI
The actual engine compartment in the vehicle may differ from the illustration.
ONX4E090004
Engine coolant reservoir
Engine oil filler cap
Brake fluid reservoir
Windshield washer fluid reservoir
Air cleaner
Fuse box
Engine oil dipstick
Battery
9-3
CarManuals2.com
Maintenance
MAINTENANCE SERVICES
Exercise the utmost care to prevent
2. Why Hyundai Genuine Parts?
damage to your vehicle and injury to
HYUNDAI Genuine Parts are
yourself whenever performing any
engineered and built to meet rigid
maintenance or inspection procedures.
manufacturing requirements.
Have your vehicle maintained and
Damage caused by using imitation,
repaired by an authorized HYUNDAI
counterfeit, or used salvage parts is
dealer. An authorized HYUNDAI dealer
not covered under the HYUNDAI New
meets HYUNDAI’s high service quality
Vehicle Limited Warranty or any other
standards and receives technical support
HYUNDAI warranty.
from HYUNDAI in order to provide you
In addition, any damage to or failure
with a high level of service satisfaction.
of HYUNDAI Genuine Parts caused
by the installation or failure of an
Guide to Hyundai Genuine Parts
imitation, counterfeit or used salvage
1. What are HYUNDAI Genuine Parts?
part are not covered by any HYUNDAI
Warranty.
HYUNDAI Genuine Parts are the parts
used by HYUNDAI Motor Company
to manufacture vehicles. They are
designed and tested for the optimum
safety, performance, and reliability for
our customers.
3. How can you tell if you are
purchasing HYUNDAI Genuine Parts?
Look for the HYUNDAI Genuine Parts
Logo on the package (see below).
HYUNDAI Genuine Parts exported
to the U.S. are packaged with labels
written only in English.
HYUNDAI Genuine Parts are only
sold through authorized HYUNDAI
Dealerships.
9-4
CarManuals2.com
09
Owner’s Responsibility
Owner Maintenance Precautions
Maintenance service and record
Inadequate, incomplete, or insufficient
retention are the owner’s responsibility.
servicing may result in operational
problems with your vehicle that could
Retain documents that show proper
cause vehicle damage or a collision that
maintenance has been performed on
results in serious injury or death.
your vehicle in accordance with the
scheduled maintenance service charts
Your vehicle must not be modified
on the following pages. You need this
in any way. Such modifications may
information to establish your compliance
adversely affect the performance, safety,
with the servicing and maintenance
or durability of your vehicle and may, in
requirements of your vehicle warranties.
addition, violate conditions of the limited
warranties covering the vehicle.
Detailed warranty information is
provided in your Owner’s Handbook &
Warranty Information booklet.
NOTICE
Repairs and adjustments required as a
Improper owner maintenance during
result of improper maintenance or a lack
the warranty period may affect
of required maintenance are not covered.
warranty coverage. For details, read the
separate Owner’s Handbook & Warranty
Information Booklet provided with the
vehicle.
9-5
CarManuals2.com
Maintenance
OWNER MAINTENANCE
WARNING
Owner Maintenance Schedule
When you stop for fuel:
Performing maintenance on the vehicle
can be dangerous. If you lack sufficient
ś Check the windshield washer fluid
knowledge, experience, or proper
level.
tools and equipment to do the work,
ś Check for low or under-inflated tires.
we recommend to have it done by an
authorized HYUNDAI dealer. Before
While operating your vehicle:
performing maintenance:
ś
Note any changes in the sound of the
ś Park your vehicle on level ground.
exhaust or any smell of exhaust fumes
Shift the vehicle to P (Park), apply the
in the vehicle.
parking brake, and move the ignition
ś
Check for vibrations in the steering
switch to the LOCK/OFF position.
wheel. Notice if there is any increased
ś Block the tires (front and back) to
steering effort or looseness in the
prevent the vehicle from moving.
steering wheel, or change in its
Remove loose clothing or jewelry that
straight-ahead position.
can become entangled in moving
ś
Notice if your vehicle constantly turns
parts.
slightly or “pulls” to one side when
ś If you must run the engine during
traveling on a smooth, level road.
maintenance, do it in an outdoor area
ś
When stopping, listen and check for
or in an area with plenty of ventilation.
unusual sounds, pulling to one side,
ś Keep flames, sparks, or smoking
increased brake pedal travel, or “hard-
materials away from the battery and
to-push” brake pedal.
fuel-related parts.
ś
If any slipping or changes in the
operation of your transmission occurs,
WARNING
check the transmission fluid level.
ś
Check the automatic transmission P
Do not touch metal parts (including strut
(Park) function.
bars) while the engine is operating or
hot to prevent serious injury. Turn off
ś
Check the parking brake.
the engine and wait until the metal parts
ś
Check for fluid leaks under your
cool down before working on the vehicle.
vehicle (water dripping from the air
conditioning system during or after
The following lists are vehicle checks and
use is normal).
inspections that should be performed
by the owner or an authorized HYUNDAI
dealer at the frequencies indicated
to help ensure safe and dependable
operation of your vehicle.
Any adverse conditions should be
brought to the attention of your
authorized HYUNDAI dealer as soon as
possible.
These Owner Maintenance vehicle
checks are generally not covered by
warranties and you may be charged for
labor, parts, and lubricants used.
9-6
CarManuals2.com
09
At least monthly:
At least twice a year:
ś Check the coolant level in the engine
ś Check the radiator, heater, and
coolant reservoir.
air conditioning hoses for leaks or
damage.
ś Check the operation of all exterior
lights, including the headlights,
ś Check the windshield washer spray
brake lights, turn signals, and hazard
and wiper operation. Clean the wiper
warning flashers.
blades with a clean cloth dampened
with washer fluid.
ś Check the inflation pressures of all
tires including the spare for tires that
ś Check the headlight alignment.
are worn, show uneven wear, or are
ś Check the muffler, exhaust pipes,
damaged.
shields, and clamps.
ś Check for loose wheel lug nuts.
ś Check the seat belts for wear and
function.
WARNING
At least once a year:
Be careful when checking your coolant
ś Clean the body and door drain holes.
level if the engine is hot. This may
result in coolant being blown out of the
ś Lubricate the door hinges and hood
opening and cause serious burns and
hinges.
other injuries.
ś Lubricate the door, hood locks, and
latches.
ś Lubricate the door rubber weather
strips.
ś Check the air conditioning system.
ś Inspect and lubricate the automatic
transmission linkage and controls.
ś Clean the battery and terminals.
ś Check the brake fluid level.
9-7
CarManuals2.com
Maintenance
SCHEDULED MAINTENANCE SERVICES
If any of the following conditions apply, follow the Maintenance Under Severe Usage
Conditions.
ś Repeated driving short distance of less than 5 miles (8 km) in normal temperature or
less than 10 miles (16 km) in freezing temperature
ś Extensive engine idling or low speed driving for long distances
ś Driving on rough, dusty, muddy, unpaved, graveled, or salt-spread roads
ś Driving in areas using salt or other corrosive materials or in very cold weather
ś Driving in heavy dust conditions
ś Driving in heavy traffic
ś Driving on uphill, downhill, or mountain roads
ś Towing a trailer or using a camper, or driving with loads on the roof
ś Driving as a patrol car, taxi, or other commercial use
ś Frequently driving at high speeds or rapid acceleration/deceleration
ś Frequently driving in stop-and-go traffic
ś Using engine oil that is not recommended (mineral type, semi-synthetic, lower
grade spec, etc.)
Information
After driving more than 10 years or 100,000 miles (160,000 km), use severe
maintenance schedule.
9-8
CarManuals2.com
09
Information
ś Engine oil is consumed while driving and the engine oil level should be checked on
regular basis.
ś The engine oil change interval under normal operating conditions is based on the
use of engine oil that meets the recommended engine specification for your vehicle.
If any other type of engine oil is used, replace the engine oil according to the
maintenance schedule under severe operating conditions.
ś The vehicle may be equipped with Oil Life Management System that predicts engine
oil life based on the driver’s driving history and alerts the driver to change engine oil.
- If the deterioration of the engine oil increases depending on the driver’s driving
severity, the remaining oil life alert appears on the instrument cluster before the
normal engine oil replacement interval. Have the engine oil and filter changed by
an authorized HYUDNAI dealer.
- Oil Life Management System works when the recommended engine oil is used.
So, if recommended engine oil is not used, replace the engine oil according to the
maintenance schedule under severe usage conditions. Also, check the amount
of engine oil regularly as this system assumes that the engine oil is being filled
normally.
- Always reset the remaining engine oil life whenever the engine oil is changed.
Otherwise, the indication of remaining Oil life in the Oil Life Management System
may not be accurate.To reset the Oil Change Reminder, select “RESET” from
the infotainment system screen. Then, select “Yes” when the message “Has the
engine oil changed? Press [Yes] to reset the oil life.” appears on the screen.
- If there is no alert until the maximum maintenance interval, have the vehicle
inspected by an authorized HYUDNAI dealer.
9-9
CarManuals2.com
Maintenance
9-10
CarManuals2.com
09
9-11
CarManuals2.com
Maintenance
9-12
CarManuals2.com
09
9-13
CarManuals2.com
Maintenance
Maintenance Under Severe Usage Conditions
The following items must be serviced more frequently on the vehicles mainly
used under severe driving conditions. Refer to the chart below for the appropriate
maintenance intervals.
R: Replace
I: Inspect and if necessary, adjust, correct, clean or replace
Maintenance
Driving
Maintenance item
Maintenance intervals
operation
condition
Engine oil and engine oil
Replace every 5,000 miles
R
D, H, I, L
filter*1
(8,000 km) or 6 months
Replace more frequently
Air cleaner filter
R
depending on the
C, E
condition
Replace more frequently
A, B, F, G, H,
Spark plugs
R
depending on the
I, K
condition
Steering gear box, linkage &
Inspect more frequently
C, D, E, F, G,
boots / lower arm ball joint,
I
depending on the
H, I
upper arm ball joint
condition
Inspect more frequently
Disc brakes and pads, calipers
C, D, G, H,
I
depending on the
and rotors
J, K
condition
Replace more frequently
Cabin air filter (for evaporator
R
depending on the
C, E
and blower unit)
condition
*1 : Requires <API SN PLUS (or above) Full synthetic> grade engine oil. If a lower grade
engine oil (mineral type, semi-synthetic, lower grade spec, etc.) is used, replace
the engine oil and engine oil filter as indicated in maintenance under severe usage
conditions.
9-14
CarManuals2.com
09
Maintenance
Maintenance
Driving
Maintenance item
operation
intervals
condition
Inspect more
Parking brake (if equipped)
I
frequently depending
C, D, G, H
on the condition
Replace more
Climate control air filter
R
frequently depending
C, E
(for evaporator and blower unit)
on the condition
Replace every 60,000
A, C, E, F, G,
Automatic transmission fluid
R
miles (96,000 km)
H, I, K
Replace every 72,000
C, D, E, G,
Rear differential oil (AWD)
R
miles (120,000 km)
H, I, J
Replace every 72,000
C, D, E, G,
Transfer case oil (AWD)
R
miles (120,000 km)
H, I, J
Inspect more
C, D, E, F,
Drive shaft
I
frequently depending
G, H, I, J
on the condition
Severe driving conditions
A. Repeatedly driving short distance of less than 5 miles (8 km) in normal temperature
or less than 10 miles (16 km) in freezing temperature
B. Extensive engine idling or low speed driving for long distances
C. Driving on rough, dusty, muddy, unpaved, graveled, or salt-spread roads
D. Driving in areas using salt or other corrosive materials or in very cold weather
E. Driving in heavy dust conditions
F. Driving in heavy traffic
G. Driving on uphill, downhill, or mountain roads
H. Towing a trailer or using a camper, or driving with loads on the roof
I. Driving as a patrol car, taxi, or other commercial use
J. Frequently driving at high speeds or rapid acceleration/deceleration
K. Frequently driving in stop-and-go traffic
L. Using engine oil that is not recommended (mineral type, semi-synthetic, lower
grade spec, etc.)
9-15
CarManuals2.com
Maintenance
EXPLANATION OF SCHEDULED MAINTENANCE ITEMS
Engine Oil and Filter
Vacuum Crankcase Ventilation
The engine oil and filter should be
Hoses
changed at the intervals specified
Visually check for proper installation,
in the maintenance schedule. If the
chafing, cracks, deterioration, and any
vehicle is driven in severe conditions,
leakage. Replace any deteriorated or
more frequent oil and filter changes are
damaged parts immediately.
required.
Air Cleaner Filter
Drive Belts
The air cleaner filter should be replaced
Inspect all drive belts for evidence
by an authorized HYUNDAI dealer.
of cuts, cracks, excessive wear, or oil
saturation. Replace them if necessary.
Spark Plugs
Check the drive belts periodically
Be sure to install new spark plugs with
for proper tension and adjusted as
the correct heat range.
necessary.
When installing new spark plugs, make
sure the ignition coils are clean and free
WARNING
of any oil or debris. Clean and wipe off
the bottom portion of the ignition coil
Always turn off the engine before
to prevent any contamination with the
inspecting the drive belts.
spark plug during installation.
Fuel Lines, Fuel Hoses and
Connections
WARNING
Check the fuel lines, fuel hoses, and
Do not remove spark plugs from the
connections for leakage and damage.
vehicle when the engine is hot. You may
Have an authorized HYUNDAI dealer
damage the engine and may also risk
replace any damaged or leaking parts
burn injury.
immediately.
Cooling System
Fuel Filter
Check the cooling system components
The fuel filter is considered to be
such as radiator, coolant reservoir,
maintenance free but periodic inspection
hoses, and connections for leakage and
is recommended depending on the fuel
damage. Replace any damaged parts.
quality. If there is fuel flow restriction,
surging, loss of power, or hard starting,
Engine Coolant
contact an authorized HYUNDAI
The coolant should be changed at
dealer to have the fuel filter replaced
intervals specified in the maintenance
immediately.
schedule.
Vapor Hose and Fuel Filler Cap
The vapor hose and fuel filler cap should
be inspected at intervals specified in the
maintenance schedule. Your HYUNDAI
dealer helps determine if replacement is
needed.
9-16
CarManuals2.com
09
Automatic Transmission Fluid
Parking Brake
The automatic transmission fluid level
Inspect the parking brake system
does not need to be checked under
including the cables.
normal usage conditions.
If driven in severe operating conditions,
Brake Discs, Pads, Calipers, and
have the automatic transmission fluid
Rotors
changed by an authorized HYUNDAI
Check the pads, the disc, and the rotor
dealer according to the maintenance
for any excessive wear-out. Inspect
schedule under severe conditions.
calipers for any fluid leakage.
Information
Drive Shaft and Related
Check the drive shaft, boots, clamps,
The color of a new automatic
rubber couplings, and center-bearing
transmission fluid is red. As the vehicle is
rubber for cracks, deterioration, or
driven, the automatic transmission fluid
damage. Replace any damaged parts
begins to look darker.
and if necessary, repack the grease.
This is normal and the automatic
transmission fluid does not need to be
Suspension Mounting Bolts
replaced based on the color change.
Check the suspension connections for
looseness or damage. Retighten to the
NOTICE
specified torque.
Only use the automatic transmission
fluid specified in the “Recommended
Steering Gear Box, Linkage &
Lubricants and Capacities” section in
Boots/Lower Arm Ball Joint
Chapter 10 to prevent transmission
With the vehicle stopped and the engine
damage.
off, check for excessive free-play in the
steering wheel. Check the linkage for
Brake Hoses and Lines
bends or damage. Check the dust boots
Visually check for proper installation,
and ball joints for deterioration, cracks,
chafing, cracks, deterioration, and any
or damage.
leakage. Replace any deteriorated or
Replace any damaged parts.
damaged parts immediately.
Air Conditioning Refrigerant
Brake Fluid
Check the air conditioning lines and
Check the brake fluid level in the brake
connections for leakage and damage.
fluid reservoir. The level should be
between the MIN and the MAX marks
on the side of the reservoir. Use only
hydraulic brake fluid conforming to DOT
4 specification.
9-17
CarManuals2.com
Maintenance
ENGINE OIL
Checking the Engine Oil Level
„ Smartstream G2.5 GDI
Engine oil is used for lubricating,
cooling, and operating various hydraulic
components in the engine. Engine oil
consumption while driving is normal,
and it is necessary to check and refill the
engine oil regularly. Also, check and refill
the oil level within the recommended
maintenance schedule to prevent
deterioration of oil performance.
ONX4092052N
Check the engine oil following the below
7. If the oil level is below the L, add
procedure.
enough oil to bring the level to F.
1. Follow all of the oil manufacturer’s
precautions.
Use only the specified engine oil (Refer
2. Make sure the vehicle is on the level
to the “Recommended Lubricants and
ground in P (Park) with the parking
Capacities” section in Chapter 10).
brake applied.
3. Turn on the engine and warm
NOTICE
the engine up until the coolant
To prevent damage to your engine:
temperature reaches a constant
ś Do not spill engine oil when adding or
normal temperature.
changing engine oil. Wipe off spilled
4. Turn off the engine, remove the oil
oil immediately.
filler cap and pull the dipstick out.
Wait for 15 minutes for the oil to return
ś The engine oil consumption may
increase while you break in the new
to the oil pan.
vehicle, and it should stabilize after
5. Wipe the dipstick clean and re-insert
driving 4,000 miles (6,000 km).
it fully.
ś The engine oil consumption may be
„ Smartstream G2.5 GDI
affected by driving habits, climate
conditions, traffic conditions, oil
quality, etc. Inspect the engine oil
level regularly and refill if necessary.
ODN8A080107
6. Pull the dipstick out again and check
the level. The level should be between
F (Full) and L (Low).
9-18
CarManuals2.com
09
Checking the Engine Oil and
Information
Filter
If the oil pressure is low, due to
insufficient engine oil, the Engine Oil
Pressure (
) warning light illuminates.
The enhanced engine protection
system that limits the engine’s power is
activated and the Malfunction Indicator
Lamp (
) illuminates. After sufficient
engine oil is added, the Engine Oil
Pressure warning light turns off and the
engine power is no longer limited.
However, for gasoline 2.5 GDI engine,
when the engine oil pressure is restored,
the warning light and the enhanced
ś
The lubrication, rust prevention,
engine protection system turns off after
cooling, and cleaning effect of the
the engine is restarted.
engine oil gradually degrades during
its use. Have the engine oil and filter
WARNING
changed by an authorized HYUNDAI
dealer according to the Oil Life
Allow the engine to cool before replacing
Management System instructions
the oil.
or the Maintenance Schedule at the
beginning of this chapter.
NOTICE
ś
To keep the engine in optimal
Never add any additives to the engine
condition, use the recommended
oil. Engine oil additives can change the
engine oil and filter. If the
properties of engine oil and may cause
recommended engine oil and filter
serious engine failure.
are not used, replace them according
to the Maintenance Schedule Under
Severe Usage Conditions.
ś
The purpose of the maintenance
schedule for engine oil replacement
is to prevent oil deterioration and it is
irrelevant to oil consumption. Check
and refill engine oil regularly.
9-19
CarManuals2.com
Maintenance
ENGINE COOLANT
The high-pressure cooling system has a
WARNING
reservoir filled with year-round antifreeze
coolant.
Never remove the engine
coolant cap or the drain plug
Check the antifreeze protection and
while the engine and radiator
coolant level at least once a year, before
are hot. Hot coolant and steam
the winter season or before traveling to a
may blow out under pressure,
colder climate.
causing serious injury.
Checking the Coolant Level
Turn the vehicle off and wait until the
engine cools down. Use extreme care
„ Smartstream G2.5 GDI
when removing the engine coolant cap.
Wrap a thick towel around it, and turn
it counterclockwise slowly to the first
stop. Step back while the pressure is
released from the cooling system. When
you are sure all the pressure has been
released, press down on the cap using
a thick towel, and continue turning
counterclockwise to remove it.
ONX4E090049
Information
Check the condition and connections
The coolant level is influenced by the
of all cooling system hoses and
engine temperature. Before checking or
heater hoses. Replace any swollen or
refilling the coolant, turn off the engine
deteriorated hoses.
and allow the engine to cool.
The coolant level should be filled
between the MAX and the MIN marks on
the side of the coolant reservoir when
the engine is cool.
If the coolant level is low, add enough
distilled (deionized) water mixed with
antifreeze to bring the level to the MAX
mark. If frequent additions are required,
contact an authorized HYUNDAI dealer.
9-20
CarManuals2.com
09
WARNING
WARNING
Make sure the coolant cap is properly
closed after refilling coolant. Otherwise,
the engine may be overheated while
driving.
„ Engine compartment front view
Keep hands, clothing, and tools away
from the rotating fan blades of the
cooling fan.
Always turn off the vehicle unless the
vehicle has to be inspected with the
engine on. The cooling fan may operate
automatically if the negative (-) battery
terminal is not disconnected.
OOSH089010L
1. Check if the coolant cap label is
straight in front.
OJX1099046
2. Make sure that the tiny protrusions
inside the coolant cap is securely
interlocked.
9-21
CarManuals2.com
Maintenance
Recommended coolant
Changing Coolant
ś When adding coolant, use only
Have the coolant changed by an
deionized water, distilled water, or soft
authorized HYUNDAI dealer according to
water for your vehicle and never mix
the Maintenance Schedule.
hard water in the coolant filled at the
factory.
NOTICE
ś An incorrect coolant mixture may
To prevent damage to engine parts, put
result in severe malfunction or engine
a thick towel around the engine coolant
damage.
cap before refilling the coolant to prevent
ś The engine in your vehicle has
the coolant from overflowing into engine
aluminum engine parts and must
parts, such as the alternator.
be protected by a phosphate-based
ethylene glycol coolant to prevent
corrosion and freezing.
ś Do not use alcohol or methanol
coolant or mix them with the specified
coolant.
ś Do not use a solution that contains
more than 60% antifreeze or less than
35% antifreeze, which could reduce
the effectiveness of the solution.
For mixing percentage, refer to the
following table:
Mixture Percentage
Ambient
(volume)
Temperature
Antifreeze
Water
5 °F (-15 °C)
35
65
-13 °F (-25 °C)
40
60
-31 °F (-35 °C)
50
50
-49 °F (-45 °C)
60
40
Information
If in doubt about the mix ratio, a 50%
water and 50% antifreeze mix is the
easiest to mix together because it is the
same quantity for each.
9-22
CarManuals2.com















Content      ..     3      4      5      6     ..
