FEATURES OF YOUR HYUNDAI
1
99
B980E01GK-GAT
Air Flow Control
OGK016095
OGK016096
Face-Level
Bi-Level
OGK046059
When selecting the "Face" mode, the indicator
When selecting the "Bi-Level" mode, the indica-
This is used to direct the flow of air. Air can be
light will come on, causing air to be discharged
tor light will come on and the air will be dis-
directed to the floor, instrument panel outlets, or
through the face level vents.
charged through the face vents and the floor
windshield. Four symbols are used to represent
Face, Bi-Level, Floor and Floor-Defrost air
vents. This makes it possible to have cooler air
position.
from the dashboard vents and warmer air from
the floor outlets at the same time.
1FEATURES OF YOUR HYUNDAI
100
B980F01GK-AAT
Defrost Switch
OGK016097
OGK016098
Floor-Level
Floor-Defrost Level
OGK046060
When selecting the "Floor-Level" mode, the
When selecting the "Floor-Defrost" mode, the
When the "Defrost" button is pressed, the " "
indicator light will come on and the air will be
indicator light will come on and the air will be
mode will be automatically selected and the air
discharged through the floor vents, windshield
discharged through the windshield defrost
will be discharged through the windshield de-
defroster nozzle, side defroster nozzle, side
nozzle, the floor vents, side defroster nozzle,
frost vents. To assist in defrosting, the air
ventilator.
side ventilator.
conditioning will operate if ambient temperature
is higher than 35.6°F (2°C) and automatically
turns off if the ambient temperature drops below
32.9 °F (0.5 °C).
FEATURES OF YOUR HYUNDAI
1
CLIMATE CONTROL AIR FILTER
101
(IN FRONT OF BLOWER UNIT)
B760A06GK-AAT
Inside air
!
Outside air
CAUTION:
Filter
o
Replace the filter every 10,000 miles
(15,000 km) or once a year. If the car is
being driven in severe conditions such
as dusty, rough roads, more frequent
climate control air filter inspections and
changes are required.
o
When the air flow rate is decreased, the
Blower fan
system should be checked at an autho-
Inside air
rized dealer.
Evaporator core
Heater core
B760A01E
The climate control air filter is located in front of
the blower unit behind the glove box.
It operates to decrease the amount of pollutants
entering the car.
To replace the climate control air filter, refer to
the page 6-16.
1FEATURES OF YOUR HYUNDAI
102
STEREO SOUND SYSTEM
B750A02A-AAT
AM reception
FM radio station
How Car Audio Works
Ionosphere
FM reception
Mountains
Unobstructed
Ionosphere
area
Buildings
Iron bridges
Obstructed area
B750A02L
B750A03L
AM broadcasts can be received at greater
FM broadcasts are transmitted at high frequen-
B750A01L
distances than FM broadcasts. This is because
cies and do not bend to follow the earth's
AM and FM radio signals are broadcast from
AM radio waves are transmitted at low frequen-
surface. Because of this, FM broadcasts gen-
transmitter towers located around your city.
cies. These long, low frequency radio waves
erally begin to fade at short distances from the
They are intercepted by the radio antenna on
can follow the curvature of the earth rather than
station. Also, FM signals are easily affected by
your car. This signal is then received by the
travelling straight out into the atmosphere. In
buildings, mountains, or other obstructions.
radio and sent to your car speakers.
addition, they curve around obstructions so that
These can result in certain listening conditions
When a strong radio signal has reached your
they can provide better signal coverage.
which might lead you to believe a problem exists
vehicle, the precise engineering of your audio
with your radio. The following conditions are
system ensures the best possible quality repro-
normal and do not indicate radio trouble:
duction. However, in some cases the signal
coming to your vehicle may not be strong and
clear. This can be due to factors such as the
distance from the radio station, closeness of
other strong radio stations or the presence of
buildings, bridges or other large obstructions in
the area.
FEATURES OF YOUR HYUNDAI
1
103
B750B05Y-AAT
Using a cellular phone or a two-way radio
When a cellular phone is used inside the vehicle,
noise may be produced from the audio equip-
ment. This does not mean that something is
wrong with the audio equipment. In such a case,
use the cellular phone at a place as far as
possible from the audio equipment.
!
WARNING:
Hyundai recommends that you never use a
B750A04L
B750A05L
cell phone while driving. This could result
o Fading - As your car moves away from the
o Station Swapping - As an FM signal weak-
in loss of control, and an accident that may
radio station, the signal will weaken and
ens, another more powerful signal near the
cause death, serious injury, or property
sound will begin to fade. When this occurs,
same frequency may begin to play. This is
damage. You must stop at a safe place to
we suggest that you select another stronger
because your radio is designed to lock onto
use a cellular phone.
station.
the clearest signal. If this occurs, select
o Flutter/Static - Weak FM signals or large
another station with a stronger signal.
obstructions between the transmitter and
o Multi-Path Cancellation - Radio signals being
NOTE:
your radio can disturb the signal causing
received from several directions can cause
Some states and cities have regulations
static or fluttering noises to occur. Reducing
distortion or fluttering. This can be caused by
prohibiting the use of cell phones while
the treble level may lessen this effect until the
a direct and reflected signal from the same
driving. You should be aware of the specific
disturbance clears.
station, or by signals from two stations with
requirements in your area.
close frequencies. If this occurs, select
another station until the condition has passed.
1FEATURES OF YOUR HYUNDAI
104
ANTENNA
B870A01A-GAT
B870D01Y-GAT
Fixed Rod Antenna
Glass Antenna (If Installed)
!
CAUTION:
o Do not clean the inner side of the rear
window glass with an abrasive type of
glass cleaner or use a scraper to remove
foreign deposits from the inner surface
of the glass as this may cause damage to
the antenna elements.
o Avoid adding metallic coating (Such as
Ni, Cd, and so on). These can disturb
receiving AM and FM broadcast signals.
OGK046085
B870A01A
Your car uses a fixed rod antenna to receive
When the radio power switch is turned on while
both AM and FM broadcast signals.
the ignition key is in either the "ON" or "ACC"
This antenna is a removable type. To remove
position, your car will receive both AM and FM
the antenna, turn the antenna counterclock-
broadcast signals through the antenna in the
wise. To install the antenna, turn the antenna
rear window glass.
clockwise.
!
CAUTION:
Be sure to remove the antenna before wash-
ing the car in an automatic car wash or the
antenna may be damaged.
FEATURES OF YOUR HYUNDAI
1
AUDIO SYSTEM
105
H280A01GK-GAT
Stereo Radio Operation (H280) (If Installed)
7
1. 2. Power Button and Volume Control
10
3. Radio Band Selection Button
4. SCAN Button
5. Automatic Channel Selection Button
3
6. Preset Button
7. Information Display Screen (LCD)
8
8. AUDIO Select Button
9. Manual Channel Selection Control (TUNE
4
Control)
10. EQ Button
1, 2
9
5
6
GK_280_NA
1FEATURES OF YOUR HYUNDAI
106
H280B01GK-GAT
5. Automatic Channel Selection Button
BASS
Turn the TUNE Controller
1. Power Button (POWER ON)
(SEEK)
clockwise to increase bass
Press this button when the ignition switch of the
tone and counterclockwise
Press the upper side of the button to automati-
automobile is set to ACC (1st notch) or ON (2nd
to decrease.
cally increase frequency and select and play
notch) to turn on the power and the audio
the receivable channel. Press the lower side of
system. Press once again when the audio
the button to automatically decrease frequency
MIDDLE
Turn the TUNE Controller
system is on to turn off the power.
and select and play the next available channel.
clockwise to increase
middle tone and counter-
2. Volume Control (VOLUME)
6. Preset Button (1~6)
clockwise to decrease.
Turn the volume control clockwise to increase
Press this button to listen to the channels
volume and counterclockwise to reduce. The
TREBLE
Turn the TUNE Controller
memorized to each button. If you want to memo-
volume level will be displayed on the screen
clockwise to increase
rize the current channel to the preset button,
when you adjust the volume.
treble tone and counter-
press the button for more than 1.5 seconds then
the channel will be memorized to the button with
clockwise to decrease.
3. Radio Band Selection Button (FM/AM)
a beep.
o Press this button to listen to either FM or AM.
BALANCE
Turn the TUNE Controller
o The radio will be set to each of the following
7. Information Display Screen (LCD)
clockwise to increase right
modes each time you press the button.
speaker volume and coun-
A variety of information will be displayed on the
FM1 ➟ FM2 ➟ AM
terclockwise to increase left
screen including the radio bands (FM1/FM2/
speaker volume.
AM) while listening to the radio, frequency of
NOTE:
each channel, the number of preset channel
Push this button when the power is off to
and "ST" for FM stereo broadcasting.
FADER
Turn the TUNE Controller
turn on the power automatically.
clockwise to increase rear
8. AUDIO Select Button
speaker volume and coun-
4. SCAN Button
Press this button to control tone. Each time you
terclockwise to increase
Press this button to automatically select chan-
press the button, the mode will switch from
front speaker volume.
nels starting from the current channel and play
BASS ➟ MIDDLE ➟ TREBLE ➟ FADER ➟
each channel for 5 seconds.
BALANCE and the mode will be displayed on the
screen.
FEATURES OF YOUR HYUNDAI
1
107
9. Manual Channel Selection Control
(TUNE)
Turn this controller while listening to the radio to
manually adjust frequency. Turn clockwise to
increase frequency and counterclockwise to
reduce frequency.
10. EQ Button
Each time you press this button the sound
equalizer setting will switch from POP ➟ JAZZ
➟ ROCK ➟ CLASSIC ➟ OFF (Not displayed).
!
CAUTION:
o Do not place beverages close to the
audio system. The audio system mecha-
nism may be damaged if you spill them.
o Do not strike or allow anything to impact
the audio system, damage to the system
mechanisms could occur.
1FEATURES OF YOUR HYUNDAI
108
H280C01GK-GAT
Cassette Tape Player Operation (H280) (If Installed)
10
1. TAPE MODE Selection Button / TAPE
Side Selection Button
2. Cassette Tape Deck
3. Tape Eject Button
1
4. DOLBY Selection Button
5. Fast Rewind
5
6. Fast Forward
7. Automatic Previous Track Selection Button
2
8. Automatic Next Track Selection Button
3
9. Section Repeat Button (REPEAT)
10. Information Display Screen (LCD)
8
7
5
6
9
4
GK_280_NA
FEATURES OF YOUR HYUNDAI
1
109
H280D01GK-GAT
4. DOLBY Selection Button
8. Automatic Next Track Selection But-
1. TAPE MODE Selection Button / TAPE
ton (TRACK UP)
Press this button when you play Dolbyized type
Side Selection Button
to reduce noise in the medium to high bands due
Press [SEEK
] button to wind the tape to the
Press this button to turn to the TAPE mode. The
to Dolby effect. The screen will display " " The
beginning of the song next to the song you are
system will play the tape if the tape is inside the
"
" mark will disappear when you press it
listening to. While winding the tape, the screen
deck and turn off CD or radio if either mode was
again.
will display "AMS." Press the button again while
on.
winding the tape to play from the current posi-
If you press this button while the tape is being
tion.
5. Fast Rewind (REW)
played, the other side of the tape will be played.
The screen will display "PLAY" along with the
Press [REW] button while playing the tape to
9. Section Repeat Button (RPT)
direction of play.
rewind the tape to the beginning and the screen
Press [RPT] button to repeat the song you are
will display "REW." Press it again while rewind-
listening to.
2. Cassette Tape Deck (Tape Insert)
ing to play from the current position.
10. Information Display Screen (LCD)
When you insert the tape, push it into the deck
6. Fast Forward (FF)
while the side of tape you want to listen to face
Various status of cassette tape will be displayed
Press [FF] button while playing the tape to wind
on the screen while listening to the tape such as
upward. If the ignition switch of the automobile
the tape to the end and the screen will display
"PLAY" while playing the tape, the direction of
is set to ACC (1st notch) or ON (2nd notch), the
"FF." Press it again while winding to play from
tape will be automatically played when you
play " or ", "FF" and "REW" for fast forward
the current position.
insert it even if the power of the audio system is
and rewind, "METAL" for playing metal tapes as
off.
well as "DOLBY" and "RPT."
7. Automatic Previous Track Selection
3. Tape EJECT Button
Button (TRACK DOWN)
Press [TRACK
] button to rewind the tape to
!
Press this button while the tape is being played
CAUTION:
the beginning of the song you are listening to.
to eject the tape.
o Do not insert anything like coins into the
While rewinding the tape, the screen will display
This will eject the tape even when the ignition
player slot as damage to the unit may
"AMS." Press the button again while rewinding
switch of the automobile is set to OFF.
occur.
the tape to play from the current position.
o Do not place beverages close to the
NOTE:
audio system. The playback mechanism
Push this button to turn the power on
may be damaged if you spill them.
automatically when the TAPE is inside and
o Do not strike or allow anything to impact
the power is off.
the audio system, damage to the system
mechanisms could occur.
1FEATURES OF YOUR HYUNDAI
110
H280E01GK-GAT
Compact Disc Player Operation (H280) (If installed)
1
1. CD Deck
3
2. CD Indicator
3. CD EJECT Button
2
4. CD Selection Button
5. Fast Backward
6. Fast Forward
4
7. Automatic Previous Track Selection Button
8. Automatic Next Track Selection Button
10
16
9. Section Repeat Button
10. Information Display Screen (LCD)
11. BOOKMAKR Button
12. RDM (Random) Button
14
13. SCROLL Button
14. FILE Search Knob
15. Directory Search Button
8
16. SCAN Button
15
7
5
6
9
12
11
13
GK_280_NA
FEATURES OF YOUR HYUNDAI
1
111
H280F01GK-GAT
5. Fast Backward (REW)
8. Automatic Next Track Selection But-
1. CD Deck
ton
Press and hold [REW] button while playing CD
Make sure the printed side of the disk faces
then the player will play the disk backwards 5
Press [SEEK
] button to go to the beginning
upward when you insert the disk. If you insert
times the regular speed for first 5 seconds and
of the song next to the song you are listening to
the disk when the ignition switch of the automo-
15 times faster after that. The sound will be
while playing the CD.
bile is set to ACC (1st notch) or ON (2nd notch),
reduced by 12dB while you are holding the
the CD Deck will automatically play CD even if
button.
the power was off. This CD Deck can play both
9. Section Repeat Button (RPT)
12cm and 8cm audio disks. If you insert video
6. Fast Forward (FF)
Press [RPT] button to repeat the song you are
CD, then the screen will display "ERROR DISC"
listening to. Press this button again to cancel
and eject the disk.
Press and hold [FF] button while playing CD
repetition.
then the player will play the disk forward 5 times
2. CD Indicator
the regular speed for first 5 seconds and 15
10. Information Display Screen (LCD)
times faster after that. The sound will be re-
This indicator light will be on if the CD is inside
Various status of the CD will be displayed on the
duced by 12dB while you are holding the button.
the CDP deck whether the audio system is on
screen while listening to the CD such as "CD"
or not. This light will go off when the CD is
while playing the CD, the track title and number,
NOTE:
ejected.
RPT, RDM and MARK.
If you press this button when the power is
off and CD is inside the deck, the power will
3. CD Eject Button
be automatically turned on.
11. BOOKMARK Button
This button lets you select the songs you want
Press [
] button to eject the disk while playing
to listen to in the CD. Move to the track and press
7. Automatic Previous Track Selection
the disk. This will eject the CD whether or not the
[MARK] for more than 1 second then the screen
ignition switch is on or off.
Button
will display "M" and select the track. Press the
button less than 1 second to play the songs you
Press [TRACK
] button to go to the beginning
4. CD Selection Button
selected and the system will display "M"
of the song you are listening to while playing the
CD. Press the button again to go to the beginning
Press this button while the disk is inside the CDP
of the song before the song you were listening
12. RDM (Random) Button
deck to listen to the CD even if the radio or tape
to. When you press this button while listening to
Press [RDM] button to play the songs in random
was on or if CD changer was in action. If you
the first track of the CD then the system will
order.
press [CD/MP3] button when the disk is ejected
move to the beginning of the last track of the CD.
and hanging in the opening, the system will
automatically insert the disk and play the CD.
1FEATURES OF YOUR HYUNDAI
112
13. SCROLL Button
NOTE:
If the title of MP3 or WMA file is too long, press
When you use CD-R or CD-RW, the CD may
!
not be played due to the manufacturing
this button to scroll the entire song title on the
CAUTION:
LCD screen.
o
Do not insert warped or poor quality
method of CD makers and the recording
discs into the CD player as damage to the
method of the user. In this case, change CD
unit may occur.
unless the continuous use of such CDs
14. FILE Search Knob
o
Do not insert anything like coins into the
may cause damage to the system.
Turn this knob to the left and right while listening
player slot as damage to the unit may
to CD to change track number. If you press the
occur.
button within 5 seconds then the selected track
o
Do not place beverages close to the
will be played. If you do not press the button
audio system. The playback mechanism
within 5 seconds then it will display the currently
may be damaged if you spill them.
played track.
o
Do not strike or allow anything to impact
the audio system, damage to the system
15. Directory Search Button
mechanisms could occur.
In case the MP3/WMA CD contains more than
o
Off-road or rough surface driving may
2 folders, press this button up and down to
cause the compact disc to skip. Do not
search each directory. You can move to the
use the compact disc when driving in
directory and turn the search knob to search
such conditions as damage to the com-
through the tracks. If you do not press the knob
pact disc face could occur.
within 5 seconds after you select a track then
o
Do not attempt to grab or pull the com-
the system will automatically return to the cur-
pact disc out while the disc is being
rent track.
pulled into the audio unit by the self-
loading mechanism. Damage to the
16. SCAN Button
audio unit and compact disc could oc-
If you press this button, the player will play 10
cur.
seconds of each track. Press it again to cancel
o
Avoid using recorded compact discs in
scanning.
your audio unit. Original compact discs
are recommended.
FEATURES OF YOUR HYUNDAI
1
113
H265A01GK-GAT
Stereo Radio Operation (H265) (If installed)
1. Power Button and Volume Control (Power
On / Volume)
2
2. Radio Band Selection Button
7
3. Automatic Channel Selection
Button(SEEK)
8
4. Manual Channel Selection Control (TUNE)
5. Preset Button
6. Information Display Screen (LCD)
7. SCAN Button
6
1
8. AUDIO Select Button
4
5
3
GK_265_NA
1FEATURES OF YOUR HYUNDAI
114
H265B01GK-GAT
3. Automatic Channel Selection Button
5. Preset Button (1~6)
1. Power Button and Volume Control
(SEEK)
Press this button but do not hold for no more than
(POWER ON/ VOLUME)
2 seconds to listen to the channels memorized
Press and hold the [
] button for more than 0.5
Press this button when the ignition switch of the
to each button. If you want to memorize the
seconds until you hear the beep to automatically
automobile is set to ACC (1st notch) or ON (2nd
current channel to the preset button when you
increase frequency and press and hold the [
notch) to turn on the power of the audio system.
are listening to channel not memorized to any of
] button for more than 0.5 seconds until you hear
When the power is turned on, turn the volume
the preset buttons, press the button and hold for
the beep to automatically decrease frequency to
control clockwise to increase volume and coun-
more than 2 seconds then the channel will be
select and play the next available channel. If the
terclockwise to reduce. Press once again when
memorized to the button with the beep.
received channel is memorized in the preset
the audio system is on to turn off the power.
buttons then the screen will display the memo-
rized channel.
6. Information Display Screen (LCD)
2. Radio Band Selection Button (FM/AM)
A variety of information will be displayed on the
North American Standard
4. Manual Channel Selection Control
screen including the radio bands (FM1/FM2/
o Press this button to listen to either FM or AM.
(TUNE)
AM) while listening to the radio, frequency of
o The radio will be set to each mode each time
each channel, the number of preset channel
you press the button in a loop;
Press and hold [
] button for less than 0.5
and "ST" for FM stereo broadcasting.
FM1➟FM2➟AM➟FM1 and soon.
seconds to increase frequency by 1 step and
[
] to decrease.
7. Automatic Channel Scan Button
European Standard
Press and hold [
] or [
] button for more than
o Press this button to listen to either FM or AM.
0.5 seconds even after you hear the beep then
Press this button to automatically select next
o The radio will be set to each mode each time
the frequency will increase or decrease quickly.
available channel and play the channel for 5
you press the button in a loop;
When you release the button, the system will
seconds and continuously move to the next
FM1➟FM2➟MW➟LW➟FM1 and soon.
turn to the automatic selection mode.
available channel and play. Press again when
you find the channel you would like to listen to
while scanning, press the button again to stop
scanning and continue to listen to the channel
you selected. And continue to listen to the
current channel.
FEATURES OF YOUR HYUNDAI
1
115
8. AUDIO Select Button
FADER
Turn the TUNE Controller
clockwise to increase rear
o Press this button to change AUDIO function
control mode.
speaker volume and coun-
Current State➟BASS➟MID➟TRE➟
terclockwise to increase
FAD➟BAL
front speaker volume.
o Select the audio control mode you want and
increase or decrease the setting by ±10 from
currently audio control mode. If no actions
are taken, the screen will return to the pre-
vious display after 3 seconds.
!
CAUTION:
o
Do not place beverages close to the
BASS
Turn the TUNE Controller
audio system. The audio system mecha-
clockwise to increase bass
nism may be damaged if you spill them.
tone and counterclockwise
o
Do not strike or allow anything to impact
to decrease.
the audio system, damage to the system
mechanisms could occur.
MIDDLE
Turn the TUNE Controller
clockwise to increase
middle tone and counter-
clockwise to decrease.
TREBLE
Turn the TUNE Controller
clockwise to increase
treble tone and counter-
clockwise to decrease.
BALANCE
Turn the TUNE Controller
clockwise to increase right
speaker volume and coun-
terclockwise to increase left
speaker volume.















Content   ..  5  6  7  8   ..
