Hyundai Santa Fe XL (2019 year). Instruction - part 14





Features of your vehicle
INTERIOR LIGHT
Map lamp
CAUTION
■ Type A
■ Type C
Do not use the interior lights for
extended periods when the
engine is not running.
It may cause battery discharge.
WARNING
Do not use the interior lights
when driving in the dark.
ODM045258
ODM045259
Accidents
could
happen
■ Type B
■ Type D
because the view may be
obscured by interior lights.
Automatic turn off function
(if equipped)
The interior lights automatically turn
off approximately
20 minutes after
the ignition switch is turned off.
ONC045604
ONC044082
If your vehicle is equipped with the
theft alarm system, the interior lights
Press the lens (1) to turn the map lamp on or off
automatically turn off approximately
• ON (2): The map lamp and room lamp stays on at all times.
5 seconds after the system is in the
• OFF (3): The lamps are off even if a door is opened.
armed stage.
• ROOM (4): The map lamp and room lamp stays on at all times.
4 133
Features of your vehicle
DOOR (5):
Room lamp
CAUTION
- The map lamp and room lamp
Type A
comes on for approximately 30
Do not leave the lamp switches
seconds when doors are unlocked
on for an extended period of
with a transmitter or smart key as
time when the vehicle is not run-
long as the doors are not opened.
ning because the battery may
drain.
- When the ignition switch is in the
ACC or LOCK/OFF position, if
any door is opened, the map
lamp and room lamp will stay on
for approximately 20 minutes. If
the door is closed, the lamps will
ODM042260
go out in 30 seconds.
Type B
- The map lamp and room lamp will
go out immediately if the ignition
switch is changed to the ON posi-
tion with all doors closed.
- When the ignition switch is in the
ON position, if any door is opened,
the map lamp and room lamp will
stay on continuously. If the door is
closed, the lamps will go out
ODM042341
immediately.
Press the button to turn the light on
or off.
NOTICE
When the lamp is turned on by
pressing the lens (1), the lamp does
not turn off even if the switch is in
the OFF position (3).
4
134
Features of your vehicle
Luggage room lamp
Vanity mirror lamp
Glove box lamp
OXM049136
OEN046081
ODM042262
• ON : The luggage room lamp stays
Opening the lid of the vanity mirror
The glove box lamp comes on when
on at all times.
will automatically turn on the mirror
the light switch is in the parking light
light.
position or headlight position and the
• DOOR : The luggage room lamp
glove box is opened.
comes on when the liftgate
(tailgate) is opened.
CAUTION
• OFF : The luggage room lamp is off.
To prevent unnecessary charg-
ing system drain, close the van-
ity mirror cover after using the
mirror.
4 135
Features of your vehicle
WELCOME SYSTEM
Headlamp welcome
Interior light
Pocket lamp
When the headlight(light switch in
When the interior light switch is in the
When all doors are locked and
the headlight or AUTO position) is on
DOOR position and all doors (and
closed, the pocket lamp will come on
and all doors (and liftgate (tailgate))
liftgate
(tailgate)) are locked and
for 15 seconds if any of the below is
are locked and closed, the headlight,
closed, the room lamp will come on
performed.
position light and tail light will come
for 30 seconds if any of the below is
• Without smart key system
on for 15 seconds if any of the below
performed.
- When the door unlock button is
is performed.
• Without smart key system
pressed on the transmitter.
• Without smart key system
- When the door unlock button is
• With the smart key system
- When the door unlock button is
pressed on the transmitter.
- When the door unlock button is
pressed on the transmitter.
• With the smart key system
pressed on the smart key.
• With the smart key system
- When the door unlock button is
- When the button of the outside
- When the door unlock button is
pressed on the smart key.
door handle is pressed.
pressed on the smart key.
- When the button of the outside
- When the vehicle is approached
door handle is pressed.
with the smart key in possession.
At this time, if you press the door lock
button (on the transmitter or smart
At this time, if you press the door lock
At this time, if you press the door lock
key), the lights will turn off immedi-
button, the lamps will turn off imme-
button, the lamps will turn off imme-
ately.
diately.
diately.
4 136
Features of your vehicle
DEFROSTER
Rear window defroster
To activate the rear window
CAUTION
defroster, press the rear window
■ Manual climate control
To prevent damage to the con-
defroster button located in the center
ductors bonded to the inside
facia switch panel.
surface of the rear window,
The indicator on the rear window
never use sharp instruments or
defroster button illuminates when the
window cleaners containing
defroster is ON.
abrasives to clean the window.
If there is heavy accumulation of
snow on the rear window, brush it off
NOTICE
before operating the rear defroster.
If you want to defrost and defog the
The rear window defroster automati-
ODM042271
front
windshield,
refer
to
cally turns off after approximately 20
■ Automatic climate control
"Windshield defrosting and defog-
minutes or when the ignition switch is
ging" in this section.
turned off. To turn off the defroster,
press the rear window defroster but-
ton again.
Outside rearview mirror defroster
(if equipped)
If your vehicle is equipped with the
outside rearview mirror defrosters,
ODM042272
they will operate at the same time
you turn on the rear window
The defroster heats the window to
defroster.
remove frost, fog and thin ice from
the rear window, while the engine is
running.
4 137
Features of your vehicle
Front wiper deicer
(if equipped)
If your vehicle is equipped with the
front wiper deicer, it will be operating
at the same time you operate the
front windshield defroster.
4 138
Features of your vehicle
MANUAL CLIMATE CONTROL SYSTEM (IF EQUIPPED)
Front climate control (Type A)
Front climate control (Type B)
1. Front windshield defrost button
2. Temperature control button
3. Air conditioning button
4. MAX A/C (Max airconditioning) button
5. Rear window defroster button
6. Air intake control button
7. Mode selection button
8. Fan speed control knob
9.3rd row climate control ON/OFF
button
3rd row air climate control (for Type A)
10.3rd row fan speed control knob
11.3rd row blower ON/OFF button
12.3rd row mode selection button
13.3rd row temperature control knob
* if equipped
ONCNCL2001/ODM042273/ONCNCL2002
4 139
Features of your vehicle
Heating and air conditioning
1. Start the engine.
2. Set the mode to the desired posi-
tion.
For improving the effectiveness of
heating and cooling;
- Heating:
- Cooling:
3. Set the temperature control to the
desired position.
4. Set the air intake control to the
outside
(fresh) air position.
(if
equipped)
5. Set the fan speed control to the
desired speed.
6. If air conditioning is desired, turn
the air conditioning system
(if
equipped) on.
ONC047083
2nd and 3
rd row outlet vents (E, F, G, H) (G, H : if equipped)
• The air flow of the 2nd and 3rd row outlet vents is controlled by the front climate
control system and delivered through the inside air duct of the floor (E, F, H).
• The air flow of the 2nd and 3rd row outlet vents (E, F, H) may be weaker than
the instrument panel vents for the long air duct.
• Close the air vents (F) in cold weather. The air flow of the 2nd and 3rd row
outlet vents may not be as warm during heating operation. (Use the 2nd and
3rd row outlet vents (F, G) during cooling operation.)
4 140
Features of your vehicle
Mode selection
MAX A/C-Level (B, D)
Bi-Level (B, D, E, C, F)
Air flow is directed towards the face
and the floor.
Floor-Level (C, A, D, E)
Most of the air flow is directed to the
floor, with a small amount of the air
being directed to the windshield, side
ODMECL2002
ODM042277
window defrosters, and side vents.
The mode selection button controls
To operate the MAX A/C, turn the fan
the direction of the air flow through
speed control knob to the right to
the ventilation system.
maximum fan speed, then press the
Floor/Defrost-Level (A, C, D, E)
MAX A/C button. Air flow is directed
toward the upper body and face.
Most of the air flow is directed to the
In this mode, the air conditioning, the
Face-Level (B, D, F)
floor and the windshield with a small
recirculated air position and max
amount directed to the side window
cool temperature will be selected
Air flow is directed toward the upper
defrosters, and side vents.
automatically.
body and face. Additionally, each
outlet can be controlled to direct the
air discharged from the outlet.
Defrost-Level (A, D)
Most of the air flow is directed to the
windshield with a small amount of air
directed to the side vents.
4 141
Features of your vehicle
Temperature control
Air intake control
Type A
ODM042279
ONCNCL2004
Instrument panel vents
Type B
ODM042280
The outlet vents can be opened or
The temperature control switch
closed separately using the thumb-
allows you to control the temperature
wheel.
of the airflow in the vehicle.
Also, you can adjust the direction of
To change the temperature:
air delivered from these vents using
• Press the
(red) switch to
the vent control lever as shown.
increase temperature.
• Press the
(blue) switch to
decrease temperature.
ODM042281
The temperature status will be dis-
This is used to select outside (fresh)
played at the above switch panel as
air position or recirculated air position.
an indicator.
To change the air intake control posi-
tion, push the control button.
4 142
Features of your vehicle
Recirculated air position
NOTICE
■ Type A, B
WARNING
The indicator light on the
Prolonged operation of the heater in
button illuminates when
the recirculated air position (with-
Continued use of the climate
the recirculated air posi-
out air conditioning selected) may
control system operation in the
tion is selected.
cause fogging of the windshield and
recirculated air position with-
With the recirculated air
side windows and the air within the
out A/C selected may allow
position selected, air
passenger compartment may
humidity to increase inside the
from the passenger
become stale.
vehicle which may fog the
compartment will be
In addition, prolonged operation of
glass and obscure visibility.
recirculated and heated
the air conditioning with the recir-
Do not sleep in a vehicle with
or cooled according to
culated air position selected will
the air conditioning or heating
the function selected.
result in excessively dry air in the
system on. This may cause
passenger compartment.
serious harm or death due to
a drop in the oxygen level
Outside (fresh) air position
and/or body temperature.
■ Type A
With the outside (fresh)
Continued use of the climate
air position selected, air
control system operation in
enters the vehicle from
the recirculated air position
outside and is heated or
may cause drowsiness or
cooled according to the
■ Type B
sleepiness and loss of vehicle
function selected.
control. Set the air intake con-
trol to the outside (fresh) air
position as much as possible
while driving.
4 143
Features of your vehicle
Fan speed control
To turn off the blowers
Air conditioning
ODM042282
ODM042283
ODM042284
The ignition switch must be in the ON
To turn off the blowers, turn the fan
Press the A/C button to turn the air
position for fan operation.
speed control knob to the "0" posi-
conditioning system on
(indicator
tion.
light will illuminate). Press the button
The fan speed control knob allows
again to turn the air conditioning sys-
you to control the fan speed of the air
tem off.
flowing from the ventilation system.
To change the fan speed, turn the
knob to the right for higher speed or
left for lower speed.
Setting the fan speed control knob to
the "0" position turns off the fan.
4 144
Features of your vehicle
2. Set the fan speed control knob (2)
System operation
3rd row climate control
to the desired position.
(if equipped)
Ventilation
3. Set the temperature control knob
Front
1. Set the mode to the
position.
(3) to the desired position.
2. Set the air intake control to the
4. Select the desired direction of the
outside (fresh) air position.
air flow by pressing the mode
selecting button (4).
3. Set the temperature control to the
desired position.
4. Set the fan speed control to the
desired speed.
Heating
ONCNCL2005
3rd row
1. Set the mode to the
position.
2. Set the air intake control to the
outside (fresh) air position.
3. Set the temperature control to the
desired position.
4. Set the fan speed control to the
desired speed.
5. If dehumidified heating is desired,
turn the air conditioning system (if
ONCNCL2002
equipped) on.
1. To turn the 3rd row climate control
• If the windshield fogs up, set the
mode to the
or
position.
on or off, press the 3rd row climate
control ON/OFF button (1 or 5).
4 145
Features of your vehicle
Operation Tips
Air conditioning
NOTICE
To prevent dust or unpleasant
HYUNDAI Air Conditioning Systems
While using the air conditioning
fumes from entering the vehicle
are filled with environmentally friend-
system, monitor the engine tem-
through the ventilation system,
ly R-134a refrigerant.
perature gauge closely while driv-
temporarily set the air intake con-
1. Start the engine. Push the air con-
ing up hills or in heavy traffic
trol to the recirculated air position.
when outside temperatures are
ditioning button.
Be sure to return the control to the
high. Air conditioning system
2. Set the mode to the
position.
fresh air position when the irritation
operation may cause engine over-
has passed to keep fresh air in the
3. Set the air intake control to the
heating. Continue to use the blow-
vehicle. This will help keep the driv-
recirculated air position. However,
er fan but turn the air condition-
er alert and comfortable.
prolonged operation of the recircu-
ing system off if the engine tem-
lated air position will excessively
Air for the heating/cooling system
perature gauge indicates engine
dry the air. In this case, change the
is drawn in through the grilles just
overheating.
air position.
ahead of the windshield. Care
Opening the windows in humid
should be taken that these are not
4. Adjust the fan speed control and
weather while operating the air
blocked by leaves, snow, ice or
temperature control to maintain
conditioning system may create
other obstructions.
maximum comfort.
water droplets inside the vehicle.
• When maximum cooling is desired,
Since excessive water droplets
To prevent interior fog on the wind-
set the temperature control to the
may cause damage to electrical
shield, set the air intake control to
extreme left position then set the
equipment, air conditioning
the fresh air position and fan speed
fan speed control to the highest
should only be used with the win-
to the desired position, turn on the
speed.
dows closed.
air conditioning system, and adjust
the temperature control to desired
temperature.
4 146
Features of your vehicle
Air conditioning system operation tips
Operating the air conditioning sys-
Climate control air filter
tem in the recirculated air position
If the vehicle has been parked in
provides maximum cooling, how-
direct sunlight during hot weather,
Outside air
ever, continual operation in this
open the windows for a short time
mode may cause the air inside the
to let the hot air inside the vehicle
Recirculated
vehicle to become stale.
escape.
air
During cooling operation, you may
To help reduce moisture inside of
the windows on rainy or humid
occasionally notice a misty air flow
because of rapid cooling and
days, decrease the humidity inside
the vehicle by operating the air
humid air intake. This is a normal
conditioning system.
system operation characteristic.
Blower
Heater core
During air conditioning system
If you operate air conditioner
Climate control
Evaporator
excessively,
the
difference
air filter
core
operation, you may occasionally
1LDA5047
notice a slight change in engine
between the temperature of the
outside air and that of the wind-
The climate control air filter installed
speed as the air conditioning com-
shield could cause the outer sur-
behind the glove box filters the dust
pressor cycles. This is a normal
face of the windshield to fog up,
or other pollutants that come into the
system operation characteristic.
causing loss of visibility. In this
vehicle from the outside through the
During the winter months, use the
case, set the mode selection knob
heating and air conditioning system.
air conditioning system every
or button to the
position and
If dust or other pollutants accumulate
month for a few minutes to ensure
fan speed control to the lower
in the filter over a period of time, the
maximum system performance.
speed.
air flow from the air vents may
When using the air conditioning
decrease, resulting in moisture accu-
system, you may notice clear water
mulation on the inside of the wind-
dripping (or even puddling) on the
shield even when the outside (fresh)
ground under the passenger side
air position is selected. If this hap-
of the vehicle. This condensation is
pens, have the climate control air filter
a normal system operation charac-
replaced by an authorized HYUNDAI
teristic.
dealer.
4 147
Features of your vehicle
NOTICE
Checking the amount of air
Air Conditioning refrigerant
conditioner refrigerant and
label
• Replace the filter according to the
compressor lubricant
Maintenance Schedule.
■ Example
If the vehicle is being driven in
When the amount of refrigerant is
severe conditions such as dusty,
low, the performance of the air con-
rough roads, more frequent cli-
ditioning is reduced. Overfilling also
mate control air filter inspections
has a negative influence on the air
and changes are required.
conditioning system.
• When the air flow rate suddenly
Therefore, if abnormal operation is
decreases, the system should be
found, have the system inspected by
checked at an authorized
an authorized HYUNDAI dealer.
HYUNDAI dealer.
WARNING
OHG045533N
Because the refriger-
The actual Air Conditioning refriger-
ant is at very high
ant label in the vehicle may differ
pressure, the air con-
from the illustration.
ditioning
system
should only be serv-
Each symbols and specification on
iced by trained and certified
air conditioning refrigerant label
technicians. It is important that
means as below ;
the correct type and amount of
oil and refrigerant is used, oth-
1. Classification of refrigerant
erwise damage to the vehicle
2. Amount of refrigerant
and personal injury may occur.
3. Classification of Compressor lubri-
cant
Refer to chapter 8 for more detail
location of air conditioning refrigerant
label.
4
148
Features of your vehicle
AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED)
Front climate control (Type A)
Front climate control (Type B)
1. Front windshield defrost button
2. Rear window defrost button
3. Display
4. Air conditioning button*
5. Mode selection button
6. SYNC button
7. Driver's temperature control button
8. Front fan speed control knob
9. AUTO (automatic control) button
10. Front blower OFF button
11. Air intake control button* or recirculated
air position button*
3rd row climate control (for Type A and B)
12.3rd row climate control ON/OFF button
(controlled from the front)
13. Passenger's temperature control button
14.3rd row fan speed control knob
15.3rd row blower ON/OFF button
16.3rd row mode selection button
17.3rd row temperature control knob
18. Climate control information screen
selection button
* if equipped
ONC046087/ONC047135N/ONCNCL2002
4 149















Content   ..  12  13  14  15   ..
