CONSUMER INFORMATION
8
5
I060A01FC-GAT
I070A01A-AAT
TIRE ROTATION
TIRE BALANCING
!
WARNING:
A tire that is out of balance may affect
o Do not use the temporary spare
handling and tire wear. The tires on
tire for tire rotation.
your Hyundai were balanced before
o Do not mix bias-ply and radial-
the car was delivered but may need
ply tires under any circum-
balancing again during the years you
stances. This may cause dan-
own the car.
gerous handling characteristics.
Whenever a tire is dismounted for
repair, it should be rebalanced before
being reinstalled on the car.
Spare tire
HA1409
Tires should be rotated every 10,000
I080A01A-AAT
km (6,000 miles). If you notice that
TIRE TRACTION
tires are wearing unevenly between
rotations, have the car checked by a
Tire traction can be reduced if you
Hyundai dealer so the cause may be
drive on worn tires, tires that are
corrected.
improperly inflated or on slippery road
After rotating, adjust the tire pres-
surfaces. Tires should be replaced
sures and be sure to check wheel nut
when tread wear indicators appear.
torque.
To reduce the possibility of losing
control, slow down whenever there is
rain, snow or ice on the road.
CONSUMER INFORMATION
8
6
I090A01HP-GAT
WHEN TO REPLACE TIRES
If you nevertheless decide to
!
WARNING:
equip your vehicle with any tire/
1.6 mm (0.06 in.)
o Driving on worn-out tires is dan-
wheel combination not recom-
gerous! Worn-out tires can cause
mended by Hyundai for off-road
loss of braking effectiveness,
driving, you should not use these
steering control and traction.
tires for highway driving.
When replacing tires, never mix
radial and bias-ply tires on the
same car. If you replace radial
Wear indicator
tires with bias-ply tires, they must
be installed in sets of four.
o Your vehicle is equipped with
I090A02FC
tires designed to provide for safe
The original tires on your car have
ride and handling capability.
tread wear indicators. The tread wear
Do not use a size and type of tire
indicators appear when the tread
and wheel that is different from
depth is 1.6 mm (0.06 in.). The tire
the one that is originally installed
should be replaced when these ap-
on your vehicle. It can affect the
pear as a solid bar across two or
safety and performance of your
more grooves of the tread. Always
vehicle, which could lead to han-
replace your tires with those of the
dling failure or rollover and seri-
recommended size. If you change
ous injury.
wheels, the new wheel's rim width
When replacing the tires, be sure
and offset must meet Hyundai speci-
to equip all four tires with the tire
fication.
and wheel of the same size, type,
tread, brand and load-carrying ca-
pacity.
CONSUMER INFORMATION
8
SPARE TIRE AND TOOLS
7
I100A01FC-GAT
D060B01FC
Your Hyundai is delivered with the
following:
Spare tire and wheel
Wheel nut wrench, Wrench bar, Span-
ner, Screw driver
Jack
VEHICLE SPECIFICATIONS
Measurement
9-2
Engine
9-3
Lubrication Chart
9-4
9
9
9 VEHICLE SPECIFICATIONS
2
J010A01FC-GAT
J030A01FC-GAT
MEASUREMENT
mm (in.)
TIRE
Standard
185/65 R14
Overall length
4,025(158.4)
Option
195/55 R15
Overall width
1,740(68.5)
205/55 R15 (1.8 DOHC only)
Overall height (unladen)
1,635(64.3)
*1,685(66.3)
J030B01FC-GAT
Wheel base
2,600(102.3)
SPARE TIRE
Wheel tread
Front
1,485 (58.5)
Standard
Temporary
Rear
1,485 (58.5)
Option
Full size
*Installed roof rack
J040A03FC-GAT
J020A01FC-GAT
ELECTRICAL
POWER STEERING
Item
GASOLINE
DIESEL
Type
Rack and pinion
Battery
MF45AH, MF60AH(12V)
CMF 68 AH
Wheel free play
0 ~ 30 mm (0 ~ 1.18 in.)
Generator
90A (13.5V)
120A (12V)
Rack stroke
146±1mm (5.7±0.04 in.)
Oil pump type
Vane type
J050A01FC-GAT
BRAKE
J060A01S-GAT
Type
Dual hydraulic with brake booster
FUEL SYSTEM
Front brake type
Ventilated disc
Fuel tank
Liter
US.gal
Imp.gal
Rear brake type
Drum
capacity
55
14.5
12
Parking brake
Cable
VEHICLE SPECIFICATIONS
9
ENGINE
3
J070A04FC-GAT
ITEMS
GASOLINE
DIESEL
Engine Type
1.6/1.8 4Cylinder in-line DOHC
1.5 4Cylinder in-line DOHC
Idle Speed (RPM)
A/CON OFF
800 ± 100 (1.6L), 750 ± 100 (1.8 L)
740 ± 100
A/CON ON
800 ± 100 (1.6L), 800 ± 100 (1.8 L)
Spark Plug
NGK
BKR5ES-11
-
Unleaded
CHAMPION
RC10YC4
-
NGK
BKR5ES
-
Leaded
CHAMPION
RC10YC
-
Spark Plug Gap
Unleaded
1.0 ~ 1.1 mm (0.039 ~ 0.043 in.)
-
Leaded
0.7 ~ 0.8 mm (0.028 ~ 0.032 in.)
-
Valve Clearance
Auto Lash (1.6 DOHC)
Intake
(Cold engine:20 ± 5°C)
0.17 ~ 0.23 mm (0.0067 ~ 0.0091 in.) (1.8DOHC)
For adjusting
Auto Lash
Auto Lash (1.6 DOHC)
Exhaust
0.25 ~ 0.31 mm (0.0098 ~ 0.0122 in.) (1.8 DOHC)
Auto Lash (1.6 DOHC)
Intake
0.12 ~ 0.28 mm (0.0047 ~ 0.011 in.) (1.8 DOHC)
For checking
Auto Lash
Auto Lash (1.6 DOHC)
Exhaust
0.20 ~ 0.38 mm (0.0079 ~ 0.015 in.) (1.8 DOHC)
Ignition Timing
BTDC 5° ± 5° (1.6L), BTDC 7° ± 5° (1.8L)
-
Firing Order
1 - 3 - 4 - 2
1 - 3 - 4 - 2
9 VEHICLE SPECIFICATIONS
LUBRICATION CHART
4
J080A07FC-GAT
Item
Oil & Grease Standard
Q'ty (liter)
Engine Oil
Gasoline
API SJ, SL
SAE 5W-20, 5W-30
1.6 DOHC - 3.3 (with oil filter)
or ABOVE,
SAE 10W-30 (ABOVE -18°C)
(3.5 us.qts., 2.9 Imp.qts)
ILSAC GF-3
SAE 15W-40 (ABOVE -13°C)
1.8 DOHC - 4.0 (with oil filter)
or ABOVE
SAE 20W-50 (ABOVE -7°C)
(4.2 us.qts., 3.5 Imp.qts)
Diesel
API CH-4
SAE 30 (0°C ~ 40°C)
1.5 CRDi - 5.3 (with oil filter)
or ABOVE,
SAE 20W-40 (ABOVE -10°C)
(5.6 us.qts., 4.7 Imp.qts)
Recommends
ACEA B4
SAE 15W-40 (ABOVE -15°C)
or ABOVE
SAE 10W-30 (-20°C ~ 40°C)
SAE 5W-30 (-25°C ~ 40°C)
SAE 0W-30 (BELOW 10°C) *1, *2
*1. Restricted to driving condition and area
*2. Not recommended for sustained high speed vehicle operation
Engine oil consumption
Normal driving condition
MAX. 1L / 1,500 Km
Severe driving condition
MAX. 1L / 1,000 Km
Transaxle
Manual
2.15 (2.3 us. qts., 1.86 Imp. qts)
HYUNDAI GENUINE PARTS MTF 75W/85 (API GL-4)
2.0 (2.11 us. qts., 1.76 Imp. qts) (1.5 CRDi)
Automatic
HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, SK ATF
6.1 (6.4 us. qts., 5.3 Imp.qts) (1.6 DOHC)
SP III or other brands approved by Hyundai Motor Co.,
6.7 (7.0 us. qts., 5.8 Imp.qts) (1.8 DOHC)
Power steering
PSF-3
As required
Brake fluid
DOT 3, DOT 4 or equivalent
As required
Gasoline : 6.2(1.6 DOHC), 6.5(1.8 DOHC)
Coolant
Ethylene glycol base for aluminum radiator
Diesel : 6.3
