1. Put a new wiper blade onto the

Replacing the Wiper Blades

wiper arm and lower the wiper blade

at the level of the wiper arm as

To replace the wiper blades, raise the

shown in the drawing.

wiper to the vertical.

To remove the wiper blade

HHR5049

2. Raise the wiper blade lightly and

pull up it.

To install the wiper blade

HHR5051

(1)

HHR5048

2. Pull up the wiper blade until you

hear an audible "click" to engage in

1. Push down the wiper blade with the

the end of the wiper arm.

locking clip (1) pressed to detach it

from the wiper arm.

NOTE:

Do not allow the wiper arm to fall

against the windshield.

HHR5050

6 DO-IT-YOURSELF MAINTENANCE

FILLING THE WASHER

CHECKING THE

RESERVOIR

TRANSAXLE OIL

G090A02A-GAT

G100A02FC-GAT

MANUAL TRANSAXLE

CAUTION:

o Radiator antifreeze (engine cool-

ant) should not be used in the

washer system because it will

damage the car's finish.

o The washer should not be oper-

ated if the washer reservoir is

empty. This can damage the

washer fluid pump.

Filler plug

Drain plug

HFC5010

The washer fluid reservoir supplies

G100A01A

fluid to the windshield washer sys-

Transaxle lubricant in the manual

tem.

WARNING:

transaxle should be checked at those

A good quality washer fluid should be

o Windshield washer fluid agents

intervals specified in the vehicle main-

used to fill the washer reservoir. The

contain some amounts of alcohol

tenance schedule in Section

fluid level should be checked more

and can be flammable under cer-

frequently during inclement weather

tain circumstances. Do not allow

Recommended Oil

or whenever the washer system is in

sparks of flame to contact the

Use only HYUNDAI GENUINE

more frequent use.

washer fluid or the washer fluid

PARTS MTF 75W/85 (API GL-4) in

The capacity of the washer reservoir

reservoir. Damage to the vehicle

the manual transaxle.

is 3.0 liters (3.2 U.S. quarts).

or its occupants could occur.

o Windshield washer fluid is poi-

Manual Transaxle Oil Capacity

sonous to humans and animals.

The oil capacity of the manual

Do not drink windshield washer

transaxle is 2.15 liters (2.3 U.S. quarts)

fluid. Serious injury or death

(2.0 liters, (2.11 U.S. quarts) -1.5 CRDi).

could occur.

DO-IT-YOURSELF MAINTENANCE

G110A02E-AAT

G110B04A-AAT

AUTOMATIC TRANSAXLE

Recommended Fluid

WARNING:

Transaxle fluid in the automatic

Your Hyundai automatic transaxle is

It is always better to check the

transaxle should be checked at those

specially designed to operate with

transaxle oil level when the engine

intervals specified in the vehicle main-

HYUNDAI GENUINE ATF SP III, DIA-

is cool or cold. If the engine is hot,

tenance schedule in Section 5.

MOND ATF SP-III, SK ATF SP III or

you should exercise great caution

other brands approved by Hundai

to avoid burning yourself on hot

NOTE:

Motor Co., Damage caused by a

engine or exhaust parts.

Automatic transaxle fluid is a red in

nonspecified fluid is not covered by

color. As driving distance increases,

your new vehicle limited warranty.

the fluid color turns darkish red

NOTE:

gradually. It is a normal condition

It is recommended that the manual

and you should not judge the need

CAUTION:

transaxle fluid should be checked

to replace based upon the changing

Use of aftermarket ATF additives

by an authorized Hyundai dealer.

color.

may cause damage to the auto-

You must replace the automatic

matic transaxle. Only use HYUNDAI

transaxle fluid in accordance with

GENUINE ATF SP III, DIAMOND

intervals specified in the vehicle

ATF SP III, SK ATF SP III or other

maintenance schedule in section

brands approved by Hyundai Mo-

tor Co., If you are having your

vehicle serviced at a facility other

than a Hyundai dealer, verify that

the correct ATF is used for your

vehicle.

6 DO-IT-YOURSELF MAINTENANCE

G110C01FC-GAT

G110D03A-GAT

Transaxle Fluid Capacity

To Check the Transaxle Fluid

Level

The fluid capacity of the automatic

transaxle is 6.1 liters (1.6 DOHC)/6.7

liters (1.8 DOHC).

WARNING:

The transaxle fluid level should be

checked when the engine is at

normal operating temperature. This

HFC5008

means that the engine, radiator,

While the engine is idling, apply the

exhaust system etc., are very hot.

brakes and move the gear selector

Exercise great care not to burn

C090A01FC

lever from "P" to each of its other

yourself during this procedure.

Park the car on level ground with the

positions -- "R", "N", "D", "2", "L" --

parking brake engaged. When the

and then return to "N" or "P". With the

transaxle fluid level is checked, the

engine still idling:

transaxle fluid should be at normal

operating temperature and the en-

1. Open the hood, being careful to

gine idling.

keep hands, long hair and clothing

clear of any moving parts.

2. Remove the transaxle dipstick, wipe

it clean, reinsert the dipstick as far

as it will go, then remove it again.

Now check the fluid level on the

dipstick. It should be in the "HOT"

range on the dipstick.

DO-IT-YOURSELF MAINTENANCE

CHECKING THE BRAKES

G120A01A-AAT

WARNING (Diesel only):

Fluid level should be within this range

CAUTION:

Never work on injection system

Because brakes are essential to

with engine running or within 30

the safe operation of the car, it is

seconds after shutting off engine.

suggested that they be checked

High pressure pump, rail, injec-

and inspected by your Hyundai

tors and high pressure pipes are

dealer. The brakes should be

subject to high pressure even af-

checked and inspected for wear at

ter the engine stopped. The fuel jet

those intervals specified in the

produced by fuel leaks may cause

C090A03FC

vehicle maintenance schedule in

serious injury, if it touch the body.

Section 5.

3. If the transaxle fluid level is low,

People using pacemakers should

use a funnel to add transaxle fluid

not move than 30cm closer to the

through the dipstick tube until the

ECU or wiring harness within the

level reaches the "HOT" range. Do

engine room while engine is run-

not overfill.

ning, since the high currents in

the Common Rail system produce

considerable magnetic fields.

WARNING:

The cooling fan is controlled by

engine coolant temperature and

may sometimes operate even when

the engine is not running. Use

extreme caution when working

near the blades of the cooling fan

so that you are not injured by a

rotating fan blade. As the engine

coolant temperature decreases, the

fan will automatically shut off. This

is a normal condition.

6 DO-IT-YOURSELF MAINTENANCE

G120B01A-AAT

G120D01A-AAT

The level should be between the "MIN"

Checking the Brake Fluid Level

To Check the Fluid Level

and "MAX" marks on the side of the

Gasoline engine

reservoir. If the level is at or below

the "MIN" mark, carefully add fluid to

WARNING:

bring it up to "MAX". Do not overfill.

Use caution when handling brake

fluid. It can damage your vision if

it gets into your eyes. It will also

damage your vehicle's paint if

spilled on it and not removed im-

mediately.

HFC5005

Diesel engine

G120C02A-AAT

Recommended Brake Fluid

Use only hydraulic brake fluid con-

forming to DOT 3 or DOT 4 specifica-

tions in your braking system. Follow

the instructions printed on the con-

tainer.

G120D02FC

The fluid level in the brake fluid reser-

voir should be checked periodically.

DO-IT-YOURSELF MAINTENANCE

CHECKING THE CLUTCH FLUID

G120E02A-AAT

G130A01S-AAT

The system should be checked for

Adding Brake Fluid

To Check the Clutch Fluid

leakage at the same time. Check to

Gasoline engine

make certain that the clutch fluid level

is always between the "MAX" and

WARNING:

"MIN" level markings on the fluid res-

Handle brake fluid carefully. It can

ervoir. Fill as required. Fluid loss indi-

damage your vision if it gets into

cates a leak in the clutch system

your eyes. Use only DOT 3 or DOT

which should be inspected and re-

4 specification fluid from a sealed

paired immediately. Consult your

container. Do not allow the fluid

Hyundai dealer.

can or reservoir to remain open

any longer than required. This will

prevent entry of dirt and moisture

HFC5005

which can damage the brake sys-

tem and cause improper opera-

Diesel engine

tion.

To add brake fluid, first wipe away

any dirt then unscrew the fluid reser-

voir cap. Slowly pour the recom-

mended fluid into the reservoir. Do

not overfill. Carefully replace the cap

on the reservoir and tighten.

G120D02FC

The clutch fluid level in the master

cylinder should be checked when

performing other under hood services.

6 DO-IT-YOURSELF MAINTENANCE

AIR CONDITIONING CARE

G130B02A-AAT

G140A01A-AAT

To Replace the Fluid

Keeping the Condenser Clean

CAUTION:

Recommended brake fluid conform-

The air conditioning condenser (and

Running the air conditioning sys-

ing to DOT 3 or DOT 4 specification

engine radiator) should be checked

tem for extended periods of time

should be used. The reservoir cap

periodically for accumulation of dirt,

with a low refrigerant level may

must be fully tightened to avoid con-

dead insects, leaves, etc. These can

damage the compressor.

tamination from foreign matter or

interfere with maximum cooling effi-

moisture.

ciency. When removing such accu-

mulations, brush or hose them away

NOTE:

carefully to avoid bending the cooling

fans.

G140C01A-AAT

Do not allow any other liquids to

Lubrication

contaminate the brake fluid. Seal

damage will result.

To lubricate the compressor and the

seals in the system, the air condition-

G140B01A-AAT

ing should be run for at least

Checking the Air Conditioning

minutes each week. This is particu-

WARNING:

Operation

larly important during cool weather

Use caution when handling brake

when the air conditioning system is

fluid. It can damage your vision if

1. Start the engine and let it run at a

not otherwise in use.

you get it in your eyes. It will also

fast idle for several minutes with

damage your vehicle's paint if

the air conditioning set at the maxi-

spilled on it and not removed im-

mum cold setting.

mediately.

2. If the air coming out of the in-dash

vents is not cold, have the air con-

ditioning system inspected by your

Hyundai dealer.

DO-IT-YOURSELF MAINTENANCE

CHANGING THE CLIMATE

CONTROL AIR FILTER

G140D01S-GAT

B140E02FC-AAT

Checking the Compressor Drive

(In Front of Blower Unit)

Belt

The climate control air filter is located

in front of the blower unit behind the

A/C

8mm

glove box.

(0.315 in.)

It helps to decrease pollutants from

entering the car.

KQNA020A

TENSION PULLEY

2. Remove the filter cover by pulling

upward the hooks of the filter cover.

CRANK PULLEY G140D01A

When the air conditioning is being

used regularly, the compressor drive

belt tension should be checked at

least once a month.

HLC2096

To check the drive belt tension, press

1. Open the glove box and remove the

down on the belt halfway between the

adjusting pins on both sides of the

engine crankshaft and compressor

glove box.

pulleys. Pressing with your finger, you

should not be able to deflect this belt

anymore than 8.0 mm. If you have

the instruments to check it with a

force of 98N (22 lb.), the deflection

should be approx. 8.0 mm (0.315 in.).

If the belt is too loose, have it ad-

justed by your Hyundai dealer.

6 DO-IT-YOURSELF MAINTENANCE

CHECKING THE FREEPLAY

G150A01A-GAT

G160A01A-GAT

Steering wheel

Clutch pedal

6 ~ 13 mm

(0.24 ~ 0.51 in.)

30 mm

KQNA020B

(1.18 in.)

3. Replace the air conditioner filter with

G150A01FC

G160A01E

a new one.

4. Installation is the reverse order of

To check the steering wheel freeplay,

With the engine off, press lightly on

disassembly.

stop the car with the wheels pointed

the clutch pedal until you feel a change

straight ahead and gently move the

in resistance. This is the clutch pedal

steering wheel back and forth. Use

freeplay. The freeplay should be within

very light finger pressure and be sen-

the limits specified in the illustration.

If it is not, have it inspected by your

sitive to changes in resistance that

CAUTION:

Hyundai dealer and adjusted or re-

mark the limits of the freeplay. If the

Be sure to install the air condi-

paired if necessary.

freeplay is greater than specified, have

tioner filter in the direction of the

it inspected by your Hyundai dealer

arrow sign. Otherwise, it may cause

and adjusted or repaired if neces-

noise or deterioration.

sary.

DO-IT-YOURSELF MAINTENANCE

CHECKING DRIVE BELTS

G170A01A-GAT

G180A01A-GAT

G190A01A-GAT

Brake pedal

CHECKING BRAKE PEDAL

Gasoline Engine

CLEARANCE

Water Pump Pulley

5~6 mm

(0.2~0.24 in.)

3 ~ 8 mm

(0.12 ~ 0.31 in.)

45.1 mm

(1.78 in.)

Alternator

Pulley

Crankshaft Pulley

HXGS508

HTB186

With the engine off, press down on

G180A01L

Drive belts should be checked peri-

the brake pedal several times to re-

You need a helper to check the brake

odically for proper tension and ad-

duce the vacuum in the brake booster.

pedal clearance. With the engine run-

justed if necessary. At the same time,

Then, using your hand, press down

ning, have your helper press down on

belts should be examined for cracks,

slowly on the brake pedal until you

the brake pedal several times and

wear, fraying or other evidence of

feel a change in resistance. This is

then hold it down with a force of about

deterioration and replaced if neces-

the brake pedal freeplay. The freeplay

490N (50 kg, 110 lbs). The brake

sary.

should be within the limits specified in

pedal clearance is the distance from

Belt routing should also be checked

the illustration. If it is not, have it

the top surface of the brake pedal to

to be sure there is no interference

inspected by your Hyundai dealer and

the asphalt sheeting under the floor

between the belts and other parts of

adjusted or repaired if necessary.

mat. If the brake pedal clearance is

the engine. After a belt is replaced,

not within the limits specified in the

the new belt should be adjusted again

illustration, have it inspected by your

after two or three weeks to eliminate

Hyundai dealer and adjusted or re-

slack resulting from initial stretching

paired if necessary.

after use.

6 DO-IT-YOURSELF MAINTENANCE

CHECKING AND REPLACING

FUSES

G190B01TB-GAT

G200A01A-AAT

Diesel Engine

Replacing a Fusible Link

CAUTION:

Alternator

When replacing a fusible link, never

use anything but a new fusible

Auto tentioner fully

link with the same or lower amper-

age rating. Never use a piece of

Power

wire or a higher-rated fusible link.

steering

Bad Good

This could result in serious dam-

pump

age and create a fire hazard.

A/C comp.

G200B01E-AAT

Replacing Accessory Fuses

G190B01A

G200A01FC

At the scheduled maintenance inspec-

A fusible link will melt if the electrical

tion, belts should be examined for

circuits from the battery are ever over-

cracks, wear, fraying or other evi-

loaded, thus preventing damage to

dence of deterioration and replaced if

the entire wiring harness. (This could

necessary.

be caused by a short in the system

Belt routing should also be checked

drawing too much current.) If this

to be sure there is no interference

ever happens, have a Hyundai dealer

between the belts and other parts of

determine the cause, repair the sys-

the engine.

tem and replace the fusible link. The

fusible links are located in a fuse box

for easy inspection.

HFC4010

The fuse box for the lights and other

electrical accessories will be found in

the backside of the multi box located

on the instrument panel to the left

side of the driver.

DO-IT-YOURSELF MAINTENANCE

On the backside of the mult box, you

will find a list showing the circuits

protected by each fuse.

If any of your car's lights or other

electrical accessories stop working, a

blown fuse could be the reason. If the

fuse has burned out, you will see that

the metal strip inside the fuse has

burned through. If you suspect a blown

fuse, follow this procedure:

Good

Burned out

G200B01FC

G200B03Y

1. Turn off the ignition and all other

switches.

4. Replace the blown fuse by pressing

2. Open the fuse box and examine

a new fuse of the same rating into

CAUTION:

each fuse. Remove each fuse by

place. The fuse should be a snug

A burned-out fuse indicates that

pulling it toward you (a small "fuse

fit. If it is not, have the fuse clip

there is a problem in the electrical

puller" tool is contained in the fuse

repaired or replaced by a Hyundai

circuit. If you replace a fuse and it

box to simplify this operation).

dealer. If you do not have a spare

blows as soon as the accessory is

3. Be sure to check all other fuses

fuse, you may be able to borrow a

turned on, the problem is serious

even if you find one that appears to

fuse of the same or lower rating

and should be referred to a

have burned out.

from an accessory you can tempo-

Hyundai dealer for diagnosis and

rarily get along without (the radio or

repair. Never replace a fuse with

cigarette lighter, for example). Al-

anything except a fuse with the

ways remember to replace the bor-

same or a lower amperage rating.

rowed fuse.

A higher capacity fuse could cause

damage and create a fire hazard.

NOTE:

See page 6-39 for the fuse panel

descriptions.

6 DO-IT-YOURSELF MAINTENANCE

CHECKING THE BATTERY

G210A01A-AAT

The fluid in the battery contains a

While batteries are being charged

strong solution of sulfuric acid, which

(either by a battery charger or by the

is poisonous and highly corrosive. Be

vehicle's alternator), they produce

careful not to spill it on yourself or the

explosive gases. Always observe

car. If you do spill battery fluid on

these warnings to prevent injuries from

yourself, immediately do the follow-

occurring:

ing:

o Charge batteries only in a well

o If battery fluid is on your skin, flush

ventilated area.

the affected areas with water for at

o Do not permit flames, sparks or

least

15 minutes and then seek

smoking in the area.

medical assistance.

o Keep children away from the area.

D010B01FC

o If battery fluid is in your eyes, rinse

out your eyes with water and get

medical assistance as soon as

WARNING:

possible. While you are being driven

Batteries can be dangerous! When

to get medical assistance, continue

working with batteries, carefully

to rinse your eyes by using a

observe the following precautions

sponge or soft cloth saturated with

to avoid serious injuries.

water.

o If you swallow battery fluid, drink a

large quantity of water or milk fol-

lowed by milk of magnesia, eat a

raw egg or drink vegetable oil. Get

medical assistance as soon as

possible.

DO-IT-YOURSELF MAINTENANCE

G210B01Y-GET

Checking the Battery

Keep batteries out of the

o When lifting a plastic-cased bat-

reach of children because

tery, excessive pressure on the

Keep the battery clean. Any evidence

batteries contain highly cor-

case may cause battery acid to

of corrosion around the battery posts

rosive SULFURIC ACID. Do

leak, resulting in personal injury.

or terminals should be removed using

not allow battery acid to

Lift with a battery carrier or with

a solution of household baking soda

contact your skin, eyes,

your hands on opposite corners.

and warm water. After the battery ter-

clothing or paint finish.

o Never attempt to charge the bat-

minals are dry, cover them with a light

If any electrolyte gets into

tery when the battery cables are

coating of grease.

your eyes, flush your eyes

connected.

with clean water for at least

o The electrical ignition system

15 minutes and get imme-

works with high voltage.

WARNING:

diate medical attention. If

Never touch these components

Always read the following

possible, continue to apply

with the engine running or the

instructions carefully when

water with a sponge or

ignition switched on.

handling a battery.

cloth until medical atten-

Keep lighted cigarettes and

tion is received.

all other flames or sparks

If electrolyte gets on your

away from the battery.

skin, thoroughly wash the

Hydrogen, which is a highly

contacted area.

combustible gas, is always

If you feel a pain or a burn-

present in battery cells and

ing sensation, get medical

may explode if ignited.

attention immediately.

Wear eye protection when

charging or working near a

battery.

Always provide ventilation

when working in an en-

closed space.

6 DO-IT-YOURSELF MAINTENANCE

CHECKING ELECTRIC

POWER STEERING FLUID

COOLING FANS

LEVEL

G220A01A-AAT

G230A03A-GAT

To check the power steering fluid

Gasoline engine

level, be sure the ignition is "OFF",

then check to make certain that the

WARNING:

power steering fluid level is between

The cooling fan is controlled by

the "MAX" and "MIN" level markings

engine coolant temperature and

on the fluid reservoir.

may sometimes operate even when

the engine is not running. Use

NOTE:

extreme caution when working

Grinding noise from the power

near the blades of the cooling fan,

steering pump may be heard im-

so that you are not injured by a

mediately after the engine is started

rotating fan blade. As the engine

in extremely cold conditions (be-

coolant temperature decreases the

HFC5004

low - 20°C). If the noise stops dur-

fan will automatically shut off. This

Diesel engine

ing warm up, there is no abnormal

is a normal condition.

function in the system. It is due to

a power steering fluid characteris-

tic in extremely cold conditions.

G220B01A-AAT

Checking Engine Cooling Fan

Recommended Fluid

The engine cooling fan should come

Use PSF-3 type fluid

on automatically if the engine coolant

temperature is high.

NOTE:

Do not start the engine when the

G230A02FC

power steering oil reservoir is

G220C01A-AAT

empty.

Checking Condenser Cooling

The power steering fluid level should

Fan

be checked regularly.

The condenser cooling fan should

come on automatically whenever the

air conditioning is in operation.

DO-IT-YOURSELF MAINTENANCE

BLEEDING THE FUEL

SYSTEM

G240A01A-AAT

G350B01FC-GAT

Air pipe

POWER STEERING HOSES

(Diesel Engine)

It is suggested that you check the

power steering hose connections for

fluid leakage at regular intervals. The

power steering hoses should be re-

placed if there is severe surface crack-

ing, scuffing or worn spots. Deteriora-

tion of the hose could cause prema-

ture failure.

G350B01FC

2. Pump the hand pump until there are

G350A01FC

no more bubbles in the fuel coming

The fuel system should be bled to

out of the air pipe. When doing this,

remove air as described in the illustra-

place a cloth around the air pipe to

tion if the fuel supply is exhausted

prevent the escaping fuel from spew-

during travel, when the fuel filter is

ing about.

replaced, or if the vehicle is not used

3. Replace the air cap when there are

for a long time.

no more bubbles in the fuel.

4. Continue pumping until the hand

1. Remove the air cap with pushing

pump becomes stiff.

the button.

5. Finally, check to be sure that there

is no leakage of fuel.

If in doubt, consult your nearest

authorized HYUNDAI dealer.

Hyundai Matrix (2007 year). Instruction - part 14
