6. PRESET STATION SELECT

A total of 18 stations can be pro-

grammed by selecting one AM and

Button

two FM stations per button.

Six (6) stations for AM, FM1 and FM2

o

When completed, any preset station

respectively can be preset in the elec-

may be recalled by selecting AM,

tronic memory circuit on this unit.

FM1 or FM2 band and the appropri-

ate station button.

HOW TO PRESET STATIONS

Six AM and twelve FM stations may be

programmed into the memory of the

!

CAUTION:

radio. Then, by simply pressing the

o Do not place beverages close to

band select button and/or one of the six

the audio system. The playback

station select buttons, you may recall

mechanism may be damaged if

any of these stations instantly. To pro-

you spill them.

gram the stations, follow these steps:

o Do not impact or strike the audio

system, or the playback mecha-

o Press band selector to set the band

nism could be damaged.

for AM, FM1, and FM2.

o Select the desired station to be stored

by seek, scan or manual tuning.

o Determine the preset station select

button you wish to use to access that

station.

o Press the station select button for

more than two seconds. A select

button indicator will show in the dis-

play indicating which select button

you have depressed. You should

then release the button, and proceed

to program the next desired station.

1 FEATURES OF YOUR HYUNDAI

108

B220C01E-BAT

CASSETTE TAPE PLAYER OPERATION (H220) (If Installed)

2. EJECT Button

3. TAPE SLOT

1. FF/REW Button

B220A01E

FEATURES OF YOUR HYUNDAI

1

109

B200D02E-BAT

1. FF/REW/PROGRAM button

!

CAUTION:

Pushing the Fast-forward button will

o Do not insert anything like coins

cause the tape to move rapidly in the

into the player slot as damage to

forward direction of play. Pushing the

the unit may occur.

Rewind button will cause the tape to

o Do not place beverages close to

move rapidly in the reverse direction of

the audio system. The playback

play.

mechanism may be damaged if

To stop FF or REW action, press the

you spill them.

opposite button.

o Do not impact or strike the audio

This allows you to play the reverse side

system, or the playback mecha-

of the tape by merely depressing the FF

nism could be damaged.

and REW buttons simultaneously.

2. TAPE EJECT button

While the tape is playing, press the

eject button when you want to eject the

cassette tape.

3. TAPE SLOT

Insert cassette with exposed tape side

facing towards to cassette slot.

Insertion of the cassette will automati-

cally cut off the radio reception and tape

playback will start.

1 FEATURES OF YOUR HYUNDAI

110

H260A01O-AAT

STEREO RADIO OPERATION (H260) (If installed)

3. BASS/TREBLE Control Knob

4. SCAN Button

6. BAND Selector

7. PRESET Button

5. TUNE/SEEK Select Button

1. POWER ON-OFF/VOLUME/BALANCE Control Knob

2. FADER Control Knob

H260A01O

1 FEATURES OF YOUR HYUNDAI

112

7. PRESET STATION Select

You should then release the button,

and proceed to program the next

Button

desired station. A total of 18 stations

Six (6) stations for AM, FM1 or FM2

can be programmed by selecting one

respectively can be preset in the elec-

AM and two FM stations per button.

tronic memory circuit on this unit.

o

When completed, any preset station

may be recalled by selecting AM,

HOW TO PRESET STATIONS

FM1 or FM2 band and the appropri-

ate station button.

Six AM and twelve FM stations may be

programmed into the memory of the

radio. Then, by simply pressing the

band select button and/or one of the six

!

CAUTION:

station select buttons, you may recall

o Do not place beverages close to

any of these stations instantly. To pro-

the audio system. The playback

gram the stations, follow these steps:

mechanism may be damaged if

you spill them.

o Press band selector to set the band

o Do not impact or strike the audio

for AM, FM1 or FM2.

system, or the playback mecha-

o Select the desired station to be stored

nism could be damaged.

by seek, scan or manual tuning.

o Determine the preset station select

button you wish to use to access that

station.

o Press the station select button for

more than two seconds. A select

button indicator will show in the dis-

play indicating which select button

you have depressed. The frequency

display will flash after it has been

stored into the memory.

FEATURES OF YOUR HYUNDAI

1

113

H260B01O-AAT

COMPACT DISC PLAYER OPERATION (H260) (If installed)

4. SCAN Button

1.Playing CD

3. TRACK UP/DOWN

6. EJECT Button

2. FF/REW Button

5. REPEAT Button

H260A01O

1 FEATURES OF YOUR HYUNDAI

114

B260D03O-AAT

3. TRACK UP/DOWN

6. EJECT Button

1. Playing CD

o

The desired track on the disc cur-

When the EJECT button

is pressed

o Insert the CD with the label facing

rently being played can be selected

with a CD loaded, the CD will eject.

upward.

using the track number.

o Insert the CD to start CD playback,

o

Press once to skip forward to the

NOTE:

during radio operation.

beginning of the next track.

o If the CD does not operate prop-

o When a disc is in the CD deck, if you

Press

once to skip back to the

erly or if the ER2 fault code is

press the CD button, the CD player

beginning of the track.

displayed, use one of two meth-

will begin playing even if the radio is

ods to reset the CD deck function.

being used.

4. SCAN Button

- Remove the audio fuse for 5

o The CD player can be used when the

minutes. Then, reinstall the

ignition switch is in either the "ON" or

o

Press the SCAN button to playback

audio fuse.

"ACC" position.

the first 10 seconds of each track.

- Disconnect the negative termi-

o

Press the SCAN button again within

nal of the battery and wait 5

2. FF/REW (

/

)

10 sec. when you have reached the

minutes. Then reconnect the

desired track.

If you want to fast forward or reverse

negative battery terminal.

through the compact disc track, push

o When replacing the fuse, replace

5. REPEAT Button

and hold in the FF (

) or REW (

)

it with a fuse having the correct

button.

o

To repeat the track you are currently

capacity.

When you release the button, the com-

listening to, press the RPT button.

o The preset station frequencies are

pact disc player will resume playing.

To cancel , press again.

all erased when the car battery is

o

If you do not release RPT operation

disconnected. Therefore, all data

when the track ends, it will automati-

will have to be set again if this

cally be replayed.

should occur.

This process will be continued until

o Do not add any oil to the rotating

you push the button again.

parts. Keep magnets, screwdriv-

ers and other metallic objects away

from the tape mechanism and head.

FEATURES OF YOUR HYUNDAI

1

115

o This equipment is designed to be

o Driving on the off-roads or other

used only in a 12 volt DC battery

vibrations may skip your compact

system with negative ground.

disc.

o This unit is made of precision

Do not use the audio system on

parts. Do not attempt to disas-

off-roads as the discs could be

semble or adjust any parts.

scratched and damaged.

o When driving your vehicle, be sure

o Do not grip or pull out the disc

to keep the volume of the unit set

with your hand while the disc is

low enough to allow you to hear

being pulled into the unit by the

sounds coming from the outside.

self loading mechanism. These

o Do not expose this equipment (in-

can cause poor disc scratching to

cluding the speakers) to water or

occur or damage the compact disc

excessive moisture.

player.

o Avoid using CD-Recordable or CD-

Rewritable as the player could not

!

be operated in recording way of

CAUTION:

the CD maker. When using the

o Do not insert warped or poor qual-

compact disc player, profession-

ity discs into the CD player as

ally recorded CDs are recom-

damage to the unit may occur.

mended.

o Do not insert anything like coins

into the player slot as damage to

the unit may occur.

o Do not place beverages close to

the audio system. The playback

mechanism may be damaged if

you spill them.

o Do not impact on the audio sys-

tem, or the playback mechanism

could be damaged.

1 FEATURES OF YOUR HYUNDAI

116

B260E01E-AAT

CD AUTO CHANGER (H260) (If installed)

6. SCAN Button

1. CD Select Button

3. TRACK UP/DOWN

4. FF/REW Button

5. REPEAT Button

2. DISC Select Button

H260A01O

FEATURES OF YOUR HYUNDAI

1

117

B260F03FC-GAT

2. DISC Select Button

5. REPEAT

The CD auto changer is located under

TUNE

the front passenger seat.

To select the CD you want, push

DISC

to

o To repeat the track you are currently

change the disc number.

listening to, press the RPT button.

o To use the CD auto changer.

To cancel , press again.

3. TRACK UP/DOWN

o If you do not release RPT operation

1. Open the sliding lid of the CD auto

when the track ends, it will automati-

o The desired track on the disc cur-

changer.

cally be replayed.

rently being played can be selected

2. To eject the compact disc maga-

This process will be continued until

using the track number.

zine, press the EJECT button lo-

you push the button again.

o Press

once to skip forward to

cated inside the CD auto changer.

the beginning of the next track.

3. Insert the discs into the maga-

6. SCAN Button

Press

once to skip back to the

zine.

beginning of the track.

o Press the SCAN button to playback

4. Push the magazine into the CD

the first 10 seconds of each track.

auto changer and close the sliding

4. FF/REW (

/

)

o Press the SCAN button again within

lid.

10 sec. when you have reached the

If you want to fast forward or reverse

desired track.

o The CD auto changer can be used

through the compact disc track, push

when the ignition switch is in either

and hold in the FF (

) or REW (

)

NOTE:

the "ON" or "ACC" position.

button.

o When replacing the fuse, replace

When you release the button, the com-

it with a fuse having the correct

1. CD Select Button

pact disc player will resume playing.

capacity.

When the CD changer magazine con-

o This equipment is designed to be

tains discs, press the CD button and

used only in a 12 volt DC battery

the CD changer can be used even if the

system with negative ground.

radio is being used. The Hyundai CD

o This unit is made of precision

changer can hold up to eight discs. The

parts. Do not attempt to disas-

disc number will be lit, and the track

semble or adjust any parts.

number, and elapsed time will be dis-

played.

1 FEATURES OF YOUR HYUNDAI

118

o When driving your vehicle, be sure

o Do not grip or pull out the disc

to keep the volume of the unit set

with your hand while the disc is

low enough to allow you to hear

being pulled into the unit by the

sounds coming from the outside.

self loading mechanism. These

can cause poor disc scratching to

occur or damage the compact disc

changer.

o Avoid using CD-Recordable or CD-

!

CAUTION:

Rewritable as the changer could

o Do not insert warped or poor qual-

not be operated in recording way

ity discs into the CD changer as

of the CD maker. When using the

damage to the unit may occur.

compact disc changer, profes-

o Do not insert anything like coins

sionally recorded CDs are recom-

into the changer slot as damage to

mended.

the unit may occur.

o Do not place beverages close to

the audio system. The playback

mechanism may be damaged if

you spill them.

!

o Do not impact or strike the audio

WARNING:

system, or the playback mecha-

Never attempt to change CDs the

nism could be damaged.

already inserted in the CD changer

o Driving on the off-roads or other

magazine while the vehicle is mov-

vibrations may skip your compact

ing. This could result in loss of con-

disc.

trol or an accident that may cause

Do not use the audio system on

death, serious insury, or property

off-roads as the discs could be

damage.

scratched and damaged.

FEATURES OF YOUR HYUNDAI

1

119

H290A01FC-GAT

STEREO RADIO OPERATION (H280) (If installed)

8. BEST STATION MEMORY

1. POWER ON/OFF VOLUME Control Knob

or SCAN Button (If installed)

7. EQUALIZER Button

3. TREBLE/FAD Konb

5. PRESET Buttons

4. TUNE/SEEK Select Button

2. BASS/BALANCE Control Knob

6. BAND Select Button

H290A01O

FEATURES OF YOUR HYUNDAI

1

121

HOW TO PRESET STATIONS

o When completed, any preset station

8. Best Station Memory Button

may be recalled by selecting AM,

(BSM) (If installed)

Six AM and twelve FM stations may be

FM1 or FM2 band and the appropri-

programmed into the memory of the

When the BSM button is pressed for

ate station button.

radio. Then, by simply pressing the

two seconds or longer, the six channels

band select button and/or one of the six

from the highest field intensity are se-

6. BAND Selector

station select buttons, you may recall

lected next and stored in memory. The

any of these stations instantly. To pro-

Pressing the

FM/AM

button changes the

stations selected are stored in the se-

gram the stations, follow these steps:

AM, FM1 and FM2 bands. The mode

quence frequency from the first preset

selected is shown on the display.

key.

o Press band selector to set the band

for AM, FM1 or FM2.

7. EQUALIZER Button

SCAN Button (If installed)

o Select the desired station to be stored

Press the EQ button to select the

When the scan button is pressed, the

by seek or manual tuning.

CLASSIC, JAZZ, ROCK and DEFEAT

frequency will increase and the receiv-

o Determine the preset station select

MODE for the desired tone quality.

able stations will be tuned in one after

button you wish to use to access that

Each press of the button changes the

another, receiving each station for 5

station.

display as follows;

seconds. To stop scanning, press the

o Press the station select button for

scan button again.

more than two seconds. A select

CLASSIC  JAZZ  ROCK  DEFEAT

button indicator will show in the dis-

play indicating which select button

!

CAUTION:

you have depressed. The frequency

o Do not place beverages close to

display will flash after it has been

the audio system. The playback

stored into the memory with beep

mechanism may be damaged if

sound. You should then release the

you spill them.

button, and proceed to program the

o Do not impact or strike the audio

next desired station. A total of 18

system, or the playback mecha-

stations can be programmed by se-

nism could be damaged.

lecting one AM and two FM station

per button.

1 FEATURES OF YOUR HYUNDAI

122

H290C01FC-GAT

CASSETTE TAPE PLAYER OPERATION (H280) (If installed)

4.TAPE EJECT Button

5.EQUALIZER

Button

2.AUTO MUSIC

Select Button

1.FF/REW Button

6.DOLBY Button

3.TAPE PROGRAM Button

H290A01O

FEATURES OF YOUR HYUNDAI

1

123

H290D02O-GAT

3. TAPE PROGRAM Button

6. DOLBY Button

1. FF/REW Button

This allows you to play the reverse side

If you get background noise during tape

o Fast forward tape winding starts

of the tape by merely depressing the

PLAY, you can reduce this consider-

when the FF (

) button is pressed

program button. An arrow will appear in

ably by merely pressing the DOLBY

during the PLAY or REW mode.

the display to show tape direction.

button. If you want to cancel the DOLBY

o Tape play starts when the FF (

)

feature, press the button again.

button is pressed again during the FF

4. TAPE EJECT button

mode.

o Tape rewinding starts when the REW

o When the

button is pressed with

!

(

) button is pressed during the

the cassette loaded, the cassette is

CAUTION:

PLAY or FF mode.

ejected.

o Do not insert anything like coins

o Tape play starts when the REW (

)

o When the

button is pressed

into the player slot as damage to

button pressed again during the REW

during the FF/REW mode, the cas-

the unit may occur.

mode.

sette is ejected.

o Do not place beverages close to

the audio system. The playback

2. AUTO MUSIC Select Button

5. EQ Button

mechanism may be damaged if

you spill them.

Press the button to find the starting

Press the EQ button to select the

o Do not impact or strike the audio

point of each song in a prerecorded

CLASSIC, JAZZ, ROCK and DEFEAT

system, or the playback mecha-

music tape. The quiet space between

MODE for the desired tone quality.

nism could be damaged.

songs (must have at least a 4 sec. gap)

Each press of the button changes the

can be identified by the AUTO MUSIC

display as follows;

Select button.

CLASSIC  JAZZ  ROCK  DEFEAT

o Pressing the

button will play the

beginning of the next music seg-

ment.

o Pressing the

button will start

replay at the beginning of the music

just listened to.

Content   ..  6  7  8  9   ..
