FEATURES OF YOUR HYUNDAI

GLOVE BOX

MIRROR

B500A01A-AAT

B510B01FC-GAT

To adjust the position of either

OUTSIDE REARVIEW MIRROR

mirror:

Electric Type

1. Move the selecting switch to the

right or left to activate the adjustable

mechanism for the corresponding

door mirror.

2. Adjust mirror angle by depressing

the appropriate directional switch

as illustrated.

HFC2095

HFC2011

WARNING:

The outside rearview mirrors can be

To avoid the possibility of injury in

adjusted to your preferred rear vision,

case of an accident or a sudden

both directly behind the vehicle, and to

stop, the glove box door should be

the rear of the left and right sides.

kept closed when the car is in mo-

The remote control outside rearview

tion.

mirror switch controls the adjustments

B510D01E

for both right and left outside mirrors.

o To open the glove box, pull on the

glove box release lever.

1 FEATURES OF YOUR HYUNDAI

B510D02HP-AAT

B510C01A-AAT

OUTSIDE REARVIEW MIRROR

FOLDING THE OUTSIDE

CAUTION:

HEATER (If installed)

REARVIEW MIRRORS

o Do not operate the switch con-

tinuously for an unnecessary

length of time.

o Scraping ice from the mirror face

could cause permanent damage.

To remove any ice, use a sponge,

soft cloth or approved de-icer.

WARNING:

HFC2080

B510C01FC

Be careful when judging the size or

To fold the outside rearview mirrors,

The outside rearview mirror heater is

distance of any object seen in the

push them towards the rear.

actuated in connection with the front/

passenger side rear view mirror. It

The outside rearview mirrors can be

rear window defroster. To heat the out-

is a convex mirror with a curved

side rearview mirror glass, push

folded rearward for parking in narrow

surface, and objects seen in this

in the switch for the front/rear window

areas.

mirror are closer than they appear.

defroster. The rearview mirror glass will

be heated for defrosting or defogging

and will give you improved rear vision

WARNING:

in inclement weather conditions. Push

Do not adjust or fold the outside

the switch again to turn the heater off.

rearview mirrors while the vehicle

The outside rearview mirror heater

is moving. This could result in loss

automatically turns itself off after 20

of control, and an accident which

minutes.

could cause death, serious injury

or property damage.

FEATURES OF YOUR HYUNDAI

SUN VISOR

B520A01A-AAT

B580A01L-GAT

NOTE:

(If Installed)

DAY/NIGHT INSIDE REARVIEW

The Supplemental Restraint Sys-

MIRROR

tem (SRS) label containing useful

Manual Type

information can be found on the

back of each sun visor.

WARNING:

Do not place the sun visor in such

a manner that it obscures visibility

Vanity mirror

of the roadway, traffic or other ob-

jects.

HFC2094

Your Hyundai is equipped with sun

HXDFL2112

visors to give the driver and front pas-

senger either frontal or sideward shade.

Your Hyundai is equipped with a day/

The sun visors are fitted on both sides

night inside rearview mirror. The "night"

on all models. To reduce glare or to

position is selected by flipping the tab

shut out direct rays of the sun, turn the

at the bottom of the mirror toward you.

sun visor down to block the annoy-

In the "night" position, the glare of

ance. A vanity mirror is provided on the

headlights of cars behind you is re-

back of the sun visor for the driver and

duced.

front passenger.

1 FEATURES OF YOUR HYUNDAI

FOLD-UP TRAY

HIGH-MOUNTED REAR

HOOD RELEASE

STOP LIGHT

B810A01FC-GAT

B550A01S-GAT

B570A01FC-GAT

(If installed)

HFC2070

HFC2018

B550A02FC

For your convenience, it may be used

1. Pull the release knob to unlatch the

as a table holding a book, cup or can.

In addition to the lower-mounted rear

hood.

stop lights on either side of the car, the

high mounted rear stop light in the

center of the rear window or inserted in

WARNING:

the rear spoiler also lights when the

To avoid the possibility of injury in

brakes are applied.

case of an accident or a sudden

stop, the fold-up tray should be

place its original position while the

vehicle is moving.

HFC203

2. Push the secondary latch lever

sidewards and lift the hood.

FEATURES OF YOUR HYUNDAI

REMOTE FUEL-FILLER LID

RELEASE

B560A03A-AAT

3. Hold the hood open with the support

rod.

WARNING:

Before closing the hood, return the

o Always double check to be sure

support rod to its clip to prevent it from

that the hood is firmly latched

rattling. Lower the hood until it is about

before driving away. If it is not

30 cm (1 ft.) above the closed position

latched, the hood could open

and let it drop. Make sure that it locks

while the vehicle is being driven,

into place.

causing a total loss of visibility,

which might result in an acci-

dent.

o The support rod must be inserted

CAUTION:

HFC2015

completely into the hole provided

Make sure that the support rod has

in the hood whenever you in-

The fuel-filler lid may be opened from

been released prior to closing the

spect the engine compartment.

inside the vehicle by pulling up on the

hood.

This will prevent the hood from

fuel-filler lid opener located on the front

falling and possibly injuring you.

floor area on the left side of the car.

o Do not move the vehicle with the

hood in the raised position, as

NOTE:

vision is obstructed and the hood

If the fuel-filler lid will not open

could fall or be damaged.

because ice has formed around it,

tap lightly or push on the lid to

break the ice and release the lid. Do

not pry on the lid. If necessary,

spray around the lid with an ap-

proved de-icer fluid (do not use ra-

diator anti-freeze) or move the

vehicle to a warm place and allow

the ice to melt.

1 FEATURES OF YOUR HYUNDAI

o Automotive fuels are flammable/

Do not use cellular phones

explosive materials. When refuel-

around a gas station. The elec-

ing, please note the following

tric current or electronic inter-

guidelines carefully.

ference from cellular phones

Before touching the fuel nozzle

can ignite fuel vapors and cause

or fuel filler cap, have one's

a fire.

hands in contact with metal

When refueling, always turn the

parts away from the filler neck

engine off. Sparks by electrical

to discharge static electricity.

equipment of the engine can

Do not get back in the vehicle

ignite fuel vapors causing a

HFC2016

while refueling. Do not operate

fire. After refueling, check to

anything that can produce static

make sure the fuel filler cap is

electricity. Static electricity dis-

securely closed, and then start

charge can ignite fuel vapors

the engine.

resulting in an explosion.

Do not smoke or try to light

WARNING:

When using a portable fuel con-

cigarettes around a gas station.

o Fuel vapors are dangerous. Be-

tainer, be sure to place the con-

Automotive fuels are flam-

fore refueling, always stop the en-

tainer on the ground while refu-

mable.

gine and never allow sparks or

eling. Static electricity dis-

open flames near the filler area. If

charge from the container can

you need to replace the filler cap,

ignite fuel vapors causing a

use a genuine Hyundai replace-

fire. While starting refueling,

ment part.

contact should be maintained

If you open the fuel filler cap dur-

until the filling is complete.

ing high ambient temperatures, a

slight "pressure sound" may be

heard. This is normal and not a

cause for concern.

Whenever you open the fuel filler

cap, turn it slowly.

FEATURES OF YOUR HYUNDAI

TAIL GATE

CD AUTO CHANGER

B540A01FC-GAT

The tail gate can be locked or un-

B800A02FC-GAT

locked with a key.

(If Installed)

The tail gate is opened by pulling the

outside handle up, raising the tail

LOCK

UNLOCK

gate manually.

To close, lower the tail gate, then

press down on it until it is closed. To

be sure the tail gate is fully closed,

always try to pull it up again without

using the outside handle.

B540A02FC

HFC2105

The CD Auto Changer is located under

WARNING:

the front passenger seat. This system

The tail gate should always be kept

can store up to 8 CDs.

completely closed while the vehicle

You may select music without chang-

is in motion. If it is left open or ajar,

ing discs. First, open the CD Auto

poisonous exhaust gases may en-

Changer door, remore the CD "maga-

ter the car resulting in serious ill-

zine" and insert up to 8 CDs. Then,

ness or death to the occupants. See

push the magazine into the CD Auto

additional warnings concerning

Changer. The CD may be operated

exhaust gases on page 2-2.

with the passenger compartment au-

dio system controls.

1 FEATURES OF YOUR HYUNDAI

LUGGAGE NET

B540D03FC-GAT

(If Installed)

WARNING:

CAUTION:

Never attempt to change CDs the

To prevent damage to the goods or

already inserted in the CD changer

the vehicle, care should be taken

magazine while the vehicle is mov-

when carrying fragile or bulky ob-

ing. This could result in loss of

jects in the luggage compartment.

control or an accident that may

cause death, serious insury, or

property damage.

WARNING:

B540D01HP

Avoid eye injury. DO NOT overstretch

Some objects can be kept in the net in

the luggage net. ALWAYS keep your

the luggage compartment.

face and body out of its recoil path.

Use the luggage net on the floor or at

DO NOT use when the strap has

the back of the luggage compartment

visible signs of wear or damage.

to prevent objects from sliding.

FEATURES OF YOUR HYUNDAI

CARGO AREA COVER

ROOF RACK

B650A01FC-GAT

B630A03FC-GAT

(If installed)

o Loading cargo or luggage above

34 kg (75 lb) on the roof rack may

damage your vehicle.

When you carry large objects,

never let them hang over the rear

or the sides of your vehicle.

o To prevent damage or loss of

cargo as you are driving, check

frequently to make sure the lug-

gage carrier and cargo are still

securely fastened.

o Always drive your vehicle at a

B640A02FC

HFC2106

moderate speed.

o To use the roof rails as a roof

If your Hyundai has a roof rack, you can

Nothing should be carried on top of the

rack, you must fit the roof rails

load things on top of your vehicle.

luggage cover. Loose materials could

with two or more crossrails or

Crossrails and fixing components to

result in injury to vehicle occupants

equivalent before carrying cargo

during sudden braking.

adapt the roof rack on your vehicle

or lugguage on the roof.

may be obtained from an authorized

o When crossrail is adapted, you

Hyundai dealer.

can load things on the roof rack.

o Loading cargo or luggage over

specification on the roof rack may

CAUTION:

damage stability of your vehicle.

o The following specifications are

o In case the sunroof is equipped,

recommended when loading

do not position roof rack loads

cargo or luggage.

that could interfere with opening

of the sunroof.

34 kg (75 lb)

ROOF RACK

EVENLY DISTRIBUTED

1 FEATURES OF YOUR HYUNDAI

AUTO FUEL CUT SWITCH

STEERING WHEEL TILT

HORN

LEVER

B560B01O-GAT

B600A01A-AAT

B610B01A-GAT

(Gasoline Engine)

(If Installed)

Without Airbag

B610B01FC

HFC4001

HFC2041

With Airbag

The auto fuel cut switch is located on

To Adjust the Steering Wheel:

the driver's side of the engine compart-

1. Push the lever downward to unlock.

ment.

2. Raise or lower the steering wheel to

In the event of a collision or sudden

the desired position.

impact, the auto fuel cut device cuts off

3. After adjustment, securely tighten

the fuel supply. If this device is acti-

the lever by pulling it upward.

vated, it must be reset by pressing in

on the top of the switch before the

engine can be restarted.

WARNING:

HFC2099

Do not attempt to adjust the steer-

Press the center hub of the steering

WARNING:

ing wheel while driving as this may

wheel to sound the horn.

Before resetting the auto fuel cut

result in loss of control of the ve-

switch, the fuel line should be

hicle which may cause serious in-

checked for fuel leaks.

jury or death.

FEATURES OF YOUR HYUNDAI

HEATING AND COOLING CONTROL

B710A01Y-GAT

B710B01A-AAT

(If installed)

CENTER VENTILATOR

The center ventilators are located in the

middle of the dashboard.

To change the direction of the air flow,

turn the control knob on the middle of

the ventilator as desired.

B710C01FC-AAT

SIDE VENTILATOR

The side ventilators are located on

each side of the dashboard. To change

the direction of the air flow, move the

knob in the center of the vent. The

vents are opened when the vent knob is

moved to " " position. The vents are

closed when the vent knob is moved to

". Keep these vents clear of any

obstructions.

1. Side Defrost Nozzle

2. Side Ventilator

3. Windshield Defrost Nozzle

HFC002

4. Center Ventilator

1 FEATURES OF YOUR HYUNDAI

HEATING AND VENTILATION

B670A01FC-GAT

B670E01A-AAT

B670B01FC-AAT

Rotary type (If installed)

Temperature Control

Fan Speed Control

(Blower Control)

Cool

Warm

HFC2064

HFC2066

This model has four controls for the

This control is used to adjust the degree

HFC2065

heating and cooling system. They are:

of heating or cooling desired.

This is used to turn the blower fan on or

off and to select the fan speed.

1. Temperature control

This blower fan speed, and therefore

2. Fan speed control

the volume of air delivered from the

3. Air flow control

system, may be controlled manually by

4. Air intake control

setting the blower control between the

"1" and "4" positions.

"1" is lowest and "4" is the highest fan

speed.

FEATURES OF YOUR HYUNDAI

B670D05A-AAT

Air Flow Control

HFC2046

HFC2047

HFC2068

Face-Level

Bi-Level

This is used to direct the flow of air. Air

Selecting the "Face" mode will cause

Air is discharged through the face vents

can be directed to the floor, dashboard

air to be discharged through the face

and the floor vents. This makes it pos-

outlets, or windshield. Five symbols

level vents.

sible to have cooler air from the dash-

are used to represent Face, Bi-Level,

board vents and warmer air from the

Floor, Floor-Defrost and Defrost air po-

floor outlets at the same time.

sition.

1 FEATURES OF YOUR HYUNDAI

HFC2048

HFC2049

HFC2050

Floor-Level

Floor-Defrost Level

Defrost-Level

Air is discharged through the floor vents.

Air is discharged through the side de-

Air is discharged through the side

frost nozzle windshield defrost vents

defrost nozzle, windshield defrost

and the floor vents.

vents.

If the "Floor-Defrost" mode is selected,

If the "Defrost" mode is selected, the

the A/C will be turn automatically and it

A/C will turn on automatically and

will be changed to "Fresh" mode will be

"Fresh" mode will be activated to im-

activated.

prove windshield defrosting.

FEATURES OF YOUR HYUNDAI

HEATING CONTROLS

B670C03FC-GAT

With the "Fresh" mode selected, air

B690A02S-AAT

Air Intake Control

enters the vehicle from the outside and

is heated or cooled according to the

function selected.

With the "Recirculation" mode selected,

air from within the passenger compart-

ment will be drawn through the heating

system and heated or cooled according

to the function selected.

NOTE:

B690A02FC

It should be noted that prolonged

HFC2067

For normal heating operation, set the air

operation of the heating in "Recircu-

This is used to select fresh outside air

intake control to the "Fresh" position

lation" mode will increase to fog-

or recirculating inside air.

and the air flow control to "Floor".

ging of the windshield and side win-

To change the air intake control mode,

dows and the air within the passen-

(Fresh mode, Recirculation mode) push

For faster heating, the air intake control

ger compartment will become stale.

the control button.

should be in the "Recirculation" posi-

In addition, prolonged use of the air

tion.

conditioning with the "Recirculation"

FRESH MODE (

) :

mode selected may result in the air

The indicator light on the button goes

If the windows fog up, move the air flow

within the passenger compartment

off when the air intake control is in fresh

control to the "Def" (defroster) position.

becoming excessively dry.

mode.

(The A/C will turn on automatically and

"Fresh" mode will be activated.)

RECIRCULATION MODE (

The indicator light on the button is

For maximum heat, rotate the tempera-

illuminated when the air intake control

ture control to "Warm".

is in recirculation mode.

1 FEATURES OF YOUR HYUNDAI

BI-LEVEL HEATING

VENTILATION

DEFROSTING/DEFOGGING

B700A01S-AAT

B710A01S-AAT

B720A02FC-GAT

HFC2111

B710A01FC

HFC2107

Your Hyundai is equipped with bi-level

To operate the ventilation system:

Use the heating/ventilation system to

heating controls. This makes it pos-

defrost or defog the windshield:

sible to have cooler air from the dash-

o Set the air intake control to "Fresh"

board vents and warmer air from the

mode (

To remove interior fog on the wind-

floor outlets at the same time. To use

o To direct all intake air to the dash-

shield:

this feature:

board vents, set the air flow control

o Set the air flow control to the defrost

to "Face".

(

) position. (The A/C will turn on

o Set the air intake control to the "Fresh"

o Adjust the fan speed control to the

automatically and "Fresh" mode will

mode (

desired speed.

be activated.)

o Set the air flow control at the "Bi-

o Set the temperature control between

o Set the temperature control to the

Level" position.

"Cool" and "Warm".

desired position.

o Adjust the fan speed control to the

o Set the fan speed control between

desired speed.

"1" and "4" position.

o Set the temperature control between

"Cool" and "Warm".

FEATURES OF YOUR HYUNDAI

AIR CONDITIONING SYSTEM

B730A01L-GAT

B740A01S-AAT

Operation Tips

Air Conditioning Switch

(If installed)

To keep dust or unpleasant fumes

from entering the car through the

ventilation system, temporarily set

the air intake control at "Recircula-

tion". Be sure to return the control to

"Fresh" when the irritation has

passed to keep fresh air in the ve-

hicle. This will help keep the driver

alert and comfortable.

HFC2108

Air for the heating/cooling system is

To remove frost or exterior fog on the

drawn in through the grilles just ahead

windshield:

of the wind-shield. Care should be

HFC2069

o Set the air flow control to the defrost

taken that these are not blocked by

leaves, snow, ice or other obstruc-

The air conditioning is turned on or off

(

) position. (The A/C will turn on

tions.

by pushing the A/C button on the heat-

automatically and "Fresh" mode will

To prevent interior fog on the wind-

ing/air conditioning control panel.

be activated.)

o Set the temperature control to warm.

shield, set the air intake control to

o Set the fan speed control to position

the fresh air (

) position, fan speed

"3" or "4".

to the desired position, turn on the air

conditioning system, and adjust tem-

perature control to desired tempera-

NOTE:

ture.

When the A/C is operated continu-

ously on the floor-defrost level (

)

or defrost level (

), it may cause fog

to form on the exterior windshield. If

this occurs, set the air flow control to

the face level position (

)and fan

speed control to the low position.

Hyundai Matrix (2007 year). Instruction - part 6
