Hyundai Matrix (2007 year). Instruction

1 FEATURES OF YOUR HYUNDAI

B310B01FC-GAT

Function of digital odometer/trip

2,3. Trip odometer

ODOMETER/TRIP ODOMETER

odometer

Records the distance of 2 trips in kilo-

Without Trip Computer

meters or miles.

pushing in the reset switch when the

ignition switch is turned "ON" will dis-

TRIP A : First distance you have trav-

play the following sequence:

eled from your origination

point to a first destination.

TRIP B : Second distance from the first

destination to the final desti-

nation.

To shift from TRIP A to TRIP B, press

the reset switch. When pressed for 1

Reset Switch

HFC2089

second, it will reset to 0.

With Trip Computer

HFC2090

1. Odometer

The odometer records the total driving

distance in kilometers or miles, and is

useful for keeping a record for mainte-

nance intervals.

Reset Switch

HFC2051

NOTE:

Any alteration of the odometer may

void your warranty coverage.

FEATURES OF YOUR HYUNDAI

TRIP COMPUTER

B400B01FC-GAT

Reset switch

1. Distance to Empty

(If Installed)

o The reset switch is used to zero the

multi-functional display mode.

Distance to empty symbol

o Pushing in the reset switch changes

the display as follows;

DISTANCE TO EMPTY

AVERAGE SPEED

Distance to empty

Reset Switch

HFC2052

HFC2051

DRIVE TIME

The trip computer is a microcomputer-

o This mode indicates the estimated

controlled driver information gauge that

distance to empty from the current

displays information related to driving,

fuel in the fuel tank and distance to

such as a distance to empty, average

empty symbol.

speed and drive time on the LCD.

o When refueling with more than 6

liters, the trip computer will recog-

nize refueling.

o When the battery has been rein-

stalled after being discharged or

disconnected, drive more than 32km

for an accurate distance to empty.

1 FEATURES OF YOUR HYUNDAI

NOTE:

2. Average speed

3. Drive time

o If the distance to empty is indi-

cated "- -", have the trip com-

Average speed symbol

Drive time symbol

puter system checked by your

authorized Hyundai dealer.

o The distance to empty can differ

from the actual tripmeter ac-

cording to driving conditions.

o The distance to empty can vary

according to the driving condi-

tions, driving pattern or vehicle

speed.

Average speed

Drive time

HFC2053

HFC2054

This mode indicates the average

This mode indicates the drive time

speed travelled since the last aver-

travelled since the last drive time

age speed reset.

reset.

Pressing the reset switch for more

than 1 second, when the average

than 1 second, when the drive time

speed is being displayed, clears the

is being displayed, clears the drive

average speed to zero.

time to zero.

FEATURES OF YOUR HYUNDAI

MULTI-FUNCTION LIGHT

SWITCH

B340A01A-AAT

B340B01A-AAT

B340C03FC-GAT

COMBINATION TURN SIGNAL,

Lane Change Signal

Headlight Switch

HEADLIGHT AND HIGH-BEAM

SWITCH

Turn Signal Operation

Pulling down on the lever causes the

turn signals on the left side of the car to

blink. Pushing upwards on the lever

causes the turn signals on the right

side of the car to blink. As the turn is

completed, the lever will automatically

return to the center position and turn

off the turn signals at the same time. If

B340B01FC

B340C01FC

either turn signal indicator light blinks

To indicate a lane change, move the

To operate the headlights, turn the bar-

more rapidly than usual, goes on but

lever up or down to a point where it

rel on the end of the multi-function

does not blink, or does not go on at all,

begins flashing.

switch. The first position turns on the

there is a malfunction in the system.

The lever will automatically return to

parking lights, sidelights, tail lights and

Check for a burned-out fuse or bulb or

the center position when released.

instrument panel lights. The second

see your Hyundai dealer.

position turns on the headlights.

NOTE:

The ignition must be in the "ON"

position to turn on the headlights.

1 FEATURES OF YOUR HYUNDAI

B340F01A-GAT

B340E01A-AAT

Parking light auto cut

Daytime Running Lights

Headlight Flasher

(If installed)

(If Installed)

o The purpose of this feature is to

Your Hyundai is equipped with day-

prevent the battery from being dis-

time running lights. The daytime run-

charged.

ning lights are used to improve visibil-

The system automatically turns off

ity for oncoming traffic. Your vehicle

the small light when the driver re-

daytime running lights are designed to

moves the ignition key and opens

remain on continuously when the en-

the driver- side door.

gine is operating even though the head-

o With this feature, the parklight will be

light switch is in the "OFF" position.

turned off automatically if the driver

However, the daytime running lights

parks on the side of road at night.

will be off while the parking brake is

B340E01FC

applied.

If necessary, to keep the lights on when

To flash the headlights, pull the switch

the ignition key is removed, perform the

lever toward you, then release it. The

following :

headlights can be flashed even though

1) Open the driver-side door.

the headlight switch is in the "OFF"

2) Turn the parklights OFF and ON

position.

again using the light switch on the

steering column.

B340D01A-AAT

High-beam Switch

To turn on the headlight high beams,

push the lever forward (away from

you). The high beam indicator light will

come on at the same time. For low

beams, pull the lever back toward you.

FEATURES OF YOUR HYUNDAI

WINDSHIELD WIPER AND

WASHER SWITCH

B350A01A-AAT

B350B01O-GAT

NOTE:

Windshield Washer Operation

o Do not operate the washer more

than 15 seconds at a time or when

the fluid reser- voir is empty.

o In icy or freezing weather, be

sure the wiper blades are not

frozen to the glass prior to oper-

ating the wipers.

o In areas where water freezes in

winter, use windshield washer

antifreeze.

B350A01FC

Mist Wiper Operation

The windshield wiper switch has three

B350B01FC

positions:

To use the windshield washer, pull the

wiper/washer lever toward the steer-

1. Intermittent wiper operation

ing wheel. When the washer lever is

2. Low-speed operation

operated, the wipers automatically

3. High-speed operation

make two passes across the wind-

shield. The washer continues to oper-

NOTE:

ate until the lever is released.

To prevent damage to the wiper

system, do not attempt to wipe away

heavy accumulations of snow or

ice. Accumulated snow and ice

B350B02FC

should be removed manually. If

If a single wipe is desired to clear mist,

there is only a light layer of snow or

push the windshield wiper and washer

ice, operate the heater in the de-

control lever upwards.

frost mode to melt the snow or ice

before using the wiper.

1 FEATURES OF YOUR HYUNDAI

HAZARD WARNING SYS-

TEM

B350C01FC-GAT

B350A01O-AAT

B370A01A-AAT

Adjustable Intermittent Wiper

Tail Gate Wiper And Washer

Operation (If installed)

Switch

HFC2078

The hazard warning system should be

B350C01FC

B350D01FC

used whenever you find it necessary

:The washer fluid will be sprayed

to stop the car in a hazardous location.

To use the intermittent wiper feature,

onto the rear window and the

When you must make such an emer-

place the wiper switch in the "INT"

wiper operates while the rear

gency stop, always pull off the road as

position. With the switch in this posi-

window wiper barrel is placed in

far as possible.

tion, the interval between wipes can be

this position.

The hazard warning lights are turned

varied from approximately 1 to 18 sec-

2.OFF

on by pushing in the hazard switch.

onds by turning the interval adjuster

3.INT:To use the intermittent wiper

This causes all turn signal lights to

barrel.

feature, place the rear window

blink. The hazard warning lights will

wiper barrel in the "INT" posi-

operate even though the key is not in

tion.

the ignition.

4.ON :When the point indicates "ON",

To turn the hazard warning lights off,

the rear window wiper operates

push the switch a second time.

continuously.

FEATURES OF YOUR HYUNDAI

FRONT/REAR WINDOW DE-

FOG LIGHT SWITCH

FROSTER SWITCH

B380A03HP-AAT

B360B01FC-GAT

Front fog light switch

CAUTION:

(If Installed)

Do not clean the inner side of the

front/rear window glass with an abra-

sive type of glass cleaner or use a

scraper to remove foreign deposits

from the inner surface of the glass as

this may cause damage to the de-

froster elements.

HFC2080

NOTE:

The front/rear window defroster and

The engine must be running for the

heated outside rear view mirrors are

front/rear window defroster to oper-

B360B01FC

turned on by pushing in the switch. At

ate.

To turn on the front fog lights, push the

the same time, the front/rear window

switch in the "ON" position. They will

defroster indicator light on the switch is

come on when the headlight switch is

turned on. To turn the defroster off,

in the first or second position.

push the switch a second time. The

front/rear window defroster automati-

cally turns itself off after about 20 min-

utes. To restart the defroster cycle,

push in the switch again after it has

turned itself off.

1 FEATURES OF YOUR HYUNDAI

HEADLIGHT LEVELING

DEVICE SYSTEM

B360A01Y-GAT

B340G01FC-GAT

Loading condition

Switch position

Rear Fog Light Switch

(If Installed)

Driver only

(If Installed)

Driver + front passenger

Full passengers

(including driver)

Full passengers

(including driver) + Maximum

permissible loading

Driver + Maximum permissible

B340G01FC

B360A01FC

To adjust the headlight beam level ac-

To turn on the rear fog lights, push the

cording to the number of the passen-

switch. They will come on when the

gers and the loading weight in the lug-

headlight switch is in the second posi-

gage area, turn the beam leveling switch.

tion and the key is in the "ON" position.

The higher the number of the switch

position, the lower the headlight beam

level. Always keep the headlight beam

at the proper leveling position, or head-

lights may dazzle other road users.

Listed below are the examples of proper

switch settings. For loading conditions

other than those listed below, adjust

the switch position so that the beam

level may be the nearest as the condi-

tion obtained according to the list.

FEATURES OF YOUR HYUNDAI

DIGITAL CLOCK

CIGARETTE LIGHTER

B400A01A-AAT

B420A02A-AAT

CAUTION:

Do not use electric accessories or

equipment other than the Hyundai

genuine parts in the socket.

HFC2091

B420A01FC

There are three control buttons for the

For the cigarette lighter to work, the key

digital clock. Their functions are:

must be in the "ACC" position or the

"ON" position.

HOUR - Push "H" to advance the hour

To use the cigarette lighter, push it all

indicated.

the way into its socket. When the

MIN

- Push "M" to advance the

element has heated, the lighter will

minute indicated.

pop out to the "ready" position.

RESET - Push "R" to reset minutes to

Do not hold the cigarette lighter pressed

":00" to facilitate resetting the

in. This can damage the heating ele-

clock to the correct time.

ment and create a fire hazard.

When this is done:

If it is necessary to replace the ciga-

rette lighter, use only a genuine Hyundai

Pressing "R" between 10 : 30 and 11 :

replacement or its approved equiva-

29 changes the readout to 11 : 00.

lent.

Pressing "R" between 11 : 30 and 12 :

29 changes the readout to 12 : 00.

1 FEATURES OF YOUR HYUNDAI

POWER OUTLET

ASHTRAY

B500D01FC-AAT

B430A01FC-GAT

(If installed)

CAUTION:

o Use the power outlet only when

the engine is running and remove

the plug from the power outlet

after using the electric device.

Using when the engine stops or

keeping the electric device with

plugged in for many hours may

cause the battery to discharge.

o Do not use the power outlet to

HFC2056

connect electric accessories or

HFC2042

equipment that are not designed

The ashtray may be opened by pulling

These supply 12V electric power to

to operate on 12 volts.

the lid up by its top edge. To remove

operate electric accessories or equip-

o Some electronic devices can cause

the ashtray to empty or clean it, pull the

ment only when the key is in the "ON"

electronic interference when

cover up all the way out. The ashtray

position.

plugged into the power outlet.

light will only illuminate when the exter-

These devices may cause exces-

nal lights are on.

sive audio noise and malfunctions

in other electronic systems or de-

vices in your vehicle.

FEATURES OF YOUR HYUNDAI

DRINK HOLDER

B450A02FC-GAT

B450B02FC-GAT

Front drink holder

Rear drink holder

(If Installed)

CAUTION:

Place the drink holder in its original

Driver's

Passenger's

position while not in use.

WARNING:

o Use caution when using the drink

holders. A spilled beverage that is

very hot can injure you or your

passengers. Spilled liquids can

damage interior trim and electri-

HFC2097

HFC2098

cal components.

o Do not place objects other than

The rear drink holder is located on the

The front drink holder is used for hold-

cups or cans in the drink holder.

ing cups.

rear main console for holding cups.

These objects can be thrown out

The drink holder can be used by push-

To use the passenger's drink holder,

in the event of a sudden stop or an

ing the knob on the rear main console

push the drink holder and pull it en-

accident, possibly injuring the pas-

tirely.

downward and then releasing it.

sengers in the vehicle.

1 FEATURES OF YOUR HYUNDAI

PARKING BRAKE

REAR SEAT ARM REST

B530A02A-AAT

In addition it is recommended that

B611A02FC-AAT

when parking the vehicle on a gradi-

(If Installed)

ent, the shift lever should be posi-

tioned in the appropriate low gear on

manual transaxle vehicles or in the

Park position on automatic transaxle

vehicles.

o To release the parking brake, first

apply the foot brake and pull up the

parking brake lever slightly. Sec-

ondly, depress the release button

and lower the parking brake lever

B530A01FC

while holding the button.

B610A01FC

The parking brake must always be set

when the vehicle is to be left unattended.

The rear seat arm rest is located in the

When the parking brake is applied, and

center of the rear seat back with a

the ignition key is at the "ON" position,

CAUTION:

storage box.

the parking brake warning lamp will be

Driving with the parking brake ap-

The drink holder in the box can be used

illuminated. Before driving the vehicle,

plied will cause excessive brake pad

by opening the lid of the arm rest.

the parking brake must be fully released

(or lining) and brake rotor wear.

and the warning lamp extinguished.

WARNING:

o To engage the parking brake, first

apply the foot brake and then without

o Do not place objects other than

pressing the release button in, pull the

cups or cans on the drink holder.

parking brake lever up as far as pos-

Such objects can be thrown out

sible.

in the event of a sudden stop or

an accident, possibly injuring the

passengers in the vehicle.

o Be careful not to injure your fin-

gers when you open the lid of the

arm rest.

FEATURES OF YOUR HYUNDAI

SUNROOF

B460A01S-AAT

B460B02S-AAT

(If installed)

OPERATING THE SUNROOF

SYSTEM

CAUTION:

The sunroof can be operated with the

Opening or Closing the Sunroof

o Do not open the sunroof in se-

ignition key in the "ON" position

verely cold temperature or when

it is covered with ice or snow.

B470A02S-AAT

o Periodically remove any dirt that

SUNSHADE

may have accumulated on the

guide rails.

o Do not press any sunroof control

button longer than necessary.

Damage to the motor or system

components could occur.

HFC2021

The sunroof can be only electrically

WARNING:

opened or closed. To open or to close,

o Do not close a sunroof if anyone's

B470A01FC

press and hold the button located in

hands, arms or body are between

The sunshade can be opened and closed

the front overhead console.

the sliding glass and the sunroof

by sliding it forward or rearward when

Release the button when the sunroof

sash, as this could result in an

the sunroof is closed. The sunshade

reaches the desired position.

injury.

will be open automatically when the

o Do not place your head or arms

sunroof is opened, but it must be closed

out of the sunroof opening at any

manually.

time.

WARNING:

Never adjust the sunshade while

driving.

1 FEATURES OF YOUR HYUNDAI

B460C02S-AAT

B460D01FC-GAT

Tilting the Sunroof

Manual Operation of Sunroof

If the sunroof does not operate electri-

cally:

HFC1037

3. Insert the hexagonal head wrench

HFC2022

provided with the vehicle into the

The sunroof can be tilted by pushing the

socket. This wrench can be found in

"UP" button with the sunroof closed.

HFC1036

the vehicle's luggage room or glove

Release the button when the sunroof

box.

1. Remove the rectangular plastic inte-

reaches the desired position. To close

rior light lens in the front overhead

the sunroof, press the "DOWN" but-

console.

ton.

2. Turn the hexagonal bolts with a

NOTE:

socketwrench counterclockwise to

After washing the car or after there is

remove the front overhead console.

rain, be sure to wipe off any water

that is on the sunroof before operat-

ing it.

HFC1038

4. Turn the wrench clockwise to open or

counterclockwise to close.

FEATURES OF YOUR HYUNDAI

INTERIOR LIGHT

B480A01E-AAT

B490A02E-AAT

o ON

FRONT INTERIOR LIGHT

Interior Light

In the "ON" position, the light stays on

Map Light

at all times.

With Sunroof

Without Sunroof

With Sunroof

Without Sunroof

CAUTION:

Do not leave the switch in this posi-

tion for an extended period time

when the vehicle is not running.

HFC490

o OFF

HFC480

The interior courtesy light has a switch

In the "OFF" position, the light stays off

The two map light switches are located

of three positions. The three positions

at all times even though a door is open.

on both sides of the front overhead

are:

console. Push in the map light switch

to turn the light on or off. This light

o DR

produces a spot beam for convenient

In the "DR" position, the interior cour-

use as a map light at night or as a

tesy light comes on when any door is

personal light for the driver and the

opened regardless of the ignition key

passenger.

position. The light goes out when the

door is closed.

1 FEATURES OF YOUR HYUNDAI

SPECTACLE CASE

MULTI BOX

ACCESSORY TRAY

B491A02FC-GAT

B500B02E-GAT

B820A01FC-GAT

(If Installed)

HFC2058

HFC2071

HXDOM241

The multi box may be opened by pulling

The accessory tray may be opened by

The spectacle case is located on the

pushing the knob sidewards and re-

it out by its grip.

front overhead console.

leasing slowly it.

It is used for storing small articles.

Push the end of the cover to open the

It is used for storing small items.

If the multi box is removed, the fuse

spectacle case.

box for the lights and other electrical

accessories will be exposed.

WARNING:

Do not open the spectacle case

while the vehicle is moving. The

rear view mirror of the vehicle may

be blocked by an open spectacle

case.

Hyundai Matrix (2007 year). Instruction - part 5
